Lenovo LT2423wC User manual

LT2423wC
Flat Panel Monitor
User's Guide

Product numbers
60A8-KAR2-WW
FirstEdition (May 2013)
CopyrightLenovo 2013.
Allrights reserved.
LENOVOproducts, data,computersoftware, andservices have beendeveloped exclusively
at privateexpense and are soldtogovernmentalentities ascommercialitemsasdefined by
48C.F.R.2.101withlimitedandrestricted rights touse,reproduction and disclosure.
LIMITEDAND RESTRICTEDRIGHTSNOTICE:If products, data, computersoftware, or
servicesare delivered pursuant aGeneral ServicesAdministration "GSA"contract,use,
reproduction, or disclosure is subject torestrictions set forth in Contract No.GS-35F-05925.
Copyright Lenovo 2013.i

Contents
Safetyinformation.....................................................................
.......................................................
.............................................................................................................
.................................................................
..............................................................................................................
....................................................................................................
...............................................................................................................
.............................................................................................................
...................................................................................................
....................................................................
iii
Chapter1.Getting started1-1
Shipping contents1-1
Attaching the base and handling yourmonitor1-1
Product overview1-2
Types ofadjustments1-2
User controls1-2
Cable lock slot1-3
Settingup your monitor1-3
Connecting and turning onyourmonitor1-3
Registering your option....................................................................................................1-6
Chapter2.Adjusting and using your monitor.........................
.................................................................................................
............................................................................................
......................................................................
.............................................................................
...........................................................................................
..........................................................................................
..................................................................................
............................................................
.................................................................................
..................................................................................
....................................................................................................
..........................................................................
..........................................
.....................................................................................................
................................................................................................................
.....................................................................................................
...........................................................
.................................................................
...........................................
....................................................................................................
.........................................................................................
.............................................................................................................
...........................................
...................................................................................................
.................................................................................................
...........................................................................................
.................................................................
.....................................................................................................
......................................................................................................................
2-1
Comfortand accessibility2-1
Arrangingyour workarea2-1
Positioningandviewing yourmonitor2-1
Quick tips forhealthyworkhabits2-2
Accessibility information 2-2
Adjusting your monitorimage2-3
Using thedirectaccess controls2-3
Using theOn-Screen Display(OSD)controls2-3
Selectinga supporteddisplay mode2-5
Understandingpower management2-6
Caringforyourmonitor2-7
Preparing the monitor for wall-mounting 2-8
Chapter3.Referenceinformation3-1
Monitorspecifications3-1
Troubleshooting3-3
Manualimage setup3-4
Installing the monitor driver in Windows Vista 3-5
Installing the monitor driver in Windows 73-6
Installing the monitor driver in Windows 8/Windows 8.1 3-7
Service informatio 3-8
Customer responsibilities3-8
Service parts3-8
Appendix A.Service and SupportA-1
Registering your optionA-1
Online technical supportA-1
TelephonetechnicalsupportA-1
Appendix B. NoticesB-1
Recycling informationB-2
TrademarksB-3
Copyright Lenovo 2013.ii

Safty information
General Safety guidelines
Before installing this product, read the Safety Information.
íí
í
Copyright Lenovo 2013.iii

Chapter1. Getting started
This User’sGuidecontains detailedinformationontheFlatPanel Monitor.
For a quickoverview,please see the Setup Posterthatwas shippedwith
your monitor.
Shipping contents
The product packageshouldincludethe following items:
·Setup Poster
·FlatPanelMonitor
·Power Cord
·Analog SignalCable
·Audio Cable
Attachingthebase andhandlingyour monitor
Toset upyourmonitor,please see theillustrations below.
Note: Do nottouchthe monitorwithin the screen area.The screen areaisglass
and canbe damagedbyrough handling orexcessive pressure.
Note: Toattach aVESAmount, please see “Detaching themonitor stand”on page 2-8.
Copyright Lenovo 2013.1-1

Product overview
This section will provide information on adjusting monitor positions, setting user
controls,and using the cable lockslot.
Typesofadjustments
Please seetheillustrationbelow foran exampleof the tiltrange.
User controls
Your monitorhas controls on the frontwhichare used toadjust the display.
Forinformationon howto use these controls,pleasesee
“Adjusting your monitor image”on page 2-3.
1-2 FlatPanel Monitor User’sGuide

