LG’S EXCLUSIVE XD ENGINE™
Six distinct processes contribute to picture improvement. LG’s XD Engine™takes the low
resolution of analog signals to near HD levels by improving brightness, contrast, detail and
enhancing color as well as reducing signal noise. This total solution results in cinema-like high
resolution images.
HIGH DEFINITION TV
A built-in ATSC/NTSC/QAM Clear Tuner allows this TV to receive over-the-air digital
broadcast signals and unscrambled digital cable.
ADVANCED CONNECTIVITY
Includes inputs for the most advanced components which allows PC interactivity.
• 1366 x 768p Resolution
• 700:1 Dynamic Contrast Ratio
• ATSC/NTSC/QAM Clear Tuner
• XD Engine™
• HDMI with HDCP
• PC Input
23LS7D
23” LCD INTEGRATED HDTV

www.LGusa.com
23LS7D
23” LCD INTEGRATED HDTV
LG Electronics U.S.A., Inc.
1000 Sylvan Avenue
Englewood Cliffs, NJ 07632
1-800-243-0000
www.LGusa.com
© 2007 LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. LG Design and Life’s Good are trademarks of LG Electronics, Inc.
All other trademarks are the property of their respective owners.
Design and specifications subject to change without notice. 02/21/07
REMOTE REAR AUDIO/VIDEO INPUTS/OUTPUTS
22.9”
16.3”
18.1”
7.8”
3.3” 3.9”
3.9”
14.4”
7.8”
HEADPHONE
IN
RS-232C IN
(CONTROL/SERVICE)
ANTENNA/
CABLE IN
COMPONENT IN
VIDEO AUDIO
Y PBPRL R
RGB IN (PC) AUDIO
(RGB) IN
SERVICE
ONLY
S-VIDEO
VIDEO AUDIO
AV IN
L(MONO) R
HDMI IN
TV
ATSC/NTSC/QAM Clear Tuner •
VIDEO
Native Display Resolution 1366 x 768p
Dynamic Contrast Ratio 700:1
Response Time (Grey to Grey) 8ms
Brightness (cd/m²) 450
XD Engine™ •
Viewing Angle (H x V) 160º x 140º
Digital Comb Filter 3D
Color Temperature Control 4 Modes
Aspect Ratio Adjustment 5 Modes
Enhanced Noise Reduction (Video Noise Filter) •
Enhanced Line Doubled •
3:2 Pull-Down Correction 3:2 (480i)
Picture Selection Mode 5 Modes
Black Stretcher (Black Level Enhancer) •
DTV Signal Strength Indicator •
ACM (Active Color Management) •
Color Processor 10 Bit
AUDIO
Mono/Stereo/Dual (MTS/SAP) •
AudioOutputPower(Watts-THD10%) 3W+3W
Speaker System Details 1 Way 2 System
Dolby Digital Decoder •
Bass/Treble/Balance Controls •
EZ Sound (Sound Status Mode) 6 Modes
Mute •
SPECIAL FEATURES
Auto Input Detect •
Custom Input Labels •
PC Mode Configuration •(Manual)
Back (Previous Channel) •
Parental Control w/V-Chip •
Closed Caption •
Trilingual Menus English, Spanish, French
EZ Menus (High Performance Interface) •
Auto Channel Programming •
Channel Add/Delete •
Favorite Channel •
Manual Clock •
On/Off Timer •
Sleep Timer •
Auto Off (When no Video is Present) •
REAR AUDIO/VIDEO INPUTS/OUTPUTS
RF In (Antenna/Cable) 1
L/R Audio/Composite Video In 1
S-Video In 1
HD Component Video In (Y,Pb,Pr) + L/R Audio 1
HDMI/HDCP Input 1
RGB In (D-Sub 15pin) - PC 1
PC Audio Input 1
RS-232c In (Control/Service) 1
Headphone In 1
USB (Service only) •
CABINET/ACCESSORIES
Cabinet Color Gloss Black
Remote Control Type Universal
VESA® Compatible (W x H) 100mm x 100mm
POWER
Consumption (Typical) 85 W
Stand-by Consumption (Cable Card Off) 1W
Energy Star Compliant •
SPECIFICATIONS
Dimensions w/Out Stand (W x H x D) 22.9" x 16.3" x 3.3"
Weight w/Out Stand 16.7 lbs.
Dimensions w/Stand (W x H x D) 22.9" x 18" x 7.8"
Weight w/Stand 17.4 lbs.
Dimensionsw/Packaging(WxHx D) 25.8" x19.3"x21.6"
Weight In Package 21.6 lbs.
UPC 719192171381
Warranty 1YearParts/Labor
