Lennox ZHA Series Installation and operation manual

Page 1 ©2014.
Corp. 1403-L4
Revised 05/2020
ZHA SERIES
Service Literature 7.5 to 10 ton
26.3 to 35.2 kW
ZHA092 through 120
The ZHA commercial heat pump is available in 7.5, 8.5 and
10 ton capacities. The refrigerant systems utilize two com
pressors, two reversing valves, two accumulators, and
other parts common to a heat pump. Optional auxiliary
electric heat is factory or field installed. Electric heat oper
ates in single or multiple stages depending on the kW input
size. 7.5kW through 60kW heat sections are available.
Units are designed to accept any of several different energy
management thermostat control systems with minimum field
wiring.
Information contained in this manual is intended for use by
qualified service technicians only. All specifications are sub
ject to change. Procedures outlined in this manual are pre
sented as a recommendation only and do not supersede or
replace local or state codes.
If the unit must be lifted for service, rig unit by attaching four
cables to the holes located in the unit base rail (two holes at
each corner). Refer to the installation instructions for the proper
rigging technique.
WARNING
Improper installation, adjustment, alteration, ser
vice or maintenance can cause property damage,
personal injury or loss of life. Installation and ser
vice must be performed by a licensed professional
HVAC installer or equivalent service agency.
CAUTION
Electrostatic discharge can affect electronic
components. Take precautions during unit instal
lation and service to protect the unit's electronic
controls. Precautions will help to avoid control
exposure to electrostatic discharge by putting
the furnace, the control and the technician at the
same electrostatic potential. Neutralize electro
static charge by touching hand and all tools on an
unpainted unit surface, such as the blower deck,
before performing any service procedure.
ELECTROSTATIC DISCHARGE (ESD)
Precautions and Procedures
CAUTION
As with any mechanical equipment, contact with
sharp sheet metal edges can result in personal in
jury. Take care while handling this equipment and
wear gloves and protective clothing.
WARNING
Electric shock hazard. Can cause injury
or death. Before attempting to perform
any service or maintenance, turn the
electrical power to unit OFF at discon
nect switch(es). Unit may have multiple
power supplies.
Options / Accessories Page 2.......................
Specifications Page 5...............................
Blower Data Page 7................................
Electrical Data Page 11.............................
Parts Arrangement Page 15.........................
I- Unit Components Page 16.......................
II- Placement and Installation Page 24...............
III- Start-Up Page 24...............................
IV- Charging Page 25..............................
V- System Service Checks Page 28.................
VI- Maintenance Page 29...........................
VII- Accessories Page 31............................
VIII-Wiring Diagrams Page 36........................

Page 2
OPTIONS / ACCESSORIES
Item Description Model
Number