Cablelockslot
Yourmonitoris equippedwith a cable lock slotlocatedonthe rearof your monitor
(in the lowerleftcorner).Pleasefollowthe instructions thatcamewith thecable
lock to attach it.
Settingupyour monitor
This section provides information tohelpyou set upyour monitor.
Connecting and turning on your monitor
1.Power off yourcomputer and allattached devices, andunplug the computer
power cord.
2.Connect theanalog signal cable tothe videoport on the back of the computer.
Chapter 1. Getting started 1-3

3.Plug the monitorpower cord andthecomputer cord into grounded electricaloutlets.
Note:A certified power supplycord has tobe used with this equipment. Therelevant
national installation and/orequipmentregulations shall be considered. Acertified
powersupplycordnotlighterthan ordinary polyvinylchlorideflexible cord according
2 2
toIEC 60227(designation H05VV-F 3G0.75mm orH05VVH2-F2 3G 0.75mm )shall be
used.Alternative aflexible cordbeofsyntheticrubberaccording toIEC60245
2
(designation H05RR-F3G0.75mm )shallbe used.
4. Connect one end of the HDMI cable to the HDMI connector on the back of the
computer, and the other end to the HDMI connector on the monitor.
1-4 FlatPanel Monitor User’sGuide

5.Connect theaudio cable tothe videoport on the back of the computer.
6.Poweron themonitor andthe computer.
7.
Install the monitor driver, download the driver of the corresponding monitor model
from the Lenovo Website http://support.lenovo.com/LT2423wC,
and then click on
the driver and install it following the on-screen instructions.
Chapter 1. Getting started 1-5

8.
Tooptimizeyourmonitorimage,ifusing the analog cable,press theAutomaticImage
Setup key.Automatic imagesetup requires that the monitor is warmed upfor atleast 15
minutes.
Note: If automatic image setup does notestablish theimage thatyou prefer, perform
manual image setup.See “Manualimage setup”on page 3-4.
Registering youroption
Thank you for purchasing this Lenovo®product.Please takea fewmoments toregister
yourproductandprovide us withinformationthatwillhelpLenovo to betterserve you
in the future.Your feedback isvaluabletous in developing products and servicesthat
are important toyou,as well as in developing better ways to communicatewith you.
Register your option on the followingWeb site:
http://www.lenovo.com/register
Lenovo willsend you information and updates on yourregistered productunless you
indicateon the Websitequestionnairethatyou donot wanttoreceive further
information.
1-6 FlatPanel Monitor User’sGuide

Chapter2. Adjusting and using yourmonitor
This sectionwillgive you information onadjusting and using yourmonitor.
Comfortandaccessibility
Goodergonomicpracticeis important togetthemostfrom yourpersonalcomputer
and to avoiddiscomfort.Arrange your workplace and theequipmentyou use to suit
yourindividualneeds and the kind of work thatyouperform. Inaddition, use healthy
work habits tomaximize your performance and comfort whileusing your computer.
Formoredetailedinformationonany ofthesetopics,visit the HealthyComputing
Websiteat: http://www.ibm.com/pc/ww/healthycomputing
Arrangingyourworkarea
Use aworksurface of appropriateheightand available working areatoallowyou
to work in comfort.
Organizeyour work areatomatchthe way youuse materialsandequipment.
Keep yourwork areacleanand clear forthematerialsthatyou typically useand
placethe items thatyou use mostfrequently,such as the computermouseor
telephone,within the easiestreach.
Equipmentlayoutand setupplay alarge rolein yourworking posture.The
following topics describehowtooptimizeequipment setup toachieve and
maintain good working posture.
Positioning and viewing your monitor
Position and adjust your computermonitorforcomfortableviewing byconsidering
the following items:
·Viewingdistance:Optimalviewing distancesformonitors range from
approximately510mmto760mm(20in to30in)and canvarydepending on
ambient light and time of day.Youcanachieve differentviewing distancesby
repositioning yourmonitororbymodifying yourpostureorchairposition.Use
aviewing distancethatis mostcomfortablefor you.
·Monitorheight:Positionthemonitorsoyourheadand neck arein a
comfortable and neutral(vertical,orupright)position. If your monitordoes not
haveheight adjustments, you might have to placebooks orothersturdyobjects
underthe base of the monitortoachieve thedesiredheight. Ageneralguideline
is toposition the monitorsuchthatthetopof the screenisat orslightlybelow
youreye-height when youarecomfortably seated.However,besureto optimize
your monitor heightsothe lineof sitebetweenyour eyes and thecenterthe
monitorsuitsyourpreferences forvisualdistanceand comfortableviewing
whenyour eye muscles arein arelaxedstate.
Copyright Lenovo 2013.2-1

