LG 26LX2R Series User manual

LCD TV
Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number and serial number of the set.
See the label attached on the back cover and quote
this information to your dealer
when you require service.
P/NO : 38289U0498D (0512-REV01)
Printed in Korea
OWNER’S MANUAL
MODELS: 26LX2R 32LX2R
Internet Home Page : http://www.lge.com
http://www.lge.com.br

2
Accessories
Power Cord
Ensure that the following accessories are included with your TV. If any accessory is missing, please contact the
dealer from where you purchased the product.
DVI-D Cable D sub to DVI Cable
Accessories
PC Sound Cable
Owner’s Manual
1.5V
1.5V
TV INPUT
VOL
FLASHBK
CH
POWER
1 2 3
4 5 6
78
0
9
POSITION
SIZE
PIP
AUDIO
CABLE
MODE
MENU
MUTE FAV
EXIT
ENTER
VOL
1 2 3
456
78
0
9
MUTE
FAV
TV
VCR
STB
SLEEP
TV
PIP
DVD
ZOOM- ZOOM+
MTS
CC
EZSOUND
EZPIC
ARC
PIPCH-
PIPCH+
SWAP
PIPINPUT
FLASHBK
AUDIO
MENU
EXIT
ENTER
PIP
ZOOM- Z
CC
EZSOUND
EZPIC
ARC
PIPCH-
PIPCH+
SWAP
PIPINPUT
CH
POSITION
SIZE
PIP
Remote Control /
AA Batteries
Twister Holder
Arrange the wires
with the twister holder.
Polishing Cloth
Polish the screen with the cloth.
•If the TV feels cold to the touch, there may be a small “flicker”when turned on.
This is normal, there is nothing wrong with TV.
•Some dot defects may appear on the screen, like red, green or blue spots. However, this will have no adverse
effect on the monitor's performance.
•Avoid touching the LCD screen or holding your fingera(s) against it for long periods of time. Doing so may pro-
duce some temporary distortion effects on the screen.
2-TV Brackets, 2-Wall Bracket2-TV Bracket Bolts

3
Safety Instructions
Safety Instructions
Safety Instructions
Cleaning
Unplug this television receiver from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
Do not use attachments not recommended by the televi-
sion receiver manufacturer as they may cause hazards.
Power Supply
This television receiver should be operated only from the
type of power source indicated on the marking label. If
you are not sure of the type of power supplied to your
home, consult your television dealer or local power com-
pany.
Installation
Do not use this television receiver near water, for exam-
ple, near a bathtub, washbowl, kitchen sink, or laundry
tub, in a wet basement, or near a swimming pool, etc.
Do not place this television receiver on an unstable cart,
stand, or table. The television receiver may fall, causing
serious injury to a child or an adult, and serious damage
to the appliance.
Use only with a cart or stand recommended by the man-
ufacturer, or sold with the television receiver. Wall or shelf
mounting should follow the manufacturer’s instructions
and should use a mounting kit approved by the manufac-
turer.
Slots and openings in the cabinet and the back or bottom
are provided for ventilation, and to insure reliable opera-
tion of the television receiver, and to protect it from over-
heating. These openings must not be blocked or covered.
The openings should never be blocked by placing the
television receiver on a bed, sofa, rug, or other similar
surface. This television receiver should not be placed in a
builtin installation such as a bookcase unless proper ven-
tilation is provided.
It is recommended not to operate this unit near speakers
or big metallic furnitures in order to keep their magnetism
from disturbing colors purity (uniformity) on the screen.
Use
Do not allow anything to rest on the power cord. Do not
locate this television receiver where the cord will be
abused by persons walking on it.
Do not overload wall outlets and extension cords as this
can result in fire or electric shock.
Never push objects of any kind into this television receiv-
er through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a fire
or electric shock.
Never spill liquid of any kind on the television receiver.
Service
Do not attempt to service this television yourself as open-
ing or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
personnel.
Writing Model And Serial Numbers
The serial number and model number are found on the
back of this unit. The serial number is unique to this unit.
You should record requested information here and retain
this guide as a permanent record of your purchase.
Please retain your purchase receipt as your proof of pur-
chase.
Date of Purchase
Dealer Purchased from
Dealer Address
Dealer Phone No.
Model No.
Serial No.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR BACK). NO USER-
SERVICEABLE PARTS IN SIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

4
Contents
Contents
Contents
Introduction
Installation
Operation
27 Turning on the TV
27 Volume Adjustment
27 Channel Selection
27 Menu Language Selection
28 How to adjust the OSD screen
29 Auto Program: Channel Search
29 Manual Program: Adding/Deleting Channels
30 Fine Tuning Adjustment
30 Favorite Channels Setup
30 System Color (some models)
31 EZ PICTURE
31 XD
32 Color Temperature Control
33 ACM (Active Color Management)
33 sRGB (DVI PC or HDMI PC mode only)
34 Manual Picture Control (EZ Picture set to User option)
35 EZ SOUND
35 SRS WOW
36 AVL (Auto Volume Leveler)
36 Manual Sound Control
37 TV Speakers Setup
37 Stereo/SAP Broadcasts Setup
38 Clock Setup
38 On/Off Timer Setup
39 Auto Off
39 Sleep Timer
2 Accessories
3 Safety Instructions
6 Controls
7 Connection Options (Model: 32LX2R)
8 Connection Options (Model:26LX2R)
9~11 Remote Control Key Functions
12 Various Installation
13 How to use back cover
13 Swivel Stand
14 How to join the product assembly to the wall to protect the set tumbling
15 Antenna Connection
15 Headphone Socket
16~17 VCR Setup
17 External AV Source Setup
18~19 DVD Setup
20 Cable TV Setup
21 Monitor Out Setup
21 External Stereo
22~23 STB Setup
24~25 PC Setup
26 Power Cord Connection
Channel Menu
Options
Picture Menu
Options
Sound Menu
Options
Basic operation
External
Equipment
Connections
Installation
Instruction
Timer Menu
Options

5
Contents
Reference
40 Key Lock
40 XD Demo
41 Closed Captions
41 Caption/Text
42 Front Light
43 Auto Adjustment (DVI PC (RGB), Analogue PC mode only)
43 Manual Configure
44 Selecting XGA mode (DVI PC (RGB) and XGA/WXGA (60Hz) mode only)
44 Setting Picture Format
45 Picture Size Zoom
45 Screen Position
46 Cinema Mode Setup (TV, Video, S-Video and Component 480i mode only)
46 NR (Noise Reduction)
47 Reset to original factory value (Initializing)
48 Watching PIP/POP/Double Window
48 Selecting an Input Signal Source for PIP/Double Window
49 PIP Size
49 Moving the PIP (PIP Mode only)
50 PIP Transparency
50 TV Program Selection for PIP
51 Swapping the PIP/Double Window
52~55 External Control Device Setup
56~57 IR Codes
58 Programming the Remote
59~60 Programming Codes
61~62 Troubleshooting Checklist
63 Product Specifications
Special Menu
Options
Screen Menu
Options
PIP (Picture-In-
Picture) / DW
(Double Window)
Menu
Operation
