LENCO LVP505MS User manual

Video Cassette Player
LVP505MS
OWNER’S MANUAL
High Quality
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` A

DRAWING YOUR ATTENTION
1
Thank you purchasing this VCP, develloped to provide advanced features and functions for high quality performance.
To obtain the best results and to avoid malfunction, PLEASE CAREFULLY READ THE DESCRIPTIONS AND OPERATING
PROCEDURE CONTAINED IN THIS OWNER’S MANUAL PRIOR TO OPERATING THIS VCP.
Caution: To prevent electric shock do not use this polarized plug with an extension cord receptacle or other outlet
unless the blades can be fully inserted to prevent blade exposure.
Warning: This video cassette player should be used with AC 90-250V~, 50/60Hz.
To prevent electric shocks and fire hazards, do NOT use any other power source.
Caution: Any changes or modification in construction of device which are not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
When you are not using the VCP for along period, it is recommended that you disconnect the power cord
from the AC outlet.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE OF THE ENCLOSURE. DO NOT
OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
The lightning flash with arrowhead symbol an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intend to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
RISK OF ELECTRIC SHOCKS
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 1

IMPORTANT SAFEGUARDS
2
For your protection, please read these safety instructions completely before operating the appliance, and keep this
manual for future reference.
Carefully observe all warnings, precautions, and instructions on the appliance, or the ones described in the
operating instructions and adhere to them.
USE
Power Sources–This set should be operated
only from the type of power source indicated on
the marking label. If you are not sure of the type
of electrical power supply at your home, consult
your dealer or local power company. For those
sets designed to operate from AC 90-250V~,
50/60Hz.
Grounding or Polarization–This set is equipped
with a polarized AC power cord plug (a plug
having one blade wider than the other), or with a
threewire grounding type plug (a plug having a
third pin for grounding).
Follow the instructions below.
Overloading–Do not overload wall outlets,
extension cords or convenience receptacle
beyond their capacity, since this can result in fire
or electric shock.
Object and Liquid Entry–Never push objects of
any kind into the set through openings as they
may touch dangerous voltage points or shart out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on the set.
Attachments–Do not use attachments not
recommended by the manufacturer, as they may
cause hazards.
Cleaning–Unplug the set from the wall outlet
before cleaning or polishing it. Do not use liquid
cleaners or aerosol cleaners. Use a cloth lightly
dampended with water for cleaning the exterior
of the set.
AC 90-250V~?
UNPLUGUNPLUG
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 2

3
Water and Moisture–Do not use powerline
operated sets near water-for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool, etc.
Accessories–Do not place the set on an unstable
cart, stand, tripod, bracket, or table. The set may
fall, causing serious injury to a child or an adult,
and serious damage to the set. Use only a cart
stand, tripod, bracket, or table recommended by the
manufacturer.
Ventilation–The slots and openings in the cabinet
are provided for necessary ventilation. To ensure
reliable operation of the set, and to protect it from
overheating, these slots and openings must never
be blocked or covered.
–Never cover the slots and openings with a cloth
or other materials.
– Never block the slots and openings by placing the
set on a bed, sofa, rug or other similar surface.
Portable Cart Warning–An appliance and cart
combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to
overturn.
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 3

4
–Never place the set in a confined space such as a
bookcase, or built-in cabinet unless proper
ventilation is provided.
Power-Cord Protection–Route the power cord in
order not to be walked on or pinched by items
placed upon or against them, paying particular
attention to the plugs, receptacles, and the point
where the cord exits from the appliance.
–Do not place the set over a radiator or heat
register, or where it is exposed to direct sunlight.
In the normal temperature, if you pour a cold liquid
into a glass, water vapour in the air will condense
on the surface of the glass. This is moisture
condensation. The moisture condensation may
occur inside of VCPs, if used in this condition, it will
cause damage to the head and the tape.
In case of moving the VCP from a cold place to
heated place,
Or the temperature of surroundings goes up due to
room heating switched on.
Or moving the VCP suddenly from air conditioned
room to a place of high temperature of humidity in
summer.
When the moisture condensation occurs inside of
the VCP, NEVER insert the cassette into the
cassette compartment. Remove the cassette, if
loaded, by pressing the STOP/EJECT key. Only
operate the VCP after the moisture condensation
has completely dried out. Normally, it takes about 2
hours.
MOISTURE CONDENSATION
When does the
mositure condensation
occur inside of the
VCP?
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 4