Catalog
Number
Unit Model No
092 102 120
COOLING SYSTEM
Condensate Drain Trap PVC - C1TRAP20AD2 76W26 XXX
Copper - C1TRAP10AD2 76W27 XXX
Corrosion Protection Factory O O O
Drain Pan Overow Switch Z1SNSR90A1 99W59 XXX
Low Ambient Kit Z1SNSR33B-1 10Z34 XXX
Refrigerant Type R-410A O O O
BLOWER - SUPPLY AIR
Blower Option CAV (Constant Air Volume) Factory O O O
MSAV (Multi-Stage Air Volume) Factory O O O
Blower Motors Belt Drive - 2 hp Factory O O O
Belt Drive - 3 hp Factory O O O
Belt Drive - 5 hp Factory O O O
Drive Kits
See Blower Data Tables for selection
Kit #1 590-890 rpm Factory O O O
Kit #2 800-1105 rpm Factory O O O
Kit #3 795-1195 rpm Factory O O O
Kit #4 730-970 rpm Factory O O O
Kit #5 940-1200 rpm Factory O O O
Kit #6 1015-1300 rpm Factory O O O
Kit #10 900-1135 rpm Factory O O O
Kit #11 1040-1315 rpm Factory O O O
Kit #12 1125-1425 rpm Factory O O O
CABINET
Coil/Hail Guards Z1GARD10B-1 10Y09 XXX
CONTROLS
L Connection® Building Automation System - - - X X X
BACnet®K0CTRL31B-1 96W15 OX OX OX
BACnet® Thermostat with Display K0SNSR01FF1 97W23 XXX
BACnet® Thermostat without Display K0SNSR00FF1 97W24 XXX
Novar® 2051 K0CTRL30B-1 96W12 OX OX OX
Plenum Cable (75 ft.) K0MISC00FF1 97W25 XXX
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed

Page 3
OPTIONS / ACCESSORIES
Item Description Model
Number
Catalog
Number
Unit Model No
092 102 120
INDOOR AIR QUALITY
Air Filters
Healthy Climate®High Efciency Air Filters
20 x 24 x 2 in. (Order 4 per unit)
MERV 8 - Z1FLTR15B-1 11H62 XXX
MERV 13 - Z1FLTR40B-1 11H63 XXX
Replacement Media Filter With Metal Mesh
Frame (includes non-pleated lter media)
C1FLTR30B-1- Y3063 XXX
Indoor Air Quality (CO2) Sensors
Sensor - Wall-mount, off-white plastic cover with LCD display C0SNSR50AE1L 77N39 XXX
Sensor - Wall-mount, off-white plastic cover, no display C0SNSR52AE1L 87N53 XXX
Sensor - Black plastic case with LCD display, rated for plenum
mounting
C0SNSR51AE1L 87N52 XXX
Sensor - Wall-mount, black plastic case, no display, rated for
plenum mounting
C0MISC19AE1 87N54 XXX
CO2 Sensor Duct Mounting Kit - for downow applications C0MISC19AE1- 85L43 XXX
Aspiration Box - for duct mounting non-plenum rated CO2sensors
(87N53 or 77N39)
C0MISC16AE1- 90N43 XXX
ELECTRICAL
Voltage 60 hz 208/230V - 3 phase Factory O O O
460V - 3 phase Factory O O O
575V - 3 phase Factory O O O
Bottom Power Entry Kit Z1PEKT01B-1 11H66 XXX
ELECTRIC HEAT
7.5 kW 208/230V-3ph - Z1EHO075B-1Y 10Y97 X X
460V-3ph - Z1EHO075B-1G 10Y98 X X
575V-3ph - Z1EHO075B-1J 10Y99 X X
15 kW 208/230V-3ph - Z1EHO150B-1Y 10Z01 XXX
460V-3ph - Z1EHO150B-1G 10Z03 XXX
575V-3ph - Z1EHO150B-1J 10Z04 XXX
22.5 kW 208/230V-3ph - Z1EHO225B-1Y 10Z05 XXX
460V-3ph - Z1EHO225B-1G 10Z06 XXX
575V-3ph - Z1EHO225B-1J 10Z07 XXX
30 kW 208/230V-3ph - Z1EHO300B-1Y 10Z08 XXX
460V-3ph - Z1EHO300B-1G 10Z09 XXX
575V-3ph - Z1EHO300B-1J 10Z10 XXX
45 kW 208/230V-3ph - Z1EHO450B-1Y 10Z11 XXX
460V-3ph - Z1EHO450B-1G 10Z12 XXX
575V-3ph - Z1EHO450B-1J 10Z13 XXX
60 kW 208/230V-3ph - Z1EHO600B-1Y 10Z14 X
460V-3ph - Z1EHO600B-1G 10Z15 X
575V-3ph - Z1EHO600B-1J 10Z16 X
ELECTRIC HEAT ACCESSORIES
Unit Fuse Block (required) - See Electrical/Electric Heat Tables for Selection XXX
