LG GR-B24FWAHL User manual

OWNER’S MANUAL
HOUSEHOLD
REFRIGERATOR-FREEZER
Please read this owner's manual thoroughly before
operating and keep it handy for reference at all times.
www.lg.com
P/No. : MFL67567714
ENGLISH
GR-B24FWAHL / GR-B24FWSHL
GR-B24FWVFC
GR-M24FBGHC

2TABLE OF CONTENTS
ENGLISH
TABLE OF CONTENTS
3 PRODUCT FEATURES
4 IMPORTANT SAFETY
INSTRUCTIONS
8 COMPONENTS
8 Refrigerator Exterior
9 Refrigerator Interior
10 INSTALLATION
10 Installation Overview
11 Unpacking Your Refrigerator
11 Choosing the Proper Location
11 - Flooring
12 - Ambient Temperature
12 Turning On the Power
12 How to Remove the Refrigerator
Door
13 How to Remove the Freezer Door
13 Height Adjustment
13 - Fridge Door Height Adjustment
14 - When the Freezer Door is Lower
15 HOW TO USE
15 Before Use
16 Control Panel
16 - Control Panel Features
17 Storing Food
17 - Food Storage Location
19 - Food Storage Tips
19 - Storing Frozen Food
20 Adjusting the Refrigerator Shelves
20 - Detaching the Shelf
20 - Refitting the Shelf
21 - Using the Folding Shelf
21 - When Closing the Door
22 Big Fresh Zone
22 - Removal of the Big Fresh Zone
drawer
22 - Refitting the Big Fresh Zone
drawer
23 How to disassemble and assemble
the vegetable box
24 Extra Space
24 Fridge Basket
24 In & Out Carrier
25 Tilting Fresh Basket
25 Dairy Corner
25 Door-In-Door
26 - Door-In-Door Shelf Disassembly
27 Adjustable Moving Basket
27 Ice Maker
28 Fresh Zone
28 Freezer Drawer
28 - Freezer Drawer Removal
29 - Refitting the Freezer Drawer
29 Freezer/Fridge Basket
30 MAINTENANCE
30 Cleaning
32 SMART DIAGNOSIS
32 Using Smart Diagnosis
33 TROUBLESHOOTING
39 SPECIFICATION

3
PRODUCT FEATURES
ENGLISH
PRODUCT FEATURES
* Depending on the model, some of the following functions may not be available.
DOOR ALARM
The Door Alarm function is designed to prevent refrigerator
malfunctioning that could occur if a refrigerator door or freezer
door remains open. If a refrigerator door or freezer door is left
open for more than 60 seconds, a warning alarm sounds in 30
second intervals until it is closed.
EXPRESS FREEZING
The freezer section is maintained at the coldest temperature
for a 24-hour period before automatically resuming normal
operation. The freezer display temperature will not change when
Express Freezing is engaged. It will also enhance ice production
whilst it is on.
AUTO CLOSING HINGE
The refrigerator doors close automatically with a slight push. (The
door only closes automatically when it is open at an angle less
than 30°.)

4IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
This guide contains many important safety messages. Always read and obey all safety
messages.
WARNING
You can be killed or seriously injured if you do not follow instructions.
CAUTION
Indicates an imminently hazardous situation which, if not avoided,
may result in minor or moderate injury, or product damage.
WARNING
To reduce the risk of fire, electric shock, or personal injury when using your product,
basic safety precautions should be followed, including the following.
Power
NEVER unplug your refrigerator by pulling on the power cord. Always grip the plug
y
firmly and pull it straight out from the outlet.
If the supply cord is damaged, it must be replaced by the manufacturer or its service
y
agent or a similarly qualified person in order to avoid a hazard. Do not use a cord that
shows cracks or abrasion damage along its length or at either the plug or connector
end.
Do not use an uncertified power outlet.
y
Unplug the power plug immediately in the event of a blackout or thunderstorm.
y
Plug in the power plug with the power cord facing downward.
y
Installation
Contact an authorized service center when you install or relocate the refrigerator.
y
When moving your refrigerator away from the wall, be careful not to roll over or
y
damage the power cord.
Connect this product to a dedicated grounded electric outlet conforming with the
y
rating prior to use. It is the user’s responsibility to replace a standard 2-prong wall
outlet with a standard 3-prong wall outlet.
Do not install the refrigerator where there may be a danger of it falling. Installation on
y
a non sturdy timber floor may cause difficulty in door alignment and cause the cabinet
to deform.
This is the safety alert symbol. It alerts you to safety messages that inform you
of hazards that can kill or hurt you or others, or cause damage to the product.
All safety messages will be preceded by the safety alert symbol and the hazard
signal word WARNING or CAUTION. These words mean:

