Spider-ManTM
Flat Screen TV
TELEVISÃO LCD DE 15’’ DO SPIDER-MAN
User guide
Manual de Instruções
LCD1SP

2

3
CONTENTS
Important Safety Instructions......................................................................................................................4
TV
Power Source.............................................................................................................................................6
Cable Connections .....................................................................................................................................6
Location of Controls....................................................................................................................................7
Preparation.................................................................................................................................................8
Basic Operation..........................................................................................................................................8
The On-Screen Menu.................................................................................................................................9
Retractable Stand.....................................................................................................................................12
Troubleshooting........................................................................................................................................13
Specications ...........................................................................................................................................13

4
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning ash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within
the product’s enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
DANGER: Invisible and hazardous laser radiation
when open and interlock failed or defeated. Avoid
direct exposure to beam.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, AND ANNOYING INTERFERENCE, USE
THE RECOMMENDED ACCESSORIES ONLY...
CAUTION-ELECTRICALLY OPERATED PRODUCT
Not recommended for children under 8 years of age. As with all elec-
tric products, precautions should be observed during handling and use
to prevent electric shock.
ATTENTION TO PARENTS
This product must be periodically examined for conditions that may
result in the risk of re, electric shock or injury to persons and, if such
conditions are present, this product should not be used until properly
repaired.SURGE PROTECTORS:
It is recommended to use a surge protector for AC connection.
Lightning and power surges ARE NOT covered under warranty for this
product.
WARNING
USE UNDER SUPERVISION OF AN ADULT DUE TO LONG CORD
This unit has a long AC cord or other long cord that can easily be
tripped on or pulled on, causing injury, Please make sure it is
arranged so it will not drape over a tabletop, etc. Where it can be
pulled on by children or tripped over accidentally.
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
PLEASE READ BEFORE OPERATING THIS EQUIPMENT.
Before using the unit, be sure to read all operating instructions
carefully. Please note that these are general precautions and may not
pertain to your unit. For example, this unit may not have the capability
to be connected to an outdoor antenna.
1. Read these instructions.
All the safety and operating instructions should be read before the
product is operated.
2. Keep these instructions.
The safety and operating instructions should be retained for future
reference.
3. Heed all warnings.
All warnings on the product and in the operating instructions should
be adhered to.
4. Follow all instructions
All operating and use instructions should be followed.
5. Do not use this apparatus near water.
Do not use this product near water and moisture, for example: near a
bathtub, washbowl, kitchen sink or laundry tub; in a wet basement; or
near a swimming pool.
6. Clean only with dry cloth.
Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. It may damage the screen. Use a
dry cloth for cleaning only.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
Slots and openings in the cabinet and in the back or bottom are
provided for ventilation, to ensure reliable operation of the product
and to protect it from overheating. These openings must not be
blocked or covered. The openings should never be blocked by placing
the product on a bed, sofa, rug or other similar surface. This product
should never be placed near or over a radiator or heat source.
This product should not be placed in a built-in installation such as
a bookcase or rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produces heat.
9. Do not defeat the safety purpose of the polarized or grounding
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided
for your safety. If the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete outlet.

5
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specied by the manufacturer, or sold with the apparatus. When
a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
An appliance and cart combination should be moved with care.
Quick stops, excessive force and uneven surfaces may cause the
appliance and cart combination to overturn.
PORTABLE CART WARNING
(Symbol provided by RETAC)
SC126A
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
To protect your product from a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the
wall outlet and disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and power-line surges.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture does not operate normally, or has
been dropped.
15. Power source
This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your appliance dealer or local power
company. For products intended to operate from battery power, or
other sources, refer to the operating instructions.
16. Power lines
An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where
it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this can result in
a risk of re or electric shock.
18. Object and liquid entry
Never push objects of any kind into this product through openings as
they may touch dangerous voltage points or short out parts that could
result in re or electric shock. Never spill or spray any type of liquid on
the product.
