PLASMA MONITOR

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE CHASSIS,

READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

CHASSIS : RF-04FA

MODEL : MW-71PY10/G

website:http://biz.LGservice.com

e-mail:http://www.LGEservice.com/techsup.html

- 2 -

CONTENTS

SAFETY PRECAUTIONS .......................................................................................2

DESCRIPTION OF CONTROLS .............................................................................3

SPECIFICATIONS ...................................................................................................8

ADJUSTMENT INSTRUCTIONS ............................................................................9

BLOCK DIAGRAM................................................................................................14

EXPLODED VIEW.................................................................................................16

EXPLODED VIEW PARTS LIST ...........................................................................17

REPLACEMENT PARTS LIST..............................................................................18

SCHEMATIC DIAGRAM ...........................................................................................

PRINTED CIRCUIT BOARD .....................................................................................

- 3 -

SAFETY PRECAUTIONS

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in

the Schematic Diagram and Replacement Parts List.

It is essential that these special safety parts should be replaced with the same components as recommended in this manual to

prevent X-RADIATION, Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

General Guidance

An isolation Transformer should always be used during

the servicing of a receiver whose chassis is not isolated from

the AC power line. Use a transformer of adequate power rating

as this protects the technician from accidents resulting in

personal injury from electrical shocks.

It will also protect the receiver and it's components from being

damaged by accidental shorts of the circuitry that may be

inadvertently introduced during the service operation.

If any fuse (or Fusible Resistor) in this monitor is blown, replace

it with the specified.

When replacing a high wattage resistor (Oxide Metal Film

Resistor, over 1W), keep the resistor 10mm away from PCB.

Keep wires away from high voltage or high temperature parts.

Due to high vacuum and large surface area of picture tube,

extreme care should be used in handling the Picture Tube.

Do not lift the Picture tube by it's Neck.

Leakage Current Cold Check(Antenna Cold Check)

With the instrument AC plug removed from AC source,

connect an electrical jumper across the two AC plug prongs.

Place the AC switch in the on position, connect one lead of

ohm-meter to the AC plug prongs tied together and touch other

ohm-meter lead in turn to each exposed metallic parts such as

antenna terminals, phone jacks, etc.

If the exposed metallic part has a return path to the chassis, the

measured resistance should be between 1MΩ and 5.2MΩ.

When the exposed metal has no return path to the chassis the

reading must be infinite.

An other abnormality exists that must be corrected before the

receiver is returned to the customer.

Leakage Current Hot Check (See below Figure)

Plug the AC cord directly into the AC outlet.

Do not use a line Isolation Transformer during this check.

Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor

between a known good earth ground (Water Pipe, Conduit, etc.)

and the exposed metallic parts.

Measure the AC voltage across the resistor using AC

voltmeter with 1000 ohms/volt or more sensitivity.

Reverse plug the AC cord into the AC outlet and repeat AC

voltage measurements for each exposed metallic part. Any

voltage measured must not exceed 0.75 volt RMS which is

corresponds to 0.5mA.

In case any measurement is out of the limits specified, there is

possibility of shock hazard and the set must be checked and

repaired before it is returned to the customer.

Leakage Current Hot Check circuit

1.5 Kohm/10W

To Instrument's

exposed

METALLIC PARTS

Good Earth Ground

such as WATER PIPE,

CONDUIT etc.

AC Volt-meter

IMPORTANT SAFETY NOTICE

0.15uF

INPUT

MENU

VOL

TruSurround XT

Front Panel Controls

MENU Button

INPUT Button

VOLUME (FF,GG) Buttons

EE, DDButtons

INDEX

Switches

LED Display

on or off.

Remote

Control

Sensor

Power Indicator

Illuminates red in standby

mode, Illuminates green when

the monitor is turned on.

Sub power Button

- 4 -

DESCRIPTION OF CONTROLS

- 5 -

REMOTE

CONTROL

RS-232C INPUT

(CONTROL/SERVICE)

AC INPUT

DVI INPUT

AUDIO INPUT RGB INPUT

AUDIO

COMPONENT

RL

VIDEO

INPUT 1

INPUT 2

VIDEO

INPUT 2

VIDEO

INPUT 1

VIDEO

MONO

AUDIO

RL

S-VIDEO

VIDEO3 VIDEO4

HDMI

R

( )

L

EXTERNAL SPEAKER

Back Connection Panel

EXTERNAL SPEAKER

(8 ohm output)

Connect to optional

external speaker(s).

* For further information,

refer to ‘Speaker &

Speaker Stand’ manual.

Audio/Video Input

Connect audio/video output from

an external device to these jacks.

Component Input (1,2)

Connect a component video/audio

device to these jacks.

EURO SCART SOCKET

Connect the euro scart of

the VCR to these sockets.

Remote Control Port

Connect your wired

remote control here.

S-Video Input

Connect S-Video out from

an S-VIDEO device to the

S-VIDEO input.

Power Cord Socket

This monitor operates on an AC power. The voltage is

indicated on the Specifications page. Never attempt to

operate the monitor on DC power.

RS-232C INPUT

(CONTROL/SERVICE) PORT

Connect to the RS-232C port

on a PC.

HDMI

Connect a HDMI

signal to this jack.

DVI Input/Audio Input/RGB Input

Connect the monitor output connector

from a PC to the appropriate input port.

- 6 -

- When using the remote control, aim it at the remote control sensor on the monitor.

- Under certain conditions such as if the remote IR signal is interrupted, the remote control may not function. Press

the key again as necessary.