5
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
Use
DO NOT allow children to climb, stand, or hang on the refrigerator doors or shelves in the
y
refrigerator. They could damage the refrigerator and seriously injure themselves.
Where fitted, do not place heavy objects on the dispenser of the refrigerator or hang onto it.
y
Do not place heavy or dangerous objects (bottles or vases with liquid) on the refrigerator.
y
Do not put live animals inside of the refrigerator.
y
Do not allow children to climb into the product when it is in or out of use.
y
In the event of a gas leak (propane/LPG), ventilate sufficiently and contact an authorized service
y
center before use. Do not touch or disassemble the electric outlet of the refrigerator.
In the event of a refrigerant leak, move flammable objects away from the refrigerator. Ventilate
y
sufficiently and contact an authorized service center.
Do not use or place flammable substances (chemicals, medicine, cosmetics, etc) near the
y
refrigerator or store them inside the refrigerator. Do not place the refrigerator in the vicinity of
flammable gas.
This appliance is intended to be used in household and similar applications such as
y
- Staff kitchen areas in shops, offices and other working environments;
- Farm houses and by clients in hotels, motels and other residential type environments;
- Bed and breakfast type environments;
- Catering and similar non-retail applications.
Do not use this product for special purposes or mobile applications (storage of medicine or test
y
materials or on ships, etc).
Unplug the power plug before cleaning or repairing the refrigerator.
y
If the refrigerator is fitted with light bulbs and require replacing, unplug the refrigerator or turn off
y
the power before doing so.
Do not modify or extend the power cord.
y
Do not use a hair dryer to dry the interior. Do not light a candle to remove any interior odor.
y
For your safety, this appliance must be properly grounded. Have the wall outlet and the circuit
y
checked by a qualified electrician to make sure the outlet is properly grounded.
Do not use an outlet that can be turned off via a remote switch. Do not use an extension cord. It
y
is the user’s responsibility to replace a standard 2-prong wall outlet with a standard 3-prong wall
outlet.
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
y
Do not use an adapter plug and plug the power plug into a multi-outlet extension cord.
y
Disconnect the power cord immediately if you hear a noise, smell a strange odor or detect
y
smoke.
Turn the power off if dust or water from above or below penetrates into the refrigerator. Call a
y
service agent.
Do not disassemble or modify the refrigerator.
y
Do not put hands, feet, or metal objects below or behind the refrigerator.
y
Do not operate the refrigerator or touch the power cord with wet hands.
y
In refrigerators with automatic icemakers, avoid contact with the moving parts of the ejector
y
mechanism or with the heating element that releases the cubes. Do not place fingers or hands
on the automatic ice-making mechanism while the refrigerator is plugged in.
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
To reduce the risk of fire, electric shock, or personal injury when using your product,
basic safety precautions should be followed, including the following.

6IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
CAUTION
Installation
The refrigerator must be properly installed in accordance with the Installer Instructions that
y
were taped to the front of the refrigerator.
Be careful when you unpack and install the refrigerator. Immediately dispose of packing
y
materials (plastic) out of reach of children.
Use
Close the doors carefully when children are around.
y
Keep fingers out of pinch point areas; clearances between the doors and cabinets are
y
necessarily small. Be careful closing doors when children are in the area.
If food is stacked or stored poorly on the shelves, it may fall and cause injury when the
y
door is opened.
Do not move refrigerator while the refrigerator is operating. A Compressor rattling noise
y
may occur as a result and will only stop when the compressor cycles off, or when the
power to the unit is turned off and back on again. (This is normal and will not impact on
the performance or the life of the compressor. The rattling will stop after the compressor
comes to a rest.)
Maintenance
Do not use strong detergents like wax or thinners for cleaning. Clean with a soft fabric.
y
Wipe foreign objects (dust, water, etc) off the prongs of the power plug and contact areas
y
before connecting.
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
To reduce the risk of fire, electric shock, or personal injury when using your product,
basic safety precautions should be followed, including the following.
When dispensing ice from the dispenser, do not use crystal ceramics.
y
Do not touch the cold surfaces in the freezer compartment with wet or damp hands, when
y
your refrigerator is in operation.
Do not put glass containers, glass bottles or beverage cans in the freezer.
y
Do not store explosive substances such as aerosol cans with a flammable propellant in this
y
appliance.
This appliance is not intended for use by persons (including children) with reduced physical,
y
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning the use of the appliance by a person
responsible for their safety.
Do not refreeze frozen foods that have thawed completely. It may result in serious health
y
issues.
If you are throwing away your old refrigerator, make sure the CFC coolant is removed for
y
proper disposal by a qualified servicer. If you release CFC coolant, you may be fined or
imprisoned in accordance with the relevant environmental law.
Disposed or abandoned refrigerators are dangerous, even if they are sitting for only a few
y
days. When disposing the refrigerator, remove the packing materials from the door or take
off the doors but leave the shelves in place so that children may not easily climb inside.
If the refrigerant gas has leaked, do not touch the refrigerator or the power outlet and
y
ventilate the room immediately. A spark could trigger an explosion causing a fire or burns.
Because this refrigerator uses natural gas (isobutene, R600a) as the environment-friendly
refrigerant, even a small amount (50~60g) is combustible. If gas leaks from severe damage
during delivering, installing or using the refrigerator, any spark may cause fire or burns.

7
IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.
To reduce the risk of fire, electric shock, or personal injury when using your product,
basic safety precautions should be followed, including the following.
SAVE THESE INSTRUCTIONS
This appliance contains a small amount of isobutane refrigerant (R600a), natural
gas with high environmental compatibility, but it is also combustible. When
transporting and installing the appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged. Refrigerant squirting out of the pipes
could ignite or cause an eye injury. If a leak is detected, avoid any naked flames or
potential sources of ignition and air the room in which the appliance is standing for
several minutes.
In order to avoid the creation of a flammable gas air mixture if a leak in the
refrigerating circuit occurs, the size of the room in which the appliance may be
sited depends on the amount of refrigerant used. The room must be 1m
2
in size
for every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in
your particular appliance is shown on the identification plate inside the appliance.
Never start up an appliance showing any signs of damage. If in doubt, consult your
dealer.
WARNING
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear
y
of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process,
y
other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
y
Do not use electrical appliances inside the food storage compartments of the
y
appliance, unless they are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in the appliance require special
y
disposal procedures. When disposal, please consult with service agent or a similarly
qualified person.
WARNING
Use drinkable water for ice making.
y

8COMPONENTS
ENGLISH
COMPONENTS
Use this page to become more familiar with the parts and features of your refrigerator.
Page references are included for your convenience.
* The appearance and specifications of the actual product may differ depending on the
model.
Refrigerator Exterior (Applicable to some models only)
LED Display
Displays the refrigerator
and freezer’s target
temperature, the water
filter condition and the
dispenser status.
Door in Door
release Button
Refrigerator
Freezer

9
COMPONENTS
ENGLISH
Refrigerator Interior (Applicable to some models only)
Shelf
Dairy Product Bin
Used to preserve
dairy products.
Shelf
Freezer Basket
Ice Maker
Hygiene Fresh filter
Door-In-Door
Folding Shelf
Big Fresh Zone
Fresh Zone
Freezer Basket
Extra Space
DrawerDrawer
LED interior lamps
The interior lamps light up
the inside of the refrigerator.
Fridge Basket
Big Fresh Zone
Tilting Fresh
Basket