19. Outdoor antenna grounding
If an outside antenna is connected to the product, be sure the antenna
system is grounded so as to provide some protection against voltage
surges and built up static charges. Section 810 of the National Electric
Code ANSI/NFPA 70 provides information with respect to proper
grounding of the mast and supporting structure, grounding of the
leading wire to an antenna discharge product, size of grounding
conductors, location of antenna-discharge product, connection to
grounding electrodes and requirements for grounding electrodes.
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
NEC-NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PARTH)
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE
20. Service
Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer
all servicing to qualied service personnel.
21. Replacement parts
When replacement parts are required, be sure the service technician
uses replacement parts specied by the manufacturer or those that
have the same characteristics as the original parts. Unauthorized
substitutions may result in re or electric shock or other hazards.
22. Safety check
Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the
product is in proper operating condition.
23. Wall or ceiling mounting
The product should be mounted to a wall or ceiling only as recom-
mended by the manufacturer.
24. Damage requiring service
Unplug the product from the wall outlet and refer servicing to qualied
service personnel under the following conditions.
a) When the power-supply cord or plug is damaged.
b) If liquid has been spilled or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by the following operating
instructions. Adjust only those controls that are covered by the
operating instructions, as an adjustment of other controls may
result in damage and will often require extensive work by a qualied
technician to restore in the product to its normal operation.
e) If the product has been dropped or the cabinet has been damaged.
f) When the product exhibits a distinct change in performance-this
indicates a need for service.
25. Note to CATV system installer
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, species that the cable ground
shall be connected to the grounding system of the building, as close
to the point of cable entry as practical.
Warning
1) To reduce the risk of re or electric shock, do not expose this
apparatus to rain or moisture.
2) The apparatus shall not be exposed to dripping or splashing and
that no objects lled with liquids, such as vases, shall be placed on
the apparatus.
3) The disconnected device (appliance inlet) shall remain readily
operable.
PRECAUTION WITH TV:
When displaying a still image.
A still image may cause permanent damage to the TV screen.
• Do not display a still image on the LCD panel for more than 2 hours
as it can cause screen image retention. This image retention is also
known as “screen burn”. To avoid such image retention, reduce the
degree of brightness and contrast of the screen when displaying a
still image.

6
• Watching the LCD TV in 16:9 format for a long period of time may
leave traces of borders displayed on the top, bottom and centre of
the screen caused by the difference of light emission on the screen.
Damages caused by the above effect are not covered by the
Warranty.
• Displaying still images from Video games and PC for longer than a
certain period of time may produce partial after-images. To prevent
this effect, reduce the “brightness” and “contrast” when displaying
still images.
NOTE ON TV:
The TFT LCD panel uses sophisticated technology to produce.
However, there may be few bright or dark pixels on the screen.
These pixels will have no impact on the performance of the product.
NOTES ON CLEANING:
Use a soft, dry cloth for cleaning
For stubborn dirt, soak the cloth in a weak detergent solution, wring
well and wipe. Use a dry cloth to wipe it dry. If you use a chemical-
saturated cloth to clean the unit, follow that product’s instructions.
Warning: Cleaning and adjustment of lenses and /or other
components of playback mechanism should be performed by a
qualied service technician.
TV SECTION
TV - POWER SOURCE
1. Insert the small plug of AC cord to the AC/DC adapter.
2. Insert the DC plug on AC/DC adapter to the TV.
3. Insert the AC plug of the AC cord into a conveniently located AC
outlet having AC~ 100-240V, 50/60Hz.
CONNECTION USING COAXIAL CABLE:
Follow the instructions below to connect an external unit, such as a
VCR or DVR (DVD Recorder) to your unit using a 75 ohm coaxial
cable. (CABLES NOT INCLUDED.)
1. Connect the cable, satellite or incoming antenna to the VHF/UHF
IN jack on the rear of the VCR/DVR.
2. Connect a 75 ohm coaxial cable from the external unit’s 75 ohm
OUT jack to the ANT jack on the bottom of the TV.
3. Set the SOURCE of the TV to TV mode.
CONNECTION USING AUDIO/VIDEO CABLES:
Follow the instructions below to connect an external unit, such as a
VCR/DVR/DVD player to your unit using Audio/Video cables.
