PERIPHERIAL PUMP
Instruction Manual
APm37 / APm75

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
CongratulationsonyourpurchaseofaLEOPeripherialPump
It is important that you read, fully understand and observe the following
safety precautions and warnings. Careless or improper use of the
machine may cause serious or fatal injury. The user is responsible for
any accidents involving other people or other people’s property.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Children shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
Attention!
If the appliance or the supply cord is damaged, it must be
repaired by manufacturer, its service agent or qualified person-
Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities.
Contact your local government for information regarding the collection
systems available.
Applications
• It is applicable tohousehold water supply,equipment support,small air- conditioning
system, pipeline pressurization, garden watering, vegetable greenhouse watering,
fish breeding and poultry raising, etc.
• Transfer clean water and other non-corrosive liquids with low viscosity; do not
transport inflammable, explosive, gasified liquids and liquids containing solid
particles or fibers. The PH of water must between 6.5 and 8.5.
Remark:
This series of pump could be transformed into automatic water pump, which is realized
through external automatic plant that is composed of pressure switch, pressure tank,
etc. Function featuresof the automatic pump are as follows: when the power is on, turn
on the water tap and the pump will start working automatically; when the water tap is
turned off, the pump will stop working automatically. If a water tower is used along with
the automatic pump, connect to the upper limit switch and the pump will start or stop
working automatically with water level in the water tower.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Model Description
Technical Data
Max. flow: 90L/min
Max. head: 100m
Output power: 0.25~2.2kW
Max. Suction: 8m
Insulation class: IPX4
Protection class: F
Max. ambient temperature: +40℃
Max. liquid temperature: +60℃
Type
APm37
APm75
Power
370 W / 0,5 HP
750 W / 1,0 HP
Inlet/outlet diameter
1” / 1”
1” / 1”
Qmax
2,4 m3/h
3,0 m3/h
Hmax
35 m
70 m
Max. Suction
8 m
8 m
Gross weight
5,5 kg
10,5 kg
Package
283x158x171mm
335x190x210mm

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Implementation Standards
 IEC/EN 60335-1 Household and similar electrical appliances--safety
Part1: General requirements.
 IEC/EN 60335-2-41 Household and similar electrical appliances--safety
Part2-41: Particular requirements for pump.
 2006/95/EC Low voltage directive
Safety Precautions
Toensure normal and safety operation of the electric pump, read the
manual carefully before use.
The electric pump should have reliable grounding to prevent short
circuit; for safety, leakage protection switch should be equipped and
be careful not to wet the power plug; socket should be connected in
damp - proof area.
Do not touch the electric pump while working; do not wash, swim
near working area or let livestock into the water to avoid accidents.
Avoid splashing pressured water to the electric pump as well as
prevent the pump immersed by water.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Keep the pump in ventilation.
In case ambient temperature is lower than 4℃or the pump is not
used for a long time, empty liquid the pipeline system to avoid ice
cracking of the pump chamber.
Do not operate the pump for a long time without water in it.
The pumped liquid maybe hot and under high pressure, before
moving and demounting the bump, valves in both sides of the
bump should be turned off first and then empty liquids in the pump
and pipelines so as not to be scalded.
Do not transfer any inflammable, explosive or gasified liquids that
beyond the stipulation.
Ensure the pump will not be accidently turned on while installing
and maintaining; if not used for a long time, cut off the power first
and then turn off valves in inlet and outlet of the pump.
Power supply should be in accordance with the voltage stated in
the nameplate. If not used for a long time, put the pump in dry,
ventilated and cool place under room temperature.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Product Structure
POS.
Part
POS.
Part
1
Pump body
10
Fan
2
Impeller
11
End plate
3
Mechanical seal
12
Cable holder
4
Support
13
Cord clip
5
Water proof gland
14
Capacitor
6
Bearing
15
Capacitor box
7
Rotor
16
Terminal board
8
Spring washer
17
Stator
9
Fan cover
18
Filling plug

