LG BBDB-FF02E User manual

.
BBDB-FF02E User Manual
Ver.1.0
FHD/FHD 2Ch. Dashcam
Inside your life !

1... BBDB-FF02E Dashcam A/S Manual
Revision Date Description of Changes Drafter
1.0 Aug.09, 2016 Initial release JH Hong
Record of Revision

2... BBDB-FF02E Dashcam A/S Manual
I. Product Summary
1. Product SPEC 4
2. Name of parts 5
3. Basic function 7

3... BBDB-FF02E Dashcam A/S Manual
Specifications
Resolution/
Number of frames
Front : FHD
Rear : FHD
1920 x 1080(30 fps)
1920 x 1080(30 fps)
Camera
Image sensor Front : 1/2.8” 2.0MP CMOS
Rear : 1/2.7” 2.0MP CMOS
Angle of view Front : 136° / Rear : 120° (Diagonal)
Display
LCD 3.5” TFT LCD with TSP (480 x 320)
Status LED Power/Record(Red/Blue), Security(White)
Video / Audio
Video/Audio codec Video : H.264, Audio : PCM
MIC Internal(Condenser MIC)
Speaker Internal(8 ohm, 1W)
Others
SD memory Micro SD 32GB(~64GB)
Operating voltage DC +12 ~ +24V
Operation temperature -20 ~ +70℃
Standby current Max. 100uA
Shock sensor 3 axis G-sensor
GPS External GPS(Option)
Chapter Ⅰ | Product Summary 1. Specifications

4... BBDB-FF02E Dashcam A/S Manual
Name Function
1. External GPS antenna
connection terminal Connects to external GPS antenna.
2. Rear camera
connection terminal Connects to rear camera.
3. Power cable
connection terminal Connects to power cable.
4. Stand fixation screw Fixates the product by tightening set screw
so that the product doesn’t shake.
5. Stand Used to attach the product to car’s front windshield.
6. Security LED LED flickers in different interval depending on
driving/parking/event.
7. Lens Video signal from product’s front is entered here.
8. Speaker You can listen to voice guide.
9. Force record button Push to record in need of forced recording.
10. Power button Push when the device is powered on to shut the power off.
11. Micro SD card slot Insert micro SD card.
12. LCD screen Check dashcam setting and play video.
13. LED status Displays operation status.
14. Embedded microphone This microphone records sound.
③
⑤
⑦
⑥
⑧
⑨
⑩
⑪
①
④
⑬
⑭⑫
2. Name of parts
Chapter Ⅰ | Product Summary
②

5... BBDB-FF02E Dashcam A/S Manual
Name Function
1. Stand Attaches rear camera to the vehicle.
2. Camera lens Video signal from rear camera is entered here.
3. LED Provided for parking status and supplemental effect.
4. Main body connection
terminal It’s a MINI USB port that connects to the main body.
5. Mirror Switch Mirror switch changes left/right of rear camera. Connect to main
body after setting it, or set it when the main body is turned off.
Chapter Ⅰ | Product Summary
②
③
④
①
⑤
2. Name of parts

6... BBDB-FF02E Dashcam A/S Manual
Operation Condition LED Status Comment
Red Green
Bootup
Bootup Light Light Each lights up then shuts off
immediately
Incorrect
SD card recognition Flicker OFF Red LED flicker
Incorrect camera
recognition OFF Flicker Green LED flicker
Constant
mode
Constant OFF Light
Records in 80MB interval during
driving
(1CH ~80 sec, 2CH ~40 sec)
Event Flicker Light
Records in 40MB interval during
impact
(1CH ~40 sec, 2CH ~20 sec)
Manual
recording Button Flicker Light Records in 40MB interval when manual recording button is pressed
Parking
recording
Event
(Motion/Impact) OFF OFF Records in 40MB interval when motion is detected while parked
Rear camera Left/right reverse - User can select using rear camera
left/right button
▶ Basic Function
※ LCD automatically shuts off during parking mode.
※ Use left/right button of rear camera while power is shut off.
▶ High Temperature Cut off
High temperature cut off is operated when the temperature inside the
car is increased in order to prevent device malfunction and protect
dashcam. Once the system shuts off due to high temperature, it needs
to be rebooted for operation.
Situation Condition
Constant
mode
LCD Shutoff
When the temperature inside your car is raised above LCD
cutoff standard temperature, the device will display
“LCD will shut off to protect the device against high
temperature” and shut off LCD screen.
(Device will not turn on even if you touch LCD screen.)
Device will become operational once temperature is
dropped below standard temperature.
System Shutoff When the temperature inside your car is raised above
system cutoff standard temperature, the device will
display “system will shut off to protect the device against
high temperature” and shut off the system.
The device must be rebooted to operate.
Parking
recording System Shutoff
▶ Security LED Operation Status
Situation Security LED Status Comment
Constant
mode
Constant Front White LED flicker Left/right motion flicker
Event Front White LED OFF -
Parking
recording
Recording Front White LED flicker Left/right motion flicker
Event Front White LED complete flicker 1 sec interval
Chapter Ⅰ | Product Summary 3. Basic function