10 INSTALLATION
ENGLISH
INSTALLATION
Installation Overview
Please read the following installation instructions first after purchasing this product or
transporting it to another location.
1 Unpacking your
refrigerator
2 Choosing the
proper location
3 Leveling and Door
Alignment

11
INSTALLATION
ENGLISH
Choosing the Proper Location
The refrigerator should always
y
be plugged into its own individual
properly grounded electrical outlet
rated for 220 Volts, 50 Hz, AC only,
and fused at 15 or 20 amperes. This
provides the best performance and
also prevents overloading house
wiring circuits which could cause a
fire hazard from overheated wires.
It is recommended that a separate
circuit serving only this appliance be
provided.
Unpacking Your Refrigerator
WARNING
Use two or more people to move and
y
install the refrigerator. Failure to do so
can result in back or other injury.
Your refrigerator is heavy. When
y
moving the refrigerator for cleaning or
service, be sure to protect the floor.
Always pull the refrigerator straight
out when moving it. Do not wiggle or
walk the refrigerator when trying to
move it, as floor damage could occur.
Wind the leveling feet up first so that
the unit is on its rollers.
Keep flammable materials and vapors,
y
such as gasoline, away from the
refrigerator. Failure to do so can result
in fire, explosion, or death.
Remove tape and any temporary labels
from your refrigerator before using. Do
not remove any warning-type labels, the
model and serial number label, or the
Tech Sheet that is located under the front
of the refrigerator.
To remove any remaining tape or glue, rub
the area briskly with your thumb. Tape or
glue residue can also be easily removed
by rubbing a small amount of liquid dish
soap over the adhesive with your fingers.
Wipe with warm water and dry.
Do not use sharp instruments, rubbing
alcohol, flammable fluids, or abrasive
cleaners to remove tape or glue. These
products can damage the surface of your
refrigerator.
Refrigerator shelves are installed in the
shipping position. Please reinstall shelves
according to your individual storage
needs.
Flooring
To avoid noise and vibration, the unit
must be leveled and installed on a solidly
constructed floor. If required, adjust
the leveling legs to compensate for
unevenness of the floor. The front should
be slightly higher than the rear to aid in
door closing. Leveling legs can be turned
easily by tipping the cabinet slightly.
Turn the leveling legs to the left to raise
the unit or to the right to lower it. Poorly
constructed timber flooring can cause a
limit in door adjustment and the cabinet to
become out of shape. (See Leveling and
door AlIgnment.)
NOTE
Installing on carpeting, soft tile
surfaces, a platform or weakly
supported structure is not
recommended.
WARNING
To reduce the risk of electric shock,
do not install the refrigerator in a wet
or damp area. do not install in any
outdoor or sheltered outdoor location
or direct sunlight.

12 INSTALLATION
ENGLISH
Ambient Temperature
Install this appliance in an indoor area
where the temperature is between
55°F (13°C) and 110°F (43°C). If the
temperature around the appliance is too
low or high, the cooling ability may be
adversely affected.
1
Place your appliance where it is easy
to use.
2
Avoid placing the unit near heat
sources, direct sunlight or moisture.
3
To ensure proper air circulation around
the fridge -freezer, please maintain
sufficient space on both the sides as
well as top and maintain at least 2
inches (5.08 cm) from the rear wall.
4
To avoid vibrations, the appliance
must be leveled.
5
Don’t install the appliance below 41°F
(5°C). It may affect the performance.
2” (5.08 cm)
24” (61 cm)
How to Remove the
Refrigerator Door
(TURN OFF THE MAIN
POWER. Same procedure for
left and right doors)
1Remove the refrigerator door hinge
cover. (left side)
2
Disassemble connection plugs and
ground wires.
Turning On The Power
Plug in the refrigerator.
CAUTION
Connect to a rated power outlet.
y
Have a certified electrician check
y
the wall outlet and wiring for
proper grounding.
Do not damage or cut off the
y
ground terminal of the power
plug.

