LG F0L9DGP Series User manual

WASHING MACHINE
SERVICE MANUAL
MODEL : F0L9DGP**
website : http://biz.lgservice.com
e-mail : http://LGEservice.com/techsup.html
CAUTION
READ THIS MANUAL CAREFULLY TO DIAGNOSE PROBLEMS
CORRECTLY BEFORE OFFERING SERVICE.
BEFORE SERVICING THE WASHING MACHINE, UNPLUG THE POWER
CORD TO AVOID THE RISK OF AN ELECTRIC SHOCK.
WHEN SERVICING INTERNAL PARTS ,
USE ONLY SE RVICE PARTS SUPPLIED FROM LG.
AFTER SERVICING THE ELECTRIC WIRE, INSURE THAT INSULATION
TAPE IS APPLIED TO PREVENT AN ELECTRICAL SHORT.

2
CONTENTS
1. SPECIFICATION ....................................................................................................................... 3
2. FEATURES & TECHNICAL EXPLANATION ............................................................................. 4
3. PARTS IDENTIFICATION .......................................................................................................... 7
4. INSTALLATION ......................................................................................................................... 8
5. WIRING DIAGRAM / PROGRAM CHART .............................................................................. 11
6. OPERATION ............................................................................................................................ 12
7. TROUBLESHOOTING ............................................................................................................ 14
7-1. BEFORE SVC CHECKING ............................................................................................. 14
7-2. QE TEST MODE ............................................................................................................. 14
7-3. HOW TO KNOW THE WATER LEVEL FREQUENCY .................................................... 14
7-4.
HOW TO KNOW TO TEMPERATURE OF EACH THERMISTOR AT OPERATING CONDITION .... 15
7-5. ERROR DISPLAY. ........................................................................................................... 15
7-7. SMART DIAGNOSIS™ ................................................................................................... 19
7-6. SMART FUNCTIOMS ................................................................................................... 17
8. ERROR DIAGNOSIS AND CHECK LIST ................................................................................ 20
8-1. DIAGNOSIS AND ANSWER FOR ABNORMAL OPERATION ........................................ 20
8-2. FAULT DIAGNOSIS AND TROUBLE SHOOTING .......................................................... 23
9. DISASSEMBLY INSTRUCTIONS ........................................................................................... 32
10. EXPLODED VIEW ................................................................................................................. 40
10-1. THE EXPLODED VIEW OF CABINET & CONTROL PANEL ASSEMBLY .................... 40
10-2. THE EXPLODED VIEW OF DRUM & TUB ASSEMBLY ............................................... 41
10-3. THE EXPLODED VIEW OF DISPENSER ASSEMBLY ................................................. 42
10-4. THE EXPLODED VIEW OF DRYER ASSEMBLY ......................................................... 43

3
1. SPECIFICATION
Refer to 1 page
STONE SILVER/WHITE
127V ,60Hz
ITEM
COLOR
POWER SUPPLY
PRODUCT WEIGHT 81 kg
ELECTRIC
POWER
CONSUMTION
WASHING 190 W
WASH HEATER 1250W
DRYING 1400W
REVOLUTION
SPEED
WASH 46 rpm
SPIN Extra Low / Low / Medium / High / Extra High
CYCLES 12
WASH / RINSE TEMPERATURES 5
SPIN SPEEDS 5
OPTIONS Turbowash, Delay End, Steam, Remote Start
Normal Dry, Extra Dry,Add Item, Time Dry, Child Lock
WATER CIRCULATION Incorporated
OPERATIONAL WATER PRESSURE 50-800kPa
CONTROL TYPE Electronic
14kg / 8kgWASH / DRY CAPACITY
DIMENSIONS 645 mm (W) X 770 mm (D) X 940 mm (H)
DELAY WASH up to 19 hours
DOOR SWITCH TYPE PTC + Solenoid
LAUNDRY LOAD SENSING Incorporated
ERROR DIAGNOSIS Incorporated
AUTO POWER OFF Incorporated
CHILD LOCK Incorporated
RLM ENABLE -
NFC -

