Leisure AquaClear LETAQCLEARSAT Installation guide

Care Instructions for your AquaClear Kitchen Sink Mixer
Care and Aftersales Enquiries – Call 01926 457628 Option 4 Please Retain these Instructions
To maintain the appearance of this tap, ensure that it is regularly cleaned using only a clean, soft damp cloth. A solution of warm
water and a mild liquid detergent may be used where necessary, and then the fitting rinsed thoroughly and wiped dry.
Any other cleaning action could invalidate your warranty.
You MUST NOT use abrasive cleaners, scouring and acidic cleaners under any circumstances as this WILL damage the integrity of
the surface finish. Avoid contact with all solvents (including chlorinated solvents, ketones or acetones) as these may result in
surface deterioration or etching. Also avoid contact with any harsh household chemicals such as oven cleaners, drain cleaners,
rust removers, paint strippers and Stainless-Steel cleaner. Where the tap has a removable aerator on the spout exit it can be
removed and cleaned periodically with water to maintain optimum flow performance.
Important Technical Data:
 Min / Max operating pressure: 0.3 bar - 5.5 bar*
 Recommended / Maximum hot water temperature: 46 - 70°C*
 Tap hole size and centres: ∅35mm
 This product is either WRAS approved or manufactured in accordance with recognised European standards.
 Please ensure that your kitchen mixer is fitted in accordance with Local Water Byelaws.
 Hot and cold supply pressures should be as closely balanced as possible for best results.
 Supply pipes should maintain the maximum diameter until immediately before the fitting.
 Always use the manufacturer’s tail pipes provided – use of non-manufacturer tails will invalidate warranty.
 The differential between the hot and cold water temperatures should be sufficient to allow correct mixing function.
 This tap has been 100% assembly tested therefore, you may expect a small residual amount of water to remain in the
tap or inner packaging when delivered. This is normal and any water marks can be removed using the care advice
above.
*If these temperatures or pressures are exceeded, even for short periods, damage can result. In these instances, a
thermostatic mixing or pressure reducing valve should be installed.
5 Year Warranty Terms and Conditions
In the event of any problem or defect in the materials or workmanship of your new Leisure mixer within FIVE years of
purchase, the purchaser’s sole remedy shall be the replacement (at the manufacturer’s discretion) of all or any part of the
product that is defective. All working parts, valves and O rings are guaranteed for a period of FIVE years from purchase.
Chrome decorative surface finishes are guaranteed for FIVE years from the date of purchase and other decorative finishes
(including granite finishes, matt black, satin steel, satin bronze) are guaranteed for THREE years from date of purchase. The
warranty extends to the original purchaser only.
You should retain a copy of your dated invoice as proof of purchase to validate any claims under this guarantee as claims
without proof of purchase may not be accepted. Surface scratches and marks caused through careless or improper installation
or accidental damage are NOT covered by this warranty. Any product returns must be packaged with all associated tap parts and
clear details of the installation name and address and the customer service number displayed on the return packaging.
IMPORTANT: All warranties extend only to mixers used for normal domestic use in the UK or Ireland and that the care,
installation and maintenance instructions have been fully observed.
Due to our continual product development, we may not be able to provide an identical replacement for a defective product
throughout the guarantee period. Where an identical product is no longer available, we will supply the nearest equivalent from
our then current product range. In assessing your claim, we must be given the opportunity to inspect the product as installed
prior to removal.
No other warranties, express or implied, are made, including merchantability or fitness for a particular purpose. Under no
circumstances shall the manufacturer be liable for any loss or damage arising from the purchase, use or inability to use this
product, or for any special, indirect, incidental, or consequential damages. No liability is accepted for consequential damage to
other household fixtures, fittings or furnishings arising from this claim, even if attached to the product. No installer, dealer,
agent or employee of Aga Rangemaster Limited has the authority to modify the obligations or limitations of this warranty.

Care Instructions for your AquaClear Kitchen Sink Mixer
Care and Aftersales Enquiries – Call 01926 457628 Option 4 Please Retain these Instructions
Installation Preparation:
All parts should be removed from their packaging and inspected for completeness and transit damage prior to installation.
IMPORTANT: Before installation, it is essential that you thoroughly flush through the supply pipes in order to remove any
remaining dirt, solder, swarf, sediment or impurities from your water system. Failure to carry out this simple procedure could
cause significant damage to the workings of the tap, reduce flow rates and invalidate the warranty. We recommend installing
isolation valves to both the hot and cold feed pipes in an accessible position. This will help to ease any future required
maintenance to the product.
 Shut off the water heating system and ensure that the mains stopcock is closed.
 Ensure both hot and cold water supplies are isolated before commencing installation.
 If replacing an existing tap, remove the tap & clean the end of the feed pipes using wire wool, the tap hole areas should be free from
dirt and sealant. You should ensure that the product will both fit into the depth of the mounting surface available and reach the
required outlet positions before installation.
 Loosely position the tap to check if any alteration to the existing pipework is required, if this is the case do this now.
Installation
1. Screw the studded rod (C) into the base of the tap (A).
2. Place the base plinth (B) on the bottom of the tap (A)
3. Screw the hot & cold water flexible pipes (G & H) into the hot and cold inlets on the
tap
4. Place the tap (A) onto the sink, passing the flexible tail pipes (G & H) and studded
rod (C) through the taphole.
5. Pass the rubber and then metal horseshoe (D & E) over the studded rod (C) and
around the tail pipes (G & H).
6. Fasten the fixing nut (F) securely onto the fixing stud (C) to fix the tap into its correct
location.
7. Connect the tail pipes (G & H) to the 15mm water supplies using the compression
fittings.
Key: Description
A Tap body x 1
B Base plinth x 1
C Fixing Stud x 1
D Rubber Horseshoe x 1
E Metal Horseshoe x 1
F Fixing Stud x 1
G Hot water flexible inlet pipe x 1
H Cold water flexible inlet pipe x 1
After installation:
Once you have visually checked the installation and all connections, ensure
that all other fittings are closed except the new tap which should be left
open. Turn on your water heating system and ensure that your mains
stopcock is open. Reconnect both the hot and cold-water supplies to this
fitting. Check the function of flow and function of hot, cold and mixed water.
Turn off the tap and check carefully for any leaks around all connections on the fitting and adjoining plumbing. If pressure
testing equipment is available check the installation to the maximum recommended pressure. Clean the tap to remove any
marks created during installation. Protect the newly installed tap from damage by placing a packaging bag over the product. The
installation should be periodically checked for damage, if the property is left unattended for a prolonged period, we recommend
isolating water supplies.