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed

Page 4
OPTIONS / ACCESSORIES
Item Description Model
Number
Catalog
Number
Unit Model No
092 102 120
ECONOMIZER
Standard Economizer (Not for Title 24)
Standard Downow Economizer with Single Temperature Control -
With Barometric Relief Dampers and Air Hoods
Z1ECON30B-1 10Z29 OX OX OX
Standard Horizontal Economizer with Single Temperature Control - With
Barometric Relief Dampers and Air Hoods
Z1ECON16B-1 11G98 XXX
Standard Economizer Controls (Not for Title 24)
Single Enthalpy Control C1SNSR64FF1 53W64 OX OX OX
Differential Enthalpy Control (order 2) C1SNSR64FF1 53W64 XXX
High Performance Economizer (Approved for California Title 24 Building Standards)
High Performance Downow Economizer with Single Temperature
Control - With Barometric Relief Dampers and Air Hoods
Z1ECON32B-1 12B44 OX OX OX
Economizer Controls (Not for Title 24)
Single Enthalpy Control C1SNSR61FF1 11G21 OX OX OX
Differential Enthalpy Control (order 2) C1SNSR61FF1 11G21 XXX
Horizontal Low Prole Barometric Relief Dampers With Exhaust Hood
Horizontal Low Prole Barometric Relief Dampers With Exhaust Hood LAGEDH03/15 53K04 XXX
OUTDOOR AIR
Outdoor Air Dampers
Motorized Dampers with outdoor air hood Z1DAMP20B-1 10Z33 XXX
Manual Dampers with outdoor air hood Z1DAMP10B-1 10Z32 XXX
POWER EXHAUST
Standard Static (Downow) 208/230V-3ph - Z1PWRE10B-1Y 10Z70 XXX
460V-3ph - Z1PWRE10B-1G 10Z71 XXX
Standard Static (Horizontal) 208/230V-3ph - Z1PWRE15A-1P 24E01 XXX
460V-3ph - Z1PWRE15A-1G 28E01 XXX
575V Transformer Kit 575V-3ph - Z1TRFM20A-1J 59E02 XXX
NOTE - Order 575V Transformer Kit with 208/230V Power Exhaust Fan for 575V applications. Order two kits for downow models, order one kit for horizontal models.
ROOF CURBS
Hybrid Roof Curbs, Downow
8 in. height Z1CURB40B-1 10Z25 XXX
14 in. height Z1CURB41B-1 10Z26 XXX
18 in. height Z1CURB42B-1 10Z27 XXX
24 in. height Z1CURB43B-1 10Z28 XXX
CEILING DIFFUSERS
Step-Down - Order one RTD11-95 29G04 X
RTD11-135 29G05 X X
Flush - Order one FD11-95 29G08 X
FD11-135 29G09 X X
NOTE - Ceiling Diffuser Transitions are not furnished and must be eld fabricated.
NOTE - Catalog and model numbers shown are for ordering eld installed accessories.
OX - Congure To Order (Factory Installed) or Field Installed
O = Congure To Order (Factory Installed)
X = Field Installed

Page 5
SPECIFICATIONS 7.5 - 8.5 TON
General Data Nominal Tonnage 7.5 Ton 7.5 Ton 8.5 Ton 8.5 Ton
Model Number ZHA092S4B ZHA092S4M ZHA102S4B ZHA102S4M
Efciency Type Standard Standard Standard Standard
Blower Type Constant Air
Volume (CAV)
MSAV (Multi-Stage
Air Volume)
Constant Air
Volume (CAV)
MSAV (Multi-Stage
Air Volume)
Cooling
Performance
Gross Cooling Capacity - Btuh 89,400 89,400 103,200 103,200
1 Net Cooling Capacity - Btuh 87,000 87,000 100,000 100,000
AHRI Rated Air Flow - cfm 2800 2800 3150 3150
Total Unit Power - kW 7.9 7.9 9.1 9.1
1 EER (Btuh/Watt) 11.0 11.0 11.0 11.0
1 IEER (Btuh/Watt) 12.2 12.5 12.2 12.5
Refrigerant Type R-410A R-410A R-410A R-410A
Refrigerant Charge Furnished Circuit 1 11 lbs. 12 oz. 11 lbs. 12 oz. 11 lbs. 10 oz. 11 lbs. 10 oz.