(CABLES INCLUDED)
From external unit's AV OUTPUT jacks
AV connection cable
external unit
TNAOEDIV-SSENOHPNIOIDUA-CP
AV IN
VIDEO LRSCART
1. Connect the left and right audio connection cable from the
external unit’s AUDIO OUTPUT jacks to the AUDIO IN jacks of
the TV. Connect the video cable from the external unit’s VIDEO
output jack to the VIDEO IN jack of the TV.
2. Set the SOURCE of the TV to AV mode.
To A U D IO IN jacks
external unit
Connection cable
S- V ID E O I N
From external unit's AUD IO OUTPUT jac ks
TNAOEDIV-SSENOHPNIOIDUA-CPAGV
AV IN
VIDEO LRSCART
DC IN
1. Connect the left and right audio cable from the external unit’s
AUDIO OUTPUT jacks to the TV’s AUDIO IN jacks.
2. Connect the external unit’s S-VIDEO OUTPUT jack to the TV’s
SVIDEO IN jack.
3. Set the SOURCE of the TV to S-VIDEO mode.
CONNECTION USING S-VIDEO CABLE:
Follow the instructions below to connect an external unit by S-VIDEO
connection cable. (CABLES NOT INCLUDED.)
CONNECTION USING VGA CABLE (CABLES NOT
INCLUDED):
TNAOEDIV-SSENOHPNIOIDUA-CPAGV
AV IN
VIDEO LRSCART
DC IN
Using a VGA 15 pin D-SUB connection cable (not included) to
connect the VGA output jack on the PC to the TV’s VGA input jack.
Using a 3.5mm stereo mini jack connection cable (not included) to
connected the PC AUDIO OUTPUT/PHONE jack on the PC to the TV’s
PC AUDIO IN jack. Set the SOURCE of TV to PC mode.
TV-CABLE CONNECTIONS
CONNECTING AN ANTENNA:
To connect an antenna, plug the antenna into the antenna input jack.
ANT.75
TNAOEDIV-SSENOHPNIOIDUA-CPAGV
AV IN
VIDEO LRSCART
DC IN
ANT.7 5
INCO MING CATV CABLE
external unit
From VCR/DVR RF OUTPUT JACK
TNAOEDIV-SSENOHP
AV IN
VIDEO LRSCART

7
TNAOEDIV-SSENOHPNIOIDUA-CPAGV
AV IN
VIDEO LRSCART
DC IN
For private listening, connect headphone (not included) into the
PHONES jack of TV. The speakers will be disconnected when
headphone are inserted into the jack.
NOTE: When the headphone is connected, the MUTE button on the
remote handset will not work.
CONNECTION USING SCART CABLE (CABLE NOT
INCLUDED):
TNAOEDIV-SSENOHPNIOIDUA-CPAGV
AV IN
VIDEO LRSCART
DC IN
EXTERNAL UNIT
INCOMING CATV
CABLE (VCR)
1. Connect the cable, satellite or incoming antenna to the VHF/UHF
IN jack on the rear of the VCR or DVD recorder.
2. Connect the SCART cable (not included) from the external unit’s
SCART jack.
3. Set the SOURCE of TV to SACRT mode.
CONNECTION USING HEADPHONE: (HEADPHONE NOT
INCLUDED)