LIGHT

INPUT

MODE

PIP

MUTE SLEEP

VOL CH

WIN. SIZE

WIN. POSITION

SPLIT ZOOM

MENU

PIP INPUT ARC

EXIT

PLAY PAUSE STOP RECORD

VIDEO COM1 RGB

DVI

ENTER

HDMI

KEY LOCK INDEX

REW FF SKIP

POWER

DW

DASP

APC

COM2

LIGHT

Illuminates the remote control buttons.

INPUT

Selects: Video1-2-3-4, Component 1-2,

RGB-DTV (or RGB-PC),

DVI-DTV (or DVI-PC), HDMI input sources.

PIP

Selects the PIP mode.

NUMBER buttons

Dosen’t work for monitor mode.

APC

Adjusts the factory preset picture according

to the room.

MUTE

Switches the sound on or off.

VCR/DVD BUTTONS

Control some video cassette recorders or

DVD player ("RECORD" button is not avail-

able for DVD player).

SPLIT ZOOM

Enlarges the picture.

MODE

Selects the remote operating mode: MNT,

VCR, DVD, CABLE, HDSTB or AUDIO.

Select other operating modes, for the

remote to operate external devices.

POWER

Turns your monitor or any other pro-

grammed equipment on or off, depending

on mode.

DW

Selects the DW mode.

SLEEP

Sets the Sleep Timer.

XD

Switches the XD on or off.

(Refer to p.24)

DASP

To select the sound appropriate to your

viewing program character:

SRS TSXT, Flat, Music, Cinema, Sports,

or User (Refer to p.21)

THUMBSTICK

(Up/Down/Left/Right/ENTER)

Allows you to navigate the on-screen

menus and adjust the system settings to

your preference.

CHANNEL UP/DOWN

Selects available channels found with Auto

program. Dosen’t work for monitor mode.

EXIT

Clears all on-screen displays and returns to

monitor viewing from any menu.

ARC

Changes the picture format. (Refer to p.25)

VOLUME UP/DOWN

Increases/decreases the sound level.

WIN.POSITION

Moves the sub picture.

MENU

Brings up the main menu to the screen.

WIN. SIZE

Adjusts the sub picture size.

PIP INPUT

Selects the input source for

the sub picture. VIDEO/COM1/COM2/RGB/DVI/HDMI

Selects: Video1-2-3-4, Component 1-2,

RGB-DTV (or RGB-PC), DVI-DTV (or DVI-

PC), HDMI input sources.

KEY LOCK

Switches the key lock on or off.

INDEX

Switches LED Display on or off.

- 7 -

Ensure that the following accessories are included with your plasma display. If an accessory is missing, please contact the dealer

where you purchased the product.

Owner’s Manual

1.5V

Batteries Power Cord

LIGHT

INPUT

MODE

PIP

MUTE SLEEP

VOL CH

WIN.SIZE

WIN.POSITION

SPLITZOOM

MENU

PIPINPUT ARC

EXIT

PLAY PAUSE STOP RECORD

VIDEO COM1 RGB

DVI

ENTER

HDMI

KEYLOCK INDEX

REW FF SKIP

POWER

DW

DASP

APC

COM2

Remote Control D-sub 15 pin cable DVI computer cable

Alcohol

(MW-71PY10G only )

Soft cloth

(MW-71PY10G only )

Accessory

CAUTION concerning the Power Cord :

Most appliances recommend they be connected to a dedicated circuit; that is, a single outlet circuit which powers only

that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be

certain.

Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power

cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire.

Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug it, dis-

continue use of the appliance, and have the cord replaced with an exact replacement part by an authorized servicer.

Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked

upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance.

Use a dedicated power cord. Do not modify or extend the power cord.

Do not install, remove, or reinstall the unit by yourself (customer).

For electrical work, contact the dealer, seller, a qualified electrician, or an Authorized Service Center. For installation,

always contact the dealer or an Authorized Service Center.

Do not use if the power cord or plug is damaged, or socket is loose. Use a dedicated outlet for this appliance.

Do not over bend the power cord and do not place anything on the power cord. Do not install the monitor near any sharp

edge to avoid wire damage.

Safety instruction (MW-71PY10G only)

When the trim becomes dirty or stained, softly polish the surface. (Use the soft cloth and alcohol supplied with this product.)

When polishing the surface, use gentle pressure. Heavy pressure can damage or discolor the surface.

Clean the surface quickly and use gentle pressure. Heavy pressure can damage or discolor the surface.

Keep the alcohol and the used cleaning towel out of the reach of children.

Carefully read all of the safety instruction on the alcohol receptacle.

Do not use anything to scrape or scratch at the surface of this unit, this will cause damage to the surface.

Use soft gloves while installing or removing this unit to prevent damaging the surface.

CAUTION

- 8 -

SPECIFICATIONS

VApplication Range

This spec is applied to the 71”PDP MONITOR used RF-04FA Chassis.

V Specification

Each part is tested as below without special appointment.

1) Temperature : 25±5°C

2) Relative Humidity: 65±10%

3) Power Voltage: Standard Input voltage (100-240V~, 50/60Hz)

* Standard Voltage of each product is marked by models.

4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with BOM.

5) The receiver must be operated for about 20 minutes prior to the adjustment.

VTest Method

1) Performance : LGE TV test method followed.

