LG LHD756W Specification sheet

SIMPLE MANUAL
DVD Wireless
Home Theater
System
To view the instructions of advanced features,
visit http://www.lg.com and then download Owner’s Manual.
Some of the content in this manual may differ from your unit.
MODEL
LHD756W
*MFL69462903* www.lg.com
ENGLISH
Specication
Power
requirements Refer to main label.
Power
consumption Refer to main label.
Dimensions
(W x H x D)
Approx.
440 mm x 65 mm x 298 mm
Net Weight Approx. 3.2 kg
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS output
power)
1,200 W
Design and specications are subject to change without
notice.
Replacement of battery
POWER: This unit operates on a mains supply of
200-240V~, 50/60Hz.
Wiring: This unit is supplied with a BS 1363 approved
main plug. When replacing the fuse, always use of the
same rating approved to BS 1362. Never use this plug
with the fuse cover omitted. To obtain a replacement fuse
cover contact your dealer. If the type of plug supplied is
not suitable for the mains sockets in your home, then the
plug should be removed and a suitable type tted. Please
refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead
of this unit must be destroyed. A mains plug with bared
wires is hazardous if inserted in a mains socket. Do not
connect either wire to the earth pin, marked with the
letter E or with the earth symbol or coloured green
or green and yellow. If any other plug is tted, use same
rating of fuse in the plug.
Important: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals in
your plug, proceed as follows: The wire which is coloured
blue must be connected to the terminal which is marked
with the letter N or coloured black. The wire which is
coloured brown must be connected to the terminal which
is marked with the letter L or coloured red.
Additional Information
LHD756W-FC.DNGAFLK_SIM_ENG_2903.indd 1-2 2016-06-03 �� 11:09:54

Front Panel Rear Panel
MIC 1/2···················· Connect a microphone.
PORT. IN ··············Connect to a Portable device.
USB Port····················Connect a USB device.
R··························Disc Tray Open / Close
T·······················Starts / Pauses playback.
I·································Stops playback.
F············· Changes the input source or function.
- / +·······························Adjusts volume.
1/! ······························Power On / Off
SPEAKERS ··················· Connect to speakers.
ANTENNA FM ·········· Connect to radio antenna.
WIRELESS ················· Connect a Wireless TX.
AUX (L/R) INPUT······ Connect to analogue device.
VIDEO OUT ························ Connect to TV.
HDMI OUT TO TV··················· Connect to TV.
OPTICAL IN ·············· Connect to digital device.
Speaker Assembling1
Home menu appears on the TV screen. Enjoy various
functions on the player.
TV Connection4
Home Menu5
HDMI & Optical Connection
aConnect the Player to the TV using HDMI &
Optical cable.
bSet the input selector to HDMI on the TV.
cSet up [External Speaker (Optical)] on your TV
setting menu.
dFollow the instructions on the TV screen using
remote control.
For more information, download the online owner’s manual. http://www.lg.com
About Ferrite Core (Optional)
Speaker design and connection method may
be different according to models.
,
Speaker Connection2
aConnect the rear speakers to the wireless
receiver.
bConnect the power cord of wireless receiver to
the outlet.
cTurn off the unit and insert the Wireless TX into
the WIRELESS connector on the rear of the unit.
dTurn on the player :
The player and wireless receiver will be
automatically connected.
If no sound is heard from the rear speakers
connected to wireless receiver, please follow as
below.
1. Press and hold ISTOP button on the unit
and MUTE button on the remote control
simultaneously.
- Displays the “REMATE”.
2. Press PAIRING on back of the wireless receiver.
- The Yellow LED will icker
3. Turn off and on the unit.
- If you see Yellow LED, it’ s successful.
4. If you don’t see Yellow LED,
try again Step 1 - Step 3.
Pair Up with Wireless Receiver3
twice
Front
(Left)
Center
Subwoofer
Unit
Surround
(Left)
Wireless
Receiver
Front
(Right)
Surround
(Right)
Small
screw
Small
screw
Big
screw
(Sold separately)
