LEW ELECTRIC PUFP-CT-WC Series User manual

!
!"#!$%&$'%()*+,*)(,-)&.//.&,0-(1",2*(
(
#0+(!.+&(-"34*+)5(PUFP-CT-B-WC,**PUFP-CT-BK-WC,**PUFP-CT-DB-WC,**PUFP-CT-
WT-WC,**PUFP-CT-NS-WC,**PUFP-CT-SS-WC*,**PUFP-CT-B-20A-2USB-WC,**PUFP-CT-BK-
20A-2USB-WC,*PUFP-CT-DB-20A-2USB,**PUFP-CT-WT-20A-2USB-WC*,*PUFP-CT-NS-
20A-2USB-WC,*PUFP-CT-SS-20A-2USB-WC*
(
!
!+,0+(&0(,-)&.//.&,0-5(
1.!!To!ensure!compliance!with!local!electric!codes,!please!contact!your!local!
electrical!inspector!prior!to!installation!
2.!!Do!not!install!PUFP-CT-WC!prior!to!electrical!inspector!authorization.!
3.!Installation!should!only!be!done!by!a!licensed!and!bonded!electrical!contractor.!
4.!All!power!must!be!turned!off!at!its!source!prior!to!installation.!!Failure!to!do!so!
may!result!in!injury!or!death.!
5.!If!anytime!water!enters!into!the!PUFP-CT-WC,!turn!off!power!at!its!source!and!
have!the!unit!replaced!by!a!licensed!and!bonded!electrical!contractor.!
6.!!All!PUFP-CT-20A-2USB-WC!are!supplied!with!dust!covers!for!the!USB!ports.!!
These!dust!covers!must!remain!inside!the!USB!openings!UNLESS!the!port(s)!is!in!
use.!!Failure!to!do!so!will!void!any!ETL!listing.!!
7.!!All!PUFP-CT-WC!include!a!20!amp!cord/plug.!!Under!no!circumstances!should!the!
cord!be!cut!and!the!unit!hard!wired.!!This!will!void!any!ETL!listing!and!any!warranty!
provided!by!Lew!Electric.!!!
8.!!All!!-0-(1#%,(!"#!$%&$'%!series!must!be!connected!to!a!GFCI!circuit!breaker.!!
Failure!to!do!so!will!increase!the!risk!of!injury.!
!
(/*'(*/*%&+,%(.%%*!&)(-0(+*)!0-),4,/,&6(,#(&7*(.408*(%0-2,&,0-)(.+*(
-0&(3*&9!
!
+*:",+*2(&00/)5(
-Construction!Adhesive,!Crimping!Pliers/!Wire!Strippers,!Philips!Head!Screw!Driver,!
and!Drill.!
!
,-)&.//.&,0-(;!<=>(0?@A5(
1.!Prior!to!installation,!a!professional!granite!cutter!should!cut!a!4!1/16”!x!4!1/16”!
hole!in!the!desired!location!of!the!PUFP-CT.!
2.!Always!use!the!supplied!PUFP-WB!stamped!steel!box.!
3.!Please!note!that!the!tabs!can!be!moved!to!the!lower!set!of!holes!on!the!PUFP-WB!
box!to!accommodate!varying!depths!of!counter!top.!

4.!For!best!performance!it!is!preferred!to!mount!the!box!with!the!top!edge!sitting!
lower!in!the!hole,!which!leaves!more!room!for!the!inside!of!the!box!(see!video).!
!
,-)&.//.&,0-((;!<=>(&BCA(
1.!Place!the!PUFP-CT!cover!on!top!of!the!PUFP-WB!box!
2.!Remove!the!protective!film!from!the!PUFP-CT-WC!cover!and!press!the!open!tab!
on!the!PUFP-CT-WC!cover!exposing!the!two!mounting!screw!holes!inside!the!cover.!
3.!Line!up!the!two!screw!holes!with!the!PUFP-CT-WC!cover!and!the!PUFP-WB!box!
and!using!the!2!provided!screws,!secure!the!cover!to!the!box,!about!¼!the!length!of!
the!screws.!
4.!!Place!the!unit!inside!the!hole!from!the!top!of!the!countertop.!
5.!!From!under!the!countertop!(inside!the!cabinet)!secure!the!mounting!tabs!to!the!
PUFP-WB!box.!
6.!!Finish!tightening!the!screws!from!step!3,!making!sure!that!the!tabs!are!tight!
against!the!bottom!of!the!countertop.!!
7.!!Move!the!PUFP-CT!TOP!back!and!forth!and!side!to!side,!making!sure!there!is!no!
movement.!
8.!!To!close!the!cover,!press!and!hold!the!open!tab!while!pressing!down!on!the!cover!
until!you!hear!a!click!and!the!unit!is!locked!into!place.!
9.!Open!and!close!the!unit!several!times!to!make!sure!that!the!unit!is!opening!
properly!and!at!the!desired!speed.!!All!units!are!preset!to!the!optimal!functioning!
speed!at!the!factory!before!they!are!shipped.!
10.!!If!the!desired!opening!speed!has!not!been!achieved,!remove!the!remove!the!
PUFP-CT-WC!from!the!counter!and!turn!the!PUFP-CT-WC!cover!upside!down.!!
Locate!the!tension!screw!and!turn!the!screw!to!add!or!subtract!the!opening!speed.!!
Then!repeat!steps!4!through!7.!!
!
!/"1(,-(%0+2(&0(.!!+08*2(*/*%&+,%./(0"&/*&(
!
&+0"4/*()700&,-1(
(
SYMPTOM
RESOLUTION
Button does not
work
Make sure that the tabs on the PUFP-WB box were installed underneath the
counter.
Turn off power at its source, take the PUFP-CT out of the box and make sure that no
excess wires are interfering with the opening mechanism.
Open the cover by pressing button and make sure that the mounting screws are not
over tightened
Turn power off at its source. Place the cover upside down, apply a small amount of
WD-40 or similar lubricant to the bottom of button
Unit pops up too
slow
Turn off power at its source, remove the PUFP-CT from the counter and turn the
PUFP upside down.
Locate the tension screw and turn the screw to add or subtract opening speed
!
!
