Lemco Combi Bike+ User manual
EN 1.0
USER MANUAL
Please read and understand before use.
2
INTRODUCTION
Congratulations with your Lemco Combi Bike Plus!
I have spent 4 years developing and rening the Lemco Combi Bike Plus
mobility exerciser from scratch. It has been a long and tough journey. We are
proud to present the result of our many years of development.
I sincerely hope the bike will give you a lot of joy and strength. I hope it will
fulll your expectations of quality and user friendly design.
You are responsible for the outcome of your training. We have developed a
truly unique possibility for people who have mobility challenges, to stay
active and experience physical improvement.
I would be very happy if you would be willing, to share your experiences with
this exerciser by writing to me.
It is important for us to read our users experiences and your
comments may inspire other people to choose this smart way of exercising
at home or in physiotherapy centers. Your feedback will help us further our
development and work.
You have the posibility to order a small training diary where you can note
your progress.
If you have any questions or you wish to acquire one or more training diaries
you can contact me at: carsten@lemco-mobility.com
You are always welcome to call me at: +45 3325 4002
Best regards.
Carsten Lemche, CEO & Inventor
3
SAFETY (1)
We recommend you get approval from your doctor or therapist before you
start training. Especially if you are in the elderly group.
Users with handicap, other disabilities, heart or breathing problems must
have approval from their doctor or therapist, before starting to exercise with
the Combi Bike Plus. Supervision during use is required.
It is recommended to seek professional assistance and get advice on how
often you should train from a physiotherapist. They can also advice you on
how to warm up before training and assist with a personal exercise program.
Please read the limitations of the use of Lemco Combi Bike Plus before you
start using the bike.
If you have any diculties using the bike after having read this manual
throughly, please contact Lemco or your reseller for advice.
Never use the bike if the function of it feels wrong.
It is advised to lock the rotation of the pedals
when the bike is being transported or is not in use.
Place the bike on an even surface.
There must be at least one meter of moving space
from the wheelchair to the bike.
Please tighten the bolts on the pedals, and the handles after
approximately one month.
Be sure to wear appropriate clothing when training.
Please wear shoes with good support and soles when training.
Avoid excessive training.
Follow your doctor or therapists exercise instructions.
FOR YOUR SAFETY:
4
SAFETY (2)
Ensure a minimum distance of 30 cm. from Lemco Combi Bike
to other objects e.g. Wall / Tables / Chairs.
Do not use the bike near small children.
Do not let children play with the trainer.
The bike is not to be used by children below 15 years old, without
supervision from an adult.
Changes to any part of the bike is prohibited. Changes can damage the bike,
reduce the performance of the bike and can cause risk of injury.
If the user feels dizzy, short breathed or have other
symptoms that could indicate danger their health, stop
exercising immediately and call a doctor.
When training, ensure that the hands of the
assistant / Therapist is held at a safe distance.
Pedals and handles are connected so they move synchronously as a part of
our BEAT technology.
The bike is not a toy. It is not security approved for use by children.
Please ensure no children has access to the bike.
Be careful of scarfs or other loose clothing. Ensure that such items do not
collide or get caught in moving parts.
Ensure not to get your ngers trapped in moving parts.
Also when moving or lifting the bike over short or long distances.
This is also applicable for assistants / helpers, helping a user exercising.
FOR YOUR SAFETY:
5
LIMITATIONS
The Lemco Combi Bike is designed for Handicapped, other disabilities and
elderly.
The Lemco Combi Bike Plus is designed to give the user an eective and easy
exercise routine, to help strengthen and build muscle in legs and arms. The
Combi Bike Plus can also help with increasing blood circulation.
The Combi Bike Plus has a 30km/h limit to pedaling speed. If you pedal above
30km/h the bike will sound an alarm to indicate max speed is exceeded.
The bike is designed for up to 40 Watt and might overheat if you exercise
above maximum for a longer period. Let the bike cool for 30 minutes
in case it feels overheated.
Lemco Combi Bike plus is not a spinning exerciser and is not designed
to be used as one.
Only use Lemco Combi Bike Plus for training from a sitting position as
described. The bike is designed to be used from wheelchair or chair.
ENVIRONMENT
Lemco Combi Bike Plus is designed for indoor use only.
Temperature: 15°C - 35°C.
Humidity: 40% - 60% RH, non-condensing.
Pressure: 960 hPa - 1060 hPa.
IP Classication: IP22
Storage & transport.
Temperature: 5°C - 35°C.
Humidity: 40% - 60% RH, non-condensing.
Pressure: 700 hPa - 1060 hPa.
EMC: IEC 60601-1-2
Do not place the exerciser in direct sunlight, discoloration might occur.
