LG FDV708 Series User manual

OWNER'S MANUAL
DRYER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
FDV708* / FDV909*
MFL71736662
Rev.00_051721
www.lg.com
Copyright © 2021 LG Electronics Inc. All Rights Reserved.

TABLE OF CONTENTS
This manual may contain images or
content that may be different from the
model you purchased.
This manual is subject to revision by the
manufacturer.
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE...........................................................3
WARNING............................................................................................................3
CARING FOR THE ENVIRONMENT....................................................................9
INSTALLATION
Parts and Specifications ..................................................................................10
Installation Place Requirements ....................................................................11
Leveling the Appliance ....................................................................................12
Stacking Instructions .......................................................................................14
OPERATION
Operation Overview.........................................................................................17
Preparing the Clothes......................................................................................18
Control Panel ....................................................................................................20
Programme Table ............................................................................................22
Option Programmes and Extra Functions ....................................................26
SMART FUNCTIONS
LG ThinQ Application.......................................................................................29
Smart Diagnosis ...............................................................................................31
MAINTENANCE
Cleaning after Every Dry .................................................................................33
Cleaning the Appliance Periodically ..............................................................35
TROUBLESHOOTING
Before Calling for Service................................................................................37
APPENDIX
Product Fiche....................................................................................................43

3
SAFETY INSTRUCTIONS
ENGLISH
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
The following safety guidelines are intended to prevent unforeseen
risks or damage from unsafe or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as
described below.
Safety Messages
WARNING
WARNING
To reduce the risk of explosion, fire, death, electric shock, injury or
scalding to persons when using this product, follow basic precautions,
including the following
Technical Safety
• In the appliance enclosure or in the built-in structure, keep
ventilation openings clear of obstruction. If not, it can result in a fire.
This symbol is displayed to indicate matters and operations
that can cause risks. Read the part with this symbol carefully
and follow the instructions in order to avoid risks.
WARNING
This indicates that the failure to follow the instructions can
cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can
cause the minor injury or damage to the appliance.
WARNING - To avoid a fire
Risk of Fire and Flammable Materials

4
SAFETY INSTRUCTIONS
• This appliance contains R290, a refrigerant that is environmentally
friendly but flammable. Do not damage the refrigerant circuit, keep
an open frame and ignition sources away from the appliance.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children of less than 3 years should be kept away unless continuously
supervised.
• Do not dry unwashed items in the appliance.
• Fabric softeners, or similar products, should be used as specified by
the fabric softener instructions.
• Remove all objects from pockets such as lighters and matches.
• Never stop the appliance before the end of the drying cycle unless all
items are quickly removed and spread out so that the heat is
dissipated.
• The appliance is not to be used if industrial chemicals have been used
for cleaning.
• Items that have been soiled with substances such as cooking oil,
vegetable oil, acetone, alcohol, petroleum, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot water
with an extra amount of detergent before being dried in the
appliance.
• Do not drink the condensed water. Failure to do so may result in food-
borne illnesses.
• If the supply cord is damaged, it must be replaced by the
manufacturer or its service agents or similarly qualified person in
order to avoid a hazard.
• The lint filter must be cleaned frequently.
• Lint must not to be allowed to accumulate around the appliance.

5
SAFETY INSTRUCTIONS
ENGLISH
• Do not spray dry cleaning detergent directly onto the appliance or
use the appliance to dry clothes left with dry cleaning detergent.
• Do not dry clothes stained with oil substances. Oil substances
(including edible oils) stained on clothes cannot be completely
removed even after washing with water.
• The appliance must not be supplied through an external switching
device, such as a timer, or connected to a circuit that is regularly
switched on and off by a utility.
• Remove clothes from the appliance immediately when drying is
complete or the power is turned off during the drying process.
Leaving clothes that have been dried in the appliance unattended
could result in fire. Clothes removed from the appliance after drying
could result in fire. Remove clothes immediately after drying, and
then hang or lay the clothes flat to cool.
• This appliance is intended to be used in household only.
Maximum Capacity
• The maximum capacity in some cycles for clothes to be dried is:
• The recommended maximum capacity for each drying programme
may differ. To get good dry results, please refer to Programme Table
in OPERATION chapter for further details.
Installation
• Make sure the appliance is properly installed, grounded, and
adjusted by qualified service personnel according to the installation
instructions.
• Never attempt to operate the appliance if it is damaged,
malfunctioning, partially disassembled, or has missing or broken
parts, including a damaged cord or plug.
• This appliance should only be transported by two or more people
holding the appliance securely.
FDV708* FDV909*
8 kg 9 kg

