Use and Care
Manual
Multi-temperature wine cabinet
with freezer compartment, built-in
WF1061/ WFI1061
050614 7084306 - 01

Contents
1 The appliance at a glance............................. 2
1.1 Additional benefits............................................ 2
1.2 Overview of the appliance and its equipment... 3
1.3 Range of appliance use.................................... 3
1.4 Conformity........................................................ 3
1.5 Energy saving.................................................. 4
2 General safety information........................... 4
3 Controls and displays................................... 5
3.1 Operating and control elements....................... 5
3.2 Temperature display........................................ 5
4 Start-up........................................................... 5
4.1 Transporting the appliance............................... 5
4.2 Setting up the appliance................................... 5
4.3 Disposal of packaging...................................... 6
4.4 Connecting the appliance................................. 6
4.5 Switching on the appliance............................... 7
4.6 Switching on the appliance............................... 7
5 Operation........................................................ 7
5.1 Temperature display unit.................................. 7
5.2 Brightness of the temperature display.............. 7
5.3 Child-proof lock................................................ 8
5.4 Door alarm....................................................... 8
5.5 Temperature alarm........................................... 8
5.6 Sabbath Mode.................................................. 8
5.7 Freezer compartment....................................... 9
5.8 Wine cooling zone............................................ 11
6 Maintenance................................................... 12
6.1 Replacing the active carbon filter..................... 12
6.2 Replacing the water filter.................................. 13
6.3 Defrosting with NoFrost.................................... 13
6.4 Cleaning the appliance..................................... 13
6.5 Cleaning the IceMaker..................................... 14
6.6 Customer service............................................. 14
6.7 Appliance Information...................................... 15
7 Troubleshooting............................................ 15
8 Putting appliance out of service.................. 18
8.1 Vacation Tips................................................... 18
8.2 Switching off the appliance............................... 18
8.3 Decommissioning ............................................ 18
9 Disposing of the appliance........................... 18
10 Liebherr Warranty Plan................................. 19
Congratulations on the purchase of your new appliance.
With this purchase, you have chosen all the advantages
of the latest refrigeration technology, guaranteeing you a
high-quality appliance with a long life span and high oper-
ating safety.
The equipment of your appliance gives you the highest
level of day-to-day ease of operation.
Together we are making an active contribution to the
conservation of our environment by purchasing this appli-
ance which is manufactured in an environmentally friendly
process with the use of recyclable materials.
We hope you enjoy your new appliance.
The manufacturer is constantly working to improve all
models. Therefore please understand that we reserve the
right to make design, equipment and technical modifica-
tions.
To get to know all the benefits of your new appliance,
please read the information contained in these instruc-
tions carefully.
The instructions apply to several models, so there may be
differences. Sections which only apply to certain appli-
ances are indicated with an asterisk (*).
Instructions for action are marked with a , the
results of action are marked with a .
1 The appliance at a glance
1.1 Additional benefits
-CFC free
-Energy-optimized refrigerant circuit
-Energy-efficient insulation
-Low energy consumption
-User-friendly electronic controls
-Active function indicators
-Temperature can be controlled in the appliance inde-
pendent of ambient conditions according to its climate
rating - Temperature can be displayed as °C or °F
-The appliance defrosts automatically - no need to
spend time defrosting
-Large freezing capacity
-Shelves can be removed to make space for large
items.
-Freezer over-temperature alarm
-Quick-freeze feature for fresh food (SuperFrost)
-Frozen food temperature indicator
-Power failure/“frost-control” display
-All freezer drawers suitable for quick-freeze
-Bright LED interior light
-Door ajar alarm
-Handle grips on all extra-large drawers for easy trans-
port
-Integrated transport grips on appliance housing
-Transport castors at back
-Easy to clean
-Door hinges can be reversed
-Soft stop mechanisms on both doors
-This unit is certified as Sabbath
compliant by the Star-K organization
thus allowing the appliance to be used
during religious holidays. For more infor-
mation please visit Star-K on the web at
www.star-k.org.
The appliance at a glance
2 * Depending on model and options

1.2 Overview of the appliance and its
equipment
Fig. 1
(1) Rear transport
handles
(8) Wooden shelf, fixed
(2) Operating and control
elements
(9) IceMaker
(3) Internal LED light (10)Freezer compartment
(4) Active carbon filter,
replaceable
(11)VarioSpace
(5) Description label (12)InfoSystem
(6) Separating plate with
sealing lip
(13)Rating plate
(7) Wooden shelf, hinged (14)Adustable feet, front
transport handles, rear
transport castors
1.3 Range of appliance use
Normal use
The appliance is only suitable for refrigerating
wine or food in a domestic environment or an
environment that is similar to a domestic one.
This includes, for example, use
-in staff kitchens, bed and breakfast establish-
ments,
-by guests in country homes, hotels, motels
and other types of accommodations,
-for catering and similar wholesale services.
Use the appliance only for normal household
purposes. All other types of uses are not
permitted.
Foreseeable misuse
The following uses are specifically prohibited:
-Storage and cooling of medication, blood
plasma, laboratory preparations or similar
substances and products in accordance with
the CMDCAS and FDA 510(k)
-Use in areas at risk of explosion
Incorrect appliance use can cause damage to
the stored products or cause them to spoil.
Climate ratings
The appliance is set to operate within specific
ambient temperature limits according to its
climate rating. The climate rating for your appli-
ance is printed on the rating plate.
Note
uCompliance with the specified ambient
temperatures is required, otherwise the refrig-
eration performance is reduced.
Climate
rating
for ambient temperatures from
SN 50 °F (10 °C) to 90 °F (32 °C)
N 61 °F (16 °C) to 90 °F (32 °C)
ST 61 °F (16 °C) to 101 °F (38 °C)
T 61 °F (16 °C) to 110 °F (43 °C)
1.4 Conformity
The refrigerant circuit has been tested for leaks. The
appliance complies with the relevant safety regulations
and the directives UL250 and CAN/CSA C22.2 No.63-93.
Instructions for testing institutes:
Tests must be carried out in accordance with the appli-
cable standards and guidelines.
The preparation and testing of the appliance must be
carried out taking account of the manufacturer's
loading plans and the instructions in the operating
manual .
The appliance at a glance
* Depending on model and options 3

