LG DLEX9000 Series User manual

DLEX9000* DLGX9001*
ENGLISHFRANÇAIS
MFL67731071
Rev.17_031521
www.lg.com
DRYER
OWNER'S MANUAL
Read this owner’s manual thoroughly before operating the appliance and keep it handy
for reference at all times.
Copyright © 2017 - 2021 LG Electronics Inc. All Rights Reserved.

2
TABLE OF CONTENTS
3IMPORTANT SAFETY
INSTRUCTIONS
3 WHAT TO DO IF YOU SMELL GAS
5 BASIC SAFETY PRECAUTIONS
6 GROUNDING INSTRUCTIONS
6 SAFETY INSTRUCTIONS FOR INSTALLATION
7 SAFETY INSTRUCTIONS FOR STEAM
FUNCTIONS
8 SAFETY INSTRUCTIONS FOR CONNECTING
ELECTRICITY
9SPECIAL FEATURES
10 PRODUCT OVERVIEW
10 Parts
10 Accessories
11 Control Panel Features
12 Display
13 INSTALLATION
13 Installation Overview
14 Installation Location Requirements
14 Clearances
16 Leveling the Dryer
17 Reversing the Door
19 Installing the Side Vent Kit
20 Venting the Dryer
22 Connecting the Inlet Hose
23 Connecting Gas Dryers
25 Connecting Electric Dryers
26 Final Installation Check
27 Installation Test (Duct Check)
29 OPERATION
29 Operating the Dryer
30 Cycle Guide
31 Sorting Loads
31 Loading the Dryer
31 Check the Lint Filter before Every Load
31 Storage Under the Lid
32 Using the Lid
33 Cycle Modifier Buttons
34 Special Functions
35 Custom Program
35 Steam Functions
36 Steam Cycle Guide
37 SMART FUNCTIONS
37 LG ThinQ Application
37 Smart Diagnosis™
40 MAINTENANCE
40 Regular Cleaning
41 TROUBLESHOOTING
41 Before Calling for Service
44 SPECIFICATIONS
45 WARRANTY
TABLE OF CONTENTS

3
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Safety for a Dryer
wWARNING
Fire Hazard
Failure to follow safety warnings exactly could result in serious injury,
death or property damage.
Do not install a booster fan in the exhaust duct.
Install all clothes dryer in accordance with the installation instructions
of the manufacturer of dryer.
wWARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury,
death or property damage.
Do not store or use gasoline or other flammable vapors and liquids in•
the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS•
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any phone in your
building.
- Clear the room, building or area of all occupants.
- Immediately call your gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer,•
service agency or your gas supplier.

4
wWARNING - RISK OF FIRE
Install the clothes dryer according to the manufacturer’s instructions
and local codes.
Clothes dryer installation must be performed by a qualified installer.•
Do not install a clothes dryer with flexible plastic venting materials.•
If flexible metal (foil type) duct is installed, it must be of a specific
type identified by the appliance manufacturer as suitable for use with
clothes dryers. Flexible venting materials are known to collapse, be
easily crushed, and trap lint. These conditions will obstruct clothes
dryer airflow and increase the risk of fire.
To reduce the risk of severe injury or death, follow all installation•
instructions.
IMPORTANT SAFETY INSTRUCTIONS
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey
all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word DANGER, WARNING, or CAUTION.
These words mean:
wDANGER
You will be killed or seriously injured if you don’t immediately follow instructions.
wWARNING
You can be killed or seriously injured if you don’t follow instructions.
wCAUTION
You may be slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell
you what can happen if the instructions are not followed.
w

5
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
wWARNING
For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, or electric
shock, or to prevent property damage, injury to persons, or death.
BASIC SAFETY PRECAUTIONS
wWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions,
including the following:
• Read all instructions before using the dryer.
• Before use, the dryer must be properly installed as
described in this manual.
• Do not place items exposed to cooking oils in your
dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause
a load to catch fire.
• Do not dry articles that have been previously cleaned
in, washed in, soaked in, or spotted with gasoline, dry-
cleaning solvents, or other flammable or explosive
substances as they give off vapors that could ignite or
explode.
• Do not reach into the dryer if the drum or any other
part is moving.
• Do not repair or replace any part of the dryer
or attempt any servicing unless specifically
recommended in this owner’s manual or in published
user-repair instructions that you understand and have
the skills to carry out.
• Do not tamper with controls.
• Before the dryer is removed from service or discarded,
remove the door to the drying compartment.
• Do not allow children to play on or in the dryer. Close
supervision of children is necessary when the dryer is
used near children.
• Do not use fabric softeners or products to eliminate
static unless recommended by the manufacturer of
the fabric softener or product.
• Do not use heat to dry articles containing foam
rubber or similarly textured rubber-like materials.
• Keep area around the exhaust opening and adjacent
surrounding areas free from the accumulation of lint,
dust, and dirt.
• The interior of the dryer and exhaust vent should be
cleaned periodically by qualified service personnel.
• Do not install or store the dryer where it will be
exposed to the weather.
• Always check the inside of the dryer for foreign
objects.
• Clean lint screen before or after each load.
• Do not store plastic, paper, or clothing that may
burn or melt on top of the dryer during operation.
• Do not place items exposed to cooking oils in your
dryer. Items contaminated with cooking oils may
contribute to a chemical reaction that could cause a
load to catch fire.
To reduce the risk of fire due to contaminated loads,
the final part of a tumble dryer cycle occurs without
heat (cool down period). Avoid stopping a tumble
dryer before the end of the drying cycle unless all
items are quickly removed and spread out so that the
heat is dissipated.
• Do not let children or pets climb inside the dryer drum.
• Do not put living animals such as pets inside the
product.
• Do not put any part of your body, such as your hands
or feet, or metal objects under the product.
• Do not let your hand get pinched when opening or
closing the dryer door.
IMPORTANT SAFETY INSTRUCTIONS