6
SAFETY INSTRUCTIONS
• Do not install the appliance in a damp and dusty place. Do not install
or store the appliance in any outdoor area, or any area that is subject
to weathering conditions such as direct sunlight, wind, rain, or
temperatures below freezing.
• Tighten the drain hose to avoid separation.
• If the power cord is damaged or the hole of the socket outlet is loose,
do not use the power cord and contact an authorized service centre.
• Do not plug multiple socket outlets, an extension power cable or
adapter with this appliance.
• Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows fitted with foam
rubber pads should not be dried in the appliance.
• This appliance must not be installed behind a lockable door, a sliding
door or a door with a hinge on the opposite side to that of the
appliance, in such a way that a full opening of the appliance door is
restricted.
• This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current.
• This appliance is equipped with a power cord having an equipment-
grounding conductor and a grounding power plug. The power plug
must be plugged into an appropriate socket outlet that is installed
and grounded in accordance with all local codes and ordinances.
• Improper connection of the equipment-grounding conductor can
result in risk of electric shock. Check with a qualified electrician or
service personnel if you are in doubt as to whether the appliance is
properly grounded.
• Do not modify the power plug provided with the appliance. If it does
not fit the outlet, have a proper outlet installed by a qualified
electrician.
Operation
• Do not attempt to separate any panels or disassemble the appliance.
Do not apply any sharp objects to the control panel in order to
operate the appliance.

7
SAFETY INSTRUCTIONS
ENGLISH
• Do not repair or replace any part of the appliance. All repairs and
servicing must be performed by qualified service personnel unless
specifically recommended in this Owner’s Manual. Use only
authorized factory parts.
• Keep the area underneath and around the appliance free of
combustible materials such as lint, paper, rags, chemicals, etc.
• Do not put animals, such as pets into the appliance.
• Do not leave the appliance door open. Children may hang on the door
or crawl inside the appliance, causing damage or injury.
• Never reach into the appliance while it is operating. Wait until the
drum has completely stopped.
• Do not put in, wash or dry articles that have been cleaned in, washed
in, soaked in, or spotted with combustible or explosive substances
(such as wax, oil, paint, gasoline, degreasers, drycleaning solvents,
kerosene, vegetable oil, cooking oil, etc.). Improper use can cause fire
or explosion.
• In case of flood, disconnect the power plug and contact the LG
Electronics customer information centre.
• Do not push down on the door, when the appliance door is open.
• Do not touch the door during a high temperature programme.
• Do not use flammable gas and combustible substances (benzene,
gasoline, thinner, petroleum, alcohol, etc.) near the appliance.
• If the drain hose or inlet hose is frozen during winter, use it only after
thawing.
• Keep all washing detergents, softener and bleach away from
children.
• Do not touch the power plug or the appliance controls with wet
hands.
• Do not bend the power cable excessively or place a heavy object on it.
Maintenance
• Securely plug the power plug in the socket outlet after completely
removing any moisture and dust.

8
SAFETY INSTRUCTIONS
• Disconnect the appliance from the power supply before cleaning the
appliance. Setting the controls to the OFF or stand by position does
not disconnect this appliance from the power supply.
• Never unplug the appliance by pulling on the power cable. Always
grip the power plug firmly and pull straight out from the socket
outlet.
• Do not spray water inside or outside the appliance to clean it.
Disposal
• Before discarding an old appliance, unplug it. Cut off the cable
directly behind the appliance to prevent misuse.
• Dispose of all packaging materials (such as plastic bags and
styrofoam) away from children. The packaging materials can cause
suffocation.
• Remove the door before disposing of or discarding this appliance to
avoid the danger of children or small animals getting trapped inside.