TV - LOCATION OF CONTROLS
2 3 4 5 6 7
1
1. POWER: Turns the TV POWER On or Off (standby)
2 MENU: Enter to setting menus
3. V-: Volume down
4. V+: Volume up
5. P-: Channel down
6. P+: Channel up
7. MODE: Enter to SOURCE setting menus
TNAOEDIV-SSENOHPNIOIDUA-CPAGV
AV IN
VIDEO LRSCART
DC IN
10
9
811 12 13 14 15 16
8. Main Power ON/OFF Switch
9. DC IN: DC input jack
10. VGA: VGA input jack
11. PC-AUDIO IN: Stereo audio input jack for PC.
12. PHONES: Phones jack
13. SCART: Scart jacks
14. S-VIDEO: S-Video input jack
15. AV IN: Audio (Left & Right) and Composite Video input jacks
16. ANT: Antenna input jack
P+
TV/AV POWER
RECALLRECALLRECALL TXT/TV
MENU V+
CANCEL
TXT-C
HOLD
MIX
SIZE
TXT-Y
INDEX
TXT-G
REVEAL
TXT-R
OSD
SWAP
NICAM/A2
1
2
3
4
5
6
17
18
16
19
20
21
22
23
24
25
7
8
9
10
11
12
13
14
15
1. TV/AV: Enter in SOURCE setting menu.
2. RECALL: Return to previous TV channel (in TV mode only).
3. P+: Channel up/Move the cursor in setting menu to up position.
4. OSD: On Screen Display.
5. MENU: Enter settings’ menu.
6. V- : Volume down/Move the cursor in setting menu to the left.
7. SWAP: SWAP channels between source channel and target
channel.
8. SOUND: Press repeatedly to select the presetting sound effect
modes.
9. P-: Channel down/Move the cursor in setting menu downwards.
10. Numeric buttons (0-9): Enter the channel number for direct
channel access.
11. -/--/---: Press repeatedly to select 1-3 digit of program number for
direct channels access.
12. INDEX: In Teletext mode, press this button to display the Teletext
index page.
13. REVEAL: Some of Teletext pages are linked with several
secondary pages. Press this button repeatedly to view the
secondary pages as desired.
14. TXT-R, TXT-G, TXT-Y and TXT-C buttons: Press to activate the
corresponding functions shows on the lower side of the Teletext
page.
15. MIX: Press to displaying the TV picture and Teletext page on the
screen simultaneously. Press again to exit.
16. POWER: Press to turn the TV On or OFF (Standby).
17. TXT/TV: Press to activate theTeletext mode, press again to
exit.(Operation in TV mode only)
18. NICAM/A2: Press repeatedly to select Stereo, Dual I or Dual
II.(Functions depends on the audio signal broadcasting from TV
station)
19. V+: Volume up/Move the cursor in the setting menu to the right.
20. SLEEP: Press repeatedly to activate the sleep function and sleep
timer setting.
21. PICTURE: Press repeatedly to select the presetting picture
modes.
22. MUTE: Mute ON/OFF.
23. SIZE: Press once to display the upper half of the Teletext page to
the full screen. Press again to display the lower half of the Teletext
page to the full screen. Press again to exit.
24. CANCEL: Press to exit from Teletext mode.
25. HOLD: Press to hold on the Teletext page.

8
TV - PREPARATION
1. Remove the screw and open the battery compartment cover.
2. Install two (2) DC 1.5V “AAA” size batteries as the polarity
diagram (+/- signs) inside the battery compartment.
3. Replace the battery compartment cover and screw.
BATTERY PRECAUTIONS
Follow these precautions when using batteries in this device:
Do not use rechargeable batteries. Non-rechargeable batteries are
not to be recharged. Rechargeable batteries are to be removed from
the toy before being charged. Rechargeable batteries are only to be
charged under adult supervision. Different types of batteries or new
and used batteries are not to be mixed. Only batteries of the same or
equivalent type as recommended are to be used. Batteries are to be
inserted with the correct polarity. Exhausted batteries are to be
removed from the toy. The supply terminals are not to be short
circuited. Do not throw batteries into a re. Remove the batteries if
you are not going to use the game for a long period of time.
WARNING: If the unit malfunctions or receives an electrostatic shock,
remove the batteries and insert them again.
EFFECTIVE DISTANCE OF THE REMOTE CONTROL
TRANSMITTER
Approx. 24 feet (8 meters)
30
30
Approx. 24 feet (8 meters)
NOTE:
When there is an obstacle between the TV and the transmitter, the
transmitter may not operate.
When direct sunlight, an incandescent lamp, uorescent lamp or any
other strong light shines on the REMOTE SENSOR of the unit, the
remote operation may be unstable.
TV - BASIC OPERATION
Power ON/OFF
1. Press the Main Power Switch on the rear of TV to ON position to
power on(Standby) the unit.
