Lenoxx magivaac RV2000 User manual

Model: RV2000
Batch: PR4362
PLEASE READ AND RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
THIS APPLIANCE IS INTENDED FOR HOUSEHOLD USE ONLY.
The illustrations used in this manual are to illustrate the operation method and structure of
the product. Where there is a small difference between the physical item and the
illustrations, please take the physical as the standard.

INTRODUCTION:
Clean-up is both effortless and easy with this high powered 3-in-1 HEPA Robot Vacuum with
Mop. Call out to your Amazon Alexa or Google Home or push a button on the downloadable
smartphone app or included remote control to power up and get started.
Enjoy 2kPa 3-speed suction power alongside with dual side vacuum brushes and a central
operational vacuum brush to get the ultimate clean on both carpets and hard floors. This
intelligent robo-vac uses gyroscope navigation and mapping to provide four easy route
types – room, spot, auto and edges cleaning. The room route is for single room cleaning, the
spot route cleans a specified one-square meter area, the auto route uses a zig zag motion to
run over the area once and the edges route runs around the edges and parameters of the
area once.
The powerful, rechargeable 14.4V 2500mAh lithium battery charges within 4-5 hours and
runs on an average time of 90-140 minutes per use. With a 600mL dustbin capacity and a
350mL water tank capacity attachment, this 3-in-1 smart vac will auto detect the
attachment and sweep, mop or vacuum – all available in the four pre-programmed route
modes. Enjoy an extra spare vacuum brush set and an extra spare mop included in the box,
so a thorough clean is available at just the simple swap of an accessory.
The quiet operation runs less than 65dB while packing in an array of smart infrared sensors
including five pairs of obstacle detection sensors, anti-collision sensors, stairway-safe anti-
fall sensors and soft cushion bumpers. The brushless motor and wheels provide lower noise
levels, durability, stability, as well as a longer run-time and lifetime.
Take it up a level with a range of extra benefits and controls through the downloadable
smartphone app including power, standby, room route, spot route, auto route, edges route,
manual controls, directional keys, scheduling programmability and an auto-return recharge
to the charging dock base when low on battery power.
Enjoy a 15° climbing angle to get onto area carpets up to 1.5-centimetres with a stronger
drive force, so no areas of the floor are left out. Have an ease of mind with an upgraded
charging dock base for improved detection accuracy.
The built-in removable HEPA filter captures the smallest particles of dust to help calm those
with asthma and allergies. Compared to a traditional vacuum that leaves a decent
percentage of dust particles behind, this is a crucial reason to upgrade to the robot vacuum
cleaner.
Emptying the bagless dustbin is also simple and straightforward. Lift the dustbin straight out
of the top of the robot vacuum and empty the dust contents into the bin – it’s that easy.
When the HEPA filter needs a cleaning, just wash and air dry it overnight. No need to
purchase an endless supply of vacuum bags.
Complete with a missed-area cleaning inspection, this 3-in-1 HEPA Robot Vacuum with Mop
is efficient and affordable for both homes and offices.
1

SAEFTY INSTRUCTIONS:
1. Only authorized technicians can disassemble this product. Users are not recommended
to disassemble this product by themselves.
2. This product can only use the power adapter provided by the factory. If other adapters
are used, the product may cause damage.
3. Do not touch wires, sockets or power adapters when your hands are wet.
4. Take care to prevent fabric or body parts from coming into contact with the product’s
drive wheels.
5. Do not place this product near cigarette butts, lighters and other smoldering fires.
6. Please clean the product after charging.
7. Do not bend wires excessively or place heavy objects and sharp objects on the machine.
8. This product is an indoor household product. Do not use it outdoors.
9. Do not sit on the product.
10. Do not use this product in a wet environment (e.g. bathroom).
11. Before using this product, please remove all vulnerable items (e.g. glasses, lamps, etc.)
from the ground as well as items (e.g. wires, paper sheets, curtains) that may get stuck
in the side brushes and air suction passages.
12. Do not put this product in a place where it is easy to fall (e.g. on desks and chairs).
13. Please carefully check whether the power adapter is connected to the socket before
using it, otherwise it may cause battery damage.
14. To prevent tripping, please inform other people in the house when the product is
working.
15. Please empty the dust container before using this product when the dust container is
full.
16. The temperature for this product to be used in is 0 to 40 degrees Celsius.
17. Do not use this product in high temperature environment.
18. Please remove the battery from the machine before disposing of this machine.
19. Please make sure that this product is not powered on when removing the battery.
20. Please recycle the discarded batteries safely.
2