7... BBDB-FF02E Dashcam A/S Manual
3. Basic function
▶ MAIN MENU
1) Initial screen
This screen is displayed on LCD after bootup.
① ②
③ ④ ⑤
No Function Operation Status
① MENU This MAIN MENU allows you to play video and change
settings.
② GPS Indicates GPS connection status.
(Activated when connected to GPS)
③ Time/Date Displays time and date of the product.
④ Car Speed Displays speed of driving car.
(Activated when connected to GPS)
⑤ Voltage Displays voltage input to the product.
2) Operation status display screen
Chapter Ⅰ | Product Summary

8... BBDB-FF02E Dashcam A/S Manual
▶ MAIN MENU
3) Change channel
Touch the upper right corner of the screen to change the screen being displayed.
How to change channel – Touch the upper right portion of displayed screen to change screen.
Front (full screen)+Rear (upper right 1/4) àRear (full screen) àFront (full screen) à
Front (full screen) + Rear (upper right 1/4)
※ Touch areas other than upper right screen to turn LCD ON/OFF.
Touch
4) Manual recording
When you press manual recording button, the recording will take place in the same manner as
event occurrence, LED status will flicker red LED, and make “ding dong” sound.
Even during operation of motion event or impact event, manual recording takes priority.
(Not supported during parking mode.)
Chapter Ⅰ | Product Summary 3. Basic function

9... BBDB-FF02E Dashcam A/S Manual
▶ MAIN MENU
No Function Operation Status
① Front Video Only displays front video on LCD screen.
②Front/Rear
Video Displays both front/rear video on LCD screen.
③ Rear Video Displays rear video on LCD screen at the same time.
④ LCD OFF Turns OFF the LCD screen.
⑤ ADAS Allows you to turn ADAS function ON/OFF and change the
setting.
⑥ MENU Allows you to see recorded video and change setting for
many items.
1) Select channel
You can select screen displayed on LCD, ADAS, and
MENU.
2) Operation status display screen
Chapter Ⅰ | Product Summary
① ② ③
④⑤⑥
3. Basic function

10... BBDB-FF02E Dashcam A/S Manual
▶ ADAS (Advanced Driver Assistance System)
1) Lane departure warning system
MAIN MENU > ADAS > LDWS
- This function detects lane departure of the vehicle while driving
and alarms the driver with sound.
*Only available when external GPS connected
2) Lane departure warning system MENU
- Operation speed: User can set function to operate while driving
in 60Km, 80Km, or 100Km speed.
- Alarm sound: User can select to turn alarm sound on or off
during lane departure. (When set to OFF, driver will only see the
alarm on the LCD screen.)
- Car: Select the type of your car to allow more accurate lane
departure detection.
Chapter Ⅰ | Product Summary 3. Basic function

11... BBDB-FF02E Dashcam A/S Manual
▶ ADAS (Advanced Driver Assistance System)
3) Condition for error/absence in lane departure warning system function
Under following conditions, lane departure warning system may experience general error/absence in operation.
- If the dashcam is installed in abnormal location, it may not operate properly.
- Device may not function properly during heavy rain/snow.
- Device may not function properly when the windshield wiper is in constant operation.
- If an item above the dashboard is severely reflected on front windshield, the device may not function properly.
- Device may not function properly if there is no lane or the lane cannot clearly be distinguished visually.
- When you depart the lane multiple times within 3 second period, the alarm does not sound continuously.
- Faulty alarm may sound in zigzag road.
- Alarm may not sound when changing lane too slowly.
- Alarm may not sound when changing lane on a road with severed lane such as crossroad.
- Device may not function properly when changing lane on a road with many letters on the floor.
4) Choose vehicle type
ADAS equipped in this dashcam operates based on video information obtained from dashcam camera sensor.
Because the installation location generally changes depending on the car type, this function provides better performance by
applying calibration data.
Therefore, it is recommended that you choose the appropriate vehicle type.
Chapter Ⅰ | Product Summary 3. Basic function

12... BBDB-FF02E Dashcam A/S Manual
▶ ADAS (Advanced Driver Assistance System)
5) Front vehicle start alarm
MAIN MENU > ADAS > FVSA
- When your car stops, the device detects the stop within 3 seconds,
and when the distance between your car and the car in front becomes
far, the device lets the driver know of front car’s departure with alarm
sound and GUI.
* Only operates when connected to GPS.
6) Front vehicle start alarm MENU
- ON/OFF : You can select to use or not use the front car
departure notice.
Chapter Ⅰ | Product Summary 3. Basic function

13... BBDB-FF02E Dashcam A/S Manual
▶ ADAS (Advanced Driver Assistance System)
7) Condition for error/absence in front car departure notice function
Under following conditions, front car departure notice may experience general error/absence in operation
- If the dashcam is installed in abnormal location, it may not operate properly.
- Device may not function properly during heavy rain/snow.
- Device may not function properly when the windshield wiper is in constant operation.
- If an item above the dashboard is severely reflected on front windshield, the device may not function properly
- Driving at night or inside dark tunnel may affect the sensor depending on the level of illumination.
- When strong light such as electronic display or flickering light enters the video, the device may not function properly.
- When you stop more than 3m from the car in front, the device may not function properly.
- When you stop in abnormal position or severely away from the driving lane, the device may not function properly.
- When driving in reverse after parking, the alarm may sound.
- Device may not function properly if the vehicle exhibits severe vibration due to aging.
- When the vehicle shakes due to strong external impact or vibration after stopping, the device may function erroneously.
Chapter Ⅰ | Product Summary 3. Basic function