9
SAFETY INSTRUCTIONS
ENGLISH
CARING FOR THE ENVIRONMENT
Disposal of Your Old Appliance
Disposal of the Packaging Material
• Dispose of the packaging waste according to recycling symbols of
material types. Put the packaging waste in relevant containers to
recycle it.
This dryer contains refrigerant gases
R290 (GWP: 3): 0.145 kg Hermetically sealed.
• This crossed-out wheeled bin symbol indicates that waste
electrical and electronic products (WEEE) should be
disposed of separately from the municipal waste stream.
• Old electrical products can contain hazardous substances
so correct disposal of your old appliance will help prevent
potential negative consequences for the environment and
human health. Your old appliance may contain reusable
parts that could be used to repair other products, and
other valuable materials that can be recycled to conserve
limited resources.
• You can take your appliance either to the shop where you
purchased the product, or contact your local government
waste office for details of your nearest authorised WEEE
collection point. For the most up to date information for
your country please see www.lg.com/global/recycling.

10
INSTALLATION
INSTALLATION
Parts and Specifications
NOTE
• Appearance and specifications may vary without notice to improve the quality of the appliance.
Front View
Available Accessories
Please contact LG Electronics Customer Information Centre or visit the LG Website at http://www.lg.com
for purchase.
a Condensing Drain Hose and Hose Holder
b Dry Rack
c Stacking Kit
NOTE
• The included accessories vary depending on the model you purchased.
a Water Container
b Control Panel
c Door

11
INSTALLATION
ENGLISH
Specifications
Asterisk(s) means model variant and can be varied (0-9) or (A-Z).
Installation Place
Requirements
Before installing the appliance, check the following
information to make sure that the appliance
should be installed in a correct place.
Installation Location
WARNING
• Do not install the appliance around a heat
source. The rear side of the appliance must be
well ventilated. Failure to follow these
instructions may result in problems.
• The appliance is not designed for maritime use
or for use in mobile installation such as caravans,
aircraft and etc.
• Do not install the appliance as a built-in
appliance. It is not suitable for built-in purpose.
NOTE
• For better drying performance, keep the rear of
the appliance away from the wall.
• Make sure that the location where the appliance
will be installed meets a minimum clearance
conditions.
• Install the appliance on a flat hard floor.
Allowable slope under the appliance is 1 degree.
• Never try to correct any unevenness in the floor
with pieces of wood, cardboard or similar
materials under the appliance.
• Install the appliance in a location where service
engineers are easily accessible in the event of a
breakdown.
• Do not install the appliance next to high-
temperature appliances such as refrigerator,
oven or stove, and etc. It can cause poor drying
performance and delay programme duration. It
also adversely affect the proper functioning of
the compressor.
• Do not install the appliance where there is a risk
of frost or dust. The appliance may not be able to
operate properly or may be damaged by
freezing of condensed water in the pump and
drain hose.
• With the appliance installed, adjust all four feet
using a spanner to ensure the appliance is
stable, and a clearance of approximately 20 mm
is left between the top of the appliance and the
underside of any work-top.
Ventilation
• Alcove or under counter
- Ensure airflow of 3.17 m
3
/mm through the
appliance.
Model FDV708* / FDV909*
Power supply 220 - 240 V~, 50 Hz
Dimension (Width X Depth X Height) 600 mm X 690 mm X 850 mm
Product weight 56 kg
Allowable temperature 5 - 35 ℃
5 cm 1 cm 1 cm