4
2. FEATURES & TECHNICAL EXPLANATION
2-1. FEATURES
nDirect Drive System
The advanced Brushless DC motor directly drives the drum without belt and pulley.
6 Motion
Washer is able to perform various drum actions or a combination of different actions
depending on the wash program selected.
Combined with a controlled spin speed and the ability of the drum to rotate both
left and right, the wash performance of the machine is greatly improved, giving you
perfect results every time.
nTurbo Wash
Wash cycle in under 1 hour with energy and water saving.
(based on half of laundry)
nWater Circulation
Sprays detergent solution and water onto the load over and over.
Clothes are soaked more quickly and thoroughly during wash cycle.
The detergent suds can be removed more easily by the water shower during rinse
cycle. The water circulation system uses both water and detergent more ef ciently.
10
nTilted Drum and Extra Large Door Opening
Tilted drum and extra large opening make it possible to load and unload clothing
more easily.
nEmbossing drum & waved lifter
Embossing drum enhances the washing performance and reduces clothes damage.
The waved lifter spray and help clothes to enhance washing performance during
the washing cycle.
nAutomatic Wash Load Detection
Automatically detects the load and optimizes the washing time.
nBuilt-in Heater
Internal heater helps to maintain water temperature at its optimum level for selected
cycles.
nChild Lock
The Child lock prevents children from pressing any button to change the settings-
during operation.
nSmart Diagnosis™
Should you experience any technical dif culty with your washing machine, it has
the capability of transmitting data by phone to the Customer Information Center.
The call center agent records the data transmitted from your machine and uses it to
analyze the issue, providing a fast and effective diagnosis.

5
2-2. NEURO FUZZY WASHING TIME OPTIMIZATION
To get the best washing performance, optimal time is determined by the water temperature,
the selected washing temperature, and the size of the load.
water
temperature
washing time
rinsing time
the best
washing
performance
spin rhythm, time
selected
washing
temperature
NEURO-
FUZZY
SENSING PROCESSING
DETERMINATION EFFECT
load
size
2-3. WATER LEVEL CONTROL
This model incorporates a pressure sensor which can sense the water level in the tub. l
The water supply is stopped when the water level reaches the preset level, the washing program then l
proceeds.
Spinning does not proceed until the water in the tub drains to a certain level. l
2-4. DOOR CONTROL
The door can be opened by pulling the door handle whenever washer is not in operation. l
When the cycle is completed, the DOOR LOCKED light will turn off. l
If a power failure has occurred while in operation, the door will unlock after 5 minutes. l
Clicking sounds can be heard when the door is locked/unlocked. l
●
●
●
●
●
●
●

6
2-5. THE DOOR CAN NOT BE OPENED
While program is operating
When a power failed and power plug is taken out in operation
While Door Lock lights turn on.
While the motor is in the process of intertial rotating, through the operation is paused.
2-6. DOOR LOCKED LAMP LIGHTS
When the frequency of water level is lower than 22.9 kHz
(It can be canceled when the frequency is more than 23.8 kHz)
When the temperature inside the tub is higher than 45 ° C and water level is not 25.5 kHz.
(It can be canceled when the water level is 25.5 kHz or the temperature inside the tub is lower than
40°C)
2-7. CHILD LOCK
Use this option to prevent unwanted use of the washer. Press and hold the Wash and Rinse button for
3 seconds to lock/unlock control.
When Child lock is set, CHILD LOCK lights and all buttons are disabled except the Power
●
●
●
● button.
You can lock the washer while it is operating.
2-8. WATER CIRCULATION
When Washing and Rinsing function of shower at the side parts of Gasket
When Washing, it continuously operates for intermittently.
When Rinsing, it continuously operates after completion of water supply.
●
●
●
●
●
●
●
Δ

7
3. PARTS IDENTIFICATION
Inlet Hose
Dispenser
Drum
Door
Drain Hose
Drain Pump Filter
Drain Plug
Power Plug
Shipping Bolts
Control Panel
Lower Cover Cap
Adjustable Feet
• If the supply cord is damaged,
it must be replaced by the
manufacturer or its authorized
service technician in order to
avoid a hazard.
ACCESSORIES
Inlet hose (1EA) Wrench Elbow Bracket
(for securing drain hose)
Non-skid pads
Caps(4)
(for covering shipping bolt
holes)
Cold Water
Inlet
Air Vent for
Safety
Back of Washer

