OWNER'S MANUAL
DRYER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
DVH5-08W / DVH45-08W / DVH45-08WG / DVH9-08B / DVH9-09B / DVH9-09W
MFL71424355
Rev.07_121621
www.lg.com
Copyright © 2020-2021 LG Electronics Inc. All Rights Reserved.

TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE...........................................................3
WARNING............................................................................................................3
INSTALLATION
Parts and Specifications ....................................................................................9
Installation Location Requirements ..............................................................11
Leveling the Appliance ....................................................................................12
Stacking Instructions .......................................................................................13
OPERATION
Operation Overview.........................................................................................16
Preparing the Clothes......................................................................................17
Control Panel ....................................................................................................19
Programme Table ............................................................................................21
Extra Options and Functions ..........................................................................25
SMART FUNCTIONS
LG ThinQ Application.......................................................................................28
Smart Diagnosis ...............................................................................................30
MAINTENANCE
Cleaning after Every Dry .................................................................................32
Cleaning the Appliance Periodically ..............................................................34
Care in Cold Climates.......................................................................................37
TROUBLESHOOTING
Before Calling for Service................................................................................39

3
SAFETY INSTRUCTIONS
ENGLISH
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as
described below.
Safety Messages
WARNING
WARNING
To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic precautions,
including the following.
Technical Safety
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
This symbol is displayed to indicate matters and operations
that can cause risks. Read the part with this symbol carefully
and follow the instructions in order to avoid risks.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the appliance.

4
SAFETY INSTRUCTIONS
• Children should be supervised to ensure that they do not play with
the appliance.
• Do not dry unwashed items in the appliance.
• Fabric softeners, or similar products, should be used as specified by
the fabric softener instructions.
• Remove all objects from pockets such as lighters and matches.
• Never stop the appliance before the end of the drying cycle unless all
items are quickly removed and spread out so that the heat is
dissipated.
• The appliance is not to be used if industrial chemicals have been used
for cleaning.
• Items that have been soiled with substances such as cooking oil,
vegetable oil, acetone, alcohol, petroleum, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot water
with an extra amount of detergent before being dried in the
appliance.
• Do not drink the condensed water. Failure to do so may result in food-
borne illnesses.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agents or similarly qualified person in
order to avoid a hazard.
• The lint filter must be cleaned frequently.
• Lint must not to be allowed to accumulate around the appliance.
• Do not spray dry cleaning detergent directly onto the appliance or
use the appliance to dry clothes left with dry cleaning detergent.
• Do not dry clothes stained with oil substances. Oil substances
(including edible oils) stained on clothes cannot be completely
removed even after washing with water.
• The appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly
switched on and off by a utility.
• Remove clothes from the product immediately when drying is
complete or the power is turned off during the drying process.
Leaving clothes that has been dried in the appliance unattended

5
SAFETY INSTRUCTIONS
ENGLISH
could result in fire. Clothes not removed from the appliance after
drying could result in fire. Remove clothes immediately after drying,
and then hang or lay the clothes flat to cool.
• Oil-affected items can ignite spontaneously, especially when exposed
to heat sources such as in a tumble dryer. The items become warm,
causing an oxidation reaction in the oil. Oxidation create heat. If the
heat cannot escape, the items can become hot enough to catch fire.
Piling, stacking or storing oil-affected items can prevent heat from
escaping and so create a fire hazard.
• If it is unavoidable that fabrics that contain vegetable or cooking oil
or have been contaminated by hair care products be placed in a
tumble dryer they should first be washed in hot water with extra
detergent – this will reduce, but not eliminate, the hazard.
• This appliance is intended to be used in household only.
Maximum Capacity
The maximum capacity in some cycles for clothes to be dried is:
WARNING - To avoid a fire
Installation
• Make sure the appliance is properly installed, grounded, and
adjusted by qualified service personnel according to the installation
instructions.
DVH5-08W / DVH45-08W /
DVH45-08WG / DVH9-08B DVH9-09B / DVH9-09W
8 kg 9 kg
Do not wash or dry clothes or items that have any
contaminants of flammable solvents or substances.
Do not clean the product with, or expose it to,
flammable substances.

