LG WFS1918EKD User manual

WFS1918EKD
WFS1938EKD
WT19DP6
MFL68019779
WASHING MACHINE
OWNER’S MANUAL
Please read this manual carefully before operating
your washing machine and retain it for future reference.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:06 페이지 1

roduct Features
P
FUZZY logic control
● A built-in loa sensor automatically etects an measures the laun ry loa an amicroprocessor
optimizes washing con itions such as i eal water consumption an washing time.
● A vance technology is built into the Electronic Control System which ensures the best washing
result.
The Turbo Drum DD washing machine oes not operate with the li open.
If the li is opene uring wash, rinse an spin cycles, the machine will stop automatically.
Please close the oor gently. Closing the oor in an agressive manner can cause amage
an or injury.
● The a vance Brushless DC motor rotates the Tub irectly without belt an
clutch, thereby re ucing the noise of the washer.
● The washing machine a justs to optimum spee accor ing to the type of
clothing in the loa .
Low Noise Direct Drive System
●It is the technology to transmit the anomalies to the service center
when there is a problem with the washer. It provi es the service
that gives faith an trust to the customers through precise an fast
analysis.
SMARTDIAGNOSISTM
New DD type washing with fabric care
It rotates the tub an
creates cannon water
flow making the effect
of the etergent faster
improving the washing
effect an preventing
fabric amages
The half cycle rotation
of the tub to the
left/right helps the melt-
ing of the etergent for
easy washing
The half cycle rotation
of the washing rotors to
the left/right removes
the stains
Smart Drum achieve by DD Motor Technology
●
Smart Drum with Drum Washing Type is more hygienic
an cleaner washer tub that protects the fabric an
prevents amages.
The half cycle r
otation of the tub
to the left/right
balances the
laun ry
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 2

ontents
C
Introduction
Before Starting to
Wash
Washing Programs
Additional Function
Program
Installation
Care and Maintenance
Troubleshooting
Specification
Safety Information 4
I entification of Parts 7
Function Information 8
Preparation Before Washing 9
Use of Water, Dispenser Drawer, Detergent, Bleach an Softener 10
Special Gui e for Stain Removal 13
Function of each Button 14
FUZZY Wash (Normal Wash) 16
WOOL Wash 16
QUICK WASH 16
JEANS Wash 16
SMART CLEANING 16
SOAK Wash 18
FAVORITE Wash 19
Pre Wash + Normal 20
TUB CLEAN 21
AIR DRY 22
TUB DRY 22
Option Washing 23
DELAY START (RESERVATION) Wash 24
Other Useful Functions 25
Placing an Leveling 26
Connecting Water Supply Hose 27
Connecting Drain Hose 30
Groun ing Metho 31
Cleaning an Maintenance 32
Use of Han le Locker 34
Common washing problems 35
Troubleshooting 36
SmartDiagnosisTM 37
Specification 38
READ THIS MA UAL
Insi e you will fin many helpful hints on how to use an maintain your washer prop-
erly. Just a little preventive care on your part can save you a great eal of time an
money over the life of your washer. You will fin many answers to common problems
in the Troubleshooting section. If you review our chart of Troubleshooting Tips first, you
may not nee to call for service at all.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 3

a ety In ormation
S
4
Introduction
Rea carefully an thoroughly through this booklet as it contains important safety information
that will protect the user from unexpecte angers an prevent potential amages to the pro uct.
This booklet is divided into 2 parts : Warning and Caution.
: This is a warning sign specifying user’s applications which might
be dangerous.
: This is a sign specifying ‘Strictly Forbidden’ applications.
Warning : Failure to comply with the instructions under this
sign may result in major physical injuries or death.
Caution
: Failure to comply with the instructions under this
sign may result in minor physical injuries or
damages to the product.
Warning
• Under certain conditions hydrogen gas may be produced in a water heater that has not been
used for two weeks or more. Hydrogen gas can be explosive under these circumstances.
If the HOT water has not been used for two weeks or more, prevent the possibility of
damage or injury by turning on all Hot water faucets and allowing them to run for several
minutes. Do this before using any electrical appliance which is connected to the HOT
water system. This simple procedure will allow any built-up hydrogen gas to escape. Since
the gas is flammable, do not smoke or use an open flame or appliance during this process.
• The base opening must not be obstructed by carpeting when the washing machine is installed on a
carpeted floor.
• Install or store where it will not be exposed to temperatures below freezing or exposed to the weather.
If the product is exposed to such conditions, electric shock, fire, reak down or
deformation may occur.
• Properly ground washer to conform with all governing codes and ordinances. Follow details in
Installation Instructions.
If not grounded properly, reak down and leakage of electricity may occur, which may
cause electric shock.
• Must be positioned so that the plug is accessible.
If the plug is placed etween the wall and the machine, it may get damaged, possi ly
causing fire or electric shock.
• Make sure the plug is completely pushed into the outlet.
Failure to do so may cause electric shock and fire due to overheating.
WATER
HEATER
SAFETY
Caution
PROPER
INSTALLATION
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 4

