LG 26LG3DCH User manual

32LG3DCH
26LG3DCH
22LG3DCH
32" c ass (31.5" diagona )
26" c ass (26.0" diagona )
22" c ass (22.0" diagona )
cd tv
Hospital Grade LCD Widescreen
w w w. LG c o m m e r c i a l . c o m
DESIGNED SPECIFICALL FOR THE HEALTHCARE INDUSTR
UL HOSPITAL GRADE LISTED
Built-in Pillow Speaker Port
Built-in Card Slot (MPI™ Interface)
Rear Speaker Disable Switch
NEW! D NAMIC POWER SAVINGS
NEW! USB CLONABLE
HD VOD PPV DECR PTION AND
INTERACTIVE S STEM CAPABILIT
Integrated Pro:Idiom®
DIGITAL HD-PPV COMPATIBILIT
MPEG-2 DECODER
BUILT-IN ATSC/NTSC/CLEAR QAM TUNER
DISPLA RESOLUTION
1366 x 768 (32”, 26”)
1680 x 1050 (22”)
NEW! D NAMIC CONTRAST RATIO
12,000:1 (32”, 26”)
3,000:1 (22”)
LG'S EXCLUSIVE XD ENGINE®
NEW! REAL CINEMA™
NEW! CLEAR VOICE™
MULTIPLE INPUTS
HDMI™, Headphone Jack, Pillow Speaker and MPI Slot
NEW! INVISIBLE SPEAKERS
STANDARD VESA™ MOUNTING INTERFACE
200mm x 100mm (32”, 26”)
100mm x 100mm (22”)
2 EAR LIMITED WARRANT
(parts and labor)
HDTV with HD-PPV Capability

BACKLIGHT
SETTING VALUE BRIGHTNESS (cd /m2)
*PO ER
CONSUMPTION
(Watts)
Level 100 299 cd/m251.8 Watts
90 90%** 93%**
80 81% 87%
70 72% 83%
60 63% 78%
50 52% 73%
40 42% 66%
30 33% 61%
20 23% 55%
10 14% 48%
1 7% 44%
Dramatization Dramatization
SHARPER
BRIGHTER
CLEARER
Power consumption was measured using IEC62087 dynamic broadcast - content video signal
By selecting lower levels of backlight settings, a
reduction in power consumption is achieved resulting
in energy savings and lower costs.
32LG3DCH in Vivid Mode
*
26LG3DCH in Vivid Mode 22LG3DCH in Vivid Mode
BACKLIGHT
SETTING VALUE BRIGHTNESS (cd /m2)
*PO ER
CONSUMPTION
(Watts)
Level 100 217 cd/m2122 Watts
90 93%** 93%**
80 87% 89%
70 79% 84%
60 72% 78%
50 59% 73%
40 57% 67%
30 50% 61%
20 44% 57%
10 36% 51%
1 29% 46%
BACKLIGHT
SETTING VALUE BRIGHTNESS
(cd /m2)
*PO ER
CONSUMPTION
(Watts)
Level 100 445 (cd /m2)124W
90 99.55%** 100%**
80 89.89% 91%
70 80.00% 83%
60 70.79% 76%
50 60.00% 68%
40 51.69% 62%
30 40.90% 54%
20 31.24% 47%
10 20.67% 40%
1 12.36% 33%
All percentages listed are percentages based off of level 100
**
32LG3DCH (silver)
26LG3DCH (silver)
22LG3DCH (silver)
PO ER SAVING LEVELS
DIGITAL RIGHTS MANAGEMENT SYSTEM
The Pro:Idiom system’s high-quality security unlocks access to premium content
availability to help assure rapid, broad deployment of HDTV and other high value
digital content. Pro:Idiom has been designed specifically for industries that use
premium HDTV content from cable, satellite or video on demand (VOD) services
and as such, could result in lower costs, and reduced maintenance. This system is
one of the leading DRM systems embraced by content providers for both of these
key programming sources. By using this embedded approach, security is provided
and helps eliminate the possibility of customers tampering with or removing
needed components.
VIE ING QUALITY AS THE DIRECTOR INTENDED
24p playback matches the original frame rate of film based content, making your
viewing experience one step closer to “Real Cinema”
Original ilm
Original film has a frame rate of
24 frames per second. To be
viewed on standard video
equipment such as TVs it must be
have a pull down solution.
Real Cinema
Real Cinema uses a 2:3 pull down
which takes ever other frame and
splits it into three fields of video for
a smoother transition from film to
video.
Dramatization
NTCS Pulldown Solution
NTSC corrects the frame rate
difference by repeating every 4th
frame. Sound must be separated
from the film to avoid any
distortion.

