LG 42LH300C User manual

47L 300C
42L 300C
47" class (47.0" diagonal)
42" class (42.0" diagonal)
lcd tv
LCD Commercial Widescreen
w w w. LG c o m m e r c i a l . c o m
P BLIC DISPLAY SETTINGS - CLONING CAPABLE
EcoSmart™
Energy Saving Levels
RoHS COMPLIANT
DYNAMIC CONTRAST RATIO
50,000:1
NATIVE DISPLAY RESOL TION
1920 x 1080 (full D 1080p)
B ILT-IN ATSC/NTSC/QAM CLEAR T NER
INVISIBLE SPEAKER SYSTEM
idden speaker grilles
LG'S EXCL SIVE XD ENGINE®
SB 2.0 MEDIA HOST FOR PHOTOS AND M SIC
SB CLONING
CLEAR VOICE II
REAL CINEMA™
2 HDMI™ INP TS WITH HDCP
V.1.3 with deep color
A TO SENSING REMOTE JACK PACK (RJP) COMPATIBLE*
2 YEAR LIMITED WARRANTY
(parts and labor)
Integrated Full 1080p HDTV
*NOTE: Contact your LG Sales representative on the RJPs that are
compatible with the L 300C series.

•EcoSmart
Energy Saving Levels - Manually select your choice for the brightness level for the
television.
•RoHS Compliant - Meets directive on restriction of hazardous substances.
L I F E ’ S G O O D . . .
W EN IT’sGREEN.
LG is committed to improving product development,
manufacturing and usage to meet the demand
for environmentally friendlier products. Our
L 200C televisions have technologies to reduce
power consumption and in return increase cost
savings per room. We’ve also placed limits in the
amounts of harmful materials used in these
televisions.
LG’s newest core technology, Picture Wizard, enables easy self-
calibration by providing on-screen reference points for key picture quality
elements such as black level, color, tint, sharpness and backlight levels. By
using this easy-to-use calibration process, the picture setting can be set to
better fit the type of room application.
BALANCED SOUND TO EMPHASIZE DIALOGUE
Clear Voice technology automatically enhances dialogue when
background sounds such as those in an action sequence swell.
Enhancements made to the Clear Voice technology now allow users to
customize their personal preferences based on their home environment
through a 12-step adjustment process. This calibration process is based
on distinct voice zoom levels and does not interfere with surrounding
sounds, ensuring consumers don’t miss a single line of dialogue.
Picture Wizard
With Picture Wizard, you can adjust the picture quality of the
original image.
G
NextPrevious
PHOTO LIST MUSIC LIST
Enter
Move

Aspect Ratio : 16:9
Picture Wizard
Energy Saving :Off
Picture Mode:Standard
• Backlight 70
•Contrast90
• Brightness50
• Sharpness70
ENERGY SA ING LE ELS
Manually select your choice for the brightness level for the television. By selecting
Minimum, Medium, or Maximum, the power consumption will be reduced and an
increase in energy savings can be achieved. (Note: Selecting minimum level may slightly increase
power consumption on some models)
Enter
Move
▼
Aspect Ratio:16:9
Picture Wizard
Energy Saving :Off
Picture Mode:Standard
• Backlight 70
• Contrast90
• Brightness50
•Sharpness70
Off
Minimum
Medium
Maximum
Screen off
USB 2.0 will support JPG and MP3 files from a USB storage device.
Page 2/3 No Marked
Photo List
Up Folder
1366x768, 125KB
KY101 06/10/2008
KY102 04/03/2008
JMJ001 01/01/2000
JMJ002 06/15/2008
JMJ003 04/03/2008
JMJ004 02/18/2008
KY103 03/30/2008
KY104 06/19/2008
KY105 01/31/2008
JMJ005 05/13/2008
JMJ006 05/26/2008
JMJ007 02/18/2008
JMJ008 02/18/2008
Up Folder
Drive1
JMJ001
Music List
Up Folder
noitaruDeltiT
Page 2/3 No Marked
Drive1
AA00:00 / 04:16
Up Folder
Applied Model Energy Saving
Level
Brightness
[cd]
Power
Consumption
[Watts]
Energy savings
[%]
47L 300C
OFF 210 188.9 0.0
Minimum 203 183.2 3.0
Medium 151 145.3 23.1
Maximum 61 80.3 57.5
Screen off 0 18.7 90.1
42L 300C
OFF 218 142 0.0
Minimum 212 137.2 3.4
Medium 147 108.2 23.8
Maximum 53 61.6 56.6
Screen off 0 19.2 86.5
TESTING CONDITION IN STANDARD MODE
Note: Power consumption was measured with video signal - IEC62087 dynamic broadcast. Energy
Saving percentages listed are based on Energy Saving default value in the Off mode.
U S B 2 . 0
M E D I A H O S T
Dramatizations