Warning:
1. Use only the original rechargeable battery and charging dock specially equipped by the
manufacturer. Non -rechargeable batteries are strictly prohibited, please refer to"
product parameters" for battery specification information.
2. Do not use product in an environment with open flames or fragile objects.
3. Do not use product in extremely hot (above 40 Degrees Celsius) or extremely cold
(below 0 Degrees Celsius) environments.
4. Do not allow human hair, clothes, fingers and other parts to come into contact
with the opening and operating parts of the product.
5. Do not use product on wet or ponding ground.
6. Do not allow product to collect any items such as stones and wastepaper, this may clog
the product.
7. Do not allow product to collect any inflammable substances, such as petrol, toner and
pastels used for printers or photocopies. Do not use the product to clean areas with
flammable items.
8. Do not allow product to collect any burning items, such as cigarettes, matches, ashes
and other articles that may cause fire.
9. Do not place articles at the suction opening. Do not use the
product when the suction port is blocked. Use a small item such as dust, cotton wool,
hair, etc. at the suction opening to check that the suction air flow is working.
10. Use the power cord carefully to avoid damage. Do not use the power cord to drag or pull
the product and the product charging dock. Do not use the power cord as a handle. Do
not clamp the power cord in the crack of the door. Do not pull the
power cord around corners. Do not allow the product to operate on the power cord,
the power cord should be far away from the heat source.
11. Do not use a damaged charging dock.
12. Even if the product has been severely damaged, burning of the product is prohibited,
this may lead to the explosion of the battery of the product.
3

CONTENTS:
Introduction 1
Safety Instructions 2
Warnings 3
Contents 4
Product Composition/ Package Contents 5
Product Composition/ Part Name 6
Remote Control 9
Light Indications 10
Installation of App 11
Quick Guide for App Use 15
Product Usage/ Preparation 18
Product Use/ Robot Charging 20
Product Use: Using the Water Tank 22
Component Maintenance/ Dust Container 23
Component Maintenance/ Main Brush and Side Brush 26
Component Maintenance/ Charge Dock Pins, Down View Sensor,
Wheel and Universal Wheel 27
Troubleshooting 28
Specifications 29
4

PRODUCT COMPOSITION/ PACKAGE CONTENTS:
Robot Charging dock Remote Control Dust Container
Cleaning Brush Side Brush x 2 Adaptor Instruction manual
Hepa Filter Water Tank Mopping Pad
5

PRODUCT COMPOSITION/ PART NAME:
Home button Power button
Power button: Press to turn the robot on or off. Push and hold it for 1 x second.
When it is powered on and the green light is on, press the power button again to begin
operation.
During operation, press the power button for 1 x second to stop operation.
The power button can be pressed once to pause operation. Then press it again to resume
operation.
If both the power button and the home button are flashing red, press and hold down the
power button for 4 x seconds until both lights stop blinking.
If the robot is caught in an obstacle, resolve the issue.
Then press the power button once to turn the robot on again and begin operation.
Home button: Press to return the robot back to the charging base while the robot is
operating.
The robot will make its way back to the charge base slowly.
It may not go straight to the charge base but will navigate its way back there.
The robot is not vacuuming during this process.
The home button can also be used during Wi-Fi pairing, press and hold it down until the
robot beeps once or twice. Further info is in the EZ pairing and AP pairing sections.
6

Top:
Control panel
Surface Cover
Omnidirectional/Lens
Dust Box/
Water Tank Button
Bottom:
Ground Sensor
Left Side brush Right Side Brush
Left wheel Right wheel
Dust box
Charging Pole Piece
Universal Wheel
Battery Cover
Rolling Brush Assembly
7

er
Dust container:
Water Tank and Mopping Pad Assembly:
Water injection port
Water tank
Mopping pad
Charging Dock:
Indicators on the charging dock:
When the charging dock is connected to power, the green indicator light will be blinking.
The robot will automatically return to the charging dock when the battery is lower than 20%
power.
8

REMOTE CONTROL:
Add 2 x AAA size batteries to the remote control.
Add the batteries to the remote control as per the polarity markings in the battery
compartment.
Mopping button
1. On/Off: Press to wake up or dormant the robot.
2. Recharge: Press to return the robot to the charging base.
3. Room cleaning: Select this mode only when one specific room needs to be cleaned.
Make sure to confine Robot to the room by closing the door. Robot will also clean
the edges before finished.
If this room does not contain the charging base, the robot will return to the original
point after cleaning has finished.
4. Spot cleaning: Robot intensively cleans a specific area in a spiral pattern within the 5
ft radius, useful if there is a concentrated area of dust or debris.
5. Wifi settings: Can be used when connecting to Wifi. Press and hold the button down.
Wait for the robot to beep twice. The buttons on the vacuum will both begin
blinking. Then you can start to connect Wifi.
6. Direction control: You can direct Robot to clean a particular area by using the
directional buttons on the remote control.
Note: the direction is based on the location of the power button facing the front of
the robot. Pressing the arrow in the up position for example will make the robot
travel forwards as per the power button. Pressing the arrow on the right hand side
will make the robot travel to the right as per the power button.
The directional arrow needs to be pressed and held on the remote to make it travel
in the chosen direction.
9
Decrease
suction
power
Increase
suction
power