1.5 Energy saving
-Always ensure good ventilation. Do not obstruct venti-
lation openings or grilles.
-Do not install the appliance in direct sunlight or next to
an oven, heater, or similar heat source.
-Energy consumption depends on installation conditions
such as the ambient temperature (see 1.3) .
-Avoid opening the appliance door for any longer then
neccesary.
-The lower the temperature is set the higher the energy
consumption.
2 General safety information
Read and follow these instructions. They contain
safety advice which is important for safe and
problem-free installation and operation. Always
read and follow the safety advice.
Dangers for the user:
-This appliance can be operated by children 8
years and older as well as by persons with
reduced physical, sensory or mental capabili-
ties or lack of experience and knowledge if
they are supervised or have been instructed in
the safe use of the appliance and understand
the associated risks. Children must not play
with the appliance. Cleaning and user mainte-
nance must not be performed by children
unless they are supervised.
-When disconnecting the appliance from the
outlet, always take hold of the plug. Do not pull
on the cable.
-Disconnect the power plug or switch off the
power if a fault occurs.
-Do not damage the mains power line. Do not
operate the appliance from a defective mains
power line.
-Repairs, work on the appliance and replace-
ment of the power cord should only be carried
out by the customer service department.
-The appliance should only be assembled,
connected and disposed of in accordance with
the instructions.
-Only install, connect and dispose of the appli-
ance in accordance with the instructions.
-Only operate the appliance after it has been
installed.
-Please keep the instructions and pass them on
to any future owner.
-All repairs to or work on the IceMaker must
only be carried out by the customer service
department or other specialist engineers
trained to do this.
-The manufacturer is not liable for damage
arising from incorrect connection to the water
supply.
Risk of fire:
-Do not operate the appliance near explosive
gases.
-Do not store explosive materials or spray cans
with flammable propellants, such as e.g.
butane, propane, pentane, etc. in the appli-
ance. You can recognize such spray cans by
the printed contents or a flame symbol. Any
leaking gasses can be ignited by electrical
components.
-Keep burning candles, lamps and other
objects with open flames away from the appli-
ance so that they do not set it on fire.
-Alcoholic beverages or other containers
holding alcohol must always be tightly sealed
for storage purposes. Any leaking alcohol can
be ignited by electrical components
Tipover hazard:
-Do not stand or climb on the base, drawers,
doors, etc. This applies in particular to chil-
dren.
Risk of food poisoning:
-Do not consume food that has passed its best
before date.
Danger of frostbite, feelings of numbness
and pain:
-Avoid continued skin contact with the cold
surfaces or chilled/frozen food or adopt protec-
tive measures, e. g. use gloves. Do not
consume ice cream (especially sherbets) and
ice cubes immediately when they are too cold.
Risk of injury and damage:
-Hot steam may lead to injuries. Do not use any
electrical heating or steam cleaning equip-
ment, naked flames or defrosting sprays for
defrosting
-Do not remove ice with sharp objects
Risk of crushing
-Do not reach into the soft stop mechanism.
Fingers may be trapped when the door is
closed.
Follow the specific instructions in the other
sections:
General safety information
4 * Depending on model and options

DANGER indicates a hazardous situation,
which if not avoided, will result in
death or serious injury.
WARNING indicates a hazardous situation,
which if not avoided, could result in
death or serious injury.
CAUTION indicates a hazardous situation,
which if not avoided, will result in
minor or moderate injury.
NOTICE indicates a hazardous situation,
which if not avoided, could result in
damage to property.
Note indicates useful advice and tips.
3 Controls and displays
3.1 Operating and control elements
Fig. 2
(1) Alarm button (14)Wine cooling zone Up
button
(2) SuperFrost button (15)Wine cooling zone
On/Off button
(3) Freezer compartment
On/Off button
(16)Zone button
(4) Freezer compartment
Down button
(17)Light button
(5) Freezer compartment
Up button
(18)Ventilation button
(6) IceMaker symbol (19)Child safety symbol
(7) Temperature display
for bottom wine
cooling zone
(20)Ventilation symbol
(8) Temperature display
for top wine cooling
zone
(21)Sabbath Mode symbol
(9) Top wine cooling
compartment symbol
(22)Menu symbol
(10)Filter symbol (23)Bottom wine cooling
compartment symbol
(11)Light symbol (24)Freezer compartment
temperature display
(12)Power failure symbol (25)SuperFrost symbol
(13)Wine cooling zone
Down button
(26)Alarm symbol
The exact contact point is between the symbol and its
label
3.2 Temperature display
The following is displayed in normal operation:
-the average wine cooling temperature
-the highest freezer temperature
The freezer compartment temperature display is flashing:
-the temperature setting has been changed
-after switch-on the temperature is not yet cold enough
-the temperature has risen several degrees
The wine zone temperature display is flashing:
-the temperature setting has been changed
-after switch-on until the set temperature is reached
-the wine cabinet temperature is too cold/too warm
Dashes are shown on the display:
-the freezer temperature is above 32 °F (0 °C).
The following displays indicate malfunction. Possible
causes and corrective actions: (see Troubleshooting).
-F0 through F9
-FE
-The power failure symbol LED flashes.
4 Start-up
4.1 Transporting the appliance
CAUTION
Risk of injury or damage if incorrectly transported.
uTransport the appliance in its packaging.
uTransport the appliance upright.
uDo not move the appliance on your own.
WARNING
There is a risk of injury from pieces of broken glass.
If transported to above 4921 ft (1500 m), the glass in the
door may break. The edges of the broken pieces will be
sharp and may cause serious injury.
uAdopt suitable protective measures.
4.2 Setting up the appliance
WARNING
Risk of fire due to moisture!
If live parts or the power cord get wet, this can cause a
short circuit.
uThe appliance is designed for use in enclosed spaces.
Do not operate the appliance in open space or in damp
areas or where there is spray.
uOnly operate the appliance after it has been installed.
Controls and displays
* Depending on model and options 5

WARNING
Risk of fire due to short circuit.
If the power cable or plug of the appliance or another
appliance and the back of the appliance touch each other
the power cable or plug will be damaged by the vibrations
of the appliance which could lead to a short circuit.
uInstall the appliance so that it does not touch any plugs
or power cables.
uDo not connect the appliance or other appliances to the
sockets on the back of the appliance.
WARNING
Danger of fire and damage!
uDo not place devices that give off heat, e.g. micro-
waves, toasters, etc. on the appliance.
CAUTION
Risk of personal injury!
uHave two people move this appliance into place.
NOTICE
Risk of damage caused by condensation
Installing the appliance next to any other refrigerator or
freezer can cause condensation or damage to the Lieb-
herr appliance.
uDo not install this appliance next to any other refriger-
ator or freezer except another Liebherr model. Liebherr
models are designed to allow side-by-side installation.
They are equipped with a heating system to eliminate
condensation when refrigerators or freezers are
installed side-by-side.
NOTICE
Risk of damage for the finished floor surface!
uProtect the finished floor surface before you uncrate the
unit.
Verify that:
qThe floor under the appliance is flat and level.
qThe floor can support the appliance's weight plus
approximately 1200 pounds (544 kg) of food weight.
qThe appliance is not placed in direct sunlight or near
the stove, range top, radiators and similar heat
sources.
qThe kitchen cabinet that the appliance is installed in is
shimmed to the floor level if the floor heights are not
equal.
qCutout dimensions are accurate.
qElectrical outlet is in correct location.
qThe air flow is not restricted. Air flow must be provided
for the appliance to operate properly. The factory air
vents provide 31 square inches (200 cm2) of air flow
per appliance. If you are replacing the air vents with an
overlay, the air flow must be the same or greater than
the factory air vents.
uExamine the unit and packaging for shipping damage.
Contact the carrier immediately if you suspect there is
any damage.
uNote the type (model, number), index, appliance/serial
number, date of purchase and where purchased
(see 6.7) .
uRemove anything attached to the rear or side walls of
appliance that would prevent proper installation or
impede proper ventilation.
uRemove the protective film from the outside of the
appliance.
Note
uClean the appliance (see 6.4) .
If the appliance is set up in humid areas, condensation
may build on the outside of the appliance.
uAlways ensure proper ventilation.
uAssemble appliances according to separate installation
instructions.
4.3 Disposal of packaging
WARNING
Danger of suffocation from packaging materials and films!
uDo not allow children to play with packaging materials.
The packaging is made from recyclable materials:
-Corrugated card/cardboard
-Parts made of foamed polystyrene
-Films and bags from polyethylene
-Packing bands from polypropylene
-Wood frame nailed together with a polyethylene
window*
uTake the packaging material to an official collection
point.
4.4 Connecting the appliance
WARNING
Electrical shock hazard!
uStart-up should only take place once the appliance has
been installed according to these instructions.
uElectrically ground appliance.
uDo not ground to a gas pipe.
uCheck with a qualified electrician if you are not sure the
appliance is properly grounded.
uDo not have a fuse in the neutral or grounding circuit.
uDo not use an extension cord, power bar or a multiple
socket adapter.
uDo not use a power cord that is frayed or damaged.
Start-up
6 * Depending on model and options