2. Press the Power button on the TV or remote control to power
ON/OFF (Standby) the unit from Standby mode.
3. If long period of time will not used the TV. Power off the TV by
press the Main Power Switch to OFF position.
NOTE: The TV will be power OFF automatically in approx. 5 minutes if
no TV signal is received. This feature is to protect the TV and save energy.
To power on the TV again, simply press the POWER button again.
SOUND MODE SELECTION
Press the SOUND button repeatedly to select the preset sound
modes as desired.
PICTURE MODE SELECTION
Press the PICTURE button repeatedly to select the preset picture
modes as desired.
CHANNEL SELECTION
• Press the P+ or P- buttons to select a preset channel as desired.
• For direct channels access:
1. Channel number 1-9: Press the “-/--/---” button once and enter
the channel number by press the numeric keys on the remote
handset.
2. Channel number 10-99: Press the “-/--/---” button twice and enter
the channel number by press the numeric keys on the remote
handset.
3. Channel number 100-125: Press the “-/--/---” button three times
and enter the channel number by press the numeric keys on the
remote handset.
VOLUME SETTING
Press the V+ or V- buttons to adjust the sound level as desired.
MUTE
Press to turn off the sound, the TV’s sound will be silenced and MUTE
will appear on the screen. Press this button again or one of V+ or V-
buttons twice to turn the sound back.
SOURCE SETTING
1. Press the MODE button on the TV or the TV/AV button on the
remote handset to enter to SOURCE setting menu.
2. Press the P+ or P- buttons to select the source to TV, AV,
S-VIDEO, SCART or PC as desired.
3. Press the V+ button to conrm the selection.
AUTO SEARCHING
The method is designed to quickly search and automatically store the
available TV stations located in your area:
1. Power ON the TV and set the SOURCE to TV mode as above.
2. Press the MENU button to enter to setting menu.
3. Press the P- button repeatedly to highlight the icon of CHANNEL,
the CHANNEL setting menu will appear on the screen. Press V+
button to enter to the setting menu.
4. Press the P- button repeatedly to highlight AUTO SCAN.
5. Press the V+ button to start searching and the unit will
automatically scan over through all the channels and store the
active channels into the TV.
SKIP:
The noisy/unwanted channels can be removed from the TV’s memory
by using the SKIP function as follows:
1. Select the noisy/unwanted TV channel by pressing the P+/P-
buttons.
2. Press the MENU button.
3. Press the P- button repeatedly until the CHANNEL icon is
highlighted.
4. Press the V+ button to highlight SOURCE.
5. Press the P- button repeatedly until SKIP is highlighted.
6. Press the V+ button to change the SKIP state from OFF to ON.

9
7. Press the MENU button twice to exit the menu. The noisy/
unwanted TV station will no longer be shown when skipping
through the channels using the P+/P- buttons.
8. Repeat the same procedures to deleted all the nosily/unwanted
stations as desired.
TELETEXT:
Most set channels carry “Teletext”, pages of written information that
provide information such like:
• Sports results.
• Subtitles for the hard of hearing.
• Television programme times.
• News bulletins and weather forecasts.
The Teletext pages are organized according to six categories as the
gure:
A B C D
E
F
TV - ON-SCREEN MENU
SETTING Menus
Press the MENU button to enter the setting menu (press again to
exit). Press the P+/P-/V+/ V- buttons to highlight the function within
the menu you want to set. Press the V+ button to conrm the
selection. Press the P+/P- buttons to toggle the sub-menu options.
TV MODE
In TV mode, there are 5 main setting menus:
PICTURE- for picture quality setting.
• Press the MENU button, the PICTURE setting menu will appear
on screen.
• Press the V+ button to highlight CONTRAST, and then press the
P+/P- buttons repeatedly until the desired setting is highlighted
(CONTRAST, BRIGHTNESS, HUE, SATURATION, SHARPNESS,
COLOR TEMP or PICTURE MODE).
• Press the V+/V- buttons repeatedly to adjust the setting.