6
IMPORTANT SAFETY INSTRUCTIONS
• Properly ground dryer to conform with all
governing codes and ordinances. Follow details in
the installation instructions. Electric shock can result if
the dryer is not properly grounded.
• Before use, the dryer must be properly installed as
described in this manual. Electric shock can result if
the dryer is not properly grounded.
• Install and store the dryer where it will not be
exposed to temperatures below freezing or
exposed to the weather.
• All repairs and servicing must be performed
by an authorized servicer unless specifically
recommended in this owner’s manual. Use only
authorized factory parts. Failure to follow this
warning can cause serious injury, fire, electric shock, or
death.
• To reduce the risk of electric shock, do not install
the dryer in humid spaces. Failure to follow this
warning can cause serious injury, fire, electric shock, or
death.
• Connect to a properly rated, protected, and sized
power circuit to avoid electrical overload. Improper
power circuit can melt, creating electric shock and/or
fire hazard.
• Remove all packing items and dispose of all
shipping materials properly. Failure to do so can
result in death, explosion, fire, or burns.
• Place dryer at least 18 inches above the floor for
a garage installation. Failure to do so can result in
death, explosion, fire, or burns.
• Keep all packaging from children. Packaging
material can be dangerous for children. There is a risk
of suffocation.
• Do not install near another source of heat such as
a stove, cooking oven. Failure to do so can cause
deform, smoke and fire.
• Do not place candles, smoking materials, or other
flammables on top of the product. Dripping wax,
smoke, or fire can result.
• Remove all protective vinyl film from the product.
Failure to do so can cause product damage, smoke or
fire.
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
wWARNING
For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, or electric
shock, or to prevent property damage, injury to persons, or death.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance for electric current. This appliance must be equipped with a cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in accordance with all local codes and ordinances.
Do not modify the plug provided with the appliance. If it will not fit the outlet, have a proper outlet installed by
a qualified electrician. This appliance must be connected to a grounded metal, permanent wiring system or an
equipment-grounding conductor must be run with the circuit conductors and connected to the equipment-
grounding terminal or lead on the appliance. Electric shock can result if the dryer is not properly grounded.
SAFETY INSTRUCTIONS FOR INSTALLATION
wWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions,
including the following:

7
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
wWARNING
For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, or electric
shock, or to prevent property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR INSTALLATION
wWARNING
To reduce the risk of injury to persons, follow all industry recommended safety procedures including the use of long
sleeved gloves and safety glasses. Failure to follow all of the safety warnings in this manual could result in property
damage, injury to persons, or death.
Exhaust/Ducting:
SAFETY INSTRUCTIONS FOR STEAM FUNCTIONS
wWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions,
including the following:
• Gas dryers MUST be exhausted to the outside.
Failure to follow these instructions can result in fire or
death.
• The dryer exhaust system must be exhausted
to the outside of the dwelling. If the dryer is not
exhausted outdoors, some fine lint and large
amounts of moisture will be expelled into the
laundry area. An accumulation of lint in any area of
the home can create a health and fire hazard.
• Use only rigid, semi-rigid, or flexible metal 4-inch
diameter ductwork inside the dryer cabinet or for
exhausting to the outside. Use of plastic or other
combustible ductwork can cause a fire. Punctured
ductwork can cause a fire if it collapses or becomes
otherwise restricted in use or during installation.
• Ductwork is not provided with the dryer, and you
should obtain the necessary ductwork locally. The
end cap should have hinged dampers to prevent
backdraft when the dryer is not in use. Failure to
follow these instructions can result in fire or death.
• The exhaust duct must be 4 inches (10.2 cm) in
diameter with no obstructions. The exhaust duct
should be kept as short as possible. Make sure
to clean any old ducts before installing your new
dryer. Failure to follow these instructions can result in
fire or death.
• Rigid or semi-rigid metal ducting is recommended
for use between the dryer and the wall. In special
installations when it is impossible to make a
connection with the above recommendations, a UL-
listed flexible metal transition duct may be used
between the dryer and wall connection only. The
use of this ducting will affect drying time. Failure to
follow these instructions can result in fire or death.
• DO NOT use sheet metal screws or other fasteners
which extend into the duct that could catch lint and
reduce the efficiency of the exhaust system. Secure
all joints with duct tape. For complete details, follow
the Installation Instructions. Failure to follow these
instructions can result in fire or death.
IMPORTANT SAFETY INSTRUCTIONS
• Do not open the dryer door during steam cycles.
Failure to follow these instructions can result in a burn
hazard.
• Do not dry articles that have been previously
cleaned in, washed in, soaked in, or spotted with
gasoline, dry-cleaning solvents, or other flammable
or explosive substances as they give off vapors
that could ignite or explode. Failure to follow these
instructions can result in fire or death.
• Do not fill the steam feeder with gasoline, dry-
cleaning solvents, or other flammable or explosive
substances. Failure to follow these instructions can
result in fire or death.
• Do not touch the steam nozzle in the drum during
or after the steam cycle. Failure to follow these
instructions can result in a burn hazard.
• Do not fill the steam feeder with hot water (over 86
˚F/30 ˚C). Failure to follow these instructions can result
in a burn hazard.