WARNING
Electrical shock hazard!
This appliance is equipped with a three-prong (grounding)
polarized plug for your protection against possible shock
hazards. Electrical Grounding Required.
uDo not remove the round grounding prong from the
plug.
uUse only an grounded adapter.
-Wait 1 hour after installation before you plug in the
appliance. This allows the refrigerant and system lubri-
cation to reach equilibrium.
-Make sure incoming voltage is the same as the appli-
ance rating. A 110-120 Volt, 60 Hz, 15 Amp electrical
supply (20 Amp for side-by-side installations) circuit
that is controlled by a circuit breaker or fuse is required.
-We recommend using a dedicated circuit for this appli-
ance to prevent electrical overload.
-Follow all Federal, State and local electrical, fire and
building codes and ordinances when installing the
receptacle and / or the appliance.
-In some communities, a wall switch is required to turn
power to the appliance ON and OFF.
-To reduce the risk of fire, electric shock, or personal
injury, installation work and electrical wiring must be
done by a qualified electrician in accordance with all
applicable codes and standards, including fire-rated
construction.
-The Power Plug must be easily accessible so that the
appliance can be disconnected from the mains quickly
in an emergency. It must not be behind the back of the
appliance.
-The top of the electric outlet must be located within
82-5/8 in. (2100 mm) from the top of the base in the
cabinet.
4.5 Switching on the appliance
wWhenever “DEMO” appears on the display, the appli-
ance is running in demonstration mode. Contact the
customer service department.
4.6 Switching on the appliance
Note
uTo switch on the entire appliance, only the freezer
compartment needs to be switched on.
Switch on the appliance 2 hours before loading
with frozen food for the first time.
Do not load frozen foods until the temperature
display reads 0 °F (-18 °C).
4.6.1 Switching on the freezer compartment
uOpen the door.
uPress On/Off button, freezer compartment
Fig. 2 (3) .
wThe temperature display for the wine cooling zone and
the Alarm symbol will flash until the set temperature is
reached.
wThe freezer compartment temperature display and the
Alarm symbol will flash until the temperature is cold
enough. If the temperature is greater than 32 °F (0 °C),
flashing dashes will appear; if the temperature is lower
than this, the current temperature will flash on the
display.
wWhenever “DEMO” appears on the display, the appli-
ance is running in demonstration mode. Contact the
customer service department.
4.6.2 Switching on the wine cooling zone
uOpen the door.
uPress Wine cooling zone On/Off button
Fig. 2 (15) .
wThe temperature display for the wine storage zone and
the Alarm symbol will flash until the set temperature is
reached.
5 Operation
5.1 Temperature display unit
The temperature display can be changed from °F to °C.
5.1.1 To change the unit
uActivate setting mode: Press SuperFrost button
Fig. 2 (2) for about 5 seconds.
wS is displayed in the temperature display.
wThe Menu symbol
Fig. 2 (22) lights up.
uUsing Freezer compartment Up button
Fig. 2 (5) / Freezer compartment Down button
Fig. 2 (4) select °.
uTo confirm: Briefly press SuperFrost button
Fig. 2 (2) .
uUsing Freezer compartment Up button
Fig. 2 (5) / Freezer compartment Down button
Fig. 2 (4) select °F or °C.
uTo confirm: Briefly press SuperFrost button
Fig. 2 (2) .
uTo exit setting mode: Press Freezer compartment
On/Off button
Fig. 2 (3) .
-or-
uWait 5 minutes.
wThe temperature is again displayed in the temperature
display.
5.2 Brightness of the temperature
display
You can adapt the brightness of the temperature display
to the light conditions in the room in which it is installed.
If the door is open or the control panel is used the temper-
ature indicator lights up at maximum brightness. About 1
minute after the door is closed or no button has been
Operation
* Depending on model and options 7

pressed on the control panel, the temperature display
goes back to the set brightness.
5.2.1 Setting the brightness
The brightness can be set between h0 (minimum lumi-
nosity) and h5 (maximum luminosity).
uTo activate setting mode: Press SuperFrost button
Fig. 2 (2) for about 5 seconds.
wS is shown on the display.
wThe Menu symbol
Fig. 2 (22) lights up.
uPress Freezer compartment Up button
Fig. 2 (5) or
Freezer compartment Down button Fig. 2 (4) to select h.
uTo confirm: Briefly press SuperFrost button
Fig. 2 (2) .
uTo set the display brighter: Press Freezer
compartment Up button
Fig. 2 (5) .
uTo set the display darker: Press Freezer
compartment Down button Fig. 2 (4) .
uTo confirm: Press SuperFrost button
Fig. 2 (2) .
wThe brightness is set to the new value.
uTo deactivate setting mode: Press Freezer compart-
ment On/Off button Fig. 2 (3) .
-or-
uWait 5 minutes.
wThe temperature is again displayed in the temperature
display.
5.3 Child-proof lock
You can use the child-proof lock to lock the
buttons. This means that children cannot acci-
dentally switch off the appliance when playing.
5.3.1 Switching on the child-proof lock
uActivate setting mode: press and hold the SuperFrost
button
Fig. 2 (2) for approximately 5 s.
wS is shown on the display.
wThe Menu symbol
Fig. 2 (22) lights up.
uUsing the Freezer compartment Up button
Fig. 2 (5) or
Freezer compartment Down button Fig. 2 (4) , select c.
uPress the SuperFrost button
Fig. 2 (2) briefly to confirm.
When c1 is shown on the display:
uTo switch on the child-proof lock, press the
SuperFrost button
Fig. 2 (2) briefly.
wThe Child lock symbol
Fig. 2 (19) LED lights up. c
flashes on the display.
When c0 is shown on the display:
uTo switch off the child-proof lock, press the SuperFrost
button Fig. 2 (2) briefly.
wThe Child safety symbol
Fig. 2 (19) LED goes out. c
flashes on the display.
uDeactivate setting mode: press the Freezer compart-
ment On/Off button Fig. 2 (3) .
-or-
uWait 5 min.
wThe temperature is again displayed on the temperature
display.
5.4 Door alarm
If the door is open for longer than 180 seconds,
the acoustic warning sounds.
The acoustic warning stops automatically when
the door is closed.
5.4.1 Switching off the door alarm
The acoustic warning can be switched off when the door
is open. The acoustic warning remains switched off as
long as the door is open. When the door is closed, the
alarm function is active again.
uPress Alarm button
Fig. 2 (1) .
wThe door alarm stops.
5.5 Temperature alarm
If the freezer temperature is not cold enough,
the audible warning sounds.
If the wine storage temperature is too warm or
too cold, the audible warning sounds.
At the same time, the temperature display and
the Alarm symbol
Fig. 2 (26) LED will flash.
The cause of a temperature being too high may be:
-When sorting and removing food from the appliance,
too much warm ambient air got in.
-The power was cut off for a while.
-The appliance is faulty.
The audible warning automatically ceases, the Alarm
symbol Fig. 2 (26) goes out, and the temperature display
stops flashing when the temperature is cold/warm enough
again.
If the alarm status remains: (see Troubleshooting).
Note
If the temperature is not cold enough, food may spoil.
uCheck the quality of the food. Do not consume spoiled
food.
5.5.1 Switching off the temperature alarm
The acoustic warning can be switched off. When the
temperature is cold enough again, the alarm function is
active again.
uPress Alarm button
Fig. 2 (1) .
wThe acoustic warning ceases.
5.6 Sabbath Mode
After entering Sabbath Mode, you do not have to worry
about lights, digits, icons, tones, alarms or fans. The
defrost cycle operates solely on clock time without any
feedback from usage of the refrigerator. After a power
failure, the appliance will return to Sabbath Mode without
requiring additional input.
Operation
8 * Depending on model and options