6
ASSISTANTS AND HELPERS
For Assistants and Helpers who instruct the users of the Lemco Combi
Bike Plus. Please read the following.
Place the pedals in the lowest position to make it easier to mount.
Make sure to initiate the lock before mounting the users feet on the pedals.
The Combi Bike Plus is equipped with a resistance lever on the user side and
on the front of the bike, so the helper or assistant can operate the resistance
level and lock ergonomically.
Make sure the user is in the right sitting height and distance from the bike.
FOR WHEELCHAIR
In our webshop you can nd the anti-tip for
wheelchair users.
If you apply a lot of force with legs
during training, please note that
the wheelchair might tip a bit.
We have an anti-tip for this occasion.
Please contact us if needed.
The anti-tip crossbar is placed against the
lower side of the handles on the wheelchair.
The other crossbar is placed against the oor.
Push the lower bar toward the wheelchair to
create a stable tension.
You can change the length of the anti-tip by
turning the knobs and pulling or pushing the
bar to extend or retract.
Make sure the anti-tip bar is placed on an even surface.
Always tightened the knobs rmly.
7
COMPUTER / DISPLAY
Change between the dierent modes by
pressing the green button. The display turns
on automatically and turns o automatically
after 4 minutes of inactivity.
• Speed: Your pedaling speed
• Dist: Distance
• Time: Time spend exercising
• Scan: Automatic change of modes
• Alarm: >30 km/h (slow down)
When SCAN is displayed, the screen automatically changes between
showing the functions on the bike with about 4 seconds interval.
The display can be locked in “one” mode, which is activated
when SCAN is not displayed on the screen.
Last users training data is reset 4 minutes post training.
If the text on the display fades, please change the battery
at the bottom of the bike. The battery is special ( 3.6v AA Battery )
and can be purchased in e.g. photocamera-stores or
online at: lemco.dk / lemco-mobility.com
SCAN FUNCTION
The display beeps when you press the button.
Press the button and hold for 5 seconds, to initiate countdown and reset
the counter. You will hear a beep when the display resets.
The display does not store any data. Write it down before resetting.
8
You can pedal clockwise and anti-clockwise
It is possible to use the exerciser with one hand or both hands.
It is also possible to only exercise using your legs.
TRAINING SUGGESTIONS
If one arm has a tendency to fall o the handle,
you can use a glove (We suggest Active Hands)
They give a comfortable stable grip, and are
easily put on and taken o. The rings make it
easy to operate with one hand.
Made for paralysed hands.
You can nd and purchase Active Hands on:
lemco.dk / lemco-mobility.com
The grips on the handle have
multiple grip positions.
The vertical grip position enables the user to
do crawl movement. Helps Increase shoulder
mobilization.
You can hold on the horizontal part of the
handle, where you can apply most force.
Place your hands as advised by the therapist.
We designed the handle to t most users
needs.
9
LEG SUPPORT
Leg supporters can help users with trouble
keeping their legs in the right position while
exercising.
Read section: Installation of leg support
(page 12). If you need advice for installation.
The leg support is mounted so it can pivot back
and forth with very little resistance.
You can order leg supports on our
website or at your reseller.
lemco.dk / lemco-mobility.com
RESISTANCE 0 - 9 AND ROTATIONAL LOCK
The magnetic resistance is adjustable from 0-9
Your Combi Bike Plus has a Lock integrated in
the resistance lever, it is shown with a lock
symbol.
When the lever is in lock position, the rotation
of handles and pedals are locked.
This is designed to make it easier for mounting
and dismounting the exerciser with arms and
legs. The locking mechanism can lock the pedals
and handles in any position.
Only activate the lock when rotating slowly
or stopped.
10
When the user is seated in front of the bike.
The users knees should always align with the
sides of the bike.
If the user is tall in stature.
Make sure their knees are not hitting the
handles and during use, the pedals are at
a comfortable turning radius.
LEG PLACEMENT
When exercising it is important that the users legs are in the right position
on the Combi Bike Plus
If the user is placed too far from the bike, their knees might
collide with the resistance lever.
CHANGEABLE OPTIONS
It is possible to have your Combi Bike Plus parts
changed to t the users needs.
If the user has a need for a shorter pedal arm
you can contact Lemco or your reseller
to have it changed.
11
VELCRO PLACEMENT
The velcro straps are located in three dierent places.
Be sure to thighten all correctly but comfortably to ensure stability.
1. Fasten the ankle support velcro.
The ankle support velcro helps to stabilize your
leg movement and keeps your leg in the right
position while exercising on the Combi Bike
Plus.
2. Fasten the upper pedal velcro.
The upper strap helps keep your foot in place
so the user does not un-mount the pedal while
exercising.
