User's Manual
Digital to Analogue Audio Converter
Headphone Amplifier
Product number: KN40579, KN40580, KN40581

2
Thank you for purchasing the converter from KanaaN.
We hold several brands to produce and distribute our products: LEICKE (power adapters,
batteries), KanaaN (adapters/converters, charging cables etc.), Sharon (iPad cases with
keyboard, fans etc.), HEBRON (protective cases, docking stations, screen protectors etc.),
MANNA (notebook and smartphone cases).
We continuously work on the development of our products, our customer support and
innovations. Our products have a long service life, are eco-friendly and high performing.
Furthermore, every day we do our very best to satisfy you as our customer. That is why you,
no matter if private or business customer, are in the focus of our company’s efforts. We take
your reviews and proposals seriously and evaluate them continuously. That way, we get to
know you and your demands on our products and services better and thus allow for positive
enhancements.
To discover more about LEICKE products, or if you have any questions about this product,
visit our website www.leicke.com.
Dear customer,
this Digital to Analogue Audio Converter from our brand KanaaN is specially designed for
either home or professional audio signal switching. It converts Coaxial or Toslink digital audio
signals into analogue L/R audio signals and allows you to connect it to an external device
such as an amplifier via standard Cinch connector. The additional 3.5 mm headphone output
is the special feature of our KanaaN Digital to Analogue Converter. The output signal can be
regulated with an additional controller. This converter is small in size and quite easy to install.
For optimum performance, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for further reference.
Your LEICKE Team!
PACKAGE CONTENTS
Before attempting to use this device, please check the packaging and make sure the
following items are contained in the package:
Name
Number of
Pieces
Note
Digital to analogue audio converter
1
-
Charger cable
1
USB (type A)
User's Manual
1
-

3
TECHNICAL DETAILS
Signal Input/Output
Input
Coaxial or Toslink digital audio
Output
L/R audio + Headphone out (amplified)
Connectors
Input connector
Toslink, 1 x Cinch (Coaxial)
Output connector
2 x Cinch (R/L), 1 x 3.5 mm PhoneJack
Sampling Rate
32, 44.1, 48, 96 and 192 KHz
Bit Rate
24 resolution
Output Voltage
Max. 500 mV, 3.5 mm PhoneJack
Dimensions
(L x W x H)
84 x 63 x 28 mm
Weight
140 g
Environmental Specifications
Operating Temperature
0°C to 70°C
Operating Humidity
10% to 85% RH (no condensation)
Storage Temperature
-10°C to +80°C
Storage Humidity
5% to 90% RH (no condensation)
Power Requirements
External Power Supply
Via charger cable USB (type A)
Power Consumption
Max. 5 W
Regulatory Approvals
Converter Unit
UL, CE, RoHS
Power Adapter
UL, CE, FCC

4
PANEL DESCRIPTION
Please study the panel drawings below and become familiar with the signal input(s), output(s)
and power connector.
CONNECTION DIAGRAM

5
CONNECTION AND OPERATION
Attention: Insert/Extract cable gently.
Step 1: Please switch all devices off before connecting the converter.
Step 2: Connect the audio source device (DVD player etc.) via a TOSLINK or coaxial
cable to the converter and the analogue output with a cinch or 3.5mm jack with a suitable
amplifier.
Step 3: Connect the AV receiver or amplifier with a compatible L/R cable to the converter.
Step 4: In addition, you can use the headphone out to use the audio signal. The
headphones need a compatible 3.5mm jack. This signal is pre-amplified in the converter and
you can adjust the volume.
Step 5: To activate the headphone out just push the volume controller a few seconds.
Step 6: You may now use the converter. Connect with the charger cable to a USB (type
A) port and switch on the source device.
Notes:
To output a digital audio signal the playback device might be set to "digital audio". You may
find such instructions in the producers user's manual.
If the converter is connected to a TOSLINK and coaxial cable simultaneously, the TOSLINK
signal will be automatically preferred.

6
FAQ
In general, in case of technical troubles check the electrical signal connections and the power
supply (LED at converter glows) first. If this turns out to be not helpful, we arranged the
following questions and answers for you to find the cause and solve the problem.
Problem Description
Possible Cause/Possible Solution
No or just very low
audio output.
Is the volume correctly adjusted at the playback device?
Is the signal source set on digital audio?
Is the amplifier set on the right input interface?
Is the proper digital output format (PCM Audio, Stereo)
used? For the use of the converter with a Dolby Surround
device, you need to adjust the stereo out format. Otherwise
different transmission protocols may lead to very low or
even no audio signal.
Is the signal cable to long? Or even defective?
There is a supply noise
Do the cables have a proper distance to transformers or
similar devices?
Are converter and amplifier connected to different circuits
(ground loop)?
If you use the Cinch input on the digital side, ground loops may
occur, especially with source devices using a switching power
supply like notebooks. Is the supply noise still there if the
Notebook runs on battery operation?
The signal is distorted
Is the right output format PCM (Dolby Digital Audio) used?
Is the correct amplifier input used?
Some sound systems have input interfaces for record players,
which are more sensible and not suitable due to possibly
occurring distortions.
Is the volume at the playback device set to high?
If the problems cannot be solved, please don't hesitate to contact us. Our customer's
support will be glad to help you under [email protected].

7
SAFETY NOTES
For your own safety and for long enjoyment of our product, please follow the following safety
instructions:
Please use device as described in the manual.
To avoid damages to the video system by inrush current, please switch the amplifier/TV
off before installing the converter. Non-compliance may cause damages to TV, amplifier
system and your hearing! The amplifier is to be switched on last, after signal source
and converter are already switched on.
If the converter does not work normally, please disconnect the power adapter from the
circuit and try to find the cause.
Use original factory power adapter. Do not attempt to use the converter with other
power adapters. Despite of matching plug connectors it may still damage the converter,
the signal source and the sound system!
Warning: Power adapters with a higher voltage may damage the converter.
Do not pull on power cord when taking off the wall socket.
Turn off power when device is not in use for a longer time.
Do not open cover and do not touch inner parts.
Please keep power adapter and converter dry and just use in dry environment.
Keep away from damp, high temperature, dusty, erosive and oxidative environment.
Do not touch with wet hands.
Keep safe from being hit or falling down.

8
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or
relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the
equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or
an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions:
1. This device may not cause harmful interference, and
2. (2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC-Caution: FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
IMPORTANT NOTE:
Radiation Exposure Statement:
1. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
End users should follow the specific instructions in the user's manual to comply with the FCC rules.
2. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
DISPOSAL
This device contains materials that must not be disposed of as household waste. Please check
local laws concerning the applicable disposal regulations. Protect the environment by
participating in recycling programs!

9
CONTACT
If you have any questions, please feel free to contact us.
PRODUCTION & WHOLESALE
LEICKE GmbH
Dohnanyistr. 28
04103 Leipzig
Germany
Web: www.leicke.com
Mail: [email protected]om