47LH300C
42LH300C
4-Screws
(not provided)
Stand
Desk
MOUNTING HOLES ON STAND
ATTAC ING T E TV TO A DESK
45.0”
28.5”
30.9”.
20.5” 13.3”
3.9”
200mm
200mm
REAR SIDE
PUBLIC DISPLAY SETTINGS
When used in public areas, these DTVs can be
easily programmed by the installer to have the
TV turn on at a specified channel/volume level,
set the minimum/ maximum volume, lock out the
control panel/remote, set the aspect ratio, and
return to a factory reset. By using Power
Management, these displays can be
programmed to turn off if there has been no
activity (remote or control panel buttons) for a
preset time (1-7) hours.
Public Display Mode No
Start Channel No
Ch. Type TV
Major 2
Minor 0
Minimum Volume 0
Maximum Volume 100
Start Volume No
Level 20
Power Management No
Setting 1
Key Management 0
Factory Reset 0
Aspect Ratio 0
PDM Plus
Public Display Setting
USB CLONING
USB cloning will allow for easy transfer of Public
Display Settings from the “Master TV” to an unlimited
number of same type televisions.
AVIN2
L/MONO
R
AUDIO
VIDEO
USBIN
40.5”
25.9”
28.2”.
20.2” 11.7”
3.5”
200mm
200mm
SOUND IS HEARD, NOT SEEN
Enjoy a combination of smart technology
and stylish design with the invisible
speaker system custom tuned by audio
expert Mr. Mark Levinson. This unique
system provides a clean, polished look
and an enhanced auditory experience
by increasing the sweet spot and
providing a wider sound field.