To stop directional control, press the Pause/Start button, then press it again to start
normal operation.
7. Pause/ Start: Press to pause the robot, press again to resume the robot.
8. Auto cleaning: Robot optimizes its cleaning path by selecting different cleaning
modes automatically until cleaning is complete.
This is the most commonly used cleaning mode.
9. Mopping button: Press to use the mopping function. The water tank needs to be
installed first. The Robot will also automatically work with mopping when the water
tank is installed, and the power button is pressed.
10. Edge cleaning: Robot reduces the moving speed when detects a wall or fixed object
and then follows the wall or fixed object to ensure the edge is cleaned thoroughly.
The robot will return to the charging base after edge cleaning is complete / return to
its original start point.
11. Power setting: Press either the standard suction power button or strong suction
power button to increase or decrease the power of suction.
LIGHT INDICATIONS:
Robot-list of lights
Power button
Home button
Recharging
Green light solid
Green light flash
Recharging finish
Green light solid
Green light solid
Cleaning
Green light solid
Light off
Cleaning finish
Green light solid
Orange light solid
Power less than 20%
Green light solid
Red light solid
Robot break down
Red light flash
Red light flash
If the Robot has not worked for 10 minutes, it will be dormant, and all lights will be off.
Press the power button to wake up the robot, and then press the power button again for
the Robot to start cleaning.
Wifi status
Power button
Home button
Wifi not connect
Green light solid
Light off
Wifi connecting
Green light solid
Green light flash quickly
Wifi connect successfully
Green light solid
Light off
After clearing an obstruction/ correcting an issue, the red lights may remain blinking.
Press and hold the power button for 4 x seconds or until the lights stop blinking.
Then press the power button once to start the robot again.
10

INSTALLATION OF APP:
Ensure that the robot, your router and your phone are close to each other before you start
the APP connection. The suggested distance is less than 4 meters.
Scan the applicable QR CODE below to download the TUYA Smart app, or search for the
TUYA Smart app in your device’s app store:
Download the TUYA Smart app (fig 01).
Open the TUYA app on your phone, after download (fig 02).
Register an account via email or mobile phone number (fig 03).
Tap the right verification code and set up a password for your TUYA ID (fig 04).
Login with account and password (fig 05).
11

Tap the plus (+) sign to add the home appliance (Fig 06).
Add manually is shown on the top of the app screen.
Tap Small Home Appliances (Fig 07).
Choose Robot Vacuum (Fig 08). Select this vacuum from the list:
Select the 2.4 GHz Wi-Fi network.
Enter the correct Wi-Fi name and password and tap Next to connect the vacuum cleaner to
the Wi-Fi network.
May need to scroll down on the app screen to locate the Next button.
Press Next.
EZ Mode pairing.
EZ Mode pairing is a quick method. It is also the default pairing method.
EZ Mode is shown in the top right hand corner of the app.
Press and hold the Wi-Fi button on the remote control for 5 seconds.
or
Press and hold the home button on the robot until the robot beeps once.
The robot will beep and the Home button and Power button on the robot will be blinking
rapidly.
The robot has entered EZ mode.
Click on “Confirm the indicator is blinking rapidly” on the app screen and press Next (Fig 09).
Type your WIFI Password if prompted (Fig 10).
12

Start device connection and wait for pairing to occur (Fig 11).
When completed successfully, an Added successfully message will be on the app screen (Fig
12).
The robot name for the device can be changed if desired (Fig 13).
Press Done in the middle of the app screen.
Start using the app to control the robot (Fig 14).
Note additional controls/ settings on the bottom of the app screen. Swipe right and left at
the bottom of the app screen to access those controls/ settings (Fig 15).
13