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Pipeline Installation
This product should be installed and maintained by personnel who is
proficient in this manual and has special qualifications. Installation and
operation should be in accordance with local regulations and recognized
operation standards.
Install pipelines properly as stipulated in the manual and meanwhile conduct frost
protection measures for the pipeline.
For the installation, the inlet
pipe should be as short as
possible with the least turnings.
The pump should be installed in
ventilated and dry environment.
It could be installed outside,
provided having proper covering
to prevent rain and wind.
For pipeline use, valves should
be installed on inlet and outlet
pipelines and the inlet pipeline
should be installed with check
valve.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Correct Installation Diagram A
A: 1. Foot valve
2. Water tap
3. Outlet pipe
4. Filling plug
5. Electric pump
6. Tie-in
7. Inlet pipe
B: Installation precautions for inlet
pipelines
1. While installing the electric pump, do
not use too soft rubber tube for the
inlet pipeline, avoiding to be sucked
flat.
2. The foot valve should be vertically
placed and installed 30cm
from water bottom to avoid
sucking in sands and stones (B2)
3. Joints of the inlet pipelines
should be sealed with the least
elbows; no water can be sucked.
4. Diameter of the inlet pipe should
be at least in accordance with
that of the water inlet, to avoid
too much water loss which will
influence outlet performance.
5. Pay attention to drop of water
level while using, the foot valve
should not be above the water
surface (B1).
6. In case the inlet pipe is longer
than 10m or its lifting height
exceeds 4m, the pipe diameter
should exceed diameter of water
inlet of the pump.
7. Ensure the pumped will not be
affected by pipeline pressures
while installing the pipelines.
8. Filter should be installed in inlet
pipelines so as to avoid
solid particles to pump.
C: Installation Precautions of the
outlet pipeline
Pipe diameter of the outlet pipeline
should be at least in accordance with that
of the water outlet, so as to reduce its
voltage drop, high flow rate and noise to
the minimum.
Correct Installation Diagram B

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Electrical Connection
Unless the power is off, do not wiring the junction box.
The electric pump should have reliable grounding to prevent current
leakagewithleakage protectionswitchbeingequipped.
 Electrical connection and protection should be conducted according to stipulations.
Specification of working voltage is marked on the nameplate; please ensure the
motor is in accordance with power supply.
 In case the working area of the electric pump is too far from the power supply, power
transmission lines should be of a heavier gauge, otherwise the electric pump cannot
work normally because the voltage drop is too dramatic.
 A rubber extension cable shall be applied for the electric pump in case of outdoor
use.
 Check rotation of the motor (three-phase motor).
 Check whether operation of the electric pump is normal, rotation is correct, which
could be observed from the fan blade terminal, e.g. clockwise rotation means
correct direction. In case the rotation is incorrect, cut off power and exchange the
two power cables.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
 Automatic device (Pressure switch)
o While using the automatic pump, in case it still operates after turning off the
water tap, lower down power cut-off pressure of the pressure switch on the
premise of pipeline without leakage, namely, rotate the variable screw nut II
in counter clockwise direction (-) to acquire lower closing pressure.
o
In case the pump is often enabled when the water tap is turned off (sometimes
it is turned on and sometimes it is turned off), check whether pipeline and the
bottom valve have leakages and pressure vessel pressure is normal,
eliminate timely if any.
o In case the pressure switch is alternately turned on and turned off (frequent start)
after turning on the water tap, increase power cut-off pressure of the pressure
switch, namely, rotate the variable screw nut I in clockwise direction to acquire
higher opening pressure.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Start-up and Maintenance
Do not start up the pump before the pump chamber is filled with
water.
Do not touch the electric pump unless its power has been cut off
for at least 5 minutes.
Do not dismount the pump body unless water in the pump chamber is emptied.
Rotate the fan blade before
start- up, check whether the
pump rotation is flexible and
then unscrew the water-filling
plug, fill the pump chamber
with clean water from the
water injection hole, then
tighten the plug screw after
the air has been completely
discharged. The valve should
be shut tightly while starting
up the pump. After the pump
discharges water and
operates normally, adjust the
valve to the required flow
(working range is displayed
on the nameplate).
Attention:
 In case no water is discharged after being started for more than 5 minutes with
water filled, turn off the electric pump, re-fill water or check whether the inlet pipeline
has leakages
 In case of any frost and ice damages, please open the drain plug to empty
water in the pump chamber. When start up the pump again, open the drain
plug, fill water and tighten it and then the pump is usable.
 In case not use for a long time, water in the pump should be emptied. The
pump body, impeller and support should be cleaned and coated with
anticorrosive oil before they are put in a ventilated and dry place for use.