6
SAFETY INSTRUCTIONS
• Never attempt to operate the appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug.
• This appliance should only be transported by two or more people
holding the appliance securely.
• Do not install the appliance in a damp and dusty place. Do not install
or store the appliance in any outdoor area, or any area that is subject
to weathering conditions such as direct sunlight, wind, rain, or
temperatures below freezing.
• If the power cord is damaged or the hole of the outlet socket is loose,
do not use the power cord and contact an authorized service centre.
• Do not use multiple outlet sockets, an extension power cable or
double adapter with this appliance.
• Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows fitted with foam
rubber pads should not be dried in the appliance.
• This appliance must not be installed behind a lockable door, a sliding
door or a door with a hinge on the opposite side to that of the
appliance, in such a way that a full opening of the appliance door is
restricted.
• This appliance must be earthed via the power cord. In the event of
malfunction or breakdown, grounding will reduce the risk of electric
shock by providing a path of least resistance for electric current.
• This appliance is equipped with a power cord having an equipment-
grounding earthing pin and a grounding power plug. The power plug
must be plugged into an appropriate outlet socket that is installed
and grounded in accordance with all local codes and ordinances.
• Improper connection of the equipment-grounding conductor can
result in risk of electric shock. Check with a qualified electrician or
service personnel if you are in doubt as to whether the appliance is
properly grounded.
• Do not modify the power plug provided with the appliance. If it does
not fit the outlet, have a proper outlet installed by a qualified
electrician.
• This appliance must not be stored or used in any outdoor location.

7
SAFETY INSTRUCTIONS
ENGLISH
Operation
• Do not attempt to separate any panels or disassemble the appliance.
Do not apply any sharp objects to the control panel in order to
operate the appliance.
• Do not repair or replace any part of the appliance. All repairs and
servicing must be performed by qualified service personnel unless
specifically recommended in this Owner’s Manual. Use only
authorized factory parts.
• Keep the area underneath and around the appliance free of
combustible materials such as lint, paper, rags, chemicals, etc.
• Do not put animals, such as pets into the appliance.
• Do not leave the appliance door open. Children may hang on the door
or crawl inside the appliance, causing damage or injury.
• Never reach into the appliance while it is operating. Wait until the
drum has completely stopped.
• Do not put in, wash or dry articles that have been cleaned in, washed
in, soaked in, or spotted with combustible or explosive substances
(such as wax, oil, paint, gasoline, degreasers, drycleaning solvents,
kerosene, vegetable oil, cooking oil, etc.). Improper use can cause fire
or explosion.
• In case of flood, disconnect the power plug and contact the LG
Electronics customer information centre.
• Do not push down on the door, when the appliance door is open.
• Do not touch the door during a high temperature programme.
• Do not use flammable gas and combustible substances (benzene,
gasoline, thinner, petroleum, alcohol, etc.) near the appliance.
• If the drain hose or inlet hose is frozen during winter, use it only after
thawing.
• Keep all washing detergents, softener and bleach away from
children.
• Do not touch the power plug or the appliance controls with wet
hands.
• Do not bend the power cable excessively or place a heavy object on it.

8
SAFETY INSTRUCTIONS
Maintenance
• Securely plug the power plug into the mains outlet socket after
completely removing any moisture and dust from the pins.
• Disconnect the appliance from the power supply before cleaning the
appliance. Setting the controls to the OFF or stand by position does
not disconnect this appliance from the power supply.
• Never unplug the appliance by pulling on the power cable. Always
grip the power plug firmly and pull straight out from the outlet
socket.
• Do not spray water inside or outside the appliance to clean it.
Disposal
• Before discarding an old appliance, unplug it and cut off the power
cable directly behind the appliance to prevent misuse.
• Dispose of all packaging materials (such as plastic bags and
styrofoam) away from children. The packaging materials can cause
suffocation.
• Remove the door before disposing of or discarding this appliance to
avoid the danger of children or small animals getting trapped inside.

9
INSTALLATION
ENGLISH
INSTALLATION
Parts and Specifications
NOTE
• Appearance and specifications may vary without notice to improve the quality of the appliance.
Front View
Available Accessories
Please contact LG Electronics Customer Information Centre or visit the LG Website at http://www.lg.com
for purchase.
a Water collection tank
b Control panel
c Door
d Drain Tube
Condensing Drain Hose Drain Hose Holder
Elbow Bracket for Securing Drain Hose Dry Rack

10
INSTALLATION
NOTE
• The included accessories vary depending on the model you purchased.
Specifications
Asterisk(s) means model variant and can be varied (0-9) or (A-Z).
Dimension(mm)
Stacking Kit
Description Value
Model DVH45-08* / DVH5-08* / DVH9-08* / DVH9-09*
Power supply 220 - 240 V~, 50 Hz
Product weight 56 kg
Allowable temperature 5 - 35 ℃
W 600 D 690D" 1115
H 850 D' 615
W
D’
D’’
D
H
