LG GR-M307QGS User manual

O NER’S MANUAL
SXS
REFRIGERATOR
Please read this owner's manual thoroughly before
o erating and kee it handy for reference at all times.
www.lg.com
ENGLISH

2
Table of contents
Introduction
Installation
Operation
Suggestion on
food storage
Care and
maintenance

This product is exclusive use at 220V/50Hz~60Hz.

You should purchase transformer of more than 2.0KVA when you
want to use it at the 110V area.
ENGLISH
Entry
Basic safety precautions
Identification of parts
Where to install
Door removal
Door replacement
Height adjustment
Starting
Control Panel
Home Screen
Basic Buttons
Food Manager
Recipes
Grocery
Memo
Calendar
REF Manager
Smart Saving
Settings
Using the Widgets
Fresh Air Filter
Refrigerator home bar
Door Ice Maker
Shelf
Folding Shelf
Egg box
Deodorizer
Freezer/Fridge basket
Fresh compartment
V Fresh compartment
Location of foods
Storing foods
General information
Cleaning
Trouble shooting
Disposal of the old appliance
It is normal…
Standard information
3
3
11
12
13
13
14
15
15
17
18
19
28
31
37
42
44
44
45
55
57
58
60
62
62
63
63
63
64
65
66
67
68
68
69
72
73
74

Introduction
3
Entry
The model and serial numbers are found on the inner case or Right side of
refrigerator compartment of this unit. These numbers are unique to this unit and
not available to others. You should record requested information here and retain
this guide as a permanent record of your purchase. Staple your receipt here.
Date of purchase :
Dealer purchased from :
Dealer address :
Dealer phone no. :
Model no. :
Serial no. :
Basic safety precautions
This guide contains many important safety messages.
Always read and obey all safety messages.
This is the safety alert symbol. It alerts you to safety messages that inform you of
hazards that can kill or hurt you or others or cause damage to the product. All safety
messages will be preceded by the safety alert symbol and the hazard signal word
DANGER, WARNING, or CAUTION. These words mean:
All safety messages will identify the hazard, tell you how to reduce the chance of injury,
and tell you what can happen if the instructions are not followed.
You will be killed or seriously injured if you don’t follow
instructions.
DANGER
You can be killed or seriously injured if you don’t follow
instructions.
WARNING
Indicates an imminently hazardous situation which, if not
avoided, may result in minor or moderate injury, or product
damage only.
CAUTION

Introduction
4
ENGLISH
To reduce the risk of fire, electric shock, or injury to persons when using your
product, basic safety precautions should be followed, including the following.
Read all instructions before using this appliance.
1. When connecting the power
The dedicated outlet should be used.
• Using several devices at one outlet may cause fire.
• The electric leakage breaker may damage food and the
dispenser may be leaked.
Prevent the power cord from being squeezed or imprinted if the refrigerator is pushed
in after the power plug is extracted during the installation.
When moving your appliance away from the wall, be careful not to roll over the power
cord or to damage it in any way.
It becomes the cause of fire or electric shock.
Do not allow the power cord bent or pressed by the heavy
object to be damaged.
It may damage the power cord to cause fire or electric shock.
Do not allow the power plug to face upward or to be squeezed at
the back of the refrigerator.
Water may be flown into or the plug may be damaged, which
causes fire or electric shock.
Do not extend or modify the length of the power plug.
It causes electric shock or fire by the electric damage of the
power cord or others.
Unplug the power plug when cleaning, handling or replacing the
interior lamp of the refrigerator.
• It may cause electric shock or injury.
• When replacing the interior lamp of the refrigerator, make sure
that the rubber ring for preventing the electric spark within the
socket is not taken off.
WARNING