14... BBDB-FF02E Dashcam A/S Manual
▶ Play files
1) Screen contents
MAIN MENU > MENU > PLAY FILES
- Check Video consists of “normal files, parking files, event files, manual
files” and recorded videos may be displayed on the LCD screen.
2) Play files
- Normal files: Contains the list of video files recorded while driving is
stored.
- Parking files : Contains the list of video files recorded when the device
detected moving car, people, or impact.
- Event files: Contains files that were recorded when the device detected
impact while driving or parked.
- Manual files : Contains files that were recorded by pushing forced
recording button on upper left front area of the product.
*Driving recording file is stored at 80Mbyte, while event and forced
recording files are stores in 40Mbyle size.
Item Ratio
Normal recording 50%
Parking recording 30%
Event recording 10%
Manual recording 5%
* Default storage ratio
Chapter Ⅰ | Product Summary 3. Basic function

15... BBDB-FF02E Dashcam A/S Manual
▶ Play files
3) Recorded file list
Select recording mode to see recorded file list.
* Video file naming method
- Recorded video file name category
4) Play files
Select camera channel you wish to play.
- Select the camera you wish you play between front / rear.
- Use below buttons during video play to select following functions.
-“Home / Previous file/ Play / Pause / Next file / Back”
- “Home ” : Select if you wish to view real-time video while playing
file.
- “Previous file ” : Select if you wish to play file that’s been recorded
before the one you’re currently playing.
- “Play ” : Select when the video is paused to play again.
- “Pause ” : Select if you wish to pause the play.
- “Next file ” : Select if you wish to play file that’s been recorded
after the one you’re currently playing.
File name REC2_20160302_161506.avi
REC 2 20160302 161506
Comment Recorded
video category
Camera channel
1:Front
2:Front+Rear
Video
storage
date
Video storage
time
File name Comment
REC Driving mode constant recording file
EVT Driving mode event recording file
MOT Parking mode motion event recording file
IMP Parking mode event recording file
MAN Manual forced recording file
Chapter Ⅰ | Product Summary 3. Basic function

16... BBDB-FF02E Dashcam A/S Manual
▶ LCD Setting
1) Screen contents
MAIN MENU > MENU > LCD SET
- LCD setting consists of “1MIN TURN OFF, 3MIN TURN OFF,
5MIN TURN OFF, ALWAYS ON” and it allows user to set the
time the LCD screen turns off.
2) LCD setting MENU contents
- “1MIN TURN OFF” : LCD screen will turn off after 1 minute.
- “3MIN TURN OFF” : LCD screen will turn off after 3 minute.
- “5MIN TURN OFF” : LCD screen will turn off after 5 minute.
- “ALWAYS ON” : Screen will always be on while driving.
- The device is set to default setting of “1MIN TURN OFF”.
Chapter Ⅰ | Product Summary 3. Basic function

17... BBDB-FF02E Dashcam A/S Manual
▶ Audio Setting
1) Screen contents
MAIN MENU > MENU > AUDIO SET
- Audio setting consists of “VOICE REC, VOLUME SET, SOUND
EFFECT, VOICE PROMPTS” and it allows the user to set
audio-related items.
2) Audio setting MENU contents (Sound recording)
MAIN MENU > MENU > Audio SET > VOICE REC
- “VOICE REC” : The device will use built-in microphone to record
sound when recording video. You can select “ON, OFF”.
“ON” will record sound when recording video,
“OFF” only records video and not the sound.
Chapter Ⅰ | Product Summary 3. Basic function

18... BBDB-FF02E Dashcam A/S Manual
▶ Audio Setting
3) Audio setting MENU contents (adjust volume)
MAIN MENU > MENU > AUDIO SET > VOLUME SET
- You can select “LOW/MID/HIGH” to adjust volume.
4) Audio setting MENU contents (Sound effect setting)
MAIN MENU > MENU > AUDIO SET > SOUND EFFECT
- You can select between “Sound Effect ON, Sound Effect OFF”
for sound effect setting.
-“ON” will play sound effect when the user touches the screen.
-“OFF” will not play sound effect when the user touches the
screen.
Chapter Ⅰ | Product Summary 3. Basic function

19... BBDB-FF02E Dashcam A/S Manual
▶ Audio Setting
5) Audio setting MENU contents (voice guide)
MAIN MENU > MENU > Audio SET > VOICE PROMPTS
- User can select from “ON, OFF” for voice prompts setting.
-“ON” will provide voice guide at the beginning and end of
recording.
-“OFF” will not provide voice guide at the beginning and end of
recording.
Chapter Ⅰ | Product Summary 3. Basic function