• When COLOR TONE is selected, press the V+/V- buttons
repeatedly to select the color temperature to WARM, COOL or
NORMAL.
• When PICTURE MODE is selected, press the V+/V- buttons
repeatedly to select the picture mode to BRIGHT, PERSONAL,
NORMAL or SOFT.
NOTES: HUE will not functioning in TV mode.
HU
E
COLOR TONE
STANDARD
ADJUST
ADJUST
NICAM/A2 STEREO
SOUND- for sound quality setting
• Press the MENU button, and then press the P- button repeatedly
to highlight the SOUND icon, the sound setting menu will appear
on screen.
• Press the V+ button to highlight BASS, then press the P+/ P-
buttons repeatedly to select BASS, TREBLE, BALANCE, SOUND
MODE or NICAM/A2.
• Press the V+/ V- buttons repeatedly to adjust the setting.
• When SOUND MODE is selected, press the V+/V- buttons
repeatedly to select the sound effect mode to THEATER,
ODEUM, NEWS or PERSONAL.
• When NICAM/A2 is selected, press V+/V- buttons repeatedly to
select MONO, STEREO or DUAL I or DUAL II (depending on the
type of audio signal broadcasted from your TV station).
A: Selected page number.
B: Broadcasting station identity.
C: Current page number or search status.
D: Date and time.
E: Text.
F: Status information.
Operations of Teletext:
• Press the P+/P- to select a preset channel providing the Teletext
service.
• Press the TXT/TV button on the remote handset to activate the
Teletext mode. To return to normal TV mode, press the TXT/TV
button again or press CANCEL button.
• In the section “F” above gure shows, there will be four
different control functions identify by different colours. Press the
corresponding colour buttons on the remote handset to activate
the corresponding functions. TXT-R button for Red, TXT-G button
for Green, TXT-Y button for Yellow and TXT-C button for Cyan.
For an example, if “P-” on the Teletext page section “F” shows
in Red, press the TXT-R button to enter to the previous Teletext
page. If “P+” on the Teletext page section “F” shows in Green,
press the TXT-G button to enter to the next Teletext page.
• In Teletext mode, press MIX button to display TV and Teletext
page on the screen simultaneously. To exit, press MIX button
again.
• In Teletext mode, press the SIZE button once to display the upper
half of the Teletext page to the full screen. Press the SIZE button
again to display the lower half of the Teletext page to the full
screen. To exit, press the SIZE button again.
• Some of Teletext pages are linked with several secondary
pages; the secondary pages are displayed in sequence. Press
the REVEAL button repeatedly to view the secondary pages as
desired. Press the HOLD button to freeze the current page (icon
of lock will appear on the screen). To exit from the freeze mode,
press this button again (icon of lock will disappear on the screen).
• To enter to the desired number Teletext page in Teletext mode,
enter the three digit of page number by the numeric buttons on
the remote handset. (All the three digit of the page number should
be entering, for an example, if the page number is “003”. Press
the buttons “0” + “0” + “3”).
• In Teletext mode, press the INDEX button to display the index
page.
NOTES:
• Make sure the TV signal reception is good. Otherwise, the
information of Teletext may not be displayed or corruptions.
• If any broken character appears while Teletext is being viewed,
make sure that the Teletext language is identical with the
language in the setup menu. If both languages are different,
select the same language with Teletext language on the setup
menu.

10
ON
WEST
BLUE SCREENBLUE SCREEN
TXT LANGUAGETXT LANGUAGE
ADJUST
FUNCTION
• Press the MENU button, and then press the P- button repeatedly
to highlight the icon of FUNCTION. The function setting menu will
appear on the screen.
• Press the V+ button to highlight the RESET, then press the P+/P-
buttons repeatedly to select RESET, BLUE SCREEN or TXT
LANGUAGE.
• Press the V+/V- buttons repeatedly to adjust the setting.
• When BLUE SCREEN is selected, you can set the blue screen on
or off by press V+/V- buttons repeatedly. If set to on, the screen
will turn to blue when no signals or weak signals receptions. If set
to off, the blue screen will not come on.