Introduction
5
Remove water or dust from the power plug and insert it with the
ends of the pins securely connected.
Dust, water or unstable connection may fire or electric shock.
Unplug the power cord from the power outlet for cleaning or other requirements.
It may cause electric shock or injury.
Make sure of grounding.
Consult a qualified electrician or service person if the
grounding instructions are not completely understood,
or if you have doubts on whether the appliance is properly
grounded.
The incorrect grounding may cause breakdown and electric
shock.
Be sure to use grounded exclusive proper voltage consent for the power plug.
Be sure to use grounded extension consents when extension consents are used.
It becomes the cause of fire.
Ground
Wire
Copper
Flat
More than
30 inches
When the power cord or the power plug is damaged or the holes
of the outlet are loosed, do not use them.
It may cause electric shock or short circuit to make fire.
Wait for 5 minutes or longer when reconnecting the plug.
It may cause the operation of the freezer to fail.
If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
Pull out the power plug not by grasping the cord but the plug of
its end.
It may cause electric shock or short circuit to fire.
Do not pull out the cord or touch the power plug with wet hands.
It may cause electric shock or injury.

Introduction
6
ENGLISH
2. When using the refrigerator
Do not place the heavy object or the dangerous object (container
with liquid) on the refrigerator.
It may be dropped to cause injury, fire or electric shock when
opening or closing the door.
Do not install the refrigerator in the wet place or the place which
water or rain splashes.
Deterioration of insulation of electric parts may cause electric
leakage.
Do not cling to the door or the shelves of the door or the
home bar of the freezer or the cool chamber.
It may make the refrigerator fallen down or damage the
hands. Especially, do not allow the children to do the above.
When water entered to electric parts inside the product, pull out the power plug, and
contact the service center.
It may cause electric shock or fire.
Prevent children from entering the product.
It may endanger the life of a child if the child enters the
refrigerator.
Opening and closing the door of the refrigerator vigorously may cause the stored food
in the refrigerator basket to fall by shock and hurt the foot, so take precautions.
Do not use or store inflammable materials ether, benzene,
alcohol, medicine, LP gas, spray or cosmetics near or in the
refrigerator.
It may cause explosion or fire.
Benzene

Ether
Thinner
Do not use drier to dry the inside, nor light a candle to remove
odor.
It may cause explosion or fire.
Do not store the medicine or the academic materials at the
refrigerator.
When the material with the strict temperature control is stored,
it may be deteriorated or it may make an unexpected reaction to
cause any risk.
The Academic
Medicine
The Medicine

Introduction
7
Use the submerged refrigerator after checking it.
It may cause electric shock or fire.
In case of thunder and lightning, or not in use for a long period of
time, detach the power plug.
There is a danger of electric shock or fire.
When gas is leaked, do not touch the refrigerator or
the outlet and ventilate the room immediately.
• The explosion by spark may cause fire or burn.
• Because this refrigerator uses natural gas (isobutene,
R600a) as the environment-friendly refrigerant, even a small
amount (70~90g) is combustible. When the gas is leaked by
the severe damage during delivering, installing or using the
refrigerator, any spark may cause fire or burn.
Do not move refrigerator while the compressor is operating.
Compressor may occur a temporary rattling noise.
(This is normal and will not impact on the performance or the life of the compressor.
The rattling will stop after the refrigerator comes to a rest.)
Do not spray water at the outside or the inside of the
refrigerator or do not clean it with benzene or thinner.
Deterioration of insulation of electric parts may cause electric
shock or fire.
Thinner
Do not place flower vase, cup, cosmetics, medicine or any
container with water on the refrigerator.
It may cause fire, electric shock or injury by dropping down.
Install in places away from the fire such as the place where
flammable gas is leaked.
It may cause fire.
Do not use the combustible spray near the refrigerator.
It may cause fire.

Introduction
8
ENGLISH
When any strange smell or smoke is detected from the
refrigerator, disconnect the power plug immediately and
contact to the service center.
It may cause fire.
Service
center
Do not use the refrigerator for non-domestic purpose
(storing medicine or testing material, using at the ship, etc.).
It may cause an unexpected risk such as fire, electric shock,
deterioration of stored material or chemical reaction.
Do not insert refrigerator shelf upside down.
The shelf may fall down and cause injury.
Be careful of the door falling down during disassembly and assembly of the door.
When disposing the refrigerator, remove the packing materials from
the door or take off the doors but leave the shelves in place so that
children may not easily climb inside.
It may cause to lock out the child.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Install the refrigerator on the solid and level floor.
Installing it on the unstable place may cause death by falling down
the refrigerator when opening or closing the door.
Do not insert the hands or the metal stick into the exit of
cool air, the cover, the bottom of the refrigerator, the
heatproof grill (exhaust hole) at the backside.
It may cause electric shock or injury.
Do not allow any person except the qualified engineer to
disassemble, repair or alter the refrigerator.
It may cause injury, electric shock or fire.