5
Damage Requiring Service–Unplug the set from
the wall outlet and refer servicing to qualified
service personnel under the following conditions:
–When the power cord or plug is damaged or
frayed.
–If liquid has been spilled or objects have fallen
into the set.
–If the set has been exposed to rain or water.
–If the set has been subjected to excessive shock
by being dropped, or the cabinet has been
damaged.
–If the set does not operate normally when
following the operating instructions, adjust only
those controls that are specified in the operating
instructions. Improper adjustment of other controls
may result in damage and will often require
extensive work by a qualified technician to restore
the set to normal operation.
–When the set exhibits a distinct change in
performance, this indicates a need for service.
Servicing–Do not attempt to service the set
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
Replacement of parts–When replacement of
parts is required, be sure the service technician has
used replacement parts specified by the
manufacturer that have the same characteristics as
the original parts. Unauthoized substitutions may
result in fire, electric shock, or other hazards.
Safety Check–Upon completion of any service or
repairs to the set, ask the service technician to
perform routine safety checks (as specified by the
manufacturer) to determine that the set is in safe
operating condition.
SERVICE
SERVICE DEPT
ALL SETS RECEIVE
OUR OK
SAFETY CHECK.
FRAYED OR CUT
AC LINE
CRACKED PLUG
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 5

6
IMPORTANT NOTES
•Audio-visual material may include works of copyright which must NOT be recorded without the authority of the owner of
copyright.
•Note that main voltage is supplied to the unit whenever the main plug is connected to the supply socket.
•To avoid the risk of fire or electric shock, do not expose the unit to rain or moisture.
•Do not attempt to open the cabinet. There are no user-serviceable parts inside. Refer all servicing to qualified service
personnel.
•Keep the unit away from radiators or other sources of heat.
•Do not operate or store the unit close to strong magnetic fields.
•Do not spill liquid of any kind onto the unit. If liquid is accidently spilled onto the unit, immediately remove the main plug
from the supply socket, and consult a qualified service engineer.
•Avoid places subjected to strong vibration.
•Do not place anything heavy on the VCP.
•Use the video cassette player in a horizontal (flat) position only.
•Before operating, remove any paper wrapping which may have been affixed to the player during manufacturing.
DO NOT COVER VENTILATION OPENINGS ON TOP AND SIDES OF THE PLAYER DURING OPERATION.
•When a cassette is inserted into the loading compartment, the power is switched on automatically as long as the power
cord is plugged into an AC outlet. DO NOT force a cassette into the compartment when the power cord is unplugged.
•Keep the player and video cassette away from strong magnetic fields.
•After playing a video cassette, remove it from the player. DO NOT move the player with a cassette in the compartment.
•Store video cassettes in their sleeves or cases and position vertically.
•If a cassette has been subjected to cold temperature, allow it to warm to room temperature before recording or playback.
For your protection, record the model and serial numbers of your
video cassette player here. In the event your player requires
servicing or is stolen, you may need this information. You may
also wish to clip or staple your sales receipt to this page.
Model Number:
Serial Number:
Date Purchased:
Store’s Name and Address:
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 6

7
ACCESSORIES
2.REMOTECONTROL 3.RFCABLE 4.BATTERIES(AAASIZE)
1. INSTRUCTION MANUAL
OWNER'S MANUAL
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 7