8
4. INSTALLATION
1 Before servicing ask troubles of customers.
2 Check the adjustment(power supply is 127V ac 60Hz, remove the transit bolts....).
3 Check the troubles referring to the trouble shooting.
4 Decide service steps referring to disassembly instructions.
5 And then, service and repair.
6 After servicing, operate the appliance whether it works OK or NOT.
STANDARD INSTALLATION
The appliance should be installed as follows:
REMOVE THE TRANSIT
BOLTS
INSTALL THE APPLIANCE
ON FLAT AND FIRM SURFACE
ADJUST THE
LEVELING
Remove the transit bolts
(4EA: )with supplied
spanner.
Keep the transit bolts and
spanner for future use.
Insert the 4 caps provided into
the hole.
●
●
●
1
2
Turn the leveling feet to adjust
the appliance.
●
Lower
Higher
Turn clockwise to raise;
counterclockwise to lower.
●
█

9
HOW TO CONNECT THE INLET HOSE
Verify that the rubber washer is inside of the valve connector.
Tighten the inlet hose securely to prevent leaks.
CONNECT THE DRAIN HOSE
█
●
●
█
Make sure that the hose is not twisted. Avoid submerging the end of the hose.
※ The end of the drain hose should be placed less than 100 cm from the floor.
CONNECT THE DRAIN HOSE
●●
█
●●
Connect the power plug to the wall
outlet.
Avoid connecting several electric
devices, as doing so may cause a fire.
Cold

10
Preparation for
washing.
Check the water heating
function.
Check the drain and spin
functions.
Press the POWER
button.
Check the automatic
reverse rotation.
Press the Start/Pause
button.
Press the Start/Pause
button.
Check the water
supply.
Water removal.
Connect the power plug to
the outlet.
Connect the inlet hose.
Press the Delay End + Temp. button
and the present temperature will
be displayed.
Power off and the power on.
Press the Spin button
Press the START/PAUSE button.
Check the spin and drain
functions.
Check if the drum rotates
clockwise and counterclockwise.
Listen for a click to determine if the
door is unlocking.
Listen for a click to determine
if the door has locked.
Check if water is supplied through
the detergent dispenser.
If SERVICE is needed during
check, remove the remaining
water by pulling out the hose cap.
1
6
7
2
5
8
3
4
9
●
●●
●
●
●
●
●
●●
7 TEST OPERATION
●
●

11
5. WIRING DIAGRAM / PROGRAM CHART
WIRING DIAGRAM
WH
WH
SBGN PP BL YL RD BN BK
GY BL NA NA
OR
NA
BK BN RD OR YL BL
WH
WH RD YL
BL BK YL BK RD BL
GYWHYL
YL BK WH
WH
WH WH WH
WHRD BK BK
RD
WH SBBL YL
BKOR
WH
WH
RD
RD
WH
WHWH RD
WH WH
NATURAL
TERMINAL TERMINAL
PIN CONNECTOR
GND
BL
BL
RD BL YL
RD BL YL
PP
WH
WH
RD
NA
PP
WH
WH
RD SB
RD YL BL BK PP YL WH GY
BK BK BK
BL RD NA BL
Atomizing
Valve
Dry Valve
Main Valve
Pre-wash
Valve
I
YL RD BL
WH
RD
RD RD
YL GY
DRY HEATER
WASH HEATER
YL
GN
BN
PK
YL
GN
BL
WH
I
I
BL BNYL
GN
GY

12
6. OPERATION
POWER BUTTON
START/PAUSE BUTTON
CYCLE
SELECTOR knob
EST.TIME REMAINING
CHILD LOCK
eht nrut ot nottub siht esU
power On/Off.
eht potS/tratS ot nottub siht esU
washer.
Rotate the Cycle selector
knob to select the cycle
designed for different types
of fabric and soil levels.
:swohs yalpsid sihT
a) eht ni gniniamer emit detamitse eht
cycle when operating.
b) neeb sah rorre na nehw edoc rorre na
detected.
eht fo esu detnawnu tneverp ot noitpo siht esU
washer. Press and hold Option and Rinse button for
3 seconds to lock/unlock control.
lla dna sthgil KCOL DLIHC ,tes si kcol dlihC nehW
buttons are disabled except the Power button.
You can lock the washer while it is operating.

