XP15 Heat Pump ◆Up to 16.70 SEER and 9.00 HSPF
Home Comfort Systems
XP15
The quietest heat pump you can buy.*
Compatible with the exclusive Humiditrol®
whole-home dehumidification system—
indoor air quality you can feel

2
Innovation never felt so good.
™
THE QUIETEST HEAT PUMP YOU CAN BUY*
The XP15 not only provides peace and quiet—it also offers peace of mind. The
exclusive Lennox®System Operations Monitor continually monitors system
performance, helping technicians solve problems faster and more accurately.
And, like all Lennox products, the XP15 is built to deliver exceptional reliability
with a promise of quality you can count on—season after season, year after year.
Dave Lennox Signature®Collection XP15 Heat Pump
*Air conditioners/heat pumps have sound ratings established per ARI’s test standard: ARI 270.
Size for size, as a product family, these heat pumps have the lowest published sound ratings
of any major U.S. brand of air conditioning/heat pump equipment.
Patented SilentComfort™
technology provides smooth,
quiet cooling and heating
Efficient design can result in
significant energy savings
Ozone-responsible
R410A meets the EPA’s
(Environmental Protection
Agency) most stringent
environmental guidelines
Lennox®System Operations
Monitor reviews system
performance for additional
peace of mind and faster,
easier servicing
Compatible with the exclusive
Humiditrol®whole-home
dehumidification system
ENERGY STAR®qualified
Efficient Compared to
an older heat pump, the XP15
heat pump can save you
hundreds of dollars each year.
The XP15 heat pump provides
cooling efficiencies of up to 16.70
SEER and heating efficiencies of up
to 9.00 HSPF. The higher the
efficiency rating, the higher your
energy savings. In the case of the
XP15 heat pump, those savings can
translate to hundreds of dollars
each year.
EFFICIENCY RATING
Up to 16.70 SEER (Seasonal
Energy Efficiency Ratio) and
9.00 HSPF (Heating Season
Performance Factor).
WARRANTY**
10-year limited warranty
on the compressor and
all remaining covered
components.
SOUND INTENSITY
Note: Manufacturers’ public ratings. Typical 80 dB air conditioner/heat pump vs. XP15-024 or 030.
It would take 40 XP15s
(running at full speed)
to equal the sound from
one typical heat pump.
**Applies to residential applications only.
See actual warranty certificate for details.
seer
16.00 vs. 10.0 16.00 vs. 13.00
$1200
$1000
$800
$600
$400
0
16.00 SEER XP15 heat pump,
compared to older, less efficient units
5-YEAR COOLING SAVINGS
This chart compares the 5-year savings you can expect from
a 16 SEER heat pump vs. units with lower efficiency ratings.
The regions used to calculate household fuel and utility costs
reflect a cross-section of cities in the U.S. using 2006
Department of Energy national average energy rates. In
addition to geography, cooling costs are based on 3-ton
capacity specifications, with 1,600 cooling hours per year.
Your actual costs will vary depending on the weather, local
fuel rates, systems settings and your personal lifestyle.
$1190
$455

3
Dave Lennox Signature®Collection XP15 Specifications
XP15 024 030 036 042 048 060
SEER Up to 16.70 Up to 15.50 Up to 15.20 Up to 14.00 Up to 15.50 Up to 14.20
HSPF Up to 8.70 Up to 8.50 Up to 9.00 Up to 7.20 Up to 8.70 Up to 8.70
Sound Rating*** – dB 63 63 68 68 70 70
Dimensions HxWxD (in.) 37 x 35-1/2 x 39-2/5 37 x 35-1/2 x 39-2/5 37 x 35-1/2 x 39-2/5 37 x 35-1/2 x 39-2/5 47 x 35-1/2 x 39-2/5 47 x 35-1/2 x 39-2/5
HxWxD (mm) 940 x 902 x 1001 940 x 902 x 1001 940 x 902 x 1001 940 x 902 x 1001 1194 x 902 x 1001 1194 x 902 x 1001
***Preliminary sound data
Note: Due to Lennox’ ongoing commitment to quality, all specifications, ratings and dimensions are subject to change without notice.
SilentComfort™Fan Grill –
Uses patent-pending, vortex-suppression
technology to reduce sound of airflow exiting unit.
Factory-Installed Lennox®System
Operations Monitor – Continually reviews
system performance to allow fast troubleshooting.
Precision-Balanced, Direct-Drive Fan –
Delivers ultra-quiet operation with a
patent-pending fan design.
High-Efficiency Outdoor Coil –
Provides exceptional heat transfer and low air
resistance for high-efficiency operation.
Dependable Scroll Compressor
with SilentComfort™Technology –
Provides smooth, efficient and reliable operation.
Durable Steel Cabinet –
Made to last with superior high-quality, pre-painted steel and
textured finish. Tested to withstand the harshest environments.
OUTSTANDING FEATURES FOR EXCEPTIONAL COMFORT AND EFFICIENCY
XP15
Up to 16.70 SEER
and 9.00 HSPF
The quietest heat
pump you can buy.*
13.0-16.70
21.013.0
THIS MODEL
Quality you can trust.
Constructed of heavy-gauge, pre-painted
steel and tested in the most extreme
environments to ensure maximum durability.
Proper sizing and installation of equipment
is critical to achieve optimal performance.
Split system air conditioners and heat
pumps must be matched with appropriate
coil components to meet ENERGY STAR®
criteria. Ask your Lennox dealer for details,
or visit www.energystar.gov.
Lennox is proud of the
fact that these products
have earned the Good
Housekeeping Seal.

© Lennox Industries Inc. 2008
Visit us at www.lennox.com, or contact us at 1-800-9-LENNOX. PC53871(14W57) XP15 04/08
1Air conditioner or heat pump
2Thermostat
3Furnace or air handler
4Filtration device
5Germicidal light
6Indoor coil
7Humidifier
8HEPA bypass filtration system
9Energy recovery ventilator
 Supply duct
 Return duct
 Dehumidifier system
 Residential generator
CUSTOMIZE YOUR COMFORT
Lennox®heating, cooling and indoor air quality products are designed to
provide efficient, economical comfort—not only as individual units, but also
together as an integrated system. This combined network of products delivers
on every comfort count, from consistent temperatures and balanced humidity to improved indoor air quality. Lennox
also offers a line of residential generators, which provide safe, reliable standby power in the event of outages.
DEALERS YOU CAN COUNT ON
Choosing the right dealer for your home’s heating, cooling and air quality needs is every bit as important as choosing the
right brand. We think you’ll agree our independent dealers are a big reason you can count on quality customer service
whenever you call. Your Lennox dealer’s dedication to quality shows in his knowledge, training and expertise in designing
the right system for your home, installing it properly and keeping it running perfectly for many years to come.