WARNING
Danger of food poisoning!
No record will be kept of a power failure during Sabbath
Mode. Thus, during Sabbath mode, if a power failure
occurs that you are not aware of, when the power comes
back on, the unit will continue to be in Sabbath Mode but
when Sabbath Mode is ended there will be no indication
that a power failure occurred.
If a power failure occurs during Sabbath mode:
uCheck the quality of the food. Do not consume spoiled
food!
-No control operations are possible other than switching
off Sabbath Mode.
-If the unit is currently running in a mode such as Super-
frost, Supercool or the Ventilation is enabled these
functions will continue and finish their timed cycles
independent of now being in Sabbath mode.
-The Ice Maker is disabled.
-No audible signals are emitted, and the temperature
display does not indicate any warnings or settings
(such as a temperature alarm or door alarm).
5.6.1 Setting Sabbath mode
uTo activate setting mode: Press and hold the Super-
Frost button
Fig. 2 (2) for approx. 5 s.
wS flashes on the display.
wThe Menu symbol
Fig. 2 (22) lights up.
uTo access the Sabbath mode function: Briefly press
theSuperFrost button Fig. 2 (2) .
When S1 is shown on the display:
uTo turn on Sabbath mode, briefly press the
SuperFrost button
Fig. 2 (2) .
When S0 is shown on the display:
uTo turn off Sabbath mode, briefly press the
SuperFrost button
Fig. 2 (2) .
uTo deactivate setting mode: Press the Freezer
compartment On/Off button Fig. 2 (3) .
-or-
uWait 5 min.
wThe Sabbath Mode symbol
Fig. 2 (21) appears on the
temperature display as long as Sabbath Mode is active.
wSabbath mode switches off automatically after 120
hours if it is not manually switched off beforehand.
5.7 Freezer compartment
You can store frozen food, make ice cubes and freeze
fresh food in the freezer compartment.
5.7.1 Freezing food
Each drawer can hold up to 55.12 lbs (25 kg) of frozen
food; each plate can hold up to 77.16 lbs (35 kg).
CAUTION
There is a risk of injury from pieces of broken glass.
Bottles and cans containing drinks can split or crack when
frozen. This applies in particular to carbonated drinks.
uDo not freeze bottles and cans containing drinks.
So that the food is rapidly frozen through to the core, do
not exceed the following quantities per pack:
- fruit, vegetables up to 2.2 lb (1 kg)
- meat up to 5.51 lbs (2.5 kg)
uPack the food in portions in freezer bags, reusable
plastic, metal or aluminum containers.
5.7.2 Defrosting food
- in the fridge compartment
- in the microwave
- in the oven/fan oven
- at room temperature
WARNING
Danger of food poisoning!
uDo not re-freeze defrosted food.
uOnly take out the amount of food that is required. Use
defrosted food as quickly as possible.
5.7.3 Setting the temperature in the freezer
compartment
The temperature can be set between 7 °F (-14 °C) and
-16 °F (-26 °C), 0 °F (-18 °C) is recommended.
uTo set a higher temperature: press the Freezer
compartment Up button Fig. 2 (5) .
uTo set a lower temperature: press the Freezer compart-
ment Down button Fig. 2 (4) .
wWhen the button is pressed for the first time, the
previous value is indicated on the freezer compartment
temperature display.
uTo change the temperature in 1 °F (1 °C) increments:
briefly press the button.
-or-
uTo change the temperature continuously: hold the
button down.
wThe value is displayed flashing during the setting oper-
ation.
wThe actual temperature is displayed about 5 seconds
after the last press of a button. The temperature slowly
adjusts to the new setting.
5.7.4 SuperFrost
Depending on how much fresh food is to be frozen you
must switch SuperFrost on in advance - for a small
amount of food to be frozen, about 6 hours, for the
maximum amount about 24 hours before putting the food
in.
Operation
* Depending on model and options 9