All screen images are simulated. Dimensions and weights are approximate.
Design, features and specifications subject to change without notice.
© Copyright 2010 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a
registered trademark of LG Corp. XD Engine is a registered trademark of LG Electronics,
Inc. ealthView and EcoSmart are trademarks of LG Corp.
Dolby and the double-D
symbol are registered trademarks of Dolby Laboratories. SRS and the SRS symbol,
TruSurround XT and WOW are trademarks or registered trademarks of SRS Labs, Inc.
VESA is a trademark of Video Electronics Standards Association. All other product and
brand names are trademarks or registered trademarks of their respective companies.
Printed in the USA. May 2010
XT
specifications
www.LGcommercial.com
lcd tv
LCD SPECIFICATION
Screen Size (Class) 47” class (47.0” diagonal)
42” class (42.0” diagonal)
Native Display Resolution 1920 x 1080
Brightness 500 cd/m
2
Dynamic Contrast Ratio 50,000:1
Contrast Ratio 1,400:1
Viewing Angle 178°/178°
Color Reproduction 10 Bit
Response Time 6ms
True Viewing Angle Yes
Life Span (Typical) 60,000 hrs
BROADCASTING SYSTEM
Analog Yes
ATSC/NTSC/Clear QAM Yes
IDEO
XD Engine Yes
Aspect Ratio 16:9
Aspect Ratio Correction 6 Modes
Just Scan (1:1 Pixel Matching)
DMI 1080p/1080i/720p
Component 1080p/1080i/720p
RF/DTV 720p
Enhanced Noise Reduction (Video Noise Filter) Yes, 3D NR/MPEG NR
Digital Comb Filter Yes (3D)
Color Temperature Control 3 Modes (Norm, Warm, Cool)
Black Stretcher Yes
24p Real Cinema Yes
Cinema 3:2/2:2 Mode Yes
Picture Reset Yes
AV Mode II (Picture & Sound) 3 Modes (Cinema, Sport, Game)
EZ Picture/PSM Yes (8 modes)
ISFccc Ready Yes
DTV Signal Strength Indicator Yes
Video Reset/Initializing Yes
AUDIO
Mono/Stereo/Dual (MTS/SAP) Yes
Audio Output Power (Watts - T D 10%) 10W x 2
Invisible Speaker System Details 1 Way 2 Speaker
Dolby Digital 5.1 Decoder Yes
Surround System Type SRS TruSurround XT, SRS WOW
Bass/Treble/Balance Controls Yes
Clear Voice II Yes
Auto Volume Leveler Yes
EZ Sound Mode/SSM 5 Modes
SPECIAL FEATURES
Public Display Settings Yes , V2.5
Energy Savings Yes (Minimum, Medium, Maximum)
Brightness Optimization Yes (Available in Standard, Natural, Sport, Game
modes)
Auto-Sensing RJP compatible Yes (with select RJP versions)
Picture Wizard Yes
Backlight Control Yes
USB Cloning Yes
Mechanical Power Off Yes
1080p Source Input
DMI 60p/30p/24p
Component 60p/30p/24p
RGB WXGA
A/V Input Navigation Yes
Input Labeling/Sub-title Yes
Quick View (Previous Channel) Yes
Quick Setup Guide Yes
e-Manual Yes
Parental Control w/V-Chip Yes
Key Lock/Child Lock Yes
Customizable Closed Caption/Sub-title Yes
LG SIMPLINK ( DMI CEC) Yes
CON ENIENCE FEATURES
Language English/Spanish/French/Korean
Alvin UI Yes
Auto Tuning/Programming Yes
Channel Add/Delete Yes
Channel Labeling Yes
Favorite Channel Programming Yes
Auto/Manual Clock Yes
On/Off Timer Yes
Sleep Timer Yes
Auto Off/Auto Sleep (When no video is present) Yes
AUDIO/ IDEO INPUTS/OUTPUTS
RF In (Antenna/Cable) 1
L/R Audio/Composite Video In 1 (rear),1(side)
D Component Video In (Y, Pb, Pr) + L/R Audio1
Variable Audio (External Speaker) Out 1 (L/R 2W each)
Digital Audio Out (Optical) 1
DMI/ DCP Input (V1.3 with Deep Color) 2
RGB In (D-Sub 15pin) - PC 1(1920 x 1080)
PC Audio Input 1
RS-232c In (Control/Service) 1
USB 2.0 Input 1 (Side) Media ost (JPEG, MP3) ,Cloning,
and Service
Remote Control Port In 1
RJ45 (for RJP interface - non PIP) 1
CABINET/ACCESSORIES
Cabinet Color Glossy Black
Swivel Stand (degrees) + 20°/-20°
Power Indicator Yes (on/off)
Fire Retardant Cabinet Material Yes
Kensington Security System Slot Yes
VESA
®
Mount Compliant (Wx ) 200mm x 200mm, M6 screw (47", 42")
Remote Control Yes
POWER
Voltage, z 100V - 240V, 50/60 z
Stand-by Mode Less than1W
Power Consumption 225W (42"), 270W (47")
Ro S Compliant Yes
DIMENSIONS & WEIGHT
TV without stand (Wx xD) 45.0" x 28.5" x 3.9" (47”)
40.5" x 25.9" x 3.5" (42”)
TV with stand (Wx xD) 45.0” x 30.9” x 13.3” (47”)
40.5.” x 28.2” x 11.7” (42”)
Shipping Dimensions (Wx xD) 58.5” x 33.9" x 10.0" (47”)
52.4” x 30.3” x 9.0” (42”)
TV without stand weight 43.9 Ibs (47”)
35.7 Ibs (42”)
TV with stand weight 49.6 Ibs (47”)
39.7 Ibs (42”)
Shipping Weight 59.3 Ibs (47”)
46.7 Ibs (42”)
SER ICE/LIMITED WARRANTY 2 Years (Parts/Labor)
UPC CODE
42L 300C 7 19192 17623 2
47L 300C 7 19192 17622 5
47L 300C
42L 300C
47" class (47.0" diagonal)
42" class (42.0" diagonal)
LG Electronics U.S.A., Inc.
Business Solutions Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
Contact your LG Regional Sales Representative
ertical Markets: 800.897.8788
Channel: 800.897.8871
Hospitality: 800.228.1236
E-mail: L[email protected]