12
INSTALLATION
• Cupboard
- Cupboard door must have 2 (louvered)
opening, each have a minimum area of 387
cm
2
, located 8 cm from bottom and top of the
door.
NOTE
• Make sure that air circulation around the
appliance is not impeded by carpets, rugs, and
etc.
Ambient Temperature
• Do not install the appliance in rooms where
freezing temperatures may occur. Frozen hoses
may burst under pressure. The reliability of the
electronic control unit may be impaired at
temperatures below freezing point.
NOTE
• If the appliance is delivered in winter and
temperatures are below freezing, place the
appliance at room temperature for a few hours
before putting it into operation.
• The appliance performs best at a room
temperature of 23 ℃.
Electrical Connection
• Do not use an extension cord or double adapter.
• Do not overload the outlet with more than one
appliance.
• Connect the appliance to an earthed socket in
accordance with current wiring regulations.
• The appliance must be positioned a place close
to outlet socket so that the plug is easily
accessible.
• Outlet socket must be within 1.5 meters of either
side of the location of the appliance.
NOTE
• Always unplug the appliance after use.
Leveling the Appliance
Checking Leveling
Leveling the appliance prevents unnecessary noise
and vibration. Check whether the appliance is
perfectly level after installation.
• If the appliance rocks when pushing the top
plate of the appliance diagonally, adjust the feet
again.
NOTE
• Timber or suspended type flooring may
contribute to excessive vibration and unbalance.
Re-enforcement or bracing of the timber floor
may need to be considered to stop or reduce
excessive noise and vibration.
• Do not install the appliance on any elevated
surface, stand or plinth as it can become
unstable and fall causing serious injury and
damage.
Adjusting and Leveling the
Appliance
When the appliance is not perfectly level, turn the
adjustable feet until the appliance no longer
wobbles.
• Turn the adjustable feet clockwise to raise or
turn the adjustable feet counterclockwise to
lower from front-to-back, side-to-side and
corner-to-corner.
Reversing the door
You can reverse the door for your convenience.
WARNING
• Do not reverse the door while the appliance is
stacked on a washing machine.

13
INSTALLATION
ENGLISH
• Before removing the hinge screws, have an
assistant support the weight of the door. The
door could fall on the floor due to the weight of
the door.
• For safety reasons, two or more people need to
work together to reverse the door.
NOTE
• The appearance of the screws varies and the
screws must be inserted differently depending
on the position. Make sure the screw is properly
selected before tightening.
1 Open the door and remove 2 screws on the
door hinge
a . After removing the screws, put
the door down carefully from the cabinet
b
with the front side facing down to the floor.
WARNING
• Remove the lower screw first. The door may fall
on to the floor due to its weight and the door can
be damaged.
2 Remove 8 screws on the hinge assembly c
from the door.
• There are 6 screws on the front and 2 screws
on the side.
3 Remove the 3 screws from the door latch
assembly
d which is fixed between the door
and the hinge assembly, and then remove the
screw which is fixed on the door hook.
4 Swap the position of the hinge assembly c and
the door latch assembly
d and then tighten
the screws in reverse order.
• Tighten the screw in their proper position
referring from steps 2 to 4.

14
INSTALLATION
5 Remove the door catch e from the appliance
frame by removing 2 screws and then
assemble them on the opposite side.
6 Remove the 2 decorative screws from the
appliance frame and then assemble them on
opposite side.
7 Install the door with the screws removed in
step 1 and then check the door closes properly.
Stacking Instructions
The appliance can be placed on top of an LG front
load washing machine and securely fixed with a
stacking kit. This installation must be conducted by
qualified service personnel to ensure it has been
installed correctly.
The qualified personnel will ensure you have the
correct stacking kit for your model of LG front load
washing machine and will ensure it is firmly fixed.
For these reasons, expert fitting is essential.
NOTE
• Some models are not sold with all of the
available accessories, you may need to purchase
the LG stacking kit first if it was not provided with
your model. Please contact LG Electronics
Customer Information Centre or visit the LG
Website at http://www.lg.com for purchase.
• Stacking on the LG SIGNATURE washing machine
is unavailable .
Stacking Kit
In order to stack the appliance, an LG stacking kit is
required.
a Dryer
b LG Front Load Washing Machine
The appliance may only be stacked on top of an LG
front load washing machine. Do not attempt to
stack the appliance on any other washing machine,
as it could result in damage, injury or property
damage.
Installation Procedure
WARNING
• For safety reasons, installation procedure should
be performed by two or more qualified service
personnel.