13
Option Button
WASH BUTTON RINSE AND SPIN BUTTON
Temp. Button
tuohtiw emit evas ot rehsaw eht fo serutaef noitazimitpO dna yarpS niwT eht sesu noitpo ehT :hsaw obruT
sacrificing performance
.sruoh 91~3 rof deyaled eb ot elcyc yna fo trats eht swollA :yaleD emiT
.naelc murd eht peek dna airetcab yna evomer ot murd ezitinas ot noitcnuf siht esU :naelC buT
.yrdnual tew yrd ot tnaw uoy nehw noitcnuf siht esU :yrD
.lairetam ngierof eht evomer ro sdaol dda ot noitcnuf siht es
U :daoL ddA
.setunim 051-021-09-06-03 : stnemercni etunim-03 ni detcles eb nac emit gniyrd ehT :yrD emiT
.tnemtaerterp deen taht sdaol rof noitpo siht esU :hsaW erP
This adds 16 minutes of prewashing before
draining.
si noitpo ”evisnetni“ delios ylivaeh si yrdnual eht fI :evisnetnI
effective.
yreve ni detceles yllacitamotua si noitpo sihT :lamroN
course except for Rinse+Spin.
.gnihtolc delios ylthgil rof elbatius si elcyc sihT :thgiL
yrdnual eht fI ,ruoh 1 tsomla dekaos si yrdnual
ehT :kaoS
needs to soak.
eht sserp ,gnilcyc esniR eht egnahc oT
Rinse button repeatedly through avail-
able options.
eht sserp ,deeps nipS eht egcahc oT
Spin speed button repeatedly to cycle
through available options.
erutarepmet retaw a tceleS
based on the type of load you
are washing.

14
7. TROUBLESHOOTING
7-1. BEFORE SVC CHECKING
Be careful of electric shock or disconnecting the parts while trouble shooting.
Voltage of each terminal is 127V~ and DC while applying an electric current.
7-2. QC TEST MODE
The washer must be empty and the controls must be in the off state.
1. Press the Rinse and Spin buttons simultaneously.
2. Press the Power button, while the above condition. Then buzzer will sound twice.
3. Press the Start/Pauser button repeatedly to cycle through the test modes.
7-3. HOW TO KNOW THE WATER LEVEL FREQUENCY
Press the Rinse and Temp. button simultaneously.
The digits means water level frequency(10-1 kHz)
ex) 241 : Water level frequency = 241 x 10-1 kHz
= 24.1 kHz
*
***
Number of times the
Start/Pause button is pressed
Check Point Display Status
0
Turns on all lamps and locks the door
WiFi modem test
1
Tumble clockwise rpm(40~50)
2
Low speed spin rpm(55~60)
3
High speed spin rpm(60~90)
4
Inlet valve for prewash turns on. Water level frequency (230~255)
5
Inlet valve for main wash turns on. Water level frequency (230~255)
6
7
Inlet valve for Atomizing turns on. Water level frequency (230~255)
8
Inlet valve for Dry turns on. Water level frequency (230~255)
9
Tumble counterclockwise Rpm(40~50)
10
Wash heater turns on for 3 sec. Water temperature.
11
Circulation pump turns on. Water level frequency (230~255)
12
Drain pump turns on. Waater level frequency (230~255)
13
Dry heater turns on for 3 sec. Water temperature and rpm of fan mo-
tor.
14
15 off Turn off all lamps.
“--”
(maintain last step without hot valve)
Inlet valve for hot water turns on.
Water level frequency (230~255)
Water level frequency (230~255)