2) Demanded other specification

Safety: UL, CSA, CE, IEC specification

EMC : FCC, ICES, CE, IEC

VGeneral Specification

Remark

Safety : UL1950, CSA1950

EMC : FCC PART 15 Class B

Model Name

MW-70PY10/G

Market

WORLD WIDE

Remark

Regular Voltage : 110V-220V~

LGE

LGE spec.

Specification

NTSC-M, PAL, SECAM, NTSC 4.43, PAL-N, PAL-M

100-240V~, 50/60Hz

All of the WORLD

71 inch

16 : 9

PDP71X10000 (1920x1080)

45% Total light transmittance (E-Mesh)

1) Temp. : 0 ~ 40 deg

2) Humidity : 0 ~80 %

1) Temp. : -20 ~ 60 deg

2) Humidity : 0 ~85 %

No

1

2

3

4

5

6

7

8

9

Item

Video input applicable system

Input Voltage

Market

Screen Size

Aspect Ratio

PDP Module

Screen Filter(Light Transmittance)

Operating Environment

Storage Environment

- 9 -

ADJUSTMENT INSTRUCTIONS

1. Application Object

These instructions apply to the RF-04FA(MN/MW-71PY10

Monitor) Chassis.

2. Specification

(1) Because this is not a hot chassis, it is not necessary to

use an isolation transformer. However, the use of isolation

transformer will help protect test equipment.

(2) Adjustment must be done in the correct order.

(3) The adjustment must be performed in the circumstance of

25±5°C of temperature and 65±10% of relative humidity.

(4) The input voltage of the receiver must keep 100~220V,

50/60Hz.

(5) The receiver must be operated for about 15 minutes prior

to the adjustment.

OAfter RGB Full white HEAT-RUN Mode, the receiver must

be returned to normal operation prior to adjustment.

OEnter into HEAT-RUN MODE

1) Press the POWER ON KEY on R/C for adjustment.

2) OSD display and screen display 100% full WHITE

PATTERN.

[Set is activated HEAT-RUN without a signal generator in

this mode.

[Single color pattern(RED/BLUE/GREEN) of HEAT-RUN

mode is used to test the PANEL.

Caution) If you turn on a still screen more than 20 minutes

(Especially digital pattern, cross hatch pattern), an

afterimage may be occur in the black level part of the

screen.

3. HDCP Download

3-1. LGIDS Setting Method

(1) Click on ‘setup’ to install in your directory.

(2) After installation has completed, check if the file shown on

(Fig. 4) has been created.

(3) Copy the KEY from source CD into the HDCP directory

which was installed just now.

(DVI_orderNo_2003_data)

(4) After running HDCP(application program) which is inside

the HDCP directory, setup the Communication.

Port : COM1(modification possible)

BaudRate : 115200

3-2. KEY Generation

(1) Click on ‘Key Generation (G)’.

(2) Input the quantity of keys to be generated.

ex) If 100 Keys are required, then just register 100 and

next time it will automatically get 101.

(3) Input file : When installing the program for the first time,

you must find the original KEY that you copied and open it.

It is crucial that you copy the original KEY into this

directory.

When you use Generation, the information is recorded in

Config.ini.

(Fig. 1)

(Fig. 2)

- 10 -

(4) Click on ‘Generation’ ———————————————(1)

If it is done correctly, you will see “Job is Success.”——(2)

Click on ‘close’——————————————————(3)

Check the Generation Data(Confirmation it’s possible

within HDCP\CreatedKeyFile)

(5) It is possible to check how many Generations are created

at this point.

(Fig. 4) shows that you have created 130 Generations and

you will start from 131 next time.

3-3. HDCP Download Method

(1) Input power of Stand-By 5V.

(Download must be executed only when the unit is in

Stand-by)

(2) The RS-232C(9PIN) must be connected to the COM1 on

the PC.

(3) If all the preparation is completed, click on ‘Download’.

(4) If abnormal state (Fig. 7) display then (3) execute.

(Fig. 3)

(Fig. 4)

(Fig. 5)

(Fig. 6) Normal State

(Fig. 7) Abnormal State

- 11 -

4. POWER PCB Assy Voltage

Adjustments (Va, Vs, 5V Vcc Voltage Adjustments)

4-1. Test Equipment : D.M.M. 1EA

4-2. Diagram for Measuring

Refer to (Fig 8).

4-3. Adjustment Method

(1) Va Adjustment

1) Connect + terminal of D.M.M to Va pin of P805, connect

- terminal to GND pin of P805.

2) Turn RV501, to adjust the Va voltage to match the value

marked on the label on the right/top of the panel.

(Deviation; ±0.5V)

(2) Vs Adjustment

1) Connect + terminal of D.M.M to Vs pin of P805, connect

– terminal to GND pin of P805.

2) Turn RV401, to adjust the Vs voltage to match the value

marked on the label on the right/top of the panel.

(Deviation; ±0.5V)

(3) 5V Voltage Adjustment

1) Connect + terminal of D.M.M to 5V Vcc pin of P804,

connect – terminal of D.M.M to GND pin of P804 on the

left PSU.

Turn RV601, to adjust the voltage value of D.M.M to be

5.3V. (Deviation; ±0.05V)

2) Connect + terminal of D.M.M to 5V Vcc pin of P804,

connect – terminal of D.M.M to GND pin of P804 on the

right PSU.

Turn RV601, to adjust the voltage value of D.M.M to be

5.3V. (Deviation; ±0.05V)

3) Connect + terminal of D.M.M to 5V Vcc pin of P804,

connect – terminal of D.M.M to GND pin of P804 on the

left PSU.

