LG LDS5811 User manual

Smooth Black
Stainless Steel
White
DISHWASHERS
LDS5811
Capacity
• XL Tall Tub cleans up to 16 place settings at once
• Design-A-Rack System allows for maximum
loading flexibility
• Adjustable Upper Rack allows storage of 12"
plates in the upper rack
• Folding Tines & Removable Tines make instant
room for larger items
• 3-1 Cutlery Baskets can be snapped together
or separated for placement in either the Upper
or Lower Racks
• Stemware Holder secures wine glasses, goblets
and champagne flutes but also doubles as a
double decker rack for storage of smaller cups
Performance and Conservation
• Premium LoDecibel Quiet Operation
• SenseClean Washing System
• 6 Wash Cycles with 3 Spray Arms
• Sanitary Cycle
• Half Load Cleaning
• Multi-Level Water Direction
• Detergent and Auto Rinse Dispenser
• Hybrid Drying System
• Slim Direct Drive Motor
• Water Heater
• Disposer/Self Cleaning Filter
• Delay Start up to 12 hours
Style and Design
• Semi-Integrated Electronic Control Panel
• Visible Digital Status Display
• Premium Color Palette of Stainless Steel, White
and Black with Pocket Handle
• Stainless Steel XL Tub
• Nylon Coated Racks and Tines with rounded tips
ENERGYSTAR®qualified models exceed the Department of Energy
standards for energy consumption by at least 25%. LG’s Energy
Star dishwashers allow consumers to save money, energy and protect
the environment.
LDS5811
LGusa.com
DISHWASHERS

Printed in August 2006 SS-LDS5811
LDS5811
CAPACITY
Total Place Settings 16
Design-A-Rack System:
Adjustable Upper Rack 2" height
Maximum Height of Upper Rack Holds up to 12" dishes and stemware
Folding Tines 2 Rows on Top Rack
Removable Tines 2 in Bottom Rack
Stemware Holder Serves as double decker cup holder
Cutlery Baskets 3 detachable baskets with covers
PERFORMANCE
6 Wash Cycles Soak, Power Scrub, Normal, Delicate, Quick Wash, Rinse Only
Options 5
Sanitary Cycle Hi Temp -161°F
Extra Rinse 
Spray Intensity Strong/Medium/Soft
Half Load Cleaning Upper or Lower Rack
Delay Start Up to 12 hours
Child Lock 
Rinse-Aid Refill Indicator 
SenseClean Turbidity System 
Variable Cleaning System 
Spray Arms 3 (top, middle, bottom)
Multi-Level Water Direction Multi-level (5) direct feed, Top Nozzle (Down),
Upper Nozzle (Up/Down), Lower Nozzle (Up/Down)
Food Disposer Stainless Steel
Detergent and Rinse-Aid Dispenser 
Rinse-Aid Refill Indicator 
Drying System Hybrid Condensing
End of Cycle Indicator 
Filter Stainless steel mesh insert with plastic
Self Cleaning 
Water Heater 
Overflow Detector 
120°F Inlet Water Capability 
Direct Drive Motor 
Premium LoDecibel Quiet Operation 
Tub Insulation Metal Cabinet, Damping Sheet, Sound Absorbing
Material (felt). Base: Damping Sheet
Door Insulation Damping Sheet & Felt
Nylon Coated Racks and Tines 
with Rounded Tips
Balanced Door 
STYLE AND DESIGN
Colors White, Black, Stainless Steel
Handle Pocket Handle
Integrated Electronic Controls Semi-Integrated Front Panel
Digital Status Displays Graphic Indicator in the front of door
Tub Material Stainless Steel
ENVIRONMENTALLY FRIENDLY FEATURES
Energy Star 
POWER SOURCE
Ratings/Requirements/Type 120 V/60 Hz, 15 Amps
Circuit Breaker Size* 15 Amps
DIMENSIONS/CLEARANCES/WEIGHT
Dimensions (WxHxD) 23 7/8" x 33 7/8" x 25"
Clearances (WxHxD) 24" x 34" x 25"
Weight 110 lbs.
WARRANTY
1 Year Labor, 2 Year Parts,
5 Year Limited on Control Board and Rack parts,
Lifetime on the Stainless Steel Tub or Liner
UPC CODES
White (WW) 048231 008464
Black (BB) 048231 008471
Stainless Steel (ST) 048231 008488
*With Food Disposer in the same circuit, a 20 AMP circuit breaker is required.
All trademarks are property of their respective owners.
Design and specifications are subject to change without notice.
DISHWASHERS
LG ELECTRONICS INC.
1000 Sylvan Ave., Englewood Cliffs, NJ 07632
800.243.0000 LGusa.com
Semi-Integrated Electronic Panel
with Digital Status Display
Provides a beautiful exterior appearance while keeping
you informed of the cycle status. Electronic controls ensure
precise cleaning for safe dish care.
Premium LoDecibel Quiet System
Ensures you can talk on the phone or listen to the TV or
the radio in your kitchen while the dishwasher is running.
A combination of sound reducing material and the Direct
Drive Motor ensures low noise.
SenseClean System
Measures turbidity in the water with an LED light during the
first rinse. Then water and time is adjusted during the second
cycle based on the need for more or less cleaning. This
provides precise cleaning and water and energy efficiency.
Half Load Cleaning
Allows for cleaning in the upper or the lower racks for
smaller loads. This feature conserves water and electricity.
Multi-Level Water Direction
Sprays water and detergent in five directions for even and
thorough cleaning
.
Hybrid Drying System
Uses a fan and condensation drying. The benefit is faster
drying, reduced spotting and better energy efficiency.
Slim Direct Drive Motor
An innovative system that enables a clean transfer of energy
that is highly reliable, durable, efficient and quiet. The
compact size allows for more usable space in the tub.