INTRODUCTION
8
CONGRATULATIONS on your purchase of a new VHS VCP.
This VCP is an existing, new VCP designed to satisfy all your VHS tape play and recording needs.
And, with proper used and care, your new VCP will offer many year of viewing enjoyment.
Just a few of the feature include.
•NTSC PLAYBACK ON PAL TV:
You can playback not only PAL tape but NTSC tape on PAL TV.
•NTSC 3.58 RECORDING & PLAYBACK
You can record not only PAL/MESECAM but NTSC (3.58).
•QUICK START
Various operation keys operate quickly when each of them is pressed.
•DIGITAL AUTO TRACKING
This VCP plays clear pictures without special operations.
•AC POWER SUPPLY (AC 90-250V~)
•COMPLETE SAFETY DEVICE
When this VCP is not in normal condition, it stops operating automatically for self-protection.
•SELF PICTURE ADJUSTMENT
Since the HEAD DRUM rotates regularly depending on the voltage change or tape condition, the picture is always
stable.
•ENCORE FUNCTION
Press the ENCORE key on the remote control to watch the desired picture once more during playback.
•BUILT-IN WIDE RANGE MODULATOR (CH. 22- CH. 40)
•BUILT-IN MULTI RF OUT MODULATOR (PAL-G/K/I)
•AUTO REPEAT SEARCH FUNCTION
If you press the A.REPEAT key during playback,the tape will be replayback after rewinding .
•2 STEP PICTURE SEARCH
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 8

TABLE OF CONTENTS
9
NOTE: This Video Cassette Player is compatible with any Video Cassette Player bearing the VHS mark. The VCP is
designed to expand your opportunities for home viewing and not for any usage which might violate the copyright laws.
Save the original shipping carton and packing materials; they will come in handy if you ever have to ship your VCP. For
maximum protection, repack the set as it was originally packed at the factory.
DRAWING YOUR ATTENTION.......................................................................................................................................................1
IMPORTANT SAFEGUARDS...........................................................................................................................................................2
INTRODUCTION.............................................................................................................................................................................8
TABLE OF CONTENTS ...................................................................................................................................................................9
IDENTIFICATION..........................................................................................................................................................................10
TO GET STARTED.........................................................................................................................................................................17
VIDEO CHANNEL SETTING..........................................................................................................................................................18
BASIC OPERATION ......................................................................................................................................................................19
SPECIAL OPERATION...................................................................................................................................................................23
PICTURE ADJUSTMENT..............................................................................................................................................................26
VIDEO SYSTEM............................................................................................................................................................................27
RECORDING TV PROGRAMS.......................................................................................................................................................28
BEFORE CALLING SERVICE PERSONNEL.....................................................................................................................................32
SPECIFICATIONS..........................................................................................................................................................................33
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 9

IDENTIFICATION
10
FRONT PANEL
STANDBY KEY
STOP/EJECT KEY
REWINDING/REVIEW KEY
(If this key is pressed in the PLAYBACK mode, the VCP
enters the Reverse Picture Search mode and if pressed in
the STOP mode, tape is rewound at a high speed.)
PLAYBACK KEY
FAST FORWARDING/CUE KEY
(If this key is pressed in the PLAYBACK mode the VCP
enters the Forward Picture Search mode and if pressed
in the STOP mode, tape advances at a high speed.)
RECORD KEY CASSETTE COMPARTMENT
CAUTION:
Standby key won’t be used
to turn on (or off) the main
power.
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 10

IDENTIFICATION (continued)
11
FRONT PANEL DISPLAY
Turned on : color is red
Turned off : color is green
Tape Loading
Playback
Fast forward
“ ” Forward Search
Rewind
“ ”, Reverse Search
Still, Frame advance
Slow
REC Record
Record Pause
, REPEAT Auto Repeat
Stop
LP Tape Speed (Long Play)
K/I RF OUT system
NTSC NTSC Video system
* “ “ means blinking.
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 11

IDENTIFICATION (continued)
12
REAR PANEL
ANT IN TERMINAL
(Connect the TV antenna to
this terminal)
VIDEO IN/OUT JACK
AUDIO IN/OUT
JACK
RF OUT TERMINAL
(Connect to the antenna terminal of the TV receiver
through the RF cable (provided))
AC POWER CORD
S137W- BG/D(LENCO) 0.10.6 9:42 AM ˘ ` 12

13
REMOTE CONTROL OPERATION RANGE
7m
1. Any object between the remote control and VCP
will block the path of beam when it is being used.
Dark walls, direct sunshine or very bright
(incandescent) light will reduce the remote control
sensitivity.
2. Hold the remote control within an angle range of
about 30° from either side of the remote sensor
center as shown.
3. When the remote control is vertical to the remote
Sensor, it will work within about 23 feet (7m) from
the VCP.
4. Point the front of the remote control directly at the
front of the VCP.
30° 30°
S137W- BG/D(LENCO) 0.10.6 10:48 AM ˘ ` 13