You do not need to switch SuperFrost on in the following
cases:
-when placing frozen food in the freezer
-when freezing up to about 2 kg of fresh food a day
Freezing with SuperFrost
uBriefly press the SuperFrost button
Fig. 2 (2) once.
wThe SuperFrost symbol
Fig. 2 (25) LED lights up.
wThe freezing temperature drops and the appliance
operates at its maximum refrigeration power rating.
When a small amount of food is to be frozen.
uWait approx. 6 hrs.
uPlace packaged food in the upper drawers.
When the maximum amount of food is to be frozen.
uWait approx. 24 hrs.
uRemove upper drawers and place the food directly
onto the upper shelves.
wSuperFrost is automatically switched off. At the earliest
after 30 hours, at the latest after 65 hours, depending
on the quantity placed inside the appliance.
wThe SuperFrost button
Fig. 2 (2) goes out when the
freezing process is complete.
wThe LED for the SuperFrost symbol
Fig. 2 (25) goes out
when the freezing process is complete.
uPlace food inside the drawers and push them closed
again.
wThe appliance returns to work in the energy-saving
normal mode.
5.7.5 Drawers
Note
Insufficient ventilation results in an increase in energy
consumption and reduction of the refrigerating perform-
ance.
For appliances with NoFrost:
uLeave the bottom drawer in the appliance.
uNever block the air slits in the fan on the rear wall.
uTo store frozen food directly on the shelves: pull the
drawer forward and lift it out.
5.7.6 Shelves
uTo remove shelf: lift it at the front and
pull out forward.
uTo reinsert shelf: simply slide it in as
far as it will go.
5.7.7 VarioSpace
In addition to the drawers, you
can also take out the shelves.
This gives you space for large
frozen items. Poultry, meat,
large joints of game and tall
bakery items can be frozen
and then presented whole.
uEach drawer can hold up to
55.12 lbs (25 kg) of frozen
food; each plate can hold
up to 77.16 lbs (35 kg).
5.7.8 Info system
Fig. 3
(1) Ready meals, ice
cream
(4) Sausages, bread
(2) Pork, fish (5) Game, mushrooms
(3) Fruit, vegetables (6) Poultry, beef/veal
The numbers indicate the storage time in months for
different types of frozen foods. The storage times given
are guidelines.
5.7.9 IceMaker
The IceMaker is in the top drawer. The drawer is labeled
“IceMaker”.
Make sure that the following conditions are fulfilled:
-The appliance is level.
-The appliance is connected to the electricity supply.
-The freezer compartment is switched on.
-The minimum freezer temperature is 14 °F (-10 °C).
-The IceMaker is connected to the water supply.
-All air was bled from the waterline before starting the
icemaker. The icemaker will only work if there is no air
in the waterline.
Switching on the IceMaker
Fig. 4
uPull out the drawer.
uPress On/Off button
Fig. 4 (1) so that the LED Fig. 4 (2)
lights up.
uPush in the drawer.
wThe IceMaker symbol
Fig. 2 (6) LED lights up.
Operation
10 * Depending on model and options

Note
uThe IceMaker only produces ice cubes when the
drawer is completely closed.
Producing ice cubes
The production capacity depends on the freezer tempera-
ture. The lower the temperature, the more ice cubes can
be produced in a certain period.
The production capacity is 90- 100 ice cubes in 24 hours
at a freezing temperature of 0 °F (-18 °C).
To have the maximum capacity of approx. 130 ice cubes
in 24 hours, activate the SuperFrost Function. Be aware
that this increases the energy consumption because the
compressor will run constantly.
The ice cubes fall out of the IceMaker into the drawer.
When the ice cubes reach a certain height in the drawer,
no more ice cubes can be produced. The IceMaker will
not fill the drawer to the top.
If large quantities of ice cubes are required, the complete
IceMaker drawer can be swapped with the neighboring
drawer. When you close the drawer, the IceMaker auto-
matically restarts production.
When the IceMaker is switched on for the first time, it may
take up to 24 hours for the first ice cubes to be produced.
Note
Particles may accumulate in the IceMaker or water line
the first time the appliance is used or after an extended
period out of service.
uTo achieve this, do not consume or use the ice cubes
that are produced within 72 hours.
Setting the water supply time
The opening time of the valve on the IceMaker can be
adjusted if, for example, the water pressure in the pipe is
too low or too high.
The water supply time can be set in stages from E1 (short
supply time) to E8 (long supply time). The default setting
is E3.
uActivate setting mode: press and hold the SuperFrost
button
Fig. 2 (2) for approximately 5 s.
wS is shown on the display.
wThe Menu symbol
Fig. 2 (22) lights up.
uUsing the Freezer compartment Up button
Fig. 2 (5) or
Freezer compartment Down button Fig. 2 (4) , select E.
uTo confirm: briefly press the SuperFrost button
Fig. 2 (2) .
uTo increase the water supply time: press the
Freezer compartment Up button
Fig. 2 (5) .
uTo decrease the water supply time: press
the Freezer compartment Down button
Fig. 2 (4) .
uTo confirm: press the SuperFrost button
Fig. 2 (2) .
uDeactivate setting mode: press the Freezer compart-
ment On/Off button Fig. 2 (3) .
-or-
uWait 5 mins.
wThe temperature is again displayed on the temperature
display.
Switching off the IceMaker
If ice cubes are not required, the IceMaker can be
switched off independently of the freezer compartment.
When the IceMaker is switched off, the drawer of the
IceMaker can also be used for freezing and storing food.
uPress the On/Off button for about 1 second until the
LED goes out.
wThe IceMaker symbol
Fig. 2 (6) LED goes out.
uClean the IceMaker.
wThis ensures that no water or ice remains in the
IceMaker.
5.8 Wine cooling zone
In the wine cooling zone you can bring your wines to the
ideal drinking temperature slowly and evenly.
5.8.1 Storing wine bottles
34 Bordeaux wine bottles (typical 750ml) can be stored in
the wine cooling zone.
uStore white wine in one compartment and red wine in
the other compartment as the temperature of the two
compartments can be controlled separately.
uPut the same types of wine next to each other on the
same storage shelf as far as possible.
uStack the bottles as little as possible.
uStore opened bottles on
the folded down wooden
shelf.
uFolding the wooden shelf
down: Push the catch
under the panel to one
side.
wThe wooden shelf folds
down.
5.8.2 Setting the temperature of the wine
cooling zone
The default setting for the appliance is normal mode. The
temperature can be set from 68 °F (20 °C) to 41 °F (5 °C),
(8 °C) to (12 °C)is recommended.
The wine cooling zone is divided into two wine cooling
compartments. The temperature of each of these can be
controlled separately.
uSelecting the wine cooling compartment: Press the
Zone button Fig. 2 (16) .
wThe selected wine cooling zone is displayed
on the temperature display.
uTo set a higher temperature: Press the wine cooling
zone UP button Fig. 2 (14) .
uTo set a lower temperature: Press the wine cooling
zone DOWN button Fig. 2 (13) .
Operation
* Depending on model and options 11