3. Fasten the lower pedal velcro.
The front velcro strap helps to keep the user
pedaling with the whole surface of their foot.
12
VELCRO BAND
Velcro bands can help your feet stay secure on
the exerciser in case you have complications that
makes it dicult to stay mounted.
Velcro bands can be ordered separately.
They are easy to apply and remove with one
hand.
If the bands stop sticking, you can order new
velcro online. They will wear out after
long time use.
Our pedals are designed so well that most people do not even
need Velcro. If you need the velcro, you can nd it on our website
or at your reseller.
INSTALLATION OF LEG SUPPORT
Installing the leg support on the pedal.
The screw hole is located on the inside of the pedal towards the bike.
The screw is pushed through the pre-cut hole in the rubber from the inside
of the pedal. Place the hex-nut on the opposite side and tighten it.
NOTE:
The Plastic washer must be placed between the pedal and the leg
support. Please lock the bolt with a 10 wrench and a 3 mm unbraco key.
The leg support must be able to pivot with little resistance.
Mounting of velcro on the leg support.
Velcro patches can be found on the backside
of the leg support. These are the attachment
points for the velcro band.
Make sure the velcro isnt attached, too tight
or too loose around the users leg.
13
You can nd Nylatex bands on:
lemco.dk / lemco-mobility.com
As an alternative to the leg support. A Nylatex
band might in many cases, be easier and more
exible option.
NYLATEX BAND
The Nylatex band is wrapped around, above the
knees to help keep the users legs straight.
Nylatex provides more exibility in movement
when exercising on the Combi Bike Plus.
Nylatex bands are often a better and more
exible solution than the leg support.
Depending on the users needs.
If you need to replace parts on the Combi Bike Plus be sure to contact Lemco
for guidance so we can provide the proper instructions.
It is important that you repair the bike with original parts and with guidance.
You can write a mail to us and book a Zoom call so we can guide you
through the process at: info@lemco-mobility.com
REPAIR GUIDANCE
14
MOVING THE BIKE
The built-in wheels makes it possible to move
the Combi Bike Plus over short distances on
hard oor. If you need to move the Combi Bike
Plus several meters, please lift the bike.
NOTE:
Because of the bikes weight, the wheels
might leave marks on the oor, if you roll the
bike on soft or painted oors.
CLEANING
Your Combi Bike Plus can be wiped with a dampened cloth and a small
amount of cleaning agent.
NOTE:
Display Is not waterproof.
Do not wipe the display with a wet cloth
as it can damage the display.
Use a disinfectant wipe or towel instead and avoid
hard pressure on the display itself.
If you have to move the Combi Bike Plus over
a longer distance we suggest lifting it.
Lock the bikes rotating parts before lifting.
It requires a minimum of two people
to lift the bike safely.
There are lifting-points where it is easiest to lift
the bike. Handles, the stand bar and resistance
lever on the user side.
15
TECHNICAL SPECIFICATIONS
DISCLAIMERS
• Warranty Professional: 1 Year
• Warranty Home Use: 1+2 years
• Resistance: 10 levels + Rotational Lock
• Max. User Weight: 120 kg
• Dimensions: 115 x 50 x 75 cm
• Display: Time, Distance, Speed
• Optional: Velcro For Feet
• Weight: 38 kg
• CE: SportingDevice EN957
• Battery: Li-ion 3.6V, 2400mAh, type AA, non-rechargeable.
Damage to the Combi Bike Plus by not following
the manuals instructions results in void of warranty.
The Combi Bike Plus is designed for indoor use only.
Damage to the Combi Bike Plus by storing it in conditions
outside of environments stated will result in a void of warranty.
Lemco-Mobility cannot be held responsible for any damages caused to oor.
Lemco-Mobility cannot be held responsible if you do not follow the safety guide
and cause injury to self or others while using the Combi Bike Plus.
The Combi Bike Plus is not a spinning exerciser and is not to be used as one.
The Combi Bike Plus may only be used according to Therapist or Doctor’s Instructions.
Only use original Lemco-Mobility parts. Un-original parts results in a void of warranty.
Using the Combi Bike Plus for unintended purposes results in a void of warranty.
Lemco-Mobility cannot be held responsible for damage caused by wrongful use of the exerciser.
It is prohibited to self-repair on the Lemco Combi Bike Plus without guidance from Lemco or
authorized reseller.
We improve human mobility
Manufacturer and Designer
LEMCO MOBILITY
Fabriksvej 3 - DK-3000 Helsingør
Tlf: +45 3325 4002
© Lemco-Mobility all rights reserved. 2021( 1.0)
Danish Design • Made in Denmark
Table of contents