Turn RV601, to adjust the voltage value of D.M.M to be

5.6V. (Deviation; ±0.05V)

4) Connect + terminal of D.M.M to 5V Vcc pin of P804,

connect – terminal of D.M.M to GND pin of P804 on the

right PSU.

Turn RV601, to adjust the voltage value of D.M.M to be

5.6V. (Deviation; ±0.05V)

* Caution 1) Because there are two units in PSU, one of

them fixes to 5.3V voltage and then the other

adjusts to 5.3V voltage. After adjusting 5.3V

voltage with each other, one of them and the

other adjust to 5.6V voltage accordingly.

* Caution 2) Make small adjustments. Great differences

can cause the unit to shutdown.

5. DDC Data Input

5-1. Required Test Equipment

(1) A jig for adjusting PC, DDC (PC serial to D-sub

Connection equipment)

(2) S/W for writing DDC (EDID Data Write & Read)

(3) D-sub 15P Cable, DVI Cable, DVI to HDMI Connector

(HDMI EDID Down load)

5-2. Setting of Device

Each PCB assembly must be checked by Check JIG Set

before assembly. (Take special note of the Power PCB, which

can easily damage the PDP module)

(Fig. 8) Connection Diagram for measuring Power Adjustments

(Fig. 9)

- 12 -

5-3. Preparation for Adjustment

(1) Set devices as above and turn the PC and jig on.

(2) Put S/W for writing DDC (EDID data Write & Read) into

operation. (operated in DOS mode.)

5-4. Sequence of Adjustment

(1) DDC Data Input for Analog-RGB

1) Put the set on the table and turn the power on.

2) Connect PC Serial to D-sub 15P Cable of jig for DDC

adjustment to RGB terminal (D-Sub 15Pin).

3) Operate S/W for DDC record and select DDC

data(GT_HD_(8691).ana) for Analog RGB in Model

Menu.

4) Operate EDID Write command.

5) Operate EDID Read command and check whether

Check Sum is 86(1page), 91(2page).

6) If Check Sum is not 86(1page), 91(2page) repeat 3) ~

4).

7) If Check Sum is 86(1page), 91(2page), DDC data for

Analog-RGB input is completed.

(2) DDC Data input for Digital-DVI

1) Connect PC Serial to DVI Cable of jig for DDC

adjustment to DVI terminal (DVI Jack).

2) Operate S/W for DDC record and select DDC data

(GT_HD_(1D8F).dvi) for Digital-DVI in model menu.

3) Operate EDID Write command.

4) Operate EDID Read command and check whether

Check sum is 1D(1page), 8F(2page).

5) If Check sum is not 1D(1page), 8F(2page), repeat 3) ~

4).

6) If Check sum is 1D(1page), 8F(2page), DDC data for

Digital-DVI input is completed.

(3) DDC Data input for Digital-HDMI

1) Connect PC Serial to DVI to HDMI Cable of jig for DDC

adjustment to HDMI terminal (HDMI Jack).

2) Operate S/W for DDC record and select DDC data

(GT_HD_HDMI_(418F).dvi) for Digital-HDMI in model

menu.

3) Operate EDID Write command.

4) Operate EDID Read command and check whether

Check sum is 41(1page), 8F(2page).

5) If Check sum is not 41(1page), 8F(2page), repeat 3) ~

4).

6) If Check sum is 41(1page), 8F(2page), DDC data for

Digital-HDMI input is completed.

6. Adjustment of COLOR

6-1. Required Equipment

Color Analyzer (CA-100 or similar product)

Pattern Generator(VG-828)

6-2. Connection Diagram of Equipment for

Measuring Color

6-3. Adjustment Method of Auto RGB

Color Balance

(1) Input 16 Gray Scale Pattern(RGB output Level : 0.7Vp-p)

at the D-SUB input terminal using PC Pattern Generator.

(2) Press ADJ KEY on the S R/C.

(3) Press Vol. + KEY and operate To SET.

(4) Auto-RGB OK means completed adjustment.

6-4. Adjustment Method of Auto Video

Color Balance

(1) Input 16 Gray Scale Pattern(RGB output Level : 0.7Vp-p)

at the Video 1 input terminal using PC Pattern Generator.

(2) Press ADJ KEY twice on the S R/C.

(3) Press Vol. + KEY and operate To SET.

(4) Auto-RGB OK means completed adjustment.

6-5. Adjustment Method of Auto Video

Color Balance

(1) Input Pattern(Fig. 12) at the Component 1 input terminal

using PC Pattern Generator.

(2) Press ADJ KEY three time on the S R/C.

(3) Press Vol. + KEY and operate To SET.

(4) Auto-RGB OK means completed adjustment.

VG-828 CA-100

PDP SET

(Fig. 10)

(Fig. 11) Auto RGB Color Balance Test Pattern

- 13 -

6-6. Adjustment of White Balance

OOperate the Zero-calibration of the CA-100, then stick

sensor to PDP module surface when you adjust.

(1) Select white pattern of heat-run mode by pressing power

key on the Service Remote Control (S R/C) then allow to

heat run at least 15 minutes.

(2) Supply 216 Level 50% Window signal to RGB input using

Pattern Generator.

(3) Press ADJ KEY four time on the S R/C. (White Balance)

Select the adjustment mode(Red Gain or Blue Gain) using

D, Ekey on the S R/C and press VOL +, - keys to adjust

until color coordination matches below.

X; 0.280±0.005, Y; 0.290±0.005

Color Temperature; 10,000°K±500°K

(4) Exit adjustment mode using AKey.