14
BATTERY INSTALLATION
1. Remove the battery cover on the reverse side of the remote control.
2. Install 2 batteries (“AAA” size) into the remote control. (Carefully install batteries to match the polarity diagrams)
3 Close the battery cover.
• It is advisable to take batteries out of the remote control when it is not in use for a long time.
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 14

IDENTIFICATION (continued)
15
REMOTE CONTROL BASIC FUNCTIONS
POWER-TURN ON/OFF
RETRACKING
SPEED
PAUSE/STILL FRAME
REWIND/REVIEW
STOP
EJECT
ENCORE
SLOW +/-
AUTO REPEAT
TRACKING –/+
PLAYBACK
FAST FORWARD/CUE
RECORD
TV/VCR(Not used)
RF OUTPUT SELECTION
PAL/NTSC
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 15

16
WHEN YOU USE THE REMOTE CONTROL
• Do not press two keys at the same time.
• It causes the VCP not to operate.
• Do not expose the remote sensor to the sunshine.
• Avoid direct sunshine and strong shock. • Keep the remote control away from dust and moisture.
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 16

TO GET STARTED
17
ANTENNA CONNECTION
1. Remove the Antenna Cable from the TV set. Connect it to the “ANT.IN” terminal of the VCP.
2. Connect one end of the RF cable to the “RF.OUT” terminal of the VCP.
3. Connect the other end to the “ANT.IN” terminal of the TV.
Antenna
TV set
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 17

18
VIDEO CHANNEL SETTING
VCP RF OUT CHANNEL SETTING VCP RF OUT SYSTEM SETTING
The built-in RF converter permits playback of video and
audio recordings through a TV receiver. The signals from
the RF converter are viewed through a vacant channel not
used for broadcasting in your viewing area.
The converter channel of all units is set to UHF channel
36 prior to shipment. Setting your TV receiver to UHF
channel 36 may provide video playback. But, to obtain the
best possible reproduction on your TV receiver, accurate
adjustment to the RF converter output is required.
ŒTurn on your TV.
´Connect the ANT.IN jack on the rear panel of TV by using the RF
cable.
ˇTurn on the VCP to display the “ ” red color indicator on the
panel.
¨Press the “RF OUT CH” key on the remote control.The test
pattern will be transmitted to the UHF 36 CH.
ˆTune the VCP into the test pattern channel by pressing the
Channel key on your TV’s remote control.
ØTune into the channel where the interference channel is the
least.
∏Tune the UHF channel by pressing the “TRK+/-” key until the test
pattern appear.
”Press the “RF OUT CH” key to memory the changed UHF channel.
ŒTurn on your TV.
´Connect the ANT.IN jack on the rear panel of TV by using the RF
cable.
ˇPlayback the tape.
¨Tune the UHF channel 36. If the sound is poor,set the RF OUT
system by pressing the “RF OUT SYS” key on the remote control,
the system will be rotated as follows.
* CAUTION1 : PAL-G is no display.
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 18

19
BASIC OPERATION
CASSETTE LOADING/UNLOADING
LOADING UNLOADING
ŒPush the cassette into the cassette compartment
gently.
(Arrow mark at the top)
´The cassette indicator LED is lit up.
• An inverted cassette cannot be inserted.
PLAY
REW
POWER STOP/ EJECT
• Upon inserting the cassette, the power is on even
if the power is off as long as the AC power cord
is plugged in.
´Pull the cassette out gently.
PLAY
REW
POWERPOWER STOP/ EJECTSTOP/ EJECT
• When you press the STOP/EJECT key even if the
power is off, the cassette will be ejected.
<Front Panel> <Remote Control>
ŒPress the STOP/EJECT key twice on the VCP (in the
PLAYBACK mode) or press EJECT key once on the
remote control. This first press will stop the tape in
any mode except AUTO REPEAT. The second press
will eject the tape. The cassette indicator LED will
be lit out.
S137W- BG/D(LENCO) 0.10.4 10:39 AM ˘ ` 19
