Letsfit AE02 User manual

AE02
Indoor Cycling Bike
User Manual
Thank you for purchasing our product. This manual addresses the safety guidelines,
warranty, and operating instructions. Please review this manual thoroughly before operating
your device.

Table of Contents
English Version................................................................... 1
Product Overview.............................................................................................. 1
Assembly........................................................................................................... 6
Adjustment........................................................................................................ 12
Using the Console............................................................................................. 17
Transportation................................................................................................... 19
Warm-up Exercise............................................................................................ 20
Care and Maintenance..................................................................................... 21
Important Safety Instructions ........................................................................... 22
Warranty............................................................................................................ 23
Deutsche Version................................................................ 24
Produktübersicht............................................................................................... 25
Montage............................................................................................................ 30
Einstellung......................................................................................................... 36
Verwendung der Konsole.................................................................................. 41
Transport........................................................................................................... 43
Aufwärmübungen.............................................................................................. 44
Pflege und Wartung.......................................................................................... 45
Wichtige Sicherheitsanweisungen.................................................................... 46
Garantie............................................................................................................ 47

Product Overview
1
Before using this equipment, please read the diagram and parts list below carefully and
familiarize yourself with the equipment.
Explosive Diagram
(11)
(18)
(12)
(23)
(27)
(13)
(32)
(24)
(1)
(26)
(3)
(16)
(14)
(7)
(33)
(4)
(9)
(10)
(5)
(31)
(29)
(8)
(17)
(30)
(2)
(25)
(28)
(19)
(6)
(15)

2
Fully Assembled Diagram
1020mm
515mm
(MAX) 1035mm
(MIN) 1065mm
(MIN) 870mm
(MAX) 1180mm

3
Packaged Parts Diagram
(1)
(2)
(3)
(4) (5)
(6)
(10) (11)
15
13
AE02 TOOLS
(17) Ф8×Ф19×2T 4PCS
(20) Open-end Wrench 1PC
(21) Allen Wrench
1PC
(15) M8×P1.25×20L 4PCS
(19) Ф8.1×Ф14.5×2.4T 4PCS
(14) M8×40L×S20L 4PCS (16) M8 4PCS
(18) Ф8×Ф16×2T 4PCS
(12) (13)
(7) (8) (9)

4
Packaged Parts List
No. Parts Name Specification Quantity
1 Main Frame 1
2 Front Stabilizer Bar 1
3 Rear Stabilizer Bar 1
4 Seat Post 25*50*1.5T*390L 1
5 Handlebar Post 1
6 Handlebar Ф25.4*1.5T*1052L 1
7 Saddle 1
8 Left Pedal L 1
9 Right Pedal R 1
10 Console Stand 1
11 Console 1
12 Cover 1
13 Bottle Holder 1
14 Screw M8*40L*S20L 4
15 Screw M8*P1.25*20L 4
16 Locknut M8 4
17 Flat Washer Ф8*Ф19*2T 4
18 Flat Washer Ф8*Ф16*2T 4
19 Spring Washer Ф8.1*Ф14.5*2.4T 4
20 Open-end Wrench 1
21 Allen Wrench 1
22 AAA Battery 2

5
Other Parts List
No. Parts Name Specification Quantity
23 Seat Fasten Knob 1
24 Seat Adjustment Knob 1
25 Leveling Feet 4
26 Crank Arm 9/16"-170L 2
27 Resistance Adjustment Knob 1
28 Brake Pad 1
29 Flywheel Ф453*24W*13KG 1
30 Transport Wheel 2
31 Handlebar Adjustment Knob 1
32 Screw M5*10L 8
33 Screw M5*16L 1

6
Assembly
Before assembling, please check whether the parts are in good condition and make sure that the parts
are not damaged or missing. Then put all the components in a clean, spacious area, and remove the
packaging materials. Do not discard the packaging materials until all assembly steps are completed.
1. Install the front stabilizer bar (2) and the rear stabilizer bar (3) on the main frame with four
screws (14), four flat washers (17), and four locknuts (16) using the open-end wrench
(20).
Notes：
● While assembling the front stabilizer bar, the transport wheels on the stabilizer bar are in
the front.
● If the equipment is placed on an uneven surface, adjusting the leveling feet (25) on the
front/rear stabilizer bar can help, but may not compensate for extremely uneven surfaces.
(1)
(2)
(16)
(14)
(25)
(17)
(3)
(20) Open-end Wrench
(17) Flat Washer Φ8×Φ19×2T
(16) Locknut M8
(14) Screw
M8×40L×S20L
15
13

7
2. Screw the left pedal (8) and the right pedal (9) into the crank arms (26) using the
open-end wrench (20), each pedal is marked with the letter L (left) or R (right) to denote
the side of the bike they are on.
Note：
Screw the left pedal into the crank arm hole counterclockwise, and screw the right pedal into
the crank arm hole clockwise.
(20) Open-end Wrench
15
13
(9)
(1)
(8)
(26)

8
3. Install the saddle (7) on the seat post (4) using the open-end wrench (20). Unscrew the
seat adjustment knob (24) counterclockwise from the main frame (1), and then insert the
seat post into the main frame. Then align the seat adjustment knob with the hole on the
seat post, and then screw it clockwise back into the main frame.
(20) Open-end Wrench
15
13
(7)
(4)
(24)
(1)
1
2
3