Introduction
9
Violating this direction may cause injury or damage house or furniture.
Always be careful, please.
CAUTION
Do not insert the hands into the ice bucket or the ice dispenser.
(only for the model with the dispenser).
Operating the ice maker may cause injury.
This appliance contains a small amount of isobutane refrigerant (R600a), natural
gas with high environmental compatibility, but it is also combustible. When
transporting and installing the appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged. Refrigerant squirting out of the
pipes could ignite or cause an eye injury. If a leak is detected, avoid any naked
flames or potential sources of ignition and air the room in which the appliance is
standing for several minutes.
In order to avoid the creation of a flammable gas air mixture if a leak in the refrigerating
circuit occurs, the size of the room in which the appliance may be sited depends on the
amount of refrigerant used. The room must be 1 in size for every 8g of R600a
refrigerant inside the appliance. The amount of refrigerant in your particular appliance is
shown on the identification plate inside the appliance. Never start up an appliance
showing any signs of damage. If in doubt, consult your dealer.
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear
of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in the appliance require special
disposal procedures. When disposal, please consult with service agent or a similarly
qualified person.

Introduction
10
ENGLISH
Do not touch food or containers at the freezer with wet hands.
It may cause frostbite.
Do not put ice in thin crystal cup or ceramic ware.
It may break cup or ceramic ware to cause injury.
When the electricity is off, remove ice from the ice bucket
(only for the model with the dispenser).
The long-time power failure may thaw ice to damage the floor.
When the long-time power failure is expected, remove ice from
the ice bucket.
Supply the automatic ice maker with drinkable water only
(only for the model with the dispenser).
Otherwise, it may cause any risk.
Do not remove the cover of the automatic ice maker.
(Only for the models with automatic ice maker)
The operation mechanic parts of the ice maker may hurt people.
Do not place the food in disorder inside the refrigerator.
The food may fall during opening and closing the door of the refrigerator and hurt
people.
Drinkable
water
Do not put bottle in the freezer.
It may freeze the contents to break the bottle to cause injury.
Do not insert the hands into the bottom of the refrigerator.
The iron plate of the bottom may cause injury.
Do not tilt the product while moving the product.
Carry the refrigerator with the handle bar at the bottom of the
front and the top of the rear.
Otherwise, your hands may be slipped to cause injury.
Because the product is heavy, carrying it alone may hurt people
or accidents may occur.

Introduction
11
Identification of parts
•
Parts, features, and options vary by model. Your model may not include every option.
NOTE
Freezer
Compartment
Refrigerator
Compartment
Ice Bank
Door rack
Ice Maker
Shelf
Shelf
LED Lamp
-35°C Fast
freezing
Corner
Door rack
Drawer
Door rack
Shelf
Fresh Air Filter
Folding Shelf
Refreshment center
Egg Box
LED Lamp
Dairy Corner
Door Rack
Door Rack
Fresh compartment
V Fresh compartment
Because opening or closing the door or the home bar of the
refrigerator may cause injury to the person around it, be
careful, please.
Opening or closing the door may cause feet or hands to be
caught in the chink in door or the child to be get hurt by the
corner.
Do not put any living animal in the refrigerator.
If refrigerator is moved in zigzag direction, it may damage the
floor. Please move it only in a straight line direction.

