STANDARD/BASS BLAST: Selects the sound effect.
DRC ON/OFF :
Makes comfortable sound at Dolby Digital.
.
WOOFER LEVEL +/-: Adjusts the volume level of
subwoofer.
AUTO POWER ON/OFF: Automatically turns on by an
input source.
Replacement of battery
Remote control
Front Panel
Rear Panel
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · Standby
······························Selects Function.
/ ························· Adjusts Volume.
(USB) ··············· Connect to a USB device.
PORT. IN (Portable) ··· Connect to a Portable device.
OPT. IN (Optical) ······ Connect to an Optical device.
Subwoofer Connection1
TV Connection2
aConnect the sound bar to the TV using
an Optical cable.
bSet up [External Speaker (Optical)] on
your TV setting menu.
Place the wireless subwoofer near the sound bar and
follow steps below.
aConnect the power cord of wireless subwoofer
and sound bar to the outlet.
bTurn on the main unit :
The sound bar and wireless subwoofer will be
automatically connected. The subwoofer's
green LED turns on.
Subwoofer Connection Manually
If the subwoofer does not make sound, try to
connect manually.
aPress Pairing button on the rear of the wireless
subwoofer.
yThe green LED on the rear of wireless
subwoofer blinks quickly.
bTurn on the main unit.
cPairing is completed.
yThe green LED on the rear of wireless
subwoofer turns on.
Keep the sound bar and the subwoofer away
from the device (ex. wireless router, microwave
oven, etc.) over 1 m to prevent wireless
interference.
!P
Additional Device Connection
aConnect to the external device as follows.
TV
(Set-top
Box, Player
etc.)
bSet the input source by pressing OPTICAL on
the remote control or pressing Fon the unit
repeatedly.
The buttons are located on the rear.
TV
Additional Information
Specication
Power requirements Refer to the main label.
Power
consumption Refer to the main label.
Dimensions
(W x H x D)
Approx.
660 mm x 56 mm x 99 mm
With foot
Bus Power Supply
(USB) 5 V 0 500 mA
Amplier
(Total RMS
Output power)
160 W RMS
Design and specications are subject to change without
notice.
