Lennox 10T50 Assembly instructions

507240-03
1/2018
Supersedes 6/2017
iComfort®Equipment
Interface Module
Installation and Setup
Guide
(10T50)

2
Shipping and Packing List.................................................................2
Application and Requirements..........................................................2
Indoor Transformer Requirements................................................... 2
Equipment ....................................................................................... 2
Installation...........................................................................................5
Conguration Setup...........................................................................5
EIM, 24VAC Furnace and iComfort Heat Pump .............................. 5
EIM, iComfort Furnace and 24VAC Heat Pump .............................. 5
Unit Type Jumpers........................................................................... 6
Heat Stage Jumper Positions .......................................................... 6
Air Temperature Sensor Connections.............................................. 6
iComfort Terminal Connections ....................................................... 6
Heat Stage Jumpers........................................................................ 7
Dual-Fuel Terminal Connections ..................................................... 7
Conventional Terminal Connections................................................ 8
LED Indicators ................................................................................. 8
Soft Disable ..................................................................................... 8
iComfort Wi-Fi Commissioning (Conventional Outdoor Unit) .......... 9
iComfort S30 Commissioning (Conventional Outdoor Unit) ............ 9
Operating Environment Specications ............................................9
Unit Dimensions ...............................................................................10
Duel-Fuel Operations .......................................................................10
Field Wiring ....................................................................................... 11
Alert Codes and Troubleshooting...................................................17