wWhen the button is pressed for the first time the
previous value is displayed on the top wine cooling
zone temperature display
Fig. 2 (8) or on the bottom
wine cooling zone temperature display Fig. 2 (7) .
uTo change the temperature in 1 °F (1 °C) steps: Press
the button briefly.
-or-
uTo change the temperature continuously: Hold the
button down.
wThe new value flashes while the settings are being
made.
wThe actual temperature is displayed about 5 seconds
after the last button is pressed. The temperature slowly
adjusts to the new value.
5.8.3 Fan
If the fan is running the relative humidity in the interior
increases so that the corks do not dry out.
Energy consumption increases if the fan is switched on.
To save energy, the fan automatically switches off when
the door is open.
Switching the fan on
uPress the ventilation
Fig. 2 (18) button
briefly.
wThe Ventilation symbol LED lights up.
wThe fan continues to run. The humidity is high.
Switching the fan off
uPress the ventilation
Fig. 2 (18) button briefly.
wThe Ventilation symbol LED is dark.
wThe fan only works when this is necessary to control
the temperature. The humidity is low.
5.8.4 Dim mode
With models with glass doors you can set dim mode for
the light, i.e. the intensity of the light after the door has
been closed.
Setting dim mode
Note
uIf the dim mode is disabled the light slowly gets darker
and then goes out after the door has been closed.
uPress the light
Fig. 2 (17) button briefly.
wThe light button
Fig. 2 (17) comes on. The dim mode is
selected.
The settings apply to all wine cooling compartments.
uSetting the light brighter: Press the light button
Fig. 2 (17) and the wine cooling zone UP button
Fig. 2 (14) at the same time.
uSetting the light darker: Press the light button
Fig. 2 (17)
and the wine cooling zone DOWN button Fig. 2 (13) at
the same time.
5.8.5 Description labels
You can write which wines are stored in the respective
compartments on the labels. You can obtain additional
description labels from your dealer.
Writing on the labels
5.8.6 Wooden shelf
Note
uDo not load the wooden shelf with more than 26.46 lbs
(12 kg).
Ensure that the wooden shelf
does not remain suspended
on the rear hook.
uTo remove the folding
wooden shelf: lift upwards
out of the pull out rail and
pull it forwards.
uTo fit the folding wooden shelf: push it under the rear
hook and press onto the rails until it clicks into place.
uTo remove the lower
wooden shelf: pull forward
at an angle and lift up at the
same time.
uTo fit the lower wooden
shelf: insert over the stop
fitted to the undershelf until
it hits the back wall of the
appliance and press down.
uTo insert other wooden
shelves: attach to the rails.
6 Maintenance
6.1 Replacing the active carbon filter
The active carbon filter guarantees optimum air quality
and should therefore be replaced once a year. It can be
ordered from a dealer.
Each wine cooling compartment is fitted with an active
carbon filter.
Maintenance
12 * Depending on model and options

uGrasp the filter by the handle.
uTurn it 90° to the right or left
Fig. 5 (1) .
uRemove the filter .
uInsert the new filter with the
handle in a vertical position.
uTurn it 90° to the right or left
Fig. 5 (1) until it clicks into place.
Fig. 5
6.2 Replacing the water filter
The water filter should be changed when the Filter symbol
Fig. 2 (10) lights up. It should be replaced every six months
at least or whenever you notice a significant decrease in
the flow rate You can order one from your dealer or by
visiting our web site at www.liebherr-appliances.com.
The used water filter contains activated carbon and can
be disposed of with normal household waste.
To remove the old water filter:
Fig. 6
ulift the ventilation grid
Fig. 6 (1) up and pull out.
uOpen the filter change flap
Fig. 6 (2) .
uPull the water filter carriage
Fig. 6 (3) out.
uRemove the filter cover
Fig. 6 (6) .
uCatch any dripping water with your hand or with a dish.
uTurn the water filter
Fig. 6 (3) about 100° anti-clockwise
and pull out.
Note
If no new water filter is inserted:
uput the filter cover on to protect the filter unit from dirt
and dust.
To install a new water filter:
Fig. 7
uInsert the new filter
Fig. 7 (4) and turn it about 100°
clockwise as far as it will go.
uPlace the cover
Fig. 7 (6) on the filter.
uWrite the date of the next filter replacement on the
supplied adhesive label
Fig. 7 (5) and affix it to the filter
cover Fig. 7 (6) .
uPush in the water filter carriage
Fig. 7 (4) .
uClose the filter change flap
Fig. 7 (3) .
uFit the ventilation grid
Fig. 7 (1) again and push down. It
must close flush with the floor.
Note
New water filters may contain particulate matter.
uDo not consume or use ice cubes produced within 72
hours after replacing the filter.
uRemove any ice still present in the IceMaker tray. You
can keep this ice in another tray for later use.
uMake sure the filter does not leak and no water is
coming out.
To reset the timer:
uSelect setting mode: Press and hold the SuperFrost
button Fig. 2 (2) for approx. 5 seconds.
wThe SuperFrost button will flash
wS will appear on the display.
uUsing the freezer compartment Up button
Fig. 2 (5) or
freezer compartment Down button Fig. 2 (4) , select F.
uTo confirm: Briefly press the SuperFrost
Fig. 2 (2)
button.
wF0 will appear on the display.
uTo confirm: Briefly press the SuperFrost
Fig. 2 (2)
button.
wThe filter symbol
Fig. 2 (10) goes out
6.3 Defrosting with NoFrost
The NoFrost system defrosts the appliance automatically.
Wine cooling zone:
The defrosted water is evaporated by the heat of the
compressor. Drops of water on the back wall are a func-
tional feature and completely normal.
uClean the drain opening regularly so that the defrosted
water can flow away (see 6.4) .
uClean rubber lip (see 6.4) .
Freezer compartment:
The moisture condenses on the evaporator and is periodi-
cally defrosted and evaporated.
uThe appliance does not need to be defrosted manually.
6.4 Cleaning the appliance
WARNING
Danger of electric shock.
uUnplug refrigerator or disconnect power.
Maintenance
* Depending on model and options 13

WARNING
Risk of injury or damage due to hot steam.
Hot steam can cause scalding/burns and damage to
surfaces.
uDo not use steam cleaners.
NOTICE
Incorrect cleaning damages the appliance.
uDo not use concentrated cleaning agents.
uDo not use steel wool or sponges that scour or scratch.
uDo not use caustic or abrasive cleaning materials or
those containing sand, chloride, chemicals or acids.
uDo not use chemical solvents.
uDo not damage or remove the rating plate on the inside
of the appliance. It is vital for the customer service
department.
uDo not pull off, kink or damage any cables or other
components.
uDo not let cleaning water get into the drain gutter, the
ventilation grille and electrical parts.
uUse soft cleaning cloths and a multi-purpose cleaning
agent with a neutral pH value.
uOnly use food-compatible cleaning and care agents
inside the appliance.
uEmpty the appliance.
uDisconnect the power plug.
uClean the plastic surfaces, outside and inside, by
hand using lukewarm water and a little dish washing
liquid.
Stainless steel which is exposed to chlorine gas or damp-
ness may become discolored. This is normal. If your
appliance is exposed to chlorine gas or dampness, clean
and polish it more frequently. If there are any signs of rust
or discoloration, clean and polish the appliance as soon
as possible.*
Do not apply stainless steel cleaning agents to glass or
plastic surfaces so as not to scratch them. Initially darker
areas and quite an intensive color of the stainless steel
surfaces are normal.*
uIf dirty clean external stainless steel surfaces with a
commercially available stainless steel cleaning agent.
Then apply the supplied stainless steel cleaning agent
evenly in the direction of the grain.*
Do not clean the glass door with abrasive cleaning
agents or rough cloths. Otherwise the surface and the
frame may become dull or be scratched.
uClean the glass door with a standard glass cleaner and
a soft cloth.
uClean fittings by hand using lukewarm water and a
little dish washing liquid.
After cleaning:
uWipe the appliance and accessories dry.
uConnect the appliance and switch it on again.
uSwitch on SuperFrost (see 5.7.4) .
When the temperature is sufficiently cold:
uput the food back in the appliance.
6.5 Cleaning the IceMaker
The IceMaker drawer must be emptied and pushed in.
uActivate setting mode: press and hold the SuperFrost
button
Fig. 2 (2) for approximately 5 s.
wS is shown on the display.
wThe Menu symbol
Fig. 2 (22) lights up.
uUsing the Freezer compartment Up button
Fig. 2 (5) /
Freezer compartment Down button Fig. 2 (4) , select I.
uTo confirm: press the SuperFrost button
Fig. 2 (2) .
uUsing the Freezer compartment Up button
Fig. 2 (5) / Freezer compartment Down button
Fig. 2 (4) , select Ic.
uTo confirm: press the SuperFrost button
Fig. 2 (2) .
wThe IceMaker moves into cleaning position and shuts
off.
uDeactivate setting mode: press the Freezer compart-
ment On/Off button
Fig. 2 (3) .
-or-
uWait 2 min.
wThe temperature is again displayed on the temperature
display.
uTake out the drawer.
uClean the ice compartment and drawer with warm
water. If necessary, use a mild dishwashing liquid.
Then rinse.
uSlide the drawer back in.
If dishwashing liquid was used:
uThrow out the first three batches of ice cubes to get rid
of any dishwashing liquid residues.
Either leave the IceMaker switched off in this position or
switch the IceMaker back on (see 5.7.9) .
6.6 Customer service
First check whether you can remedy the fault yourself
(see Troubleshooting). If this is not the case, please
contact a qualified service provider.
WARNING
Risk of injury from repairs by non-professionals.
uRepairs and work on the appliance and the power
supply cable not described in the Manual (see Mainte-
nance) should only be carried out by a qualified service
provider.
uRead the appliance
designation
Fig. 8 (1) ,
service no. Fig. 8 (2)
and serial no.
Fig. 8 (3) from the
rating plate. The
rating plate is
located inside the
appliance on the left-
hand side.
Fig. 8
Maintenance
14 * Depending on model and options