15
7-4. HOW TO KNOW TO TEMPERATURE OF EACH THERMISTOR AT
OPERATING CONDITION.
Thermistor in tub : Press the [Delay End + Temp.] button.
Thermistor in dry duct : Press the [Delay End + Normal Dry] button.
7-5. ERROR DISPLAY.
If you press the START/PAUSE button when an error is displayed, any error except
·will disappear
and the machine will go into the pause status.
In case of
·, , if the error is not resolved within 20 sec., or the in case of other errors,
if the error is not resolved within 4 min., power will be turned off automatically and the error code will
blink. But in the case of , power will not be turned off.
ERROR SYMPTOM CAUSE
1WATER INLET
ERROR
Correct water level (248) is not reached within 8 minutes after ·
water is supplied or it does not reach the preset water level
within 25 minutes.
2UNBALANCE
ERROR
The load is too small. ·
The appliance is tilted. ·
Laundry is gathered to one side. ·
Non distributable things are put into the drum. ·
3DRAIN
ERROR
Not fully drained witnin 10 minutes. ·
4OVER FLOW
ERROR
Water is over flowing(under 21.3kHz). ·
※ If is displayed, drain pump operates to drain water
automatically.
5
PRESSURE
SENSOR
ERROR
The SENSOR SWITCH ASSEMBLY is out of order. ·
6DOOR OPEN
ERROR
Door not all the way closed. ·
Loose electrical connections at Door switch and PWB Assembly. ·
The DOOR SWITCH ASSEMBLY is out of order. ·
7HEATING
ERROR
The THERMISTOR is out order. ·

16
ERROR SYMPTOM CAUSE
8
OVER
CURRENT
ERROR
MOTOR
LOCKED
ERROR
MAIN PWB ASSEMBLY is out of order. ·
Winding in the STATOR ASSEMBLY is short-circuited. ·
Motor locked ·
10
9
DRY
HEATER
ERROR
The Dry Heater is out of order ·
·
Replace the Dry Heater
The Connector of the Dry Heater is not connected properly to
·
the connector in the Main PWB ASSEMBLY
· Reconnect or repair the connector
The Dry fan motor is out of order
·
·
Replace the fan Motor.
11
POWER
SUPPLY
ERROR
Supplied voltage is not correct.·
Supplied voltage and rated voltage are not matched.·

17
7-6. Smart Functions
LG ThinQ Application
The LG ThinQ application allows you to
communicate with the appliance using a
smartphone.
LG ThinQ Application Features
Communicate with the appliance from a
smartphone using the convenient smart features.
Remote Start
It allows you to control the appliance remotely
from the LG ThinQ application.
Download Cycle
You can download new and special cycles that are
not included in the basic cycles on the appliance.
A variety of specialty cycles specific to the appliance
can be downloaded to the successfully registered
appliances.
Once cycle download is completed in the appliance,
the appliance keeps the downloaded cycle until a
new cycle is downloaded.
NOTE
Only one downloaded cycle can be stored on the
appliance at a time.
.
.
.
.
.
Tub Clean Coach
This function shows how many cycles remain
before it is time to run the Tub Clean function.
Energy Monitoring
This function checks the energy consumption of
the recently used cycles and monthly average.
Smart Diagnosis
This function provides useful information for
diagnosing and solving issues with the appliance
based on the pattern of use.
Settings
Allows you to set various options on the appliance
and in the application.
Push Alert
When the cycle is complete or the appliance has
problems, you have the option of receiving push
notifications on a smartphone. The notifications
are triggered even if the LG ThinQ application is
off.
NOTE
If you change your wireless router, Internet
service provider, or password, delete the
registered appliance from the LG ThinQ
application and register it again.
The application is subject to change for
appliance improvement purposes without notice
to users.
Functions may vary by model.
Before Using LG ThinQ
Application
1 Check the distance between the appliance and
the wireless router (Wi-Fi network).
If the distance between the appliance and
the wireless router is too far, the signal
strength becomes weak. It may take a long
time to register or installation may fail.
2 Turn off the Mobile data or Cellular Data on
your smartphone.
3 Connect your smartphone to the wireless
router.