15
INSTALLATION
ENGLISH
• The weight of the appliance and the height of the
installation makes the installation procedure too
risky for one person.
• Incorrect installation can cause serious
accidents.
• Do not operate if the appliance is not properly
stacked.
NOTE
• The stacking kit should be aligned depending on
the depth of the washing machine. (When you
open the door or look at the side of the washing
machine, you can find the dimension
information of your washing machine at the
label.)
• For
Type A , it must be assembled with 550R or
550L on upper part.
• For
Type B , it must be assembled with 600R or
600L on upper part.
*1 The depth of the washing machine
1 Place the appliance on the top of an LG front
load washing machine.
2 Remove the 2 screws from the bottom of the
rear cover on each side.
3 Align the LG stacking kit holes and the rear
cover holes in a line.
• In case of that the depth of the washing
machine is 550 mm or more and 599 mm or
less
• In case of that the depth of the washing
machine is 600 mm or more and 650 mm or
less
4 Fasten the 2 screws that were removed earlier
from the appliance to the stacking kit.
5 Use the 4 screws in the accessory box (16 mm)
to assemble the washing machine rear cover
and stacking kit.
6 The procedure for the opposite side will be the
same.
How to align LG stacking kit to the appliance
Type A Type B
550 mm 1 the
depth
*1
1 599 mm
600 mm
1 the
depth
*1
1 650 mm

16
INSTALLATION
Installing the Optional Drain
Hose
Normally, condensed water is pumped up to the
water container where water is collected until
manually emptied. Water can also be drained out
directly to a mains drain, especially when the
appliance is stacked on top of a washing machine.
With the connecting elbow or T piece of the mains
drain hose, simply change the water path and re-
route to the drainage facility as below:
1 Separate the anti-backflow lid a and the water
container hose
b from the connecting elbow
or T piece.
2 Attach the anti-backflow lid a to the head of
the connecting elbow or T piece and then
connect the optional drain hose
c to the
opposite side of the connecting elbow or T
piece.
CAUTION
• If the optional drain hose is installed in a way
that leaves it bent or pinched, drainage may not
function properly.
b
a
a
c

17
OPERATION
ENGLISH
OPERATION
Operation Overview
Using the Appliance
Before the first cycle, set the appliance to dry for 5
minutes to warm up the drum. Open the door
between loads the first few times you use the
appliance to allow any odours from the interior of
the appliance to disperse.
Children must be supervised so that they do not
climb inside the drum.
1 Ensure the lint filter and water container are
clean.
• Open the door and ensure the lint filter is
clean. When the filter is full with lint, drying
times will be longer than usual.
• Pull out the water container and empty the
condensed water. When the water container
is full, the appliance may stop during the
cycle.
NOTE
• In some instance, LED window may display E
icon to inform you that the water container is
full. If this occurs, empty the water container.
2 Place the clothes into the drum after sorting
and close the door.
• Push the clothes deep into the drum so that
the clothes keeps away from the door seal.
When the clothes get stuck between the
door and seal, they may get damaged while
drying.
• The clothes should be sorted by fabric types
and dryness level.
• All strings and attached belts of clothes
should be well tied and fixed before being
put into the drum.
3 Press the Power button to turn the appliance
on.
• Depending on the models, the
Power button
may light up to indicate that the appliance is
ready for dry.
4 Choose a drying programme by turning the
programme selector knob.
5 Press the Start/Pause button to start the
drying programme.
• When you press the button, the appliance
ventilates the inside of the drum for 10
seconds in order to get the appliance ready
for drying operation.
NOTE
• The appliance washes lint, which builds up onto
the surface of the condenser, automatically
using water that is condensed from the clothes
during operation.