·Tilt: Adjust the tiltofyour monitortooptimize the appearanceof thescreen
contentandtoaccommodateyourpreferredheadandneck posture.
·Generallocation:Positionyour monitor toavoidglare orreflections on the
screen from overheadlighting ornearby windows.
The following aresome othertips forcomfortableviewing of yourmonitor:
·Use adequatelighting forthetypeofworkyou are performing.
·Use themonitorbrightness, contrast,andimage adjustment controls, ifequipped,
tooptimizethe imageon your screen tomeetyour visualpreferences.
·Keep yourmonitorscreenclean so you canfocus on the screen’scontents.
Anyconcentratedand sustained visualactivitycan betiring for your eyes.Besureto
periodicallylookawayfromyour monitorscreen and focus onafarobject to allow
youreye muscles to relax.Ifyou havequestions oneyefatigue or visual discomfort,
consultavision carespecialist foradvice.
Quicktipsforhealthyworkhabits
The following informationis asummary of someimportant factorsto considerto
helpyouremaincomfortableandproductive whileyou use your computer.
·Good posture startswithequipment setup:The layout of your work area and
the setupofyour computerequipment have alarge effecton yourposturewhile
using your computer.Besuretooptimizethepositionand orientationofyour
equipmentbyfollowing thetipsoutlinedin “Arranging yourworkarea”onpage2-1
soyou canmaintainacomfortableand productive posture.Also, besuretousethe
adjustment capabilities of your computercomponentsand officefurnituretobest
suityourpreferences nowand asyour preferenceschangeovertime.
·Minorchanges inposture canhelp avoid discomfort:The longeryousitand
work with yourcomputer,themoreimportantitis toobserve your working
posture. Avoidassuming anyonepostureforanextendedperiodoftime.
Periodicallymake minormodifications in yourposturetohelpdeterany
discomforts thatmight arise.Make useof anyadjustments that youroffice
furnitureorequipment provide toaccommodatechanges inposture
·Short,periodicbreaks help ensurehealthycomputing:Becausecomputing is
primarily astatic activity,itisparticularlyimportanttotake short breaks from
yourwork. Periodically,stand upfrom yourwork area, stretch, walkforadrink of
water,orotherwisetake ashortbreak from using your computer.Ashortbreak
from work givesyour body awelcomechangeinpostureand helps to ensureyou
remain comfortable and productivewhileyou dowork.
Accessibilityinformation
Lenovo is committedtoproviding greateraccess toinformation andtechnologyto
people with disabilities. With assistive technologies, users can access informationin
the way most appropriatetotheirdisability.Someof these technologies arealready
provided in youroperating system; otherscanbepurchased through vendorsor
accessedat:
https://www-03.ibm.com/research/accessibility/requests/accvpat.nsf/lenovo-bidx?
OpenForm
2-2 FlatPanel Monitor User’sGuide

Adjustingyour monitor image
This sectiondescribestheusercontrolfeatures usedtoadjust your monitorimage.
Usingthedirectaccesscontrols
The directaccess controls can beused when theOn Screen Display(OSD)is not
displayed.
Table2-1.Directaccess controls
IconControlDescription
ImageSetupActivatesautomaticimageadjustment.
BrightnessDirectaccess toBrightnessadjustment.
Volume Adjust the volume.
To useotherdirectaccess controls:
1.Press and hold for10secondsto lock the OSD.This will preventaccidental
adjustments to the OSD.Press andhold for 10secondsto unlock the OSDand
allowadjustmentstothe OSD.
2.EnablesDDC/CIbydefault.UseOSDExit Key,Press andholdthebutton
for10 seconds todisable/enableDDC/CI function. The words "DDC/CI
Disable"or “DDC/CI Enable”willbedisplayed.
UsingtheOn-Screen Display(OSD) controls
The settings adjustable with the usercontrols areviewed through the On-Screen
Display (OSD),asshownbelow.
Tousethe controls:
1.Press toopen the mainOSDmenu.
2.Use or tomove among the icons. Selectan icon and press toaccess that
function.Ifthereis asub-menu,you canmove between options using or ,
then press toselectthatfunction. Use or tomake adjustments. Press to
save.
3.Press tomove backwards through thesub-menus and exitfrom the OSD.
Chapter 2.Adjusting andusing your monitor 2-3
Brightness/Contrast