18
NOTE
To verify the Wi-Fi connection, check that
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
icon
on the control panel is lit.
The appliance supports 2.4 GHz Wi-Fi networks
only. To check your network frequency, contact
your Internet service provider or refer to your
wireless router manual.
LG ThinQ is not responsible for any network
connection problems or any faults,
malfunctions, or errors caused by network
connection.
If the appliance is having trouble connecting to
the Wi-Fi network, it may be too far from the
router. Purchase a Wi-Fi repeater (range
extender) to improve the Wi-Fi signal strength.
The Wi-Fi connection may not connect or may be
interrupted because of the home network
environment.
The network connection may not work properly
depending on the Internet service provider.
The surrounding wireless environment can
make the wireless network service run slowly.
The appliance cannot be registered due to
problems with the wireless signal transmission.
Unplug the appliance and wait about a minute
before trying again.
If the firewall on your wireless router is enabled,
disable the firewall or add an exception to it.
The wireless network name (SSID) should be a
combination of English letters and numbers. (Do
not use special characters.)
Smartphone user interface (UI) may vary
depending on the mobile operating system (OS)
and the manufacturer.
If the security protocol of the router is set to
WEP, you may fail to set up the network. Please
change it to other security protocols (WPA2 is
recommended) and register the product again.
Installing the LG ThinQ
Application
Search for the LG ThinQ application from the
Google Play Store or Apple App Store on a
smartphone. Follow instructions to download and
install the application.
Using the Appliance Remotely
Remote Start
Use a smartphone to control your appliance
remotely. You can also monitor your cycle
operation so you know how much time is left in the
cycle.
Using this function
1 Put the clothes into the drum.
If desired, add bleach or fabric softener to
the appropriate areas of the dispenser.
2 Press the Power button.
3 Press and hold Remote Start button for 3
seconds to enable the remote control function.
4 Start a cycle from the LG ThinQ application on
your smartphone.
NOTE
Once this function is enabled, you can only start
a cycle from the
LG ThinQ smartphone
application. If the cycle is not started, the
appliance will wait to start the cycle until it is
turned off remotely from the application or this
function is disabled.
If the door has been opened, you can not start a
cycle remotely.
Disable this function manually
When this function is activated, press and hold the
Remote Start button for 3 seconds.
Open Source Software Notice
Information
To obtain the source code under GPL, LGPL, MPL,
and other open source licenses, that is contained in

19
7-7. Smart Diagnosis™
this product, please visit http://
opensource.lge.com.
In addition to the source code, all referred license
terms, warranty disclaimers and copyright notices
are available for download.
LG Electronics will also provide open source code to
you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of
media, shipping, and handling) upon email request
to [email protected]. This offer is valid for a
period of three years after our last shipment of this
product. This offer is valid to anyone in receipt of
this information.
This feature is only available on models with the
or logo.
Use this feature to help you diagnose and solve
problems with your appliance.
NOTE
For reasons not attributable to LGE’
the service may not operate due to external
factors such as, but not limited to, Wi-Fi
unavailability, Wi-Fi disconnection, local app
store policy, or app unavailability.
The feature may be subject to change without
.
.
.
.
.
prior notice and may have a different form
depending on where you are located.
Using LG ThinQ to Diagnose
Issues
If you experience a problem with your Wi-Fi
equipped appliance, it can transmit
troubleshooting data to a smartphone using the
LG ThinQ application.
Launch the
LG ThinQ application and select the
Smart Diagnosis feature in the menu. Follow
the instructions provided in the
LG ThinQ
application.
Using Audible Diagnosis to
Diagnose Issues
Follow the instructions below to use the audible
diagnosis method.
Launch the
LG ThinQ application and select the
Smart Diagnosis feature in the menu. Follow
the instructions for audible diagnosis provided
in the
LG ThinQ application.
1 Press the Power button to turn on the
appliance.
Do not press any other buttons.
2 Place the mouthpiece of your smartphone
close to the or logo.
3 Press and hold the Temp. button for 3 seconds
or longer while holding the smartphone
mouthpiece to the logo until the data transfer
is complete.
Keep the smartphone in place until the data
transfer has finished. Time remaining for
data transfer is displayed.
4 After the data transfer is complete, the
diagnosis will be displayed in the application.
NOTE
For best results, do not move the smartphone
while the tones are being transmitted.
Max.
10 mm
s negligence,

20
8-1. DIAGNOSIS AND ANSWER FOR ABNORMAL OPERATION
8. ERROR DIAGNOSIS AND CHECK LIST
SYMPTOM GUIDE FOR SERVICE CALL
NO POWER Is the power plug connected rmly to
AC 127V outlet?
YES
Power failure? or Breaker opened?
NO
Visit to check
Water inlet trouble Is “ “ displayed?
YES
Is the tap opened?
YES
Is the tap frozen?
NO
Is the water supply shut-off?
NO
Is FI lter in the inlet valve clogged with
foreign material? YES
NO
Clean the lter of
inlet valve
Visit to check
FI