13
INSTALLATION
ENGLISH
3
Remove the door by
raising it from the
lower hinge.
How to Remove the Freezer
Door (TURN OFF THE MAIN
POWER. Same procedure for
left and right doors)
1Remove the inner hinge bolt.
2Twist the hinge to raise the pivoting
end so that the door can be lifted
off.
3Turn 1around to release lock and
raise hinge up.
4Disassemble Door, raising it from
Hinge Center.
Upper hinge
Keeper
CAUTION
Remove it after you open Door to
90 degrees.
Lower hinge
Refrigerator
door
Height difference
Freezer door
Refrigerator
door
Refrigerator
door
Freezer door
Freezer door
GR-M24F****
GR-*24****
GR-B24F****
Height Adjustment
Leveling the doors may not be possible
when the floor is not leveled, or is of weak
or poor construction. The refrigerator is
heavy and should be installed on a rigid
and solid surface. Some Timber flooring
may cause levelling difficulties if it flexes
excesively.
Fridge Door Height Adjustment
If the left door is lower, lift the door
y
and screw a door hinge bolt using a
spanner as illustrated in the figure.
Use
y
1
spanner in refrigerator.
(GR-*24****)
If the right door is lower, lift the right
y
door and insert an additional
3
snap
ring using a long nose plier until both
doors are level. (GR-M24F****)

14 INSTALLATION
ENGLISH
Nut Releasing
Nut Tightening
When the Freezer Door is Lower
Method 1 is recommended.
y
Use spa
ynner
2
for freezer door
adjustment.
1(Method 1 recommended.)
Open the door and adjust the level
by using the nut on the adjustable
round foot of the lower side first
by using the supplied number 2
spanner as per the below diagram.
2
(Method 2)
(1) Using the large side of the number
2
spanner, rotate the locking nut
( ) clockwise to unlock it before
adjusting the Adjust-Hinge pin.
(2) Rotate the Adjust-hinge pin either
( ) clockwise or ( ) counter-
clockwise using the narrow side of the
spanner spanner to adjust the level
difference between the refrigerator
door and freezer door (this method
provides limited adjustment).
(3) After adjusting door height, firmly
tighten the Locking nut ( )
counter-clockwise
until secured.
Height difference
Release Locking Nut
Adjust Hinge Pin
Lower Door Down
Raising Door Up
Spanner Lower Door
Down
Raising
Door Up
CAUTION
Do not adjust the hinge pin height
level too much. The hinge pin
can fall out. (Range of height
adjustment : Max. 3mm)

15
HOW TO USE
ENGLISH
HOW TO USE
Before use
Clean the refrigerator.
Clean your refrigerator thoroughly and wipe off all dust that may have
accumulated during shipping.
NOTE
Remove adhesive residue by wiping it off with your thumb or
dishwashing detergent.
CAUTION
Do not scratch the refrigerator with a sharp object or use a
y
detergent that contains alcohol, a flammable liquid or an abrasive
when removing any tape or adhesive from the refrigerator,.
Do not peel off the model or serial number label or the technical
y
information on the rear surface of the refrigerator.
Connect the power supply.
Check if the power supply is connected before use.
Read the “Turning On The Power” section. (Your plug type might be
different from the picture.)
CAUTION
Putting food in the refrigerator before it has cooled could
cause the food to spoil, or a bad odor could remain inside the
refrigerator.
Wait for the refrigerator to cool.
Allow your refrigerator to run for at least three to four hours
before putting food in it. Check the flow of cold air in the freezer
compartment to ensure proper cooling.
The refrigerator makes a loud noise after initial operation.
This is normal. The loudness will decrease as the temperature lowers.
Before Plugging in, open the refrigerator doors to ventilate the
interior.
The inside of the refrigerator may smell like plastic at first. Remove
any adhesive tape from inside the refrigerator and open the
refrigerator doors for ventilation until any odors have subsided.