(Fig. 12)

(Fig. 13)

- 14 -

BLOCK DIAGRAM

- 15 -

MEMO

- 16 -

EXPLODED VIEW

301

305 306

307

101

102

200

212

211

210

209

203

204

213

600

214

215 208

207

206

205

202

201

580

400

401

520

501

540 590

591

530

560

561

310

302

304

570

303

550

- 17 -

EXPLODED VIEW PARTS LIST

101 5900V12003B FAN,DC D12025S SDS 120MM*120MM*25MM 12V/0.2A 1300 5V-13.2V FROM 5900V12003A

102 4980V00B53A SUPPORTER, FAN EGI DN-71PY10

200 6348Q-J001G PDP, 71 16:9 1920*1080 PDP71H10000.AKLGG

201 6871QDH076A PWB(PCB) ASSEMBLY,DISPLAY YDRV ASSY HAND INSERT 71X1 4LAYER(TOP)

202 6871QDH077A PWB(PCB) ASSEMBLY,DISPLAY YDRV ASSY HAND INSERT 71X1 4LAYER(BTM)

203 6871QCH047A PWB(PCB) ASSEMBLY,DISPLAY CTRL ASSY HAND INSERT 71X1 TMDS 8LAYER

204 6871QEH017A PWB(PCB) ASSEMBLY,DISPLAY ETC HAND INSERT PDP50X20000 TEMP. SENSOR B/D

205 6871QFH004A PWB(PCB) ASSEMBLY,DISPLAY XRLB ASSY HAND INSERT 71X1

206 6871QHH002A PWB(PCB) ASSEMBLY,DISPLAY XRCB ASSY HAND INSERT 71X1_XCLB

207 6871QHH003A PWB(PCB) ASSEMBLY,DISPLAY XRCB ASSY HAND INSERT 71X1_XCRB

208 6871QGH005A PWB(PCB) ASSEMBLY,DISPLAY XRRB ASSY HAND INSERT 71X1

209 6871QLH041A PWB(PCB) ASSEMBLY,DISPLAY XRLT ASSY HAND INSERT 71X1

210 6871QXH026A PWB(PCB) ASSEMBLY,DISPLAY XRCT ASSY HAND INSERT 71X1_XCLT

211 6871QXH027A PWB(PCB) ASSEMBLY,DISPLAY XRCT ASSY HAND INSERT 71X1_XCRT

212 6871QRH047A PWB(PCB) ASSEMBLY,DISPLAYXRRT ASSY HAND INSERT 71X1

213 6871QYH001B PWB(PCB) ASSEMBLY,DISPLAY YSUS ASSY HAND INSERT A31 LG PCB OBU

214 6871QZH037A PWB(PCB) ASSEMBLY,DISPLAY ZSUS ASSY HAND INSERT 71X1 4LAYER

215 6871QPH009A PWB(PCB) ASSEMBLY,SUB DCDC ASSY HAND INSERT 71H1 DC-DC B/D ASSY

301 3210V00267A FRAME, FRONT UPPER AL MN-71PY10 TOP

3210V00267B FRAME, FRONT UPPER AL MN-71PY10G GOLD

302 3210V00277A FRAME, FRONT SIDE AL MN-71PY10 LEFT

3210V00277B FRAME, FRONT SIDE AL MN-71PY10G (GOLD) LEFT

303 3210V00268A FRAME, FRONT LOWER AL MN-71PY10 BOTTOM

3210V00268B FRAME, FRONT LOWER AL MN-71PY10G GOLD

304 3210V00276A FRAME, FRONT SIDE AL MN-71PY10 RIGHT

3210V00276B FRAME, FRONT SIDE AL MN-71PY10G (GOLD) RIGHT

305 5230V00024A FILTER(MECH), DU-71PY10 GLASS FILTER PDP 71 LG CHEMICAL GLASS LG LOGO

306 4980V00D29A SUPPORTER, FILTER AL TOP, BOTTOM MN-71PY10

307 4980V00D30A SUPPORTER, FILTER AL SIDE R,L MN-71PY10

310 5020V00995A BUTTON ,CONTROL DU-50PY10 ABS, AF-303S 7KEY .

400 3809V00559D BACK COVER ASSEMBLY, MW-71PY10

3809V00559G BACK COVER ASSEMBLY, MW-71PY10G GOLD

401 3300V00392A PLATE, AV AL COVER VSC TUNER DN-71PY10

3300V00392B PLATE, AV AL COVER VSC TUNER MN-71PY10G

501 3301V00040D PLATE ASSEMBLY, ASSY 3300V00390A, 3300V00391D MW-71PY10 A/V PLATE

3301V00040F PLATE ASSEMBLY, ASSY 3300V00390A, 3300V00391F MW-71PY10G A/V PLATE

520 6871VMMT32A PWB(PCB) ASSEMBLY,MAIN MAIN RF-04FA 71 DIGITAL VSC

530 6871VSMJ35A PWB(PCB) ASSEMBLY,SUB SUB RF04FA 71 ANALOG VSC

540 6871VSMZ98A PWB(PCB) ASSEMBLY,SUB RF04FA SPK_TERMINAL 71

550 6871VSMG26A PWB(PCB) ASSEMBLY,SUB RF04FA FAN CTRL

560 6871VSMZ99A PWB(PCB) ASSEMBLY,SUB KEYBOARD RF03LA LOCAL KEY 71

561 4980V00B54A SUPPORTER PCB AL CONTROL BOX MN-71PY10

570 6871VSMJ03A PWB(PCB) ASSEMBLY,SB RF04FA MN-71PY10 INDEX B/D

580 6709V00020A POWER SUPPLY ASSEMBLY, PDP 71INCH RF04FA 900W 1H211WI SANKEN PSU ASSY(MW)

590 3141VSNJ23A CHASSIS ASSEMBLY, SUB RF04FA NOISE FILTER ASSY.