Circuit 2 10 lbs. 8 oz. 10 lbs. 8 oz. 9 lbs. 14 oz. 9 lbs. 14 oz.
Heating
Performance
1 Total High Heat Capacity - Btuh 89,000 89,000 100,000 100,000
Total Unit Power - kW 7.9 7.9 8.9 8.9
1 C.O.P. 3.3 3.3 3.3 3.3
1 Total Low Heat Capacity - Btuh 53,000 53,000 55,000 55000
Total Unit Power (kW) 6.9 6.9 7.2 7.2
1 C.O.P. 2.25 2.25 2.25 2.25
Electric Heat Available - See page 3 7.5,15,22.5,30 & 45 kW
Compressor Type (number) Scroll (2) Scroll (2) Scroll (2) Scroll (2)
Outdoor
Coils
Net face area (total) - sq. ft. 26.2 26.2 26.2 26.2
Tube diameter - in. 3/8 3/8 3/8 3/8
Number of rows 2222
Fins per inch 20 20 20 20
Expansion device type Balance port TXV, removable head
Outdoor
Coil Fans
Motor - (No.) hp (2) 1/3 (2) 1/3 (2) 1/3 (2) 1/3
Motor rpm 1075 1075 1075 1075
Total Motor watts 650 650 650 650
Diameter - (No.) in. (2) 24 (2) 24 (2) 24 (2) 24
Number of blades 3 3 3 3
Total Air volume - cfm 8800 8800 8800 8800
Indoor
Coils
Net face area (total) - sq. ft. 12.8 12.8 12.8 12.8
Tube diameter - in. 3/8 3/8 3/8 3/8
Number of rows 3 3 4 4
Fins per inch 14 14 14 14
Drain connection - Number and size (1) 1 in. NPT coupling
Expansion device type Refrigerant Metering Orice (RFC)
2Indoor
Blower and
Drive
Selection
Nominal motor output 2 hp, 3 hp, 5 hp
Maximum usable motor output
(US Only)
2.3 hp, 3.45 hp, 5.75 hp
Motor - Drive kit number 2 hp
Kit 1 590-890 rpm
Kit 2 800-1105 rpm
Kit 3 795-1195 rpm
3 hp
Kit 4 730-970 rpm
Kit 5 940-1200 rpm
Kit 6 1015-1300 rpm
5 hp
Kit 10 900-1135 rpm
Kit 11 1040-1315 rpm
Kit 12 1125-1425 rpm
Blower wheel nominal diameter x width - in. (1) 15 X 15 (1) 15 X 15 (1) 15 X 15 (1) 15 X 15
Filters Type of lter Disposable
Number and size - in. (4) 20 x 24 x 2
Electrical characteristics 208/230V, 460V or 575V - 60 hertz - 3 phase
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1 AHRI Certied to AHRI Standard 340/360:
Cooling Ratings - 95°F outdoor air temperature and 80°F db/67°F wb entering indoor coil air.
High Temperature Heating Ratings - 47°F db/43°F wb outdoor air temperature and 70°F entering indoor coil air.
Low Temperature Heating Ratings - 17°F db/15°F wb outdoor air temperature and 70°F entering indoor coil air.
2 Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of
motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within
the service factor limitations outlined on the motor nameplate.
NOTE – Units equipped with MSAV® (Multi-Stage Air Volume) option are limited to a motor service factor of 1.0.

Page 6
SPECIFICATIONS 10 TON
General Data Nominal Tonnage 10 Ton 10 Ton
Model Number ZHA120S4B ZHA120S4M
Efciency Type Standard Standard
Blower Type Constant Air Volume (CAV) MSAV (Multi-Stage Air Volume)
Cooling
Performance
Gross Cooling Capacity - Btuh 121,900 121,900
1 Net Cooling Capacity - Btuh 118,000 118,000
AHRI Rated Air Flow - cfm 3600 3600
Total Unit Power - kW 10.7 10.7
1 EER (Btuh/Watt) 11.0 11.0
1 IEER (Btuh/Watt) 11.3 12.5
Refrigerant Type R-410A R-410A
Refrigerant Charge Furnished Circuit 1 16 lbs. 0 oz. 16 lbs. 0 oz.