Table2-2.OSDfunctions
OSD Icon SubmenuDescriptionControls and Controls
onMain Adjustments and
Menu (Analog) Adjustments
(Digital)
Brightness-
/Contrast
Brightness
Adjustsoverall brightness
Contrast
Adjustsdifference betweenlightanddarkareas
Dynamic
Contrast Ratio
This function can improve your video input contrast
ration automatically.
Sameas
Analog
Position
HorizontalPosition
Movestheimageleftorright
VerticalPosition
Movestheimageupordown.
Setup
Automatic
Automaticallyoptimizes theimage.
Manual
Manuallyoptimizes theimage. See "Menualmagesetup"page3-4.
.Clock .Phase .Save
Controls
Locked not
required for
digitalinput
.
Image /
Audio
Properties
Color
Adjustsintensityofred, green,andblue.
Presetmode .. ..
ReddishsRGB*NeutralBluish
Custom .Red:Increasesordecreases thesaturationof"red"intheimage.
.Green:Increases ordecreases thesaturationof"green"intheimage.
.Blue:Increases ordecreases thesaturationof"blue"intheimage.
.Save:Saves thecustomcolorchoices.
InputSignal
Thismonitorcanacceptvideo signalsthroughtwodifferentconnectors.
Mostdesktop computersuse aD-SUBconnector.Selectdigitalamong
OSDControlswhenyouuse HDMI connector.
.SelectsD-SUB(Analog)
.SelectsHDMI
Scaling
Expends imagesizetofullscreen.
.Off (OriginalAR):sameAspectRatiowithinputsignal.
.On(Full):Expendsimagesizetofull screen.
Volume Adjust the volume.
Audio input Audio input select: .Line in .HDMI
Sameas
Analog
OptionsInformation
Showsresolution,refreshrate, andproductdetails. Note:Thisscreen
does notallowany changes tothesettings.
MenuLanguage
Thissectionliststhelanguages supportedbyyourmonitor.
Note: ThelanguagechosenonlyaffectsthelanguageoftheOSD.It
has noeffectonanysoftwarerunningonthecomputer.
Sameas
Analog
*Note:Brightness and Contrast cannotbe adjusted insRGBmode.
2-4 FlatPanel Monitor User’sGuide

Table2-2.OSDfunctions(continued)
OSD Iconon SubmenuDescriptionControls and Controlsand
MainMenu Adjustments Adjustments
(Analog) (Digital)
OptionsMenu Position
Adjusts menu locationonthescreen.
DefaultReturnsthemenu positiontothedefaultsettings.
Custom
·Horizontal: ChangesthehorizontalpositionoftheOSD.
·Vertical:ChangestheverticalpositionoftheOSD.
·Save
FactoryDefault
·Cancel
·Reset
Resets monitortotheoriginalfactorysettings.
Accessibility
Changebuttonrepeat rate andmenu time-outsettings.
Buttonrepeatrate:
Selector
tochange.
·Off
·Default
·Slow
Menu timeout:Sets thelengthoftimetheOSDwill
remainactiveafterthelast timeabuttonispressed.
SameasAnalog
Exit
ExitthemainmenuSameasAnalog
Selecting asupporteddisplaymode
The display modethe monitor uses is controlledbythe computer.Therefore,referto
yourcomputer documentationfordetailson howtochange display modes.
The imagesize,positionandshapemightchangewhen the display modechanges.
This isnormalandthe imagecan bereadjustedusing automaticimagesetup andthe
image controls.
UnlikeCRTmonitors, which requireahigh refresh ratetominimizeflicker,LCD or
FlatPaneltechnology isinherently flicker-free.
Note: If your system has previouslybeenusedwith aCRTmonitorand iscurrently
configuredto adisplay modeoutsidetherange ofthismonitor,you mayneed
tore-attachtheCRTmonitortemporarily untilyou havere-configuredthe
system;preferablyto1920x1080at60Hz,whichis the NativeResolution
Display mode.
Chapter 2.Adjusting andusing your monitor 2-5

The display modes shown below have been optimized at the factory.
Table 20-3. Factory set display modes
Addressability Refresh rate
640 x 480 60 Hz, 72 Hz, 75 Hz
720 x 400 70 Hz
800 x 600 56 Hz, 60 Hz, 72 Hz, 75 Hz
832 x 624 75 Hz
1024 x 768 60 Hz, 70 Hz, 75 Hz
1152 x 864 75 Hz
1280 x 1024 60 Hz, 70 Hz, 75 Hz
1366 x 768 60 Hz
1440 x 900 60 Hz
1600 x 900 60 Hz, 75 Hz
1680 x 1050 60 Hz
1920 x 1080 60 Hz
Understanding power management
Powermanagementis invokedwhenthecomputer recognizesthatyou have not used
yourmouse or keyboardforauser-definableperiod.There areseveralstatesas
describedin thetable below.
Foroptimalperformance,switch offyourmonitorattheend of each working day,or
wheneveryouexpect toleaveit unused for long periods during the day.
2-6 FlatPanel Monitor User’sGuide