18
OPERATION
NOTE
• The frequency of cleaning condenser may vary
depending on the size and the initial moisture
amount of the clothes.
6 After the drying programme has finished, open
the door and unload the clothes.
CAUTION
• Be careful! The drum inside may still be hot.
7 Press the Power button to turn the appliance
off.
8 Clean the lint filter and empty the water
container.
9 To help reduce odours from forming, the
dryer’s door can be left open or slightly ajar for
a short period of time if possible to help
ventilate the drum after use.
WARNING
• For safety reasons, do not allow children or
animals to enter the appliance. It may cause
damage or injury.
NOTE
• The final part of a tumble dry cycle occurs
without heat (cool down cycle) to ensure that the
clothes are left at a temperature that ensures
the clothes will not be damaged.
• A high atmospheric temperature and a small
room may both increase drying time as well as
energy consumption.
Preparing the Clothes
NOTE
• Do not overload the appliance for the best
drying performance and most efficient energy
usage.
Checking the clothes before
loading
CAUTION
• Check that the clothes are not stuck between
appliance and door, otherwise the clothes may
get damaged while drying.
• Observe the maximum load capacity on the
programme table for the relevant drying
programme to get optimum drying results.
Overloading gives a poor drying result and
causes unnecessary creasing.
• Do not load soaking wet clothes into the
appliance. It will cause an increasing of drying
time and energy consumption. Make sure that
the clothes are spun thoroughly before loading.
• A mixed fabric load can cause the drying time to
be extended and the time remaining in the
display to pause during active drying. The
remaining time will then continue when it is the
actual time that remains.
• Make sure to empty all pockets. Items such as
nails, hair clips, matches, pens, coins and keys
can damage both your appliance and clothes.
• Remove loose belts and close zippers, hooks and
strings to make sure that these items do not
snag other clothes.
Sorting the Clothes
Clothes have their own fabric care labels, so drying
according to the fabric care label is recommended.
Sort the clothes into size and type of fabric and
then prepare the clothes according to the symbols
on the fabric care labels.

19
OPERATION
ENGLISH
Woollens
• Dry woollens on the Wool programme. Be sure
to follow fabric care label symbols first. Wool
may not be completely dried from the cycle, so
do not repeat drying. Pull woollens to their
original shape and dry them flat.
Woven and Loopknit Materials
• Some woven and loopknit materials may shrink,
depending on quality.
Non-Iron and Synthetics
• Do not overload the appliance. Take out non-
Iron items as soon as the appliance stops to
reduce creases.
Baby Clothes and Night Gowns
• Always check fabric care labels.
Rubber and Plastics
• Do not dry any items made from or containing
rubber or plastics such as:
- Aprons, Bibs and Chair Covers
- Curtains and Table Clothes
- Bathmats
Fiberglass
• Do not dry fiberglass items in the appliance.
Glass particles left in the appliance may be
subsequently picked up by your clothes in later
cycles.
Checking the Fabric Care Label
The symbols on the fabric care label tell you about
the fabric content of your clothes and how it should
be dried.
Symbol Description
Dry
Tumble Dry
Permanent Press / Crease
Resistant
Gentle / Delicate
Do not Tumble Dry
Do not Dry
High Heating
Medium Heating
Low Heating
No Heating / Air
Line Dry / Hang to dry
Drip Dry
Dry Flat
In the Shade
Symbol Description

20
OPERATION
Control Panel
Control Panel Features
Description
a
Power On/Off button
• Press the Power button to turn power on and off.
• Press the
Power button to cancel the Delay End function.
b
Programme Selector
• Programmes are available according to the clothing type.
• The lamp will light up to indicate the selected programme.
c
Start/Pause Button
• This Start/Pause button is used to start or pause a dry cycle.
• When in pause, the power is turned off automatically after a certain time for safety
reasons.
d
Extra Options and Functions / Additional Programme Buttons
• Use these buttons to select the desired options for the selected programme. Not all
options are available in each programme.
Remote Start
• With the LG ThinQ app, you can use a smartphone to control your appliance remotely.
• In order to use the Remote Start function, refer to
SMART FUNCTIONS .
Wi-Fi
• Press and hold Delay End button for 3 seconds to initiate the connection of the appliance
to the
LG ThinQ application.
e
Time and Status Display
• The display shows the settings, estimated remaining time, options, and status messages.
When the appliance is turned on, the default settings in the display will illuminate.