Circuit 2 14 lbs. 12 oz. 14 lbs. 12 oz.
Heating
Performance
1 Total High Heat Capacity - Btuh 116,000 116,000
Total Unit Power - kW 10.3 10.3
1 C.O.P. 3.3 3.3
1 Total Low Heat Capacity - Btuh 70,000 70,000
Total Unit Power (kW) 9.1 9.1
1 C.O.P. 2.25 2.25
Electric Heat Available - See page 3 15, 22.5, 30, 45 and 60 KW
Compressor Type (number) Scroll (2) Scroll (2)
Outdoor
Coils
Net face area (total) - sq. ft. 26.2 26.2
Tube diameter - in. 3/8 3/8
Number of rows 3 3
Fins per inch 20 20
Expansion device type Balance port TXV, removable head
Outdoor
Coil Fans
Motor - (No.) hp (2) 1/2 (2) 1/2
Motor rpm 1075 1075
Total Motor watts 960 960
Diameter - (No.) in. (2) 24 (2) 24
Number of blades 3 3
Total Air volume - cfm 9000 9000
Indoor
Coils
Net face area (total) - sq. ft. 13.54 13.54
Tube diameter - in. 3/8 3/8
Number of rows 4 4
Fins per inch 14 14
Drain connection - Number and size (1) 1 in. NPT coupling
Expansion device type Refrigerant Metering Orice (RFC)
2Indoor
Blower and
Drive
Selection
Nominal motor output 2 hp, 3 hp, 5 hp
Maximum usable motor output
(US Only)
2.3 hp, 3.45 hp, 5.75 hp
Motor - Drive kit number 2 hp
Kit 1 590-890 rpm
Kit 2 800-1105 rpm
Kit 3 795-1195 rpm
3 hp
Kit 4 730-970 rpm
Kit 5 940-1200 rpm
Kit 6 1015-1300 rpm
5 hp
Kit 10 900-1135 rpm
Kit 11 1040-1315 rpm
Kit 12 1125-1425 rpm
Blower wheel nominal diameter x width - in. (1) 15 X 15 (1) 15 X 15
Filters Type of lter Disposable
Number and size - in. (4) 20 x 24 x 2
Electrical characteristics 208/230V, 460V or 575V - 60 hertz - 3 phase
NOTE - Net capacity includes evaporator blower motor heat deduction. Gross capacity does not include evaporator blower motor heat deduction.
1 AHRI Certied to AHRI Standard 340/360:
Cooling Ratings - 95°F outdoor air temperature and 80°F db/67°F wb entering indoor coil air.
High Temperature Heating Ratings - 47°F db/43°F wb outdoor air temperature and 70°F entering indoor coil air.
Low Temperature Heating Ratings - 17°F db/15°F wb outdoor air temperature and 70°F entering indoor coil air.
2 Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable output of
motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep within
the service factor limitations outlined on the motor nameplate.
NOTE – Units equipped with MSAV® (Multi-Stage Air Volume) option are limited to a motor service factor of 1.0.

Page 7
BLOWER DATA
092S STANDARD EFFICIENCY BELT DRIVE BLOWER − BASE UNIT
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY (NO HEAT SECTION) WITH DRY INDOOR COIL AND AIR
FILTERS IN PLACE. FOR ALL UNITS ADD:
1 − Wet indoor coil air resistance of selected unit.
2 − Any factory installed options air resistance (heat section, economizer, etc.)
3 − Any eld installed accessories air resistance (duct resistance, diffuser, etc.)
Then determine from blower table blower motor output required.
See page 9 for blower motors and drives.
See page 9 for wet coil and option/accessory air resistance data.
MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT (Maximum Static Pressure - 2.0 in. w.g.):
7.5 kW, 15 kW, 22.5 kW - 2065 cfm
30 kW - 2250 cfm
45 kW - 3000 cfm
Total
Air
Volume
cfm
Total Static Pressure − in. w.g.
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0 2.2 2.4 2.6
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1750 494 0.11 562 0.34 632 0.56 702 0.74 771 0.85 838 0.96 902 1.07 961 1.19 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
2000 514 0.26 581 0.49 650 0.70 719 0.87 786 0.98 852 1.09 915 1.20 972 1.32 1026 1.47 1076 1.65 - - - - - - - - - - - - - - - - - -
2250 533 0.41 599 0.62 667 0.82 735 0.99 802 1.10 866 1.21 928 1.33 984 1.46 1037 1.63 1085 1.81 1132 2.01 1178 2.21 1226 2.43
2500 553 0.55 619 0.76 685 0.95 753 1.10 818 1.22 881 1.34 942 1.47 997 1.62 1048 1.80 1096 1.99 1142 2.20 1188 2.41 1237 2.64
2750 573 0.70 638 0.90 705 1.08 771 1.22 835 1.35 897 1.49 957 1.63 1011 1.80 1061 1.99 1108 2.19 1154 2.41 1200 2.63 1249 2.87
3000 594 0.85 659 1.05 725 1.22 791 1.36 853 1.50 915 1.65 973 1.81 1026 1.99 1075 2.20 1121 2.42 1167 2.64 1213 2.87 1262 3.12
3250 617 1.01 682 1.20 747 1.37 812 1.52 873 1.67 934 1.83 990 2.01 1042 2.21 1089 2.43 1135 2.66 1181 2.90 1228 3.13 1277 3.38
3500 640 1.17 706 1.36 771 1.53 834 1.70 895 1.86 954 2.03 1008 2.23 1058 2.46 1105 2.69 1150 2.93 1196 3.17 1243 3.41 1293 3.65
3750 665 1.34 731 1.54 796 1.72 857 1.89 917 2.07 975 2.26 1027 2.48 1076 2.72 1121 2.97 1166 3.22 1212 3.46 1261 3.71 1311 3.96
4000 692 1.54 758 1.75 822 1.93 882 2.11 940 2.30 996 2.51 1047 2.76 1094 3.02 1139 3.27 1184 3.52 1230 3.77 1280 4.03 1330 4.29
4250 722 1.76 787 1.97 849 2.15 908 2.35 965 2.56 1018 2.79 1067 3.06 1113 3.33 1157 3.59 1202 3.85 1250 4.11 1300 4.38 1352 4.65

Page 8
BLOWER DATA
102 AND 120S STANDARD EFFICIENCY BELT DRIVE BLOWER − BASE UNIT
BLOWER TABLE INCLUDES RESISTANCE FOR BASE UNIT ONLY (NO HEAT SECTION) WITH DRY INDOOR COIL AND AIR
FILTERS IN PLACE. FOR ALL UNITS ADD:
1 − Wet indoor coil air resistance of selected unit.
2 − Any factory installed options air resistance (heat section, economizer, etc.)
3 − Any eld installed accessories air resistance (duct resistance, diffuser, etc.)
Then determine from blower table blower motor output required.
See page 9 for blower motors and drives.
See page 9 for wet coil and option/accessory air resistance data.
MINIMUM AIR VOLUME REQUIRED FOR USE WITH OPTIONAL ELECTRIC HEAT (Maximum Static Pressure - 2.0 in. w.g.)
15 kW, 22.5 kW- 2065 cfm
30 kW - 2250 cfm
45 kW - 3000 cfm
60 kW - 4000 cfm
Total
Air
Volume
cfm
Total Static Pressure − in. w.g.