26.1”
17.7”
4.1”
200mm
100mm
31.6”
21.4”
4.3”
100mm
200mm
20.8”
15.3”
3.3”
100mm
100mm
AV IN 2
L/MONO
R R
AUDIO
VIDEO
H/P
AUDIO IIN
((RGB/DVII)
VVIIDDEEOO
AUDIOAUDIO
HDMI/DVI INHDMI/DVI IN
USB IN
AAVVIINN11
VIDEOVIDEO
MMOONNOO
(())
AUDIOAUDIO
SS--VVIIDDEEOO
COMPONENTCOMPONENT
IINN
RGB IN (PC)
RREESSEETT
UUPPDDAATTEE
RS-232C IN
(SERVICE ONLY)
REMOTE
CONTR OLLOUT
SPEAKER OUT
8
PIILLOWW
SPEAKER
NORMAL
SPEAKER
PILLOW
SPEAKER
S P E AKER SW I T C H
( )
ANTENNA IN M.P.I.
(SERVICE ONLY)
26LG3DCH/32LG3DCH
32LG3DCH
26LG3DCH
Dramatization Dramatization Dramatization
PILLOW
SPEAKER
HDMI/DVI IN
RS-232C IN
(SERVICE ONLY)
USB IN
SERVUCE ONLY
REMOTE
CONTROL OUT
AV IN 1I
VIDEO
AUDIO
MONO
(
()
)
NORMAL
SPEAKER
PILLOW
SPEAKER
SPEAKER SWITCH
RESET
UPDATEU
H/P
ANTENNA IN M.P.I.
22LG3DCH
22LG3DCH
REAR SIDE REAR
By using the optional
handheld, rechargeable
TVLink-Loader, the installer
can “clone” the Commercial
Settings from one TV and
then transfer this information
quickly to many other TVs
that have this feature.
TLL-1100A
TVLink-Loader
USB IN
1
or
CLONING OPTIONS
The optional LT2002 allows
for custom setup and
programming information to
be quickly copied from a
“master” LG or Zenith brand
LCD, Plasma, or CRT TV (with
the MPI input) into an
unlimited number of identical
models. This saves the
installers hours of time
duplicating the hotel TV
settings, such as minimum
volume, maximum volume,
start up channel, channel
mapping, etc.
LT2002
CLONING PROGRAMER
REMOTE
QUICKSET II CLONE©
FRONT
USB CLONING

specifications
Auto/Manual Clock Yes
On/Off Timer Yes
Sleep Timer Yes
Auto/Manual Clock Yes
Channel Labeling Yes
avorite Channel Yes
Closed Caption Analog/Digital
Mute Yes
lashback (Quick View) Yes
Parental Control/V-Chip Yes
unction Menu Yes
Auto Off Yes
Remote Not Included
JACKS
R in 1 (NTSC+ATSC tuner)
A/V In 1 (Rear)
S-Video In 1 (Rear) (except 22”)
Component & R/L Audio In 1 (Rear) (except 22”)
RGB In (DB15-RGB) 1 (Rear) (except 22”)
Audio in (Phone Jack) 1 (Rear: PC) (except 22”)
HDMI 1 (Rear)
Speaker Out Yes (8 ohm mono 1W Phone Jack) (except 22”)
Headphone Jack Yes (Side) (26”, 32”) , ( ront) (22”)
(1/8” stereo mini jack)
Pillow Speaker Yes
RS-232C 1 (Rear) Service Only
IR In/out 1 (out to MPI Slot)
USB 1 (Cloning and Service)
MPI Slot 1 Slot (Standard Type )
OPTIONAL REMOTES
Installer Remote 124-213-07
Patient Remote 124-213-08
"Clone" Programmers TLL-1100A, LT2002
REQUIRED CERTIFICATIONS
UL, C-UL Yes
UL Hospital Grade Yes
CABINET
Color Silver
Power/Standby Indicator Illuminates red in standby mode/green in on mode
Unit Dimensions (WxHxD) 31.6" x 21.4" x 4.3"
(32”)
26.1" x 17.7" x 4.1" (26”)
20.8" x 15.3" x 3.3" (22”)
Unit Weight 26.2 lbs (32”)
20.95 lbs (26”)
13.54 lbs (22”)
Shipping Dimensions (WxHxD) 38.7" x 26.0" x 7.4" (32”)
32.4" x 21.5" x 8.1" (26”)
27.28" x 19.0" x 6.3" (22”)
Shipping Weight 36.8 lbs (32”)
26.0 lbs (26”)
18.5 lbs (22”)
Invisible Speakers Yes (Built-in)
VESA™ Standard Mount Interface 200mm x 100mm, M4 screws, (26”, 32”)
100mm x 100mm, M4 screws, (22”)
UL Hospital Grade Power Cord Yes
Stand Not included
PO ER
Dynamic/Static Power Savings Yes
Power Source 110V 50/60Hz
Power Consumption (typ.) with 50W
(22”) , 120W (26”) , 139W (32”)
Power Saving modes disabled
Power Stand-by Mode 2.4W, (26”, 32”) , 2W, (22”)
SERVICE/LIMITED ARRANTY 2 Years (Parts/Labor)
UPC CODE
32LG3DCH 7 19192 17402 3
26LG3DCH 7 19192 17403 0
22LG3DCH 7 19192 17436 8
LG Electronics U.S.A., Inc.