16 HOW TO USE
ENGLISH
NOTE
The displayed temperature is the
target temperature, and not the actual
temperature of the refrigerator. The
actual refrigerator temperature depends
on the food inside the refrigerator as
well as ambient temperatures and how
often the doors are opened and closed.
Control Panel (Applicable to
some models only)
Control Panel Features
Hygiene Fresh
The Hygiene Fresh function has three
y
modes, Auto (default mode when icon
is lit up) Power mode (when icon and
Power are lit up) and Off (icon is not
lit up) Power mode can be engaged
by pressing the Hygiene Fresh touch
control respectively.
Auto > Power > Off > Auto.....
Power mode will resume back to Auto
mode after 4 hours.
Express Freezing
This function increases both ice making
and freezing capabilities.
When you touch the
yExpress Freezing
(急速冷冻)button, the graphic will
illuminate in the display and will
continue for 3 hours. The function will
automatically disable itself after 3 hours.
You can stop this function manually by
y
touching the button one more time.
Control Lock
The Control Lock function disables the
button functions only on the display.
When power is initially connected to
y
the refrigerator, the Lock function is off.
If you want to activate the
yLock function
to lock other buttons, press and hold
the Lock(锁定)button for 3 seconds or
more. The Lock icon will display and the
Lock function is now enabled.
To disable the
yLock function, press
and hold the Lock(锁定)button for
approximately 3 seconds.
Fridge Temperature
Indicates the set target temperature of
the refrigerator compartment in Celsius
(°C).
The recommended Fridge set temperature
in normal ambient conditions and loads is
3°C ~ 4°C.
Freezer Temperature
Indicates the set target temperature of
the freezer compartment in Celsius (°C).
The recommended Freezer set
temperature in normal ambient conditions
and loads is -17°C ~ -19 °C.

17
HOW TO USE
ENGLISH
Storing Food
Food Storage Location (Applicable to some models only)
Each compartment inside the refrigerator is designed to store different types of
food.
Store your food in the optimal space to enjoy the freshest taste.
Freezer Basket
Preserve small packaged
frozen food or frequently-
taken out foods.
Ice Maker
If necessary, preserve ices
made in icemaker.
Big Fresh Zone
Preserve vegetables and
fruits.
Drawer (1)
Preserve small packaged frozen food or
frequently-taken out foods.
Drawer(2)
Preserve frozen food to keep it long.
Tilting Fresh Basket
Preserve short term ready to
eat vegetables.
Fridge Basket
Store beverages, water, etc.

18 HOW TO USE
ENGLISH
Food Storage Location (Applicable to some models only) (continued)
CAUTION
Do not store food with high moisture content towards the top of the refrigerator.
y
The moisture could come in direct contact with the cold air and freeze.
Wash food before storing it in the refrigerator. Vegetables and fruit should be washed,
y
and food packaging should be wiped down to prevent adjacent foods from being
contaminated.
If the refrigerator is kept in a hot and humid place, frequent opening of the door or
y
storing a lot of vegetables in the refrigerator may cause condensation to form. Wipe off
the condensation with a clean cloth or a paper towel.
If the refrigerator doors are opened or closed too often, warm air may penetrate the
y
refrigerator and raise its temperature. It can also increase the refrigerator’s electricity
usage.
NOTE
If you are leaving home for a short period of time, like a short vacation, the
y
refrigerator should be left on. Refrigerated foods that are able to be frozen will stay
preserved longer if stored in the freezer.
If you are leaving the refrigerator turned off for an extended period of time, remove
y
all food and unplug the power cord. Clean the interior, and leave the doors slightly
ajar to prevent mold from growing in the refrigerator.
Dairy Product Bin
Store diary foods such as butter, cheese, etc.
Extra Space
Preserve small foods such
as eggs, ham, etc.
Fresh Zone
It is possible to keep fresh
some food for long-term
storage for a long time
without the odor mixed
with other food. This
container can be stored in
the refrigeration chamber or
freezer chamber according
to the food in the container.
Door-In-Door
Preserve frequently-
taken out foods such as
beverages, snacks, etc.
Folding Shelf
Fold a shelf to store large-
sized container or food.