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2 2.2 2.4 2.6
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2000 542 0.43 602 0.60 664 0.75 732 0.89 802 1.02 869 1.15 927 1.27 979 1.41 1029 1.57 1079 1.75 1129 1.95 1179 2.15 1230 2.37
2250 560 0.55 619 0.71 681 0.86 748 1.00 817 1.14 882 1.27 939 1.41 991 1.57 1041 1.74 1090 1.93 1140 2.13 1190 2.35 1241 2.57
2500 579 0.68 637 0.83 699 0.98 766 1.12 834 1.26 897 1.41 953 1.57 1005 1.74 1054 1.92 1103 2.12 1152 2.33 1202 2.55 1254 2.79
2750 599 0.81 657 0.97 719 1.11 785 1.25 851 1.41 913 1.57 968 1.74 1020 1.93 1068 2.13 1116 2.34 1165 2.56 1215 2.78 1268 3.01
3000 620 0.95 678 1.11 741 1.25 806 1.40 870 1.58 930 1.75 985 1.94 1036 2.14 1084 2.36 1131 2.58 1180 2.80 1230 3.02 1283 3.26
3250 643 1.10 701 1.26 764 1.41 828 1.57 891 1.76 950 1.95 1003 2.16 1053 2.38 1100 2.61 1148 2.83 1196 3.06 1246 3.29 1299 3.52
3500 667 1.26 726 1.43 788 1.58 851 1.77 913 1.97 970 2.17 1023 2.41 1071 2.65 1118 2.88 1165 3.11 1213 3.33 1264 3.57 1317 3.81
3750 693 1.44 752 1.61 813 1.78 876 1.98 936 2.20 992 2.43 1043 2.68 1091 2.93 1137 3.17 1183 3.40 1232 3.64 1284 3.88 1338 4.13
4000 720 1.65 779 1.82 840 2.00 902 2.22 961 2.46 1015 2.71 1064 2.98 1111 3.24 1156 3.48 1203 3.72 1253 3.96 1305 4.22 1359 4.48
4250 748 1.86 807 2.04 868 2.24 929 2.48 986 2.75 1038 3.02 1086 3.30 1132 3.57 1177 3.81 1224 4.05 1274 4.31 1327 4.57 1382 4.85
4500 778 2.09 837 2.28 898 2.51 957 2.78 1012 3.07 1062 3.37 1108 3.65 1154 3.92 1199 4.17 1247 4.41 1297 4.67 1350 4.94 1405 5.22
4750 809 2.34 868 2.56 929 2.82 986 3.12 1038 3.43 1087 3.74 1132 4.03 1177 4.29 1223 4.54 1270 4.79 1321 5.04 1374 5.31 1428 5.58
5000 841 2.62 901 2.87 960 3.17 1015 3.50 1065 3.83 1112 4.14 1157 4.43 1201 4.69 1247 4.94 1295 5.18 1345 5.42 1398 5.68 - - - - - -
5250 875 2.93 935 3.23 992 3.56 1044 3.91 1092 4.26 1138 4.57 1182 4.85 1226 5.10 1272 5.34 1320 5.57 - - - - - - - - - - - - - - - - - -
5500 911 3.30 969 3.63 1024 4.00 1074 4.37 1120 4.71 1165 5.02 1208 5.29 1253 5.53 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
5750 948 3.71 1004 4.08 1056 4.48 1104 4.85 1148 5.19 1192 5.49 1235 5.74 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
6000 985 4.18 1039 4.59 1088 5.00 1134 5.37 1177 5.69 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
6250 1022 4.70 1073 5.14 1120 5.54 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Page 9
BLOWER DATA
FACTORY INSTALLED BELT DRIVE KIT SPECIFICATIONS
Nominal
hp
Maximum
hp
Drive Kit Number RPM Range
22.3 1590 - 890
22.3 2800 - 1105
22.3 3 795 - 1195
3 3.45 4730 - 970
3 3.45 5 940 - 1200
3 3.45 6 1015 - 1300
5 5.75 10 900 - 1135
5 5.75 11 1040 - 1315
5 5.75 12 1125 - 1425
NOTE - Using total air volume and system static pressure requirements determine from blower performance tables rpm and motor output required. Maximum usable
output of motors furnished are shown. In Canada, nominal motor output is also maximum usable motor output. If motors of comparable output are used, be sure to keep
within the service factor limitations outlined on the motor nameplate.