591 4980V00B63A SUPPORTER, MOUNTING EGI LINE FILTER & SPK TERMINAL MN-71PY10

600 6871VPMA93A PWB(PCB) ASSEMBLY, SMPS RF-04FA POWER INTERFACE

No. Part No. Description

M62320FP,I/O EXPANDER 16P SOP TP

M62320FP,I/O EXPANDER 16P SOP TPP

KA7805R FAIRCHILD 2P D-PAK R/TP 500MA

AT24C02N-10SI-2.7 ATMEL 8P SOIC R/TP

MAX4572EAI-T MAXIM 28P/SSOP R/TP

74ACT253SC FAIRCHILD 16P SOIC R/TP

DS232AS 16P,SOP TP RS-232 DRIVER/RECEIVER

M74HC123RM13TR 16P SOP R/TP

SIL9993CTG100 SILICON IMAGE 100P/TQFP

AT24C02N-10SI-2.7 ATMEL 8P SOIC R/TP

HA4314BCBZ96 INTERSIL 14P/SOIC R/TP

74ACT253SC FAIRCHILD 16P SOIC R/TP

74HC14D 14SOP TP SHITTER TRIGGER

74LVC126AD PHILIPS 14P SO R/TP

X98017L128-3.3-Z XICOR 128P/MQFP

MAX4572EAI-T MAXIM 28P/SSOP R/TP

VPC3230D C5 80P QFP TRAY

ML87V2105TBZ03A OKI 100P/TQFP

FLI2300BD GENESIS 208P PQFP

MAX4572EAI-T MAXIM 28P/SSOP R/TP

EL5261ISZ-T7 ELANTEC 8P/SOIC R/TP

HY57V643220C(L)T-6 HYNIX 86P TSOP

FLI2300BD GENESIS 208P PQFP TRAY

HY57V643220C(L)T-6 HYNIX 86P TSOP

GM1601H-LF-BD GENESIS 416P/PBGA

KIA7042AF SOT-89 TP 4.2V

AT24C32AN-10SI-2.7 ATMEL 8PIN SOP

M62320FP,I/O EXPANDER 16P SOP TP

ICS670M-01ILFT(PB-FREE) ICS SOIC 16P

MAX4572EAI-T MAXIM 28P/SSOP R/TP

HY5DU283222AQ-5 HYNIX 100P LQFP

SOFT WARE, 3.00V 233B PDP RF04FA

LGDP4410 LG IC 176P TQFP

SIL160CT100 SILICON IMAGE 100 TQFP ST

BA033FP-E2 3P-SOP

SC1565IST-1.8 SEMTECH 3P SOT223 TP

MIC39100 3P SOT223 R/TP LDO TYPE 2.5V

PQ05DZ1U SHARP 5, SMD TYPE R/TP

MIC39100 3P SOT223 R/TP LDO TYPE 2.5V

LM2611AMFX 5P/SOT23-5 R/TP 1.4MHZ

KA7809R, FAIRCHILD 2P D-PAK, R/TP

REPLACEMENT PARTS LIST

LOCA. NO PART NO DESCRIPTION

IC2601

IC2602

IC301

IC302

IC401

IC402

IC5001

IC5002

IC5003

IC5004

IC5005

IC5006

IC501

IC502

IC503

IC504

IC505

IC601

IC602

IC603

IC681

Q101

Q102

Q103

Q104

Q105

Q106

Q107

Q108

Q109

Q110

Q1101

Q1102

Q1103

Q1104

Q111

Q112

Q113

Q114

Q1201

Q1202

Q1203

Q1204

Q1205

Q1206

Q1207

Q1208

Q1209

Q1210

Q1301

Q1302

0IMCRRH001A

0IMMRNE002A

0IMCRET003A

0IMMRNE002A

0IMCRET003A

0IKE780500Q

0ISH092100B

0ISH122100B

0IMI623200B

0IDS162100B

0IMCRMN028B

0IMCRNL001B

0IKE704200J

0IMCRTI028C

0IPRPJR017A

0IMCRSH001A

0IPRPML001A

0IMCRFA010A

0IPMGNS032A

0TR387500AA

0TR830009BA

0TR387500AA

0TR104009AF

0TR387500AA

0TR150400BA

0TR387500AA

0TR104009AF

0TR387500AA

0TR150400BA

0TR387500AA

0TR830009BA

BA033FP-E2 3P-SOP,TO252-3 R/TP 3.3V

UPD64083GF3BA NEC 100 QFP ST

EL5261ISZ-T7 ELANTEC 8P/SOIC

UPD64083GF3BA NEC 100 QFP ST

EL5261ISZ-T7 ELANTEC 8P/SOIC R/TP

KIA7805API 3P TO-220 ST 5V(=KIA7805PI)