Commercial Products Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Contact your LG Regional Sales Representative
Healthcare: 877.793.6484
Customer Service: 888.865.3026
SPEC_22-32LG3DCH_090803_PR
All screen images are simulated. Dimensions and weights are approximate. Design,
features and specifications subject to change without notice.
© Copyright 2008 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a
registered trademark of LG Corp. XD Engine is a registered trademark of LG Electronics
USA, Inc. Pro:Idiom is a registered trademark and MPI is a trademark of Zenith
Electronics Corp.
Dolby and the double-D symbol are registered trademarks of Dolby
Laboratories. SRS and the SRS symbol are registered trademarks of SRS Labs, Inc. in the
U.S. and selected foreign countries. TruSurround XT is a trademark of SRS Labs, Inc.
VESA
is a trademark of Video Electronics Standards Association. All other product and brand
names are trademarks or registered trademarks of their respective companies.
Printed in the USA. September 2008
www.LGcommercial.com
XT
XT
ULUS
C
LISTED
32LG3DCH
26LG3DCH
22LG3DCH
32" c ass (31.5" diagona )
26" c ass (26.0" diagona )
22" c ass (22.0" diagona )
cd tv
DISPLAY
LCD Panel Type 22”, 26”, 32”
Display Area 22.0”, 26.0”, 31.5” diagonal
Aspect Ratio 16:9
Native Resolution 1680 x 1050 (22”) , 1366 x 768 (26”, 32”)
Pixels (H×V×3) 5,292,000 (22”) , 3,147,264 (26”, 32”)
Brightness 300 cd/m
2
(22”) ,500 cd/m
2
(26”, 32”)
Dynamic Contrast Ratio 3,000:1 (22”) ,12,000:1 (26”, 32”)
Contrast Ratio 1000:1 (22”) , 2500:1 (26”) , 1500:1 (32”)
Viewing Angle (Horizontal/Vertical) 160°/160° (22”) , 176°/176° (26”) , 178°/178° (32”)
Color Depth 8bit (16.7M)
Life Span (approx. hrs) 50,000 hours (22”, 32”) , 60,000 hours (26”)
Response Time 5ms (G to G) (22”) , 6ms (G to G) (26”, 32”)
MAIN SYSTEM
MPEG Decoder MPEG2/AC-3
Max Output Resolution UXGA/WSXGA+
VIDEO
ATSC/NTSC/QAM Clear Tuner Yes (Built-in)
ATSC with HD-PPV Yes (Built-in)
All ormat Convertor Yes (1080p/1080i/720p/480p/480i > 1050p) (22”)
(1080p/1080i/720p/480p/480i > 768p) (26”, 32”)
Comb ilter Yes (3D Digital)
Digital Progressive Scan Yes
Color Temperature Yes (Cool/Normal/Warm)
Enhanced Video Yes
Advanced Ghost Cancelor Yes
DLTI (Digital Luminance Transient Limiter) Yes
DCTI (Digital Color Transient Improver) Yes
Black/Blue Stretcher Yes
3:2 Pull-Down (film mode) Yes
Aspect Ratio 6 Modes (Set by Program, 4:3, 16:9, Zoom 1, Zoom 2,
Just Scan at Digital & HDMI & Comp high res)
Picture Control Con/Bri/Tint/Color/Sharpness
Noise Reduction Yes
XD Engine Yes
EZ Picture 7 Modes
(Vivid/Standard/Cinema/Sports/Game/Expert 1/Expert 2)
AUDIO
# of Speaker 2
Dolby Digital
®
Decoder Yes
Mono/Stereo/SAP Yes
Surround System SRS TruSurrond XT™
Clear Voice Yes
Total Audio Watts (RMS) 2 x 3W (6W) (22”, 26”) , 2 x 10W (20W) (32”)
Bass/Treble/Balance Yes
EZ SoundRite (Auto Volume Leveler) Yes
EZ Sound 5 Modes (Standard, Music, Cinema, Sports, Game)
Internal Speaker on/off Yes
SPECIAL FEATURES
USB Cloning Yes
Integrated Pro:Idiom Yes
OSD Type (Menu System) EZ Menu
Trilingual Menus Yes (English, rench, Spanish)
Commercial Installation Menu Yes (English only)
Discrete IR Codes Yes
Real Cinema Yes
Last Source Power-on Recall Yes
Auto Power Option Yes