8
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
wWARNING
For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, or electric
shock, or to prevent property damage, injury to persons, or death.
SAFETY INSTRUCTIONS FOR CONNECTING ELECTRICITY
wWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions,
including the following:
SAVE THESE INSTRUCTIONS
• Do not, under any circumstances, cut or remove
the ground prong from the power cord. To prevent
injury to persons or damage to the dryer, the electrical
power cord must be plugged into a properly grounded
outlet.
• For personal safety, this dryer must be properly
grounded. Failure to do so can result in electric shock
or injury.
• Refer to the installation instructions in this manual
for specific electrical requirements for your model.
Failure to follow these instructions can create an
electric shock hazard and/or a fire hazard.
• This dryer must be plugged into a properly
grounded outlet. Electric shock can result if the
dryer is not properly grounded. Have the wall
outlet and circuit checked by a qualified electrician
to make sure the outlet is properly grounded.
Failure to follow these instructions can create an
electric shock hazard and/or a fire hazard.
• The dryer should always be plugged into its own
individual electrical outlet which has a voltage
rating that matches the rating plate. This provides
the best performance and also prevents overloading
house wiring circuits which could cause a fire hazard
from overheated wires.
• Never unplug your dryer by pulling on the power
cord. Always grip plug firmly and pull straight out
from the outlet. The power cord can be damaged,
resulting in a risk of fire and electric shock.
• Repair or replace immediately all power cords that
have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage
along its length or at either end. The power cord can
melt, creating an electric shock and/or fire hazard.
• When installing or moving the dryer, be careful not
to pinch, crush, or damage the power cord. This will
prevent injury and prevent damage to the dryer from
fire and electric shock.
IMPORTANT SAFETY INSTRUCTIONS

9
SPECIAL FEATURES
EASY-TO-USE CONTROL PANEL
Rotate the cycle selector knob to select the desired dry cycle. Add cycle options or adjust settings with the touch
of a button.
EASY-ACCESS REVERSIBLE DOOR
The wide-opening door provides easy access for loading and unloading. The door hinge can be reversed to adjust
for installation location.
ULTRA-CAPACITY STAINLESS STEEL DRUM WITH DRUM LIGHT
The ultra-large stainless steel drum offers superior durability. The drum is equipped with a light that illuminates
when the dryer door is opened and turns off when the door is closed.
STEAM FUNCTIONS
LG’s steam technology injects fabrics with a swirling jet of hot steam to refresh clothes. Simply select the STEAM
FRESH™ cycle, or add a steam option to selected cycles.
FLOW SENSE™ DUCT BLOCKAGE SENSING SYSTEM INDICATOR
The FLOW SENSE™ duct blockage sensing system detects and alerts you to restrictions in the installed household
ductwork that reduce exhaust airflow through the dryer. If you see the alert: Clean or repair the ducts to remove
the restrictions. Keep your ducts clean to help increase efficiency and reduce long drying times caused by blocked
ducts.
LG ThinQ
Remote Start – Use a smart phone to control your appliance remotely. Also, it is possible to monitor your cycle
operation so you know how much time is left in the cycle.
Smart Grid – Smart appliances can communicate with local utility companies that are equipped with Smart Grid
equipment.
Push Alerts – When the cycle is complete or the appliance has problems, you will receive a push message.
Downloaded – Download new and special cycles that are not included with the machine.
Smart DiagnosisTM – Should you experience technical difficulty, your appliance has the capability of transmitting
data by phone to the Customer Information Center to diagnosis the problem.
Setting – Allows you to set various options on the appliance and in the application.
Energy Monitoring – Your dryer energy usage is affected by the cycle and settings so you may see some changes
in energy usage from one cycle to another.
C
E
R
T
I
F
I
E
D
D
E
S
I
G
N
SPECIAL FEATURES