NOTE – Units equipped with MSAV® (Multi-Stage Air Volume) option are limited to a motor service factor of 1.0.
POWER EXHAUST FAN PERFORMANCE
Return Air System Static Pressure Air Volume Exhausted
in. w.g. cfm
03575
0.05 3405
0.10 3550
0.15 3245
0.20 3115
0.25 3020
0.30 2900
0.35 2785
FACTORY INSTALLED OPTIONS/FIELD INSTALLED ACCESSORY AIR RESISTANCE - in. w.g.
Air
Volume
cfm
Wet Indoor Coil Electric
Heat Economizer
Filters
MERV 8 MERV 13
092 102, 120
1750 0.03 0.04 0.03 0.03 0.01 0.03
2000 0.04 0.05 0.03 0.05 0.01 0.03
2250 0.05 0.06 0.04 0.06 0.01 0.04
2500 0.05 0.07 0.04 0.08 0.01 0.05
2750 0.06 0.08 0.05 0.09 0.02 0.05
3000 0.07 0.09 0.06 0.11 0.02 0.06
3250 0.08 0.10 0.06 0.13 0.02 0.06
3500 0.09 0.11 0.09 0.15 0.03 0.07
3750 0.10 0.13 0.09 0.17 0.03 0.08
4000 0.11 0.14 0.09 0.19 0.04 0.08
4250 0.13 0.15 0.13 0.21 0.04 0.09
4500 0.14 0.17 0.14 0.24 0.04 0.09
4750 0.15 0.18 0.17 0.26 0.05 0.10
5000 0.16 0.20 0.20 0.29 0.06 0.10
5250 0.17 0.22 0.22 0.32 0.06 0.11
5500 0.19 0.23 0.25 0.34 0.07 0.12
5750 0.20 0.25 0.31 0.37 0.07 0.12
6000 0.22 0.27 0.33 0.40 0.08 0.13

Page 10
BLOWER DATA
CEILING DIFFUSERS AIR RESISTANCE - in. w.g.
RTD11 Step-Down Diffuser FD11 Flush
Diffuser
Unit Size Air Volume
cfm 2 Ends Open 1 Side, 2 Ends Open
All Ends & Sides
Open
092 Models
2400 0.21 0.18 0.15 0.14
2600 0.24 0.21 0.18 0.17
2800 0.27 0.24 0.21 0.20
3000 0.32 0.29 0.25 0.25
3200 0.41 0.37 0.32 0.31
3400 0.50 0.45 0.39 0.37
3600 0.61 0.54 0.48 0.44
3800 0.73 0.63 0.57 0.51
102 & 120 Models
3600 0.36 0.28 0.23 0.15
3800 0.40 0.32 0.26 0.18
4000 0.44 0.36 0.29 0.21
4200 0.49 0.40 0.33 0.24
4400 0.54 0.44 0.37 0.27
4600 0.60 0.49 0.42 0.31
4800 0.65 0.53 0.46 0.35
5000 0.69 0.58 0.50 0.39
5200 0.75 0.62 0.54 0.43
CEILING DIFFUSER AIR THROW DATA
Model No. Air Volume
1 Effective Throw Range
RTD11 Step-Down FD11 Flush
cfm ft. ft.
092 Models
2600 24 - 29 19 - 24
2800 25 - 30 20 - 28
3000 27 - 33 21 - 29
3200 28 - 35 22 - 29
3400 30 - 37 22 - 30
102, 120
Models
3600 25 - 33 22 - 29
3800 27 - 35 22 - 30
4000 29- 37 24 - 33
4200 32 - 40 26 - 35
4400 34 - 42 28 - 37
1 Throw is the horizontal or vertical distance an air stream travels on leaving the outlet or diffuser
before the maximum velocity is reduced to 50 ft. per minute. Four sides open.