In case the pump is halted for a long time, start it up again according to
above diagram.
 In summer or when the ambient temperature is high, pay attention to
ventilation, avoid dew on electrical parts which will result in electrical faults.
 In case the motor is hot or abnormal, cut off the power immediately and
check faults according to the following table.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Troubleshooting
Check the pump after power cut-off.
Symptom
Cause
Corrective Action
The motor cannot be
started
Single-phase power
supply (three-phase
electric motor):
a. poor connection of
thepower switch;
b. fuseisburnedout;
c. loose power lead;
phasefailureofthecable.
a. repair switch contact
orreplace the switch;
b. replace the safety fuse;
c. check and tighten
the power
connector;
d. repair or replace cables.
Capacitor is burned out.
Replacewitha sametype
capacitor (send to the
maintenance point for
repair).
The rotating shaft and
bearingare jammed.
Replace the bearing
(send to the
maintenance point for
repair).
Impeller is jammed.
Turn rotating shaft of the
fan blade terminal with
screw driver to let it
rotate flexiblyor demount
the pump body to clear
sundries.
Stator winding is damaged.
Replace winding coils
(sendtothe maintenance
point for repair).
The motor is in
operation, but no water
is discharged
Incorrect direction of pump
rotation.
Invert two-phase
wirings of the motor
(three-phase motor).
The pump is not fully filled
with water.
Re-fill the pump with
water.
The impeller is damaged.
Replacetheimpeller(send
to the maintenance point
for repair).
Leakage of the suction
pipe.
Check sealing of various
joints oftheinletpipelines.
Water level is too low.
Adjustinstallationheightof
the pump.
Freeze caused by
accumulated water in the
pipeline or the chamber.
Start up the pump after ice
is melted.
Insufficient pressure
Incorrect pump type.
Select suitable pump.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Insufficient pressure
Theinletpipelineistoolong
or with too many bends,
pipe diameter is not
selected as required.
Apply the pipe with the
stipulated diameter,
andmaketheinletpipe
short.
Inlet pipeline, filter screen
or pump chamber is
blocked by foreign
materials.
Clean pipeline, foot
valve or pump
chamber, clear
sundries.
Motor works intermittently
or the stator winding is
burned out
The impeller is jammed
or under overload
operationforalongtime.
Clear sundries in the
pump chamber; operate
the pump under the
rated flow as much as
possible.
Incorrect grounding,
broken cable or the
electric pump is hit by
lightning.
Seek for the reason, and
replace winding coils.

Acquaer Ltd. H-4900, Fehérgyarmat, Szatmári út 11.
Guarantee terms
Please carefully retain the guarantee card completed by the seller, or the proof
of purchase.
Pre-conditions for the 24-month guarantee entitlement:
- Deployment of the device solely for private use.
The guarantee is reduced to 12 months in the commercial sector or leasing
business.
- Proper handling and observance of all information given in the operating manual,
which forms part of our guarantee terms.
- Observance of the prescribed maintenance intervals
- No unauthorized alteration of the design.
- Presentation of the completed guarantee card and/or proof of purchase.
Any guarantee claim shall be immediately void in the event of unauthorized
repairs. Faults and defects, which can be traced to material or manufacturing
faults will be rectified exclusively by our contracted workshops (the seller has
the right to remedy a defect) in your vicinity or by the manufacturer if the latter
is closer. Any claims going beyond the provision of a guarantee are ruled out.
Any transport damage should be reported not to us but to the shipper in
question since, otherwise, any compensation claims the shipper would be
voided.
Information concerning the packaging materials
The used packaging materials must be thrown into the relevant waste collector.
In case of the need of any parts, questions or service instructions please
contact:
 [email protected]
 [phone]
Acquaer Ltd., 4900 Fehérgyarmat, Szatmári u. 11 certifies CE conformity of the above-
mentioned product and that it complies with the technical data specified in the data
plate and the “Operating instructions”.
You can get detailed information about the CE declarations at: www.gamagarden.eu