Alternative pairing method.
AP Mode pairing.
AP Mode is a slower pairing mode which may be required if a more stable signal is needed.
After selecting the Robot Vacuum (Wifi) from the devices in the app, and selecting the 2.4
GHz Wi-Fi network and pressing Next,
Press EZ Mode in the top right had corner of the app screen.
Select AP Mode.
Press and hold the home button on the robot for 5 seconds. The robot beeps every 2.5
seconds. After the robot beeps twice, robot enters the AP mode, and the Home button and
Power button will be blinking slowly.
Button no longer needs to be held down.
The Home button and Power button on the robot will be blinking rapidly.
Click on “Confirm the indicator is blinking rapidly” on the app screen and press Next.
Connect your mobile phone to the device’s hotspot. Press “Go to Connect” on the app
screen.
Select the SmartLife - XXXX hotspot.
This hotspot is created after the machine is connected to your Wi-Fi network.
If it shows ‘connected without internet’ that is ok.
After the machine is connected to the hotspot, return to the TUYA Smart app.
The app automatically returns to the Connect your mobile phone to the device's hotspot
screen. Wait for the device to be added.
When the app prompts that the connection is set up successfully, you can operate the
machine in the app.
14

QUICK GUIDE FOR APP USE:
Select from ‘Auto cleaning’, Recharge mode’, ‘Room cleaning’, ‘Edge cleaning’, ‘Spot
cleaning’ when required to use your desired cleaning methods (Fig 15 + Fig 16).
Press ‘Cleaning strength’ to enter the suction power settings (Fig 17).
Press ‘Schedule cleaning’ to enter the scheduled cleaning settings.
Press ‘Add Schedule’ or ‘Add’ to choose a working time (Fig 19) and day/days if required (Fig
20).
Start/Pause/Standby/Sleeping mode:
Press to start or pause the robot (Fig 21).
Note: When the robot pauses for over 10 minutes, it will enter sleeping mode.
If it is in sleeping mode, press ; the robot will be woken up and go into standby mode.
Press the cleaning mode which you require for cleaning.
Direction control:
You can direct Robot to clean a particular area by using the directional buttons on the app
screen.
Note: the direction is based on the location of the power button facing the front of the
robot. Pressing the arrow in the up position for example will make the robot travel forwards
as per the power button. Pressing the arrow on the right hand side will make the robot
travel to the right as per the power button.
The directional arrow needs to be pressed and held on the app screen to make it travel in
the chosen direction.
To stop directional control, press the Pause/Start button, then press it again to start normal
operation.
15

Working map and cleaning record:
The app will show a map of the working cleaning part of the robot (Fig 22).
Note, that this app may not update in real time.
Tap “Cleaning record’ to view the cleaning records of the working time and cleaned area.
The data can also be cleared (Fig 23).
Find robot:
You may not know where the robot is when it finished cleaning and stops.
Press ‘positioning of robot’ in the app (Fig 24).
The robot will beep once when it is pressed. You can press it repeatedly to assist with
locating the robot.
If the ‘mute’ option has been selected in the ‘More’ settings, the robot will not beep when
‘positioning of robot’ is pressed.
Mute:
Tap ‘More’ to enter the mute settings (Fig 25).
When the icon is green, the sound will be mute (Fig 26).
16

Supported Third-party control:
The robot works with Amazon Alexa, Google Assistant and some other third party control
devices.
Tap in the top right corner (Fig 27). The find ‘Supported Third-party Control” and tap the
corresponding icon to make connection (Fig 28).
Share Devices:
Only one main ID for one single device is available.
If you want to share the device to others in your family, tap on the top right corner;
Choose “Share devices” (Fig 29); type correct registered cellphone number/email ID to add
additional users (Fig 30).
Note: other users must have a TUYA ID before being added.
17

PRODUCT USAGE/ PREPARATION:
IMPORTANT TIPS BEFORE USE:
a. Remove power cords and small objects from the floor that may entangle Robot. You
can use the supplied cable ties to organize your wires and power cords.
b. Fold tasseled edges of area rugs underneath to prevent tangling Robot. Avoid
cleaning very dark-colored high-pile rugs or rugs thicker than 1.02 in/26 mm as
they may cause Robot to malfunction.
c. Keep Robot away from spaces lower than 2.87 in/73 mm to prevent Robot from
getting stuck. If necessary, place a physical barrier to block off the problem areas.
d. Keep Robot away from wet areas.
e. Robot may climb on top of objects less than 0.63 in/16 mm in height. Remove these
objects if possible.
f. Anti-drop sensors prevent Robot from tumbling downstairs and steep drops. They
may work less effectively if dirty or used on reflective/very dark-colored floors.
It is recommended to place a barrier or boundary in front of fireplaces and areas that
may cause damage to the robot if entered. Block off areas where Robot may fall.
18

Remove Protection
Before using the Robot, remove the protective strip on the Robot and remove the
protective film on the charging dock.
Ensure the side brushes are installed according to the left and right (L/R) before use.
19