Table2-4. Power indicator
StatePowerIndicatorScreenRestoringOperationCompliance
OnSteadygreenNormal
Standby/SuspendSteadyorange BlankPressakeyormovethe
mouse
Theremaybeaslight
delaybeforetheimage
reappears.
Note:Standbyalso
occursifthereisnoimage
outputtothemonitor.
ENERGYSTAR
OffOffBlankPressthe power button
Theremaybe aslight
delaybeforetheimage
reappears.
ENERGYSTAR
Caringfor your monitor
Besuretoturnoff thepowerbeforeyou performany maintenanceonthemonitor.
Donot:
·Applywaterorliquiddirectlytoyourmonitor.
·Use solvents orabrasives.
·Use flammable cleaning materialstocleanyour monitor oranyotherelectrical
equipment.
·Touchthescreen areaofyour monitor with sharporabrasive items. Thistypeof
contactmaycause permanent damagetoyour screen.
·Use any cleanerwhich contains an anti-staticsolutionorsimilaradditives. This
mayharmthe coating of the screenarea.
Do:
·Lightly dampen asoftclothwithwaterand use thistogentlywipethecovers and
the screen.
·Remove grease orfingermarks withadamp cloth and alittlemilddetergent.
Chapter 2.Adjusting andusing your monitor 2-7

Preparingthemonitor for wall-mounting
WARNING: Toreducethe risk of personal injuryor of damagetothe equipment,check
that the wall-mounting fixture is adequatelyinstalledand secured beforeattaching the
monitor.Refertotheinstructions suppliedwith the wall-mounting fixture and check
thatit is capable of supporting themonitor.
1.Disconnect thepower cable andanyothercables fromthemonitor.
2.Place themonitorface down on a flat,protectedsurface.
3.Remove the monitor base from stand.
4.Remove the three screwsin themonitor stand.Lift themonitorstand off themonitor.
5.Fourthreaded holes areexposed.These holesarefor screwstoattach the swing arm
orother mounting fixturetotheback of themonitor.
6.Followthe instructions included with the mounting fixture to ensurethat the
monitorissafelyattached.
7.Attach a swing arm orothermounting fixture.
NOTE: For useonly with UL(expand UL) Listed WallMount Bracket with minimum
weight/loadbearing capacity of3.7 kg.
2-8 FlatPanel Monitor User’sGuide

Chapter 3. Reference information
This section contains monitor specfications, instructions to manually install the
monitor driver, troubleshooting information, and service information.
Monitor specifications
Table 3-1. Monitor specfications for type-model 60A8-KAR2-WW
Dimensions Height 414.3 mm
Depth 216.7 mm
Width 567.1 mm
Panel Size 24 in.
Backlingt LED
Aspect Ratio 16:9
Stand Tilt range Range: 5º, +22º
VESA mount Supported 100 mm(3.94 in)
Image Viewable image size 609.7 mm(24 in.)
Maximum height 298.89 mm(11.77 in.)
Maximum width 531.36 mm(20.92 in.)
Pixel pitch 0.276 mm(0.0109 in.) (V)
Power input Supply voltage 100-240 V~, 50/60 Hz
Max supply current 1.5 A
Power consumption Max Consumption < 31 W
Note: Power consumption
figures are for the monitor Typical Consumption < 21 W
andthe power supply Standby/Suspend < 0.5 W
combned. Off < 0.5 W
Video input(Analog) Input signal Analog Direct Drive,
75 ohm 0.7 V
Horizontal addressability 1920 pixels (max)
Vertical addressability 1080 lines (max)
Clock frequency 205 MHz
Copyright Lenovo 2013.3-1

Table 3-1. Monitor specfications for type-model 60A8-KAR2-WW(continued)
Communic atons VESA DDC CI
HDMI input Input signal TMDS
Horizontal addressability 1920 pixels (max)
Vertical addressability 1080 lines (max）
Clock frequency 205 MHz
Supported Display Modes
(VESA Standard modes
between noted ranges)
Horizontal frequency VGA: 30 kHz - 81 kHz
Vertical frequency 50 Hz - 75 Hz
Native Resolution 1920 x 1080 at 60 H
Temperature Operating 0º to 45ºC (32º to 104º F)
Storage -20º to 60ºC (-4º to 140º F)
Shpping -20º to 60ºC (-4º to 140º F)
Humidity Operating 10% to 90%
Storage 10% to 90%
Shipping 10% to 90%
3-2FlatPanel Monitor User’sGuide
