10
INSTALLATION
- Maintain more than 15 cm gap between the
side of drain hose and the wall.
- The base openings must not be obstructed by
carpeting when the washing machine is
installed on a carpeted floor.
• The machine has mobility function by manual
intervention, care to be taken to avoid any body
parts coming under wheels.
• Install the washing machine on a horizontal
support. Otherwise, it may cause vibration and
noise.
• Incorrect installation may cause severe noise
and break down.
Connecting the earth wire
(only for models with
two prong plug)
• Install the earth wire to prevent short- circuit due
to leaking current and electric shock.
• It is attached at the back of the washer. Connect
it to the metal water pipe. If the water pipe is
made of plastics, it does not have the earth
effect.
• Do not connect the earth wire
a
to the gas pipe
b
, lightning arrester, telephone connector, etc.
• The appliance with two pronged plug must be
grounded.
Connecting the power plug
• Insert the power plug into the outlet.
• Before connecting the power plug, check if the
voltage setting of the washer matches the outlet
voltage.
• If AC outlet with ground terminal is used,
grounding is not needed. If not, never forget
earthing (earthing method above).
• The appliance must be positioned so that the
plug is accessible.
Other earthing method
• After connecting the earth wire
a
to the earth
cooper plate
b
, bury it atleast 75 cm deep under
the wet ground.
• Connect the earth wire
c
to the earthing-only
outlet.
• If grounding method as described are not
possible, a separate circuit-breaker
d
should be
employed and installed by a qualified electrician.
Installing the Drain Hose
Before connecting the drain hose, check your drain
hose model and follow the instructions for that
model.