10
PRODUCT OVERVIEW
Parts
PRODUCT OVERVIEW
NOTE
• Contact LG Customer Service at 1-800-243-0000 (1-888-542-2623 in Canada) if any accessories are missing.
• For your safety and for extended product life, use only authorized components. The manufacturer is not
responsible for product malfunction or accidents caused by the use of separately purchased unauthorized
components or parts.
• The images in this manual may be different from the actual components and accessories, which are subject to
change by the manufacturer without prior notice for product improvement purposes.
Leveling
feet
Reversible
Door
Top Plate
Power Cord
Location
(Gas
Models)
Gas
Connection
Location
(Gas Models)
Power
Cord
Location
(Electric
Models)
Exhaust
Duct
Outlet
Inlet Valve
Included accessories
Inlet Hose-Long
(Steam Models)
Inlet Hose-Short
(Steam Models)
Accessories
Side vent kit
(sold separately)
Kit No. 383EEL9001B
Drying rack
Optional accessories

11
Control Panel Features
Following are instructions for starting and using your new dryer. Please refer to specific sections of this
manual for more detailed information.
wWARNING : To reduce the risk of fire, electric shock, or injury to persons, read this entire manual,
including the Important Safety Instructions, before operating this dryer.
Button Description
POWER ON/OFF BUTTON
- Press to turn the dryer ON. To turn the dryer off, press and hold more than 0.4
seconds.
NOTE : Pressing the ON/OFF button during a cycle will cancel that cycle and any
load settings will be lost.
CYCLE SELECTOR KNOB
- Turn this knob to select the desired cycle. Once the desired cycle has been
selected, the standard presets will be shown in the display. On MANUAL DRY
cycles, these settings can be adjusted using the cycle modifier buttons anytime
before starting the cycle.
START/PAUSE BUTTON
- Press and hold this button more than 0.5 seconds to start the selected cycle. If
the dryer is running, use this button to pause the cycle without losing the current
settings.
NOTE : If you do not press the Start/Pause button to resume a cycle within four
minutes, the dryer turns off automatically.
MORE TIME/LESS TIME BUTTONS
- To adjust the drying time, use these buttons with MANUAL DRY, TIME DRY, and
STEAM FRESH™ cycles, as well as the REDUCE STATIC and EASY IRON options. Press
the MORE TIME button to increase the selected manual cycle time by a minute;
press LESS TIME to decrease the cycle time by a minute.
CYCLE MODIFIER BUTTONS
- Use these buttons to modify the default cycle settings for the selected cycle. The
current settings are shown in the display. Press the button for that option to view
and select other settings.
OPTION BUTTONS
- The OPTION buttons allow you to select additional cycle options. Certain buttons
marked with an asterisk also allow you to activate special functions by pressing
and holding the button for 3 seconds.
STEAM FUNCTIONS
- LG’s steam technology injects fabrics with a swirling jet of hot steam to refresh
clothes, reduce static, and make ironing easier. Simply select the Steam Fresh™
cycle, or you can add a steam option to selected cycles.
Operation
PRODUCT OVERVIEW

12
Display
The display shows the settings, estimated time remaining, options, and status messages for your dryer.
When the dryer is turned on, the light in the display will illuminate.
wWARNING : To reduce the risk of fire, electric shock, or injury to persons, read this entire manual,
including the Important Safety Instructions, before operating this dryer.
Display and Icons Description
ESTIMATED TIME REMAINING
- When the Start button is pressed and held, the dryer will display the estimated
(SENSOR DRY) or set time (TIME DRY) remaining, and begin tumbling.
NOTE : The cycle time on SENSOR DRY cycles may fluctuate as the dryer
recalculates drying time for optimal results
CYCLE COMPLETION INDICATOR WITH CHECK FILTER REMINDER
- This portion of the display shows which stage of the drying cycle is currently
underway (CLEAN FILTER, DRY, or COOL).
CHILD LOCK INDICATOR
- When CHILD LOCK is set, the CHILD LOCK indicator will appear and all buttons are
disabled except the POWER button. This prevents children from changing settings
while the dryer is operating
CLEAN FILTER REMINDER
- The display will show CLEAN FILTER when the dryer is turned on as a reminder to
clean the lint filter. It turns off when the Hold to Start button is pressed.
CUSTOM PROGRAM
- If you have a special combination of settings that you use frequently, you can
save these settings as a CUSTOM PROGRAM.
FLOW SENSE™ DUCT BLOCKAGE SENSING SYSTEM INDICATOR
- The FLOW SENSE™ duct blockage sensing system detects and alerts you to
blockages in the ductwork that reduce exhaust flow from the dryer. This improves
operating efficiency and helps minimize service calls, saving you money.
WI-FI CONNECTION INDICATOR
- When the appliance is connected to the internet through a home Wi-Fi network,
this indicator appears.
PRODUCT OVERVIEW

13
INSTALLATION
Installation Overview
Checking and
choosing the proper
location
Leveling the dryer Venting the Dryer
Installation test
Connecting Gas Dryers
(Gas Dryer Type)
Plugging in the power cord
and grounding
Test run
Press and hold
120V
240V(USA)
230V(CANADA)
INSTALLATION
(Gas) (Electric)