PQ09RD21 4SIP ST

PQ12RD21 4SIP ST

M62320FP,I/O EXPANDER 16P SOP TP

DS1621V 8P SOIC ST THERMOSTAT

MSP4410K MICRONAS 80P/PQFP

NSP-6241A NEOFIDELITY 64P TQFP

KIA7042AF SOT-89 TP 4.2V VOLTAGE

TAS5122DCARG4,LF 56P/TSSOP R/TP

NJU26901E2 JRC 8P,EMP R/TP

PQ05DZ1U SHARP 5, SMD TYPE R/TP

MIC39100 MICREL 3P SOT223 R/TP

KA7809R, FAIRCHILD 2P D-PAK, R/TP

LM2611AMFX 5P/SOT23-5 R/TP 1.4MHZ

CHIP 2SC3875S(ALY) BK KEC

BSS83 TP PHILIPS N-CHANNEL S/W TR

CHIP 2SC3875S(ALY) BK KEC

CHIP KRC104S SOT-23 TP KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP KRC104S SOT-23 TP KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

BSS83 TP PHILIPS N-CHANNEL S/W TR

LOCA. NO PART NO DESCRIPTION

IC101

IC102

IC105

IC1102

IC1103

IC1104

IC1201

IC1202

IC1203

IC1204

IC1301

IC1303

IC1401

IC1411

IC1421

IC1451

IC1452

IC1471

IC1472

IC1501

IC1502

IC1601

IC1701

IC1801

IC1901

IC2001

IC201

IC202

IC2051

IC2101

IC2151

IC2201

IC2202

IC2203

IC2204

IC2205

IC2206

IC221

IC2301

IC2302

IC2401

IC2451

IC2501

IC2502

IC2503

IC2504

IC2505

IC2506

IC2507

IC2508

IC2509

0IMI623200B

0IMCRFA015A

0IMMRAL014B

0IPRPMX014A

0IFA742530B

0IDS232000A

0ISTLSG009A

0IMCRS5005A

0IMMRAL014B

0IPRPIS003A

0IFA742530B

0IPH741400E

0IMCRPH018A

0IPRPXI002A

0IPRPMX014A

0IIT323000E

0IPRPOK004A

0IMCRGN002C

0IPRPMX014A

0IMCRET003A

0IMMRHY033A

0IMCRGN002C

0IMMRHY033A

0IPRPGN017A

0IKE704200J

0IMMRAL025A

0IMI623200B

0IPRPIC014A

0IPRPMX014A

0IMMRHY020B

6927V1101AG

0ICTMLG018A

0IS5160000A

0IMCRRH001A

0IMCRSJ001A

0IPRPML001A

0IMCRSH001A

0IPRPML001A

0IPMGNS032A

0IMCRFA010A

IC

TRANSISTOR

- 18 -

- 19 -

LOCA. NO PART NO DESCRIPTION

Q1341

Q1501

Q1502

Q201

Q202

Q203

Q204

Q221

Q222

Q2501

Q2502

Q2503

Q301

Q302

Q303

Q304

Q305

Q306

Q307

Q308

Q309

Q310

Q311

Q312

Q401

Q402

Q403

Q404

Q405

Q406

Q407

Q408

Q409

Q410

Q411

Q412

D101

D102

D103

D104

D105

D106

D107

D108

D109

D110

D1101

D1102

D1103

D1104

0TR387500AA

0TR830009BA

0TR387500AA

0TR150400BA

0TR387500AA

0TR150400BA

0TR387500AA

0TR150400BA

0TR387500AA

0TR150400BA

0TR387500AA

0TR150400BA

0TR387500AA

0TR150400BA

0TR387500AA

0TR150400BA

0TR387500AA

0TR150400BA

0TR387500AA

0TR150400BA

0DD226239AA

CHIP 2SC3875S(ALY) BK KEC

BSS83 TP PHILIPS N-CHANNEL S/W TR

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

CHIP 2SC3875S(ALY) BK KEC

CHIP 2SA1504S(ASY) BK KEC

KDS226 TP KEC

LOCA. NO PART NO DESCRIPTION

D1105

D1106

D1107

D111

D1110

D1111

D1118

D1119

D112

D1120

D1121

D1122

D1123

D1124

D113

D114

D115

D116

D117

D118

D119

D1301

D2502

D2503

D2504

D2505

D2506

D2507

D2508

D2509

D2510

D2601

D2602

D5001

D601

D602

D603

D681

D8201

D8202

ZD101

ZD102

ZD1105

ZD501

C1122

C1124

C1138

C115

C118

C1207

0DD226239AA

0DD184009AA

0DD226239AA

0DD184009AA

0DD226239AA

0DR340009AA

0DD226239AA

0DD100009AM

0DD226239AA

0DR340009AA

0DR360000BA

0DZRM00178A

0DR050008AA

0DZ820009AH

0CE476SF6DC

0CE107SF6DC

0CE477VF6DC

0CE475WJ6DC

0CE107SF6DC

KDS226 TP KEC

KDS184 TP KEC - 85V - 300MA

KDS226 TP KEC

KDS184 TP KEC - 85V - 300MA

KDS226 TP KEC

MBRS340 TP FAIRCHILD - 40V 3A 80A - 2MA

KDS226 TP KEC

EU1ZV(1) TP SANKEN

KDS226 TP KEC

MBRS340 TP FAIRCHILD - 40V 3A 80A - 2MA

FMB-36M BK SANKEN - 0.62V 100NSEC 10MA

UDZS TE-17 5.1B R/TP SMD 0.2W 5.1V 5MA -PF

SD05.TC R/TP SEMTECH SOD323 5V 5A 15A

MTZJ8.2B TP-K DO34 - 8.2V 5UA -

47UF MVG 16V 20% SMD R/TP

100UF MVG 16V 20% SMD R/TP

470UF MV 16V 20% R/TP(SMD) SMD

4.7UF MVK 35V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

DIODE

CAPACITOR

For Capacitor & Resistors,

the charactors at 2nd and 3rd

digit in the P/No. means as

follows;