• When TXT LANGUAGE is selected, press the V+/V- buttons
repeatedly to select the Teletext language to WEST, EAST,
RUSSIAN, ARABIC, FARSI or AUTO.
OSD (On Screen Display)
• Press the MENU button, and then press the P- button repeatedly
to highlight the OSD icon, the OSD setting menu will appear on
screen.
• Press the V+ button to highlight LANGUAGE, then press the
P+/P- buttons repeatedly to select LANGUAGE, H-POSITION,
V-POSITION, DURATION, or HALFTONE.
• Press the V+/V- buttons repeatedly to adjust the setting.
• When LANGUAGE is selected, press the V+/V- buttons
repeatedly to select the language as desired.
M
O
V
E
AV, S-VIDEO or SCART MODE
These modes have 4 main setting menus:
PICTURE- for picture quality setting.
• Press the MENU button, the PICTURE setting menu will appear
on screen.
• Press the V+ button to highlight CONTRAST, and then press the
P+/P- buttons repeatedly until the desired setting is highlighted
(CONTRAST, BRIGHTNESS, HUE, SATURATION, SHARPNESS,
COLOR TONE or PICTURE MODE).
• Press the V+/V- buttons repeatedly to adjust the setting.
• When COLOR TONE is selected, press the V+/V- buttons
repeatedly to select the color temperature to WARM, COOL or
NORMAL.
• When PICTURE MODE is selected, press the V+/V- buttons
repeatedly to select the picture mode to BRIGHT, PERSONAL,
NORMAL or SOFT.
HU
E
COLOR TONE
STANDARD
ADJUST
SOUND- for sound quality setting
• Press the MENU button, and then press the P- button repeatedly
to highlight SOUND. The sound setting menu will appear on
screen.
• Press the V+ button to highlight BASS, then press the P+/
P- buttons repeatedly to select BASS, TREBLE, BALANCE or
SOUND MODE.
• Press the V+/ V- buttons repeatedly to adjust the setting.
• When SOUND MODE is selected, press the V+/V- buttons
repeatedly to select the sound effect mode toTHEATER, ODEUM,
NEWS or PERSONAL.
NOTE: In AV, S-VIDEO or SCART mode, the NICAM/A2 can not be
chosen.
CHANNEL- for tuning your TV.
• Press the MENU button, and then press the P+/P- buttons until
the CHANNEL icon is highlighted. The channel setting menu will
appear on screen.
• Press the V+ button to highlight AUTO SCAN, then press the P+/
P- buttons until the desired setting is highlighted: AUTO SCAN,
CHANNEL, COLOR.SYS, SOUND SYS., SKIP, MANUAL or FINE.
• Press the V+/V- buttons repeatedly to adjust the setting.
• When CHANNEL is selected, you can select the channel number
by press V+/V- buttons repeatedly.
• When SKIP is selected, press the V+ repeatedly to turn the
current channel skip ON or OFF.
• When AUTO SCAN is selected, press the V+ button to start
searching and the unit will automatically scan over through all the
channels and stored the active channels into the TV.
• When COLOR .SYS is selected, press the V+/V- buttons
repeatedly to select SECAM, AUTO or PAL. (The TV color system
in UK and German is PAL, in France is Secam, if you are not sure
what is the color system in your area, set it to AUTO)
• When SOUND.SYS is selected, press the V+/V- buttons
repeatedly to select B/G; I; D/K; L. (the sound system in UK is I,
in German is B/G, in France is L. If your are not sure what is the
sound system in your area, press the V+/V- buttons repeatedly
unit the clear sound was be heard.)
• When MANUAL is selected. Press the V+ button to search the
next available TVchannel at upper frequency, press the V- button
the to search the next availableTV channel at lower frequency.
The new channel will be stored in the TV memory automatically.
• When FINE is selected, press the V+/V- buttons repeatedly to
adjust the reception of the current TV channel.
AUTO SCAN
COLOR .
S
Y
S
L
SECAM
ON
S
OUND .
S
Y
S
MANUA
L
40.00MHZ
40.00MHZ
SKI
P
FINE
ADJUST