Installation
12
ENGLISH
1. Place your appliance where it is easy to use.
2. Avoid placing the unit near heat sources, direct
sunlight or moisture.
3. To ensure proper air circulation around the fridge
-freezer, please maintain sufficient space on both the
sides as well as top and maintain at least 2 inches
(5 cm) from the rear wall.
4. To avoid vibrations, the appliance must be leveled.
5. Don't install the appliance below 5°C. It may cause
affect the performance.
Select a good
location
Where to Install
Appliance
usage range
This appliance is intended to be used in household and similar applications such as
– staff kitchen areas in shops, offices and other working environments;
– farm houses and by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
More than
5 cm to back
Keep it at a
proper distance
Keep it at a
Keep it at a
proper distance
proper distance

Installation
13
Door removal
Remove the
freezer
compartment
door
Remove the
refrigerator
door
1) Removing the hinge cover by loosening
the screws. Separate all connection
wires.
2) Remove the keeper by rotating it
counter clockwise (c) and then lifting
the upper hinge up (d).
3) Remove the freezer compartment door by
lifting it upward.
1) Loosen the hinge cover screws and
remove the cover. Remove connection
wire.
2) Remove keeper by rotating it clockwise
(c) and then remove the upper hinge
by lifting it up (d).
3) Remove the refrigerator compartment
door by lifting it up.
•
When removing the upper hinge, be careful that
the door does not fall forwards.
NOTE
•
Move the refrigerator compartment door passing
through the access door and lay it down.
NOTE
Lower hinge
Lower hinge
Keeper
Connection
wires
Connection
wires
Hinge
cover
Upper
hinge
Keeper Upper hinge
Upper
hinge
Door replacement
Pass the refrigerator laterally through the
access door as shown in the right figure.
Mount them in the reverse sequence of removal after they pass through the access
door.
Pass the
refrigerator
1
2
345
Max
FRZ
TEMP
REF
TEMP
Min 5
432
1Max

Installation
14
ENGLISH
Height adjustment
- When the height of the door may not be leveled
when the floor is not leveled.
왘When the freezer door is lower – 
Use the spanner to turn the nut of the height
adjustment screw on the left to the counterclockwise
direction to level the door.
왘When the fridge door is lower – 
Use the spanner to turn the nut of the height
adjustment screw on the right to the clockwise
direction to level the door.
When the floor
is not leveled
The refrigerator doors will close smoothly by heightening the front side by adjusting the
height adjusting screw. If the doors do not close correctly, performance may be
affected.
After leveling
the door height
Next
1. Wipe off all dust accumulated during shipping and clean your appliance thoroughly.
2. Install accessories such as the ice cube box, cover evaporating tray, etc., in their
proper places. They are packed together to prevent possible damage during shipping.
3. Connect the power supply cord (or plug) to the outlet. Don't double up with other
appliances on the same outlet.
Do not force too hard to level the height. The hinge pin can be pulled out.
(Adjustable range of height is a maximum of 2" (5 cm))
CAUTION
왘When the fridge door is lower than the freezer door while using the refrigerator,
level the doors.
1. Use the 햴tool for adjustment on
the wide side to turn nut 햲( )
in the clockwise direction to loosen
the keeper nut.
2. Use the 햴tool for adjustment on
the narrow side to turn the
adjustment hinge pin 햳in ( )
clockwise direction or ( )
counterclockwise direction to
adjust the height of the fridge and
freezer doors.
3. After aligning the height of the
door, turn the keeper nut in counterclockwise direction tightly.
When the fridge
door is lower
than the freezer
door
Height difference
When using
the spanner
Height difference
Up
Down
keeper nut
Adjustment
hinge pin
Tool for
adjustment

Operation
15
Starting
Control Panel
When your refrigerator is first installed, allow it to stabilize at normal operating
temperatures for 2-3 hours prior to filling it with fresh or frozen foods.
If operation is interrupted, wait 5 minutes before restarting.
* Depending on the model, some of the following functions may not be available.
Indicates the set temperature of the refrigerator compartment in
Celsius (°C).
If you want to set the temperature, touch the up and down arrow
button.
Indicates the set temperature of the freezer compartment in
Celsius (°C).
Refrigerator
Temperature
Freezer
Temperature
•
The displayed temperature is the target temperature, and not the actual temperature
of the refrigerator. The actual refrigerator temperature depends on the food inside the
refrigerator.
NOTE
1
2