14
Installation Location Requirements
wWARNING
Read all installation instructions completely before installing and operating your dryer! It is important that
you review this entire manual before installing and using your dryer. Detailed instructions concerning electrical
connections, gas connections, and exhaust requirements are provided on the following pages.
Do not operate your dryer at temperatures below 45°F (7°C). At lower temperatures, the dryer might not shut off
at the end of an automatic cycle. This can result in longer drying times. The dryer must not be installed or stored in
an area where it will be exposed to water and/or weather. Check code requirements. Some codes limit, or do not
permit, installation of the dryer in garages, mobile homes or sleeping quarters. Contact your local building inspector.
Clearances
INSTALLATION SPACING FOR RECESSED AREA OR CLOSET INSTALLATION
The following clearances are recommended for this dryer. Although this dryer has been tested for 1inch (2.5cm)
clearance on the sides and rear, the recommended clearances should be considered for the following reasons:
• A location that allows for proper exhaust installation.
A gas dryer must be exhausted to the outdoors. See
Venting the dryer.
• A grounded electrical outlet located within 2 ft.
(61 cm) of either side of the dryer. See Connecting
Electric Dryers.
• A sturdy floor to support the total dryer weight of 200
lbs (90.7 kg). The combined weight of a companion
appliance should also be considered.
• No other fuel-burning appliance can be installed in the
same closet as a dryer.
• Additional clearance should be considered for ease of
installation and servicing.
• Additional clearances might be required for wall, door
and floor moldings.
• Additional clearance should be considered on all sides
of the dryer to reduce noise transfer.
For closet installation, with a door, minimum
ventilation openings in the top and bottom of the
door are required. Louvered doors with equivalent
ventilation openings are acceptable.
• Companion appliance clearances should also be
considered.
24 in.
2*
(155 cm
2
)
18" min.*
(45.7 cm)
1"*
(2.5 cm)
5"**
(12.7 cm)
48 in.
2*
(310 cm
2
)
14" max.*
(35.6 cm)
3"
*
(7.6 cm)
3"
*
(7.6 cm)
1"
(2.5 cm)
29"
(73.7 cm)
1"
(2.5 cm)
1"*
(2.5 cm)
5"**
(12.7 cm)
14" max.*
(35.6 cm)
18" min.*
(45.7 cm)
0"
(0 cm)
40
7/8
"
(103.9 cm)
1"*
(2.5 cm)
29"
(73.7 cm)
1"*
(2.5 cm)
7"* (17.8 cm)
9"*
(22.9 cm)
7"* (17.8 cm)
1"**
(2.5 cm)
29"
(73.7 cm)
5"*
(12.7 cm) (2.5 cm)
(2.5 cm)
48 in.
2
*
(310 cm
2
)
3"* (7.6 cm)
3"* (7.6 cm)
1"* (2.5 cm)
24 in.
2
*
(155 cm
2
)
6"* (15.2 cm)
81.6 "
(207.2 cm)
29"
(73.7 cm)
1"
(2.5 cm)
1"
(2.5 cm)
5 "**
(14 cm)
2/4
33
3/8
"
(84.8 cm)
33
3/8
"
(84,8 cm)
33
3/8
"
(84.8 cm)
24 in.
2*
(155 cm
2
)
18" min.*
(45,72 cm)
1"*
(2,5 cm)
5"**
(12,7 cm)
48 in.
2*
(310 cm
2
)
14" max.*
(35,6 cm)
3"
*
(7,6 cm)
3"
*
(7,6 cm)
1"
(2,5 cm)
27"
(68,6 cm)
1"
(2,5 cm)
1"*
(2,5 cm)
5"**
(12,7 cm)
14" max.*
(35,6 cm)
18" min.*
(45,72 cm)
0"
(0 cm)
38" min.
(96,52 cm)
1"*
(2,5 cm)
27"
(68,6 cm)
1"*
(2,5 cm)
30"
(76,1 cm)
30"
(76,1 cm)
7"* (17,8 cm)
9"*
(22,9 cm)
7"* (17,8 cm)
5"**
(12,7 cm)
27"
(68,6 cm)
1"*
(2,5 cm) (2,5 cm)
(2,5 cm)
48 in.
2
*
(310 cm
2
)
3"* (7,6 cm)
3"* (7,6 cm)
1"* (2,5 cm)
24 in.
2
*
(155 cm
2
)
6"* (15,2 cm)
76"
(193 cm)
27"
(68,6 cm)
1"
(2,5 cm)
1"
(2,5 cm)
5 "**
(14 cm)
1/2
30"
(76,1 cm)
24 in.
2*
(155 cm
2
)
18" min.*
(45,7 cm)
1"*
(2,5 cm)
5"**
(12,7 cm)
48 in.
2*
(310 cm
2
)
14" max.*
(35,6 cm)
3"
*
(7,6 cm)
3"
*
(7,6 cm)
1"
(2,5 cm)
29"
(73,7 cm)
1"
(2,5 cm)
1"*
(2,5 cm)
5"**
(12,7 cm)
14" max.*
(35,6 cm)
18" min.*
(45,7 cm)
0"
(0 cm)
40
7/8
"
(103,9 cm)
1"*
(2,5 cm)
29"
(73,7 cm)
1"*
(2,5 cm)
33
3/8
"
(84,8 cm)
7"* (17,8 cm)
9"*
(22,9 cm)
7"* (17,8 cm)
1"**
(2,5 cm)
29"
(73,7 cm)
5"*
(12,7 cm) (2,5 cm)
(2,5 cm)
48 in.
2
*
(310 cm
2
)
3"* (7,6 cm)
3"* (7,6 cm)
1"* (2,5 cm)
24 in.
2
*
(155 cm
2
)
6"* (15,2 cm)
81,6 "
(207,2 cm)
29"
(73,7 cm)
1"
(2,5 cm)
1"
(2,5 cm)
5 "**
(14 cm)
2/4
33
3/8
"
(84,8 cm)
33
3/8
"
(84,8 cm)
NOTE
• Floor must be level, with a maximum slope of 1 inch (2.5 cm) under entire dryer. Clothes may not tumble
properly, and automatic sensor cycles may not operate correctly if dryer is not level.
• For a garage installation, you will need to place the dryer at least 18 inches (46 cm) above the floor. If using a
pedestal, you will need 18 inches (46 cm) to the bottom of the dryer.
NOTE
There should be at least a little space around the dryer (or any other appliance) to eliminate the transfer of
vibration from one to the other. With enough vibration, the appliances will make noise or touch each other
causing paint damage and making even more noise.
INSTALLATION