uNotify a qualified service provider, specifying the fault,
appliance designation
Fig. 8 (1) , service no. Fig. 8 (2)
and serial Fig. 8 (3) no.
wThis will help us to provide you with a faster and more
accurate service.
uKeep the appliance closed until the Customer Service
engineer arrives.
wThe food will stay cool longer.
uDisconnect the power plug (do not pull on the power
cord to do this) or switch off the fuse.
6.7 Appliance Information
Make a note of this information when the appliance is
installed:
Type Designation: _____________________
Service Number: _____________________
Appliance / Serial Number: _____________________
Date of purchase: _____________________
Where purchased: _____________________
7 Troubleshooting
Your appliance is designed and manufactured for reliable
operation and a long lifespan. If a malfunction nonethe-
less occurs during operation, please determine if the
malfunction is due to an operating error. If a service call
determines operator error, you will be charged for the
costs incurred, even during the warranty period. You may
be able to rectify the following problems yourself:
Problem Possible Cause Correction
The appliance
does not work.
The appliance is not switched on. uSwitch on the appliance.
The power plug is not properly
inserted in the wall socket.
uCheck the power plug.
The fuse in the wall socket is not OK. uCheck the fuse.
Power failure uKeep the appliance closed.
uProtect the food: place dry ice on top of the food or
use an alternate freezer, if the power failure persists
for some time.
uDo not re-freeze defrosted food.
The compressor
runs for a long
time.
When less refrigeration is required,
the speed-controlled compressor
switches to a low speed. Although
the running time is increased as a
result, energy is saved.
uThis is normal in energy-saving models.
SuperFrost function is activated. uThe compressor runs long to rapidly freeze food.
This is normal.
A LED at the
lower rear of the
appliance (for
the compressor)
flashes regularly
every 15
seconds*.
The inverter is equipped wth a diag-
nostic LED.
uThe flashing is normal.
Noises are too
loud.
The different speed levels of speed-
controlled* compressors can cause
them to generate various noises
during operation.
uThese noises are normal.
A gurgling
sound
This sound comes from the refrig-
erant flowing in the refrigeration
circuit.
uThe sound is normal.
Troubleshooting
* Depending on model and options 15

Problem Possible Cause Correction
A faint clicking
sound
The sound always occurs when the
refrigeration unit (the motor) auto-
matically switches on or off.
uThe sound is normal.
A hum. It is
briefly a little
louder when the
refrigeration unit
(the motor)
switches on.
The refrigeration increases automati-
cally when the SuperFrost function is
activated, fresh food has just been
placed in the appliance or the door
has been left open for a while.
uThe sound is normal.
The ambient temperature is too high. uSolution: (see 1.3)
A low hum The sound occurs as a result of fan
air flow.
uThe sound is normal.
Vibration noise The appliance is not standing firmly
on the floor As a result, adjoining
units or objects are set into vibration
by the running refrigeration unit
uCheck the installation and, if necessary, re-align the
appliance.
uMove bottles and containers apart.
Flow noise on
the soft stop
mechanism.
The sound is caused by the soft stop
mechanism.
uThe sound is normal.
Mold on wine
bottles
As encountered with other forms of
storage, a little mold may form
depending on the type of label adhe-
sive.
uRemove adhesive residues.
The temperature
display indi-
cates: F0 to F9.
There is a fault. uContact the customer service department (see Main-
tenance).
The temperature
display reads: FE
There is a fault. uContact the customer service department (see Main-
tenance).
The temperature
display shows a
flashing power
failure symbol
. The
warmest temper-
ature reached
during the
power failure is
displayed in the
temperature
display.
The freezer temperature rose too
high during the last hours or days
due to power failure or power inter-
ruption. When the power interruption
is over, the appliance will continue to
operate at the last temperature
setting.
uTo delete the display of the warmest temperature:
Press the Alarm button
Fig. 2 (1) .
uCheck the quality of the food. Do not consume
spoiled food. Do not re-freeze defrosted food.
DEMO lights up
in the tempera-
ture display.
The demo mode is activated. uContact the customer service department (see Main-
tenance).
The Filter Symbol
Fig. 2 (10) lights
up.
The water filter should be replaced. uReplace the water filter (see Maintenance).
Troubleshooting
16 * Depending on model and options

Problem Possible Cause Correction
The outside
surfaces of the
appliance are
hot*.
The heat of the refrigerant circuit is
used to prevent condensate from
forming.
uThis is normal.
The IceMaker
cannot be
switched on.
The appliance and therefore the
IceMaker are not connected.
uConnect the appliance (see Start-up).
The IceMaker is
not making ice
cubes.
The IceMaker is not switched on. uSwitch the IceMaker on.
The drawer of the IceMaker is not
properly closed.
uClose the drawer properly.
The water connection is not open. uOpen the water connection.
The water supply to the IceMaker
was interrupted.
uCheck the connection to the water supply (see the
Assembly Instructions, Connecting the Water
Supply).
uCheck the pipes and hoses (see the Assembly
Instructions, Connecting the Water Supply).
There is a blocked filter at the end of
the water supply hose or at the
connecting part on the machine.
uClean the filters.
The waterline was not bled of all air
during installation
uPlease contact your qualified installation plumber to
ensure the above criteria is met before calling for
service.
The temperature
is not cold
enough.
The door of the appliance is not
closed properly.
uClose the appliance door.
Insufficient ventilation. uClear ventilation grilles.
The ambient temperature is too high. uSolution: (see 1.3)
The appliance was opened too
frequently or for too long.
uWait to see whether the required temperature resets
itself by itself. If not, contact the customer service
department (see Maintenance).
Too much fresh food was placed
inside without SuperFrost.
uSolution: (see 5.7.4)
The temperature is incorrectly set. uSet to a colder temperature and check after 24 hours
The appliance is too near to a heat
source (stove, heater etc).
uChange location of appliance or the heat source.
Display show
two dashes (“-
-”).
The freezer temperature display will
only show temperatures that are
below freezing.
uWhen initially starting the appliance it will not be
below freezing. It will take three to five hours
(depending on ambient conditions) for freezing
temperatures to be achieved and thus displayed
numerically.
The freezer temperature has risen
above zero degrees due to a power
failure or power interruption.
uSee also “Power failure” and “ ”
The interior light
is not on.
The appliance is not switched on. uSwitch on the appliance.
Troubleshooting
* Depending on model and options 17