Operation
16
ENGLISH
The Fresh Air Filter helps remove odors from the refrigerator. The
Fresh Air Filter has two settings, Auto and Power(PWR). In Auto
mode, the Fresh Air Filter will cycle on and off in increments of ten
minutes on and one hundred ten minutes off. If set to the
Power(PWR) mode, the Fresh Air Filter will stay on continuously for
four hours, cycling on and off in increments of ten minutes on and five minutes off.
After four hours, the Fresh Air Filter will switch back to Auto mode.
This function increases both ice making and freezing capabilities.
• When you touch the `ON' button, this function will automatically
shut off after 24 hours.
• You can stop this function manually by touching the `OFF' button.
The Smart Saving function disables the mullion heater located on the
refrigerator door in order to conserve electricity. Touch the On or Off
button to turn the Smart Saving feature either on or off.
If you enable the Lock to prevent a mistake, you can not touch
any button except unlock button.
• Activate the Lock to disable every function on the display except for
the Lock button.
• To activate the Lock, press and hold the Lock button for approximately three seconds.
The Lock icon will display and the Lock function is now enabled.
• When the Lock function is activated, no other buttons will work. The dispenser pad is
also deactivated.
• To disable the Lock function, press and hold the Lock button for approximately three
seconds.
When the refrigerator is in the Power Saving Mode, the display will remain off until a
door is opened or a button is pressed. Once on, the display will remain on for 1 minute
and photo slide show. Photo slide show time can be set in Settings > Screen Saver.
- Replace Filter notification.
2
`Replacement' is shown on the screen.
1
Reset Button will activate.
- After replacing the filter, press and hold the `Reset' button for approximately 3 seconds
to complete replacement of the filter.
It is recommended to change the air filter approximately every six months.
Fresh Air Filter
Express Frz
Smart Saving
Lock
Power Saving
Mode
Change Filter
•
Discontinue using the Eco Friendly function if excessive moisture begins to collect on
the door mullion.
NOTE

Operation
17
CAUTION
- The touch screen will only respond to the human touch. Touch gloves, pens or other
objects will not work with the touchscreen, and may cause a malfunction.
Home Screen
- The Home screen shows Widgets, Function Icons, Date/Time, Wi-Fi, Energy Saving,
Zigbee.
- If you wish to change the order and position of Homescreen widget, use Settings >
Edit Homescreen.
Function Icons
This is composed of 8 icons.
Wi-Fi signal strength display
Displays the Wi-Fi signal connection. If Wi-Fi is
not connected, check your wireless network.
Widget
The home screen Includes nine Widgets that are located on seven separate
pages. You can scroll through the pages by swiping left or right.
Lock
When the Lock is set, all functions on the display screen
are disabled except for the Lock button.

Operation
18
ENGLISH
Basic Buttons
- When a function icon is touched, the basic buttons ( ) will display on the
top left corner.
Home Button
Touch the Home button to return to the Home screen.
Back Button
Touch the Back button to return to the previous screen.
The touch screen will only respond to the human touch. Touch gloves, pens or other
objects will not work with the touchscreen, and may cause a malfunction.
CAUTION

Operation
19
- Touch the Food Manager button at the bottom of the Home screen.
- In Food Manager, you can search for food items with the Add New Food button or
magnify lens button to search using the keypad.
- You can check the food stored in
each chamber (Refrigerator,
Freezer, etc.).
- Select View List to view the
entire food list in alphabetical
order.
Food Manager
Touch for Food Manager using Keypad.

Operation
20
ENGLISH
The Category tab in the Food
Manager screen allows you to
easily select food items to add
to your refrigerator or freezer by
category.
- Select the Food Manager
button on the Home Screen.
- Select the Refrigerator or
Freezer button.
- To add food items to the
refrigerator by category, select
Category.
- Select the Category tab.
- Select the desired food
category.
- Select the food items that you
would like to add to the
refrigerator. Once all of the
desired food items in that
category are selected, touch
the Add button.
- Touch the Back button to
return to the category list and
add more food items.
Food Manager
by Category
If a food item is already in the refrigerator,
an alert will display on the screen.
CAUTION