15
Clearances (cont.)
RECOMMENDED INSTALLATION SPACING FOR CABINET INSTALLATION
• For cabinet installation with a door, minimum ventilation openings in the top of the cabinet are required.
*Required spacing
**For side or bottom venting,
2 inches (5.1 cm) spacing is allowed.
24 in.
2*
(155 cm
2
)
18" min.*
(45.7 cm)
1"*
(2.5 cm)
5"**
(12.7 cm)
48 in.
2*
(310 cm
2
)
14" max.*
(35.6 cm)
3"
*
(7.6 cm)
3"
*
(7.6 cm)
1"
(2.5 cm)
29"
(73.7 cm)
1"
(2.5 cm)
1"*
(2.5 cm)
5"**
(12.7 cm)
14" max.*
(35.6 cm)
18" min.*
(45.7 cm)
0"
(0 cm)
40
7/8
"
(103.9 cm)
1"*
(2.5 cm)
29"
(73.7 cm)
1"*
(2.5 cm)
7"* (17.8 cm)
9"*
(22.9 cm)
7"* (17.8 cm)
1"**
(2.5 cm)
29"
(73.7 cm)
5"*
(12.7 cm) (2.5 cm)
(2.5 cm)
48 in.
2
*
(310 cm
2
)
3"* (7.6 cm)
3"* (7.6 cm)
1"* (2.5 cm)
24 in.
2
*
(155 cm
2
)
6"* (15.2 cm)
81.6"
(207.2 cm)
29"
(73.7 cm)
1"
(2.5 cm)
1"
(2.5 cm)
5 "**
(14 cm)
2/4
33
3/8
"
(84.8 cm)
33
3/8
"
(84,8 cm)
33
3/8
"
(84.8 cm)
24 in.
2*
(155 cm
2
)
18" min.*
(45,72 cm)
1"*
(2,5 cm)
5"**
(12,7 cm)
48 in.
2*
(310 cm
2
)
14" max.*
(35,6 cm)
3"
*
(7,6 cm)
3"
*
(7,6 cm)
1"
(2,5 cm)
27"
(68,6 cm)
1"
(2,5 cm)
1"*
(2,5 cm)
5"**
(12,7 cm)
14" max.*
(35,6 cm)
18" min.*
(45,72 cm)
0"
(0 cm)
38" min.
(96,52 cm)
1"*
(2,5 cm)
27"
(68,6 cm)
1"*
(2,5 cm)
30"
(76,1 cm)
30"
(76,1 cm)
7"* (17,8 cm)
9"*
(22,9 cm)
7"* (17,8 cm)
5"**
(12,7 cm)
27"
(68,6 cm)
1"*
(2,5 cm) (2,5 cm)
(2,5 cm)
48 in.
2
*
(310 cm
2
)
3"* (7,6 cm)
3"* (7,6 cm)
1"* (2,5 cm)
24 in.
2
*
(155 cm
2
)
6"* (15,2 cm)
76"
(193 cm)
27"
(68,6 cm)
1"
(2,5 cm)
1"
(2,5 cm)
5 "**
(14 cm)
1/2
30"
(76,1 cm)
24 in.
2*
(155 cm
2
)
18" min.*
(45,7 cm)
1"*
(2,5 cm)
5"**
(12,7 cm)
48 in.
2*
(310 cm
2
)
14" max.*
(35,6 cm)
3"
*
(7,6 cm)
3"
*
(7,6 cm)
1"
(2,5 cm)
29"
(73,7 cm)
1"
(2,5 cm)
1"*
(2,5 cm)
5"**
(12,7 cm)
14" max.*
(35,6 cm)
18" min.*
(45,7 cm)
0"
(0 cm)
40
7/8
"
(103,9 cm)
1"*
(2,5 cm)
29"
(73,7 cm)
1"*
(2,5 cm)
33
3/8
"
(84,8 cm)
7"* (17,8 cm)
9"*
(22,9 cm)
7"* (17,8 cm)
1"**
(2,5 cm)
29"
(73,7 cm)
5"*
(12,7 cm) (2,5 cm)
(2,5 cm)
48 in.
2
*
(310 cm
2
)
3"* (7,6 cm)
3"* (7,6 cm)
1"* (2,5 cm)
24 in.
2
*
(155 cm
2
)
6"* (15,2 cm)
81,6"
(207,2 cm)
29"
(73,7 cm)
1"
(2,5 cm)
1"
(2,5 cm)
5 "**
(14 cm)
2/4
33
3/8
"
(84,8 cm)
33
3/8
"
(84,8 cm)
INSTALLATION