Problem Possible Cause Correction
The door was open for longer than
15 minutes.
uThe interior light automatically switches itself off if
the door has been open for about 15 minutes.
The LED interior light is faulty or the
cover is damaged WARNING
Risk of injury from electrical shock.
Live parts are under the cover.
uThe LED interior light should only be replaced or
repaired by the Customer Service department or by
engineers trained to do so.
WARNING
Risk of injury from LED lamp!
The lighting intensity of the LED light complies with laser
class 1/1M.
If the cover is faulty:
uDo not gaze directly at this lighting unit with optical
lenses while very close to the light source. This can
cause damage to your eyes.
8 Putting appliance out of
service
8.1 Vacation Tips
Short vacations: If you will be away for less than four
weeks
uTurn off the icemaker.
uShut down the water supply to the icemaker.
Long vacations: If you will be away for a month or more
uRemove all food from the appliance.
uTurn OFF the appliance.
uClean the appliance (see 6.4) .
uLeave the door open to prevent unpleasant odors.
wThis will also keep mold from building up.
uTurn off the icemaker.
uShut off the water supply to the icemaker.
8.2 Switching off the appliance
Note
uTo switch off the entire appliance, only the freezer
compartment needs to be switched off.
8.2.1 Switching off the freezer compartment
uPress and hold down the freezer compart-
ment On/Off button
Fig. 2 (3) for approx. 2
seconds.
wThe temperature displays are dark. The
appliance is switched off.
8.2.2 Switching off the wine cooling zone
uPress and hold down the wine cooler zone On/Off
button Fig. 2 (15) for approx. 2 seconds.
wThe temperature display of the top wine cooling zone
Fig. 2 (8) and the temperature display of the bottom
cooling zone
Fig. 2 (7) are dark. The wine cooling zone
is switched off.
8.3 Decommissioning
uEmpty the appliance.
uPut the IceMaker in the cleaning position (see Mainte-
nance).
uDisconnect the power plug.
uClean the appliance (see 6.4) .
uLeave the door open to prevent bad smells.
9 Disposing of the appliance
Follow the local regulations for the disposal of appliances.
Old appliances can be dangerous. Contact the local
refuse collection department for additional information.
DANGER
There is a risk of suffocation.
Children playing can shut themselves in and suffocate.
uTake the door(s) off.
uRemove the drawers.
uLeave the storage shelves in the appliance so that chil-
dren cannot easily climb into the appliance.
Putting appliance out of service
18 * Depending on model and options

WARNING
Danger of electric shock.
uCut off the plug from the power cord and discard.
uCut off the power cord from the discarded appliance.
Dispose of separately from the appliance.
Ensure during and after disposal that the appliance isn't
stored in the vicinity of gasoline or other flammable vapors
and liquids.
When disposing of the appliance, ensure that the refriger-
ation circuit is not damaged to prevent uncontrolled
escape of the refrigerant it contains (data on type plate)
and oil.
10 Liebherr Warranty Plan
FULL TWO YEAR WARRANTY - For two years from the
date of original purchase, your Liebherr warranty covers
all parts and labor to repair or replace any part of the
product which proves to be defective in materials or work-
manship.
FULL FIVE YEAR WARRANTY - For five years from the
date of original purchase, your Liebherr warranty covers
all parts and labor to repair or replace any components
that prove to be defective in materials or workmanship in
the sealed system. The “Sealed System” means only the
compressor, condenser, evaporator, drier and all
connecting tubing.
LIMITED 6TH THROUGH 12TH YEAR WARRANTY -
From the 6th through 12th year from the date of original
purchase, your Liebherr warranty covers all parts that
prove to be defective in materials or workmanship in the
Sealed System (parts only).
TERMS APPLICABLE TO EACH WARRANTY
All service provided by Liebherr under the warranty must
be performed by authorized Liebherr service representa-
tives, unless otherwise specified by Liebherr. Service will
be provided in the home during normal business hours.
This warranty applies only to products installed for normal
residential use. Details regarding a non-residential
warranty are available on request.
The warranty applies only to products installed in any one
of the fifty states of the United States or the District of
Columbia. The warranty does not cover any parts or labor
to correct any defect caused by negligence, accident or
improper use, maintenance, installation, service or repair,
including but not limited to improper removal and reinstal-
lation of the condensing unit.
THE WARRANTIES DESCRIBED ABOVE ARE MADE
EXPRESSLY IN LIEU OF ANY OTHER WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE, AND OF ANY OTHER
OBLIGATION OR LIABILITY ON THE PART OF LIEB-
HERR. IN NO EVENT SHALL LIEBHERR BE LIABLE
FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES ARISING FROM THE BREACH OF THESE
WARRANTIES OR ANY OTHER WARRANTIES,
WHETHER EXPRESS, IMPLIED OR STATUTORY.
Some states do not allow the exclusion or limitation of
incidental or consequential damages so the above limita-
tion or exclusion may not apply to you. This warranty
gives you specific legal rights and you may also have
other legal rights which very from state to state.
To receive parts and/or service and the name of the Lieb-
herr authorized service representative nearest you,
contact your Liebherr dealer or distributor or contact the
Liebherr designated national service provider:
in the US: [email protected] or call
1-866-LIEBHER (1-866-543-2437).
in Canada: www.euro-parts.ca or call 1-888-LIEBHER
(1-888-543-2437).
Liebherr Warranty Plan
* Depending on model and options 19

For Service in the U.S.:
Liebherr Service Center
Toll Free: 1-866-LIEBHER or 1-866-543-2437
[email protected]
PlusOne Solutions, Inc.
3501 Quadrangle Blvd, Suite 120
Orlando, FL 32817
For Service in Canada:
Liebherr Service Center
Toll Free: 1-888-LIEBHER or 1-888-543-2437
www.euro-parts.ca
EURO-PARTS CANADA
39822 Belgrave Road
Belgrave, Ontario, N0G 1E0
Phone: [phone]
Fax: [phone]
Part No. 7084306 - 01
www.liebherr-appliances.com
