Lenovo 4014HB6 User manual

Product number
4014-HB6
First Edition ( 2010)
LENOVO products, data, computer software, and services have been developed exclusively at private expense and
are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted
rights to use, reproduction and disclosure.
LIMITED AND RESTRICTED RIGHTS NOTICE: IF products, data, computer software, or services are delivered
pursuant a General Services Administration "GSA" contract, use, reproduction, or disclosure is subject to
restrictions set forth in Contract No. GS-35F-05925.
CopyrightLenovo2010. i
05

Contents
Safety information ……………………………………………………………………iii
Chapter 1. Getting started ……………………………….…………………………1-1
Shipping contents ………………………………………………………………………………………..…1-1
Product overview ………………………………………………………………………………………..… 1-2
Types of adjustments ……………………………………………………………………………………... 1-2
User controls ……………………………………………………………………………………………… 1-3
Cable lock slot ……………………………………………………………………………………………. 1-4
Setting up your monitor ……………………………………………………………………………………... 1-4
Connecting and turning on your monitor ………………………………………………………………… 1-4
Registering your option ……………………………………………………………………………………... 1-9
Chapter 2. Adjusting and using your monitor…………………………………………..2-1
Comfort and accessibility …………………………………………………………………………………… 2-1
Arranging your work area………………………………………………………………………………... 2-1
Quick tips for healthy work habits……………………………………………………………………….. 2-2
Accessibility information ………………………………………………………………………………… 2-2
Adjusting your monitor image……………………………………………………………………………… 2-3
Using the direct access controls………………………………………………………………………….. 2-3
Using the On-Screen Display (OSD) controls…………………………………………………………… 2-3
Using the ThinkVision Duo (TVD) software control ………………………….………………………… 2-4
Selecting a supported display mode ……………………………………………………………………….... 2-10
Understanding power management…………………………………………………………………………. 2-10
Caring for your monitor ………………………………………………………………………………………2-11
Detaching the monitor stand………………………………………………………………………………… 2-11
Chapter 3. Reference information ………………………………………………..……..3-1
Monitor specifications ………………………………………………………………………………………..3-1
Troubleshooting ………………………………………………………………………………………………3-2
Manual Image setup ………………………………………………………………………………………. 3-3
Manually installing the monitor driver …………………………………………………………………… 3-4
Service information ……………………………………………………………………………………….. 3-9
Appendix A. Service and Support …………………………………………..…………...A-1
Online technical support ………………………………………………………………………..……………. A-1
Telephone technical support ………………………………………………………………………..………... A-1
Worldwide telephone list …….…………………………………………………………………….………A-1
Appendix B. Notices ………………………………………………………………….……B-1
Recycling information………………………………………………………………………………………….B-2
Trademarks …………………………………………………………………………………………………… B-3
Turkish statement of compliance……………………………………………………………………………….B-4
Copyright Lenovo 2010. ii

3AFETY INFORMATION
   ǰ   ¢ ǯ
    ǰ   ³ä  ³ǯ
0REDINSTALAC¤TOHOTOPRODUKTUSIPRECTETEPR¤RUCKUBEZPECNOSTN¤CHINSTRUKC¤
® Ğǰ è   Ĵ ǯ
  Ĵ §§ Ĵǰ    ¢ ǯ
 Ȃ  ǰ £    ··ǯ
       ǯ
    Ĵǰ   £  ££ǯ
        Ğǯ
  ǻ¢ Ǽ è   Ĵ ǯ
    ǰ   ³ä  ³ǯ
       à  ǯ
Måt tålfsifutjogpsnbujpofo joobo ev jotubmmfsbs efo iås qspevlufo/
ii i
sUmGanBt’manli¥tl¥n; muneBlcab;epIþmbBa©ÚlkmμviFI
Prije instaliranja ovog proizvoda obavezno pročitajte sigurnosne upute.
General Safety guidelines
For tips to help you use your computer safety, go to:
http://www.lenovo.com/safety
Ț ¢  ŘŖŖ9.

Chapter 1. Getting started
This User’s Guide contains detailed information on the ThinkVision L2321x Wide
Flat Panel Monitor. For a quick overview, please see the Setup Poster that was
shipped with your monitor.
Shipping contents
The product package should include the following items:
● Setup Poster
● Monitor Safety, Troubleshooting, and Warranty Guide
● Reference and Driver CD
● Flat Panel Monitor
● Power Cord
● Analog Interface Cable- Attached to monitor
● DisplayPort Cable
● USB Cable
● Cable Cover
Note: To attach a VESA mount, please see
“Detachingthemonitorstand”onpage2-7.
Copyright Lenovo 2010. 1-1
®

Product overview
This section will provide information on adjusting monitor positions, setting user
controls, and using the cable lock slot.
Types of adjustments
Tilt
Please see the illustration below for an example of the tilt range.
Swivel
With the built-in pedestal, you can tilt and swivel the monitor for the most
comfortable viewing angle.
Height Adjustment
After pressing the top of the monitor, remove the fixed pin and adjust the height of
the monitor.
1-2 L2321x Wide Flat Panel Monitor User’s Guide

Monitor Pivot
- Adjust height to the top position before rotation the monitor.
- Rotate clockwise until the monitor stops at 90°.
User controls
Your monitor has controls on the front which are used to adjust the display.
For information on how to use these controls, please see “Adjusting your monitor
image ” on page 2-3.
Chapter 1. Getting started 1-3
Note: The L2321x monitor does not provide automatic detection of image rotation. If the
monitor head is rotated then the user should use the image rotation options provided
by the graphics properties of the operating system and video driver to rotate the image.
The ThinkVision Duo software does not support Auto Setup of the image if the image
is rotated.

Cable lock slot
Your monitor is equipped with a cable lock slot located on the rear of your monitor
(in the lower right corner). Please follow the instructions that came with the cable
lock to attach it.
Setting up your monitor
This section provides information to help you set up your monitor.
For best dual mode performance, Lenovo recommends use of the ThinkVision Duo software.
Detailed information on this software is available on page 2-4 of this User Guide.
Connecting and turning on your monitor
Note: Be sure to read the Safety Information located in the Monitor Safety, troubleshooting
and Warranty Guide before carrying out this procedure.
1. Power off your computer and all attached devices, and unplug the computer power
cord.
2. Connect the analog signal cable to the D-SUB connector of the monitor and the other end
on the back of the computer.
Note: One end of the signal cable is already pre-attached to your monitor.
1-4 L2321x Wide Flat Panel Monitor User’s Guide

3. Connect one end of the DP cable to the DP connector on the back of the computer, and
the other end to the DP connector on the monitor.
4. Connect one end of the USB hub cable to the USB connector on the back of the
computer, and the other end to the upstream USB connector on the monitor.
5. Plug the monitor power cord and the computer cord into grounded electrical outlets.
Chapter 1. Getting started 1-5

6. Rotate the head of the monitor into portrait view.
7. Remove the four rubbers from the stand
8. Replace the Cable Cover