16
Leveling the Dryer
wWARNING
• To reduce the risk of injury to persons, adhere to all
industry recommended safety procedures including
the use of long sleeved gloves and safety glasses.
Failure to follow this warning can cause serious injury
or death.
• The appliances are heavy. Two or more people are
required when installing the dryer. Failure to follow
this warning can cause serious injury or death.
To ensure that the dryer provides optimal drying
performance, it must be level. To minimize vibration,
noise, and unwanted movement, the floor must be a
perfectly level, solid surface.
1. Position the dryer in the final location. Place a level
across the top of the dryer.
• All four leveling feet must rest solidly on the floor.
Gently push on the top corners of the dryer to make
sure that the dryer does not rock from corner to corner.
If you are installing the dryer on the optional pedestal,
you must use the leveling feet on the pedestal to
level the dryer. The dryer leveling feet should be fully
retracted.
2. Use an adjustable wrench to turn the leveling feet.
Turn clockwise to raise the dryer or counterclockwise
to lower it. Raise or lower the leveling feet until the
dryer is level from side to side and front to back.
Make sure that all four leveling feet are in firm contact
with the floor.
Level
Leveling Feet
NOTE
Adjust the leveling feet only as far as necessary to
level the dryer. Extending the leveling feet more than
necessary can cause the dryer to vibrate.
INSTALLATION

17
Tools Needed: flat blade screwdriver, Phillips screwdriver
Before Starting
1. Unplug the machine or turn off the power supply at
the main circuit before reversing the door. Open the
dryer door.
wWARNING
Be sure to support the weight of the door before
removing the hinge screws.
Removing the Door
1. While supporting the door, remove the four hinge
screws.
2. Carefully pull the door away from the cabinet to reveal
the wire harness behind the hinge at the top. Depress
the side lock tab to disconnect the wire harness
connector. The twist tie and cap should prevent the
wire harness from pulling back into the cabinet.
3. Remove the door from the cabinet cover. Set the door
face down on a protected work surface.
Cap R
Reversing the Door’s Hinge and Strike
1. Remove the four screws on the right door frame
(handle and strike), lift it off, and set the parts aside.
(The two center strike screws are longer.)
2. Remove the four screws on the left door frame (hinge
assembly).
3. Carefully lift out the hinge assembly, revealing the
wire harness connector at the top of the hinge.
Depress the side lock tab to disconnect the wire
harness connector.
4. Rotate the hinge assembly 180 degrees and connect
the wire harness to the connector in the bottom right
side of the door.
5. Install the hinge assembly in the recess on the right
side of the door, tucking the wire harness in the corner
to make room. Insert and tighten the four screws.
6. Rotate the handle removed in step one 180 degrees
and install it on the left side of the door using the two
shorter screws. Use the longer screws to mount the
door strike in the center.
Reversing the Door
wWARNING
THE DRYER DOOR IS VERY LARGE AND HEAVY. Failure
to follow the instructions below can result in damage
to the dryer, property damage or injury to persons.
• To avoid damage to the dryer or the door, support
the door with a stool or box that fits under the
door, or have an assistant support the weight of
the door.
• Always reverse the door BEFORE stacking the
dryer on top of the washer.
• Avoid dropping the door to avoid damage to the
door or the floor.
INSTALLATION
Frame L Frame R

18
Reversing the Cabinet Components
1. Remove the two screws and the latch assembly from
the left side of the opening.
2. Rotate the latch assembly and remount it on the right
side of the opening with the two screws.
3. Switch the two caps. Untie the twist tie and remove
the small cap from the side of the wire harness on the
top right of the cabinet. Make sure the wire harness
does not slip back into the cabinet.
4. Remove the left cap by gently prying it up with a flat
blade screwdriver, being careful not to scratch the
paint. Disconnect the wire harness attached to the
cap by pressing the tabs on either side.
5. Attach the left cap to the wire harness on the top right
of the cabinet. Snap the cap into place.
6. Attach the twist tie and the small cap removed in step
1 to the side of the wire harness on the bottom left of
the cabinet. The wire harness will be attached to the
harness in the door.
7. Unscrew the four decorative screws from the left side
of the cabinet and insert them into the matching
holes on the right side of the cabinet.
Latch
Cap L
Cap L
wWARNING
Be sure to support the weight of the door while
inserting the hinge screws.
Preparing to Remount the Door
1. While supporting the door, move the door into
position with the hinge on the left side.
2. Connect the wire harness from the hinge to the
connector on the lower left side of the cabinet.
Harness
Connector
Hinge Hole
Mounting the Door
1. Align the hinge with the mounting holes.
2. While supporting the door, fasten the four hinge
screws.
Final Check
1. Check that the door closes and latches properly.
INSTALLATION