19
HOW TO USE
ENGLISH
Food Storage Tips
* The following tips may not be applicable
depending on the model.
Wrap or store food in the refrigerator
in airtight and moisture-proof material
unless otherwise noted. This prevents
food odor and taste transfer throughout
the refrigerator. For dated products, check
use by dates to ensure freshness.
Food How to
Butter or
Margarine
Keep opened butter in a covered
dish or closed compartment.
When storing an extra supply, wrap
in freezer packaging and freeze.
Cheese Store in the original wrapping
until you are ready to use it. Once
opened, rewrap tightly in plastic
wrap or aluminum foil.
Milk
Wipe milk cartons. For best
storage, place milk on interior shelf,
not on door shelf.
Eggs Store in original carton on interior
shelf, not on door shelf.
Fruit Do not wash or prepare fruit until it
is ready to be used. Sort and keep
fruit in its original container, in a
crisper, or store in a completely
closed paper bag on a refrigerator
shelf.
Leafy
Vegetables
Remove store wrapping and trim
or tear off bruised and discolored
areas. Wash in cold water and
drain. Place in plastic bag or plastic
container and store in crisper.
Vegetables
with skins
(carrots,
peppers)
Place in plastic bags or plastic
container and store in crisper.
Fish Store fresh fish and shellfish in
the freezer section if they are not
being consumed the same day of
purchase. It is recommended to
consume fresh fish and shellfish
the same day purchased.
Leftovers Cover leftovers with plastic wrap,
aluminum foil, or plastic containers
with tight lids.
Storing Frozen Food
Freezing
Your freezer will not quick-freeze a
large quantity of food. Do not put more
unfrozen food into the freezer than will
freeze within 24 hours (no more than 1
to 1.5kg. of food per cubic foot of freezer
space). Leave enough space in the freezer
for air to circulate around packages. Be
careful to leave enough room at the front
so the door can close tightly.
Storage times will vary according to
the quality and type of food, the type of
packaging or wrap used (how airtight
and moisture-proof) and the storage
temperature. Ice crystals inside a sealed
package are normal. This simply means
that moisture in the food and air inside
the package have condensed, creating ice
crystals.
NOTE
Check a freezer food guide or a reliable
cookbook for further information about
preparing food for freezing or food
storage times.
NOTE
Allow hot foods to cool at room
temperature for 30 minutes, then
package and freeze. Cooling hot foods
before freezing saves energy.
NOTE
Never freeze beverage cans or bottles
of any kind as they can explode or
shatter.

20 HOW TO USE
ENGLISH
Storing Frozen Food (continued)
Packaging
Successful freezing depends on correct
packaging. When you close and seal
the package, it must not allow air or
moisture in or out. If it does, you could
have food odor and taste transfer
throughout the refrigerator and could
also dry out frozen food.
Packaging recommendations:
Rigid plastic containers with tight-
y
fitting lids
Straight-sided canning/freezing jars
y
Heavy-duty aluminum foil
y
Plastic-coated paper
y
Non-permeable plastic wraps
y
Specified freezer-grade self-sealing
y
plastic bags
Follow package or container instructions
for proper freezing methods.
Do not use
Bread wrappers
y
Non-polyethylene plastic containers
y
Containers without tight lids
y
Wax paper or wax-coated freezer
y
wrap
Thin, semi-permeable wrap
y
Adjusting the Refrigerator
Shelves
The shelves in your refrigerator are
adjustable to meet your individual storage
needs. Your model may have either glass
or wire shelves.
Adjusting the shelves to fit different
heights of items will make finding the
exact item you want easier. Doing so
will also reduce the amount of time the
refrigerator door is open which will save
energy.
Detaching the Shelf
Tilt up the front of the shelf and lift it
straight up. Pull the shelf out.
Refitting the Shelf
Tilt the front of the shelf up and guide the
shelf hooks into the slots at the desired
height. Then, lower the front of the shelf
so that the hooks drop into the slots.
CAUTION
Make sure that shelves are level
from one side to the other. Failure to
do so may result in the shelf falling
or spilling food.