CC, CX, CK, CN : Ceramic

CQ : Polyestor

CE : Electrolytic

RD : Carbon Film

RS : Metal Oxide Film

RN : Metal Film

RF : Fusible

- 20 -

LOCA. NO PART NO DESCRIPTION

C121

C1212

C1217

C1218

C1223

C1226

C1227

C1251

C1252

C1253

C1254

C1255

C1256

C1301

C1308

C1313

C1315

C1318

C1324

C1326

C1344

C1405

C1415

C1425

C1452

C1461

C1473

C1502

C1522

C1537

C1548

C1607

C1616

C1618

C1621

C1623

C1629

C1632

C1633

C1707

C1716

C1718

C1721

C1723

C1729

C1732

C1733

C1808

C1908

C202

C2021

C203

0CE475WJ6DC

0CE106SF6DC

0CE105SK6DC

0CE106SF6DC

0CE105SK6DC

0CE476SF6DC

0CE105SK6DC

0CE226VF6DC

0CE106SF6DC

0CE226VF6DC

0CE107SF6DC

0CE226VF6DC

0CE476SF6DC

0CE106SF6DC

0CE226VF6DC

0CE107SF6DC

0CE106SF6DC

0CE476SF6DC

0CE107SF6DC

0CE106SF6DC

0CE107SF6DC

0CE106SF6DC

0CE107SF6DC

0CE106SF6DC

0CK684DF56A

0CE107SF6DC

0CE106SF6DC

0CE107SF6DC

0CE106SF6DC

0CE107SF6DC

0CE106SF6DC

0CK684DF56A

0CE226VF6DC

0CE107SF6DC

0CE105SK6DC

0CE476SF6DC

4.7UF MVK 35V 20% R/TP(SMD) SMD

10UF MVG 16V 20% R/TP(SMD) SMD

1UF MVG 50V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

1UF MVG 50V 20% SMD R/TP

47UF MVG 16V 20% SMD R/TP

1UF MVG 50V 20% SMD R/TP

22UF MV 16V 20% R/TP(SMD) SMD

10UF MVG 16V 20% R/TP(SMD) SMD

22UF MV 16V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

22UF MV 16V 20% R/TP(SMD) SMD

47UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

22UF MV 16V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

47UF MVG 16V 20% SMD R/TP

100UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

0.68UF 2012 16V 10% R/TP X7R

100UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

0.68UF 2012 16V 10% R/TP X7R

22UF MV 16V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

1UF MVG 50V 20% SMD R/TP

47UF MVG 16V 20% SMD R/TP

LOCA. NO PART NO DESCRIPTION

C2033

C2036

C2039

C204

C2042

C2045

C2048

C205

C206

C207

C208

C209

C211

C2121

C2133

C2136

C2139

C214

C2142

C2145

C2148

C216

C217

C218

C219

C2204

C222

C223

C224

C225

C226

C2261

C227

C228

C229

C230

C231

C232

C233

C235

C237

C2417

C2424

C2452

C2456

C2458

C2460

C2501

C2506

C2507

C2512

C2515

0CE226VF6DC

0CE476SF6DC

0CE226VF6DC

0CE106SF6DC

0CE476SF6DC

0CE106SF6DC

0CE105SK6DC

0CE226VF6DC

0CE107SF6DC

0CE226VF6DC

0CE106SF6DC

0CE476SF6DC

0CE335SK6DC

0CE107SF6DC

0CE476SF6DC

0CE107SF6DC

0CE476SF6DC

0CE107SF6DC

0CE106SF6DC

0CE476SF6DC

0CE477SF6DC

0CE227VF6DC

0CE477SF6DC

0CE227VF6DC

22UF MV 16V 20% R/TP(SMD) SMD

47UF MVG 16V 20% SMD R/TP

22UF MV 16V 20% R/TP(SMD) SMD

10UF MVG 16V 20% R/TP(SMD) SMD

47UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

1UF MVG 50V 20% SMD R/TP

22UF MV 16V 20% R/TP(SMD) SMD

100UF MVG 16V 20% SMD R/TP

22UF MV 16V 20% R/TP(SMD) SMD

10UF MVG 16V 20% R/TP(SMD) SMD

47UF MVG 16V 20% SMD R/TP

3.3UF MVG 50V 20% SMD R/TP

100UF MVG 16V 20% SMD R/TP

47UF MVG 16V 20% SMD R/TP

100UF MVG 16V 20% SMD R/TP

47UF MVG 16V 20% SMD R/TP

100UF MVG 16V 20% SMD R/TP

10UF MVG 16V 20% R/TP(SMD) SMD

47UF MVG 16V 20% SMD R/TP

470UF MVG 16V 20% R/TP(SMD) SMD

220UF MV 16V 20% R/TP(SMD) SMD

470UF MVG 16V 20% R/TP(SMD) SMD

220UF MV 16V 20% R/TP(SMD) SMD

For Capacitor & Resistors,

the charactors at 2nd and 3rd

digit in the P/No. means as

follows;

CC, CX, CK, CN : Ceramic

CQ : Polyestor

CE : Electrolytic

RD : Carbon Film

RS : Metal Oxide Film

RN : Metal Film

RF : Fusible

LG MW 71PY10 User manual

Popular Monitor manuals by other brands