19
Installing the Side Vent Kit
wWARNING
• Use a heavy metal vent.
• Do not use plastic or thin foil duct.
• Clean old ducts before installing this dryer.
• To reduce the risk of injury to persons, adhere to all
industry recommended safety procedures including
the use of long sleeved gloves and safety glasses.
• Failure to follow all of the safety warnings in this
manual could result in property damage, injury to
persons, or death.
Your new dryer is shipped to vent to the rear.
It can also be configured to vent to the bottom or side
(right-side venting is not available on gas models).
An adapter kit, part number 383EEL9001B, may be
purchased from an LG retailer. This kit contains the
necessary duct components to change the dryer vent
location.
1. Remove the rear exhaust duct retaining screw. Pull
out the exhaust duct.
OPTION 1: SIDE VENTING
2. Press the tabs on the knockout and carefully remove
the knockout for the desired vent opening (right-
side venting is not available on gas models). Press the
adapter duct onto the blower housing and secure to
the base of the dryer as shown.
3. Preassemble a 4-inch (10.2 cm) elbow to the next
4-inch (10.2 cm) duct section, and secure all joints
with duct tape. Be sure that the male end of the elbow
faces AWAY from the dryer. Insert the elbow/duct
assembly through the side opening and press it onto
the adapter duct. Secure it in place with duct tape.
Be sure that the male end of the duct protrudes 1½
inches (3.8 cm) to connect the remaining ductwork.
Attach the cover plate to the back of the dryer with
the included screw.
OPTION 2: BOTTOM VENTING
2. Press the adapter duct onto the blower housing and
secure it to the base of the dryer as shown.
3. Insert the 4-inch (10.2 cm) elbow through the rear
opening and press it onto the adapter duct. Be sure
that the male end of the elbow faces down through
the hole in the bottom of the dryer. Secure it in place
with duct tape.
Attach the cover plate to the back of the dryer with
the included screw.
Rear
Exhaust Duct
Retaining
Screw
Elbow
Cover
Plate
Knockout
Bracket
Adapter
Duct
Bracket
Adapter
Duct
Elbow
Cover
Plate
12/4”
(3.8 cm)
INSTALLATION

20
Venting the Dryer
wWARNING
To reduce the risk of fire, electric shock, or injury to persons when using this appliance, follow basic precautions,
including the following:
• Do not crush or collapse ductwork. Failure to follow
these instructions can result in fire or death.
• Do not allow ductwork to rest on or contact sharp
objects. Failure to follow these instructions can result
in fire or death.
• If connecting to existing ductwork, make sure it
is suitable and clean before installing the dryer.
Failure to follow these instructions can result in fire or
death.
• Venting must conform to local building codes.
Failure to follow these instructions can result in fire or
death.
• Gas dryers MUST exhaust to the outdoors.
Failure to follow these instructions can result in fire or
death.
• Use only 4-inch (10.2 cm) rigid, semi-rigid, or
flexible metal ductwork inside the dryer cabinet
and for venting outside. Failure to follow these
instructions can result in fire or death.
• To reduce the risk of fire, combustion, or
accumulation of combustible gases, DO NOT
exhaust dryer air into an enclosed and unventilated
area, such as an attic, wall, ceiling, crawl space,
chimney, gas vent, or concealed space of a
building. Failure to follow these instructions can result
in fire or death.
• To reduce the risk of fire, DO NOT exhaust the dryer
with plastic or thin foil ducting.
Failure to follow these instructions can result in fire or
death.
• The exhaust duct must be 4 inches (10.2 cm) in
diameter with no obstructions. The exhaust duct
should be kept as short as possible. Make sure
to clean any old ducts before installing your new
dryer. Failure to follow these instructions can result in
fire or death.
• Rigid or semirigid metal ducting is recommended
for use between the dryer and the wall. In special
installations when it is impossible to make a
connection with the above recommendations, a
UL-listed flexible metal transition duct may be used
between the dryer and wall connection only. The
use of this ducting will affect drying time. Failure to
follow these instructions can result in fire or death.
• DO NOT use sheet metal screws or other fasteners
which extend into the duct that could catch lint and
reduce the efficiency of the exhaust system. Secure
all joints with duct tape. Failure to follow these
instructions can result in fire or death.
• To maximize operating results, please observe the
duct length limitations noted in the chart on the
next page. Failure to follow these instructions can
result in fire or death.
• Ductwork is not provided with the dryer. You
should obtain the necessary ductwork locally. The
end cap should have hinged dampers to prevent
backdraft when the dryer is not in use. Failure to
follow these instructions can result in fire or death.
• The total length of flexible metal duct shall not
exceed 8 ft. (2.4 m)
• In Canada, only those foil-type flexible ducts,
if any, specifically identified for use with the
appliance by the manufacturer shall be used. In the
United States, only those foil-type flexible ducts, if any,
specifically identified for use with the appliance by the
manufacturer and that comply with the Outline for
Clothes Dryer Transition Duct, Subject 2158A, shall be
used.
INSTALLATION