a ety In ormation
S
5
Introduction
Warning
• Keep the area underneath and around your appliances free of combustible
materials such as lint, paper, rags, chemical, etc.
Operating with such materials around the machine may trigger
explosion or fire.
• The appliance is not intended for use by young children or infirm persons
without supervision.
• Young hildren should be supervised to ensure that they do not play with
appliance.
There is potential danger that children might drown in the tu .
Do not touch the power plug with a wet hand.
It will cause electric shock
Do not put your hand, foot or anything under the washing machine while
the washing machine is in operation.
There is a rotating mechanism under the machine, so you could e injured.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
hildren should be supervised to ensure that they do not play with the appliance.
• Make sure that drainage is working properly.
If water is not drained properly, your floor may get flooded. Flooded floors
may induce electricity leakage, further resulting in electric shock or fire.
• If, during spinning, opening the lid does not stop the tub within about 15 seconds,
immediately discontinue operating the machine.
Call for repair. A machine that spins with its door open may cause injuries.
Never reach into washer while it is moving.
Wait until the machine has completely stopped before opening the lid.
Even slow rotation can cause injury.
Never attempt to operate this appliance if it is damaged, malfunctioning, partially
disassembled, or has missing or broken parts, including a damaged cord or plug.
Operating with a damaged plug may cause electric shock.
Do not use water hotter than 50° .
Use of excessively hot water may cause damage to fa rics or cause
leakage of water.
• Use this appliance only for its intended purpose as described in this Owner’s Manual.
• The laundry process can reduce the flame retardancy of fabrics. To avoid such a result,
carefully follow the garment manufacturer’s wash and care instructions.
• To minimize the possibility of electric shock, unplug this appliance from the power
supply or disconnect the washer at the household distribution panel by removing the
fuse or switching off the circuit breaker before attempting any maintenance or cleaning.
YOUR
LAUNDRY
AREA
Caution
WHEN USING
THE WASHER
OTE : Pressing Circuit button to turn off does OT
disconnect the appliance from the power supply.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 5

a ety In ormation
S
6
Introduction
Warning
Do not use a plug socket and wiring equipment for more than their rated capacity.
Exceeding the limit may lead to electric shock, fire , reak down, and/or
deformation of parts.
Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover.
Mixing different chemicals can produce toxic gases which may cause death.
Do not wash or dry articles that have been cleaned in, washed in, soaked in, or spotted
with combustible or explosive substances (such as wax, oil, paint, gasoline, dry-cleaning
solvents, kerosene, etc). Do not add these substances to the wash water.
Do not use or place these substances around your washer or dryer during operation.
It may ignite or explode.
• Turn off water faucets to relieve pressure on hoses and valves and to minimize leakage
if a break or rupture should occur. heck the condition of the fill hoses; they may need
replacement after 5years.
• When the air temperature is high and the water temperature is low, condensation may
occur and thus wet the floor.
• Wipe off dirt or dust on the contacts of the power plug.
Using unclean power plug may cause fire.
• Before discarding a washer, or removing it from service, remove the washer lid to
prevent children from hiding inside.
Children may e trapped and suffocated if the lid is left intact.
Do not attempt to repair or replace any part of this appliance unless specifically
recommended in this Owner’s Manual, or in published user-repair instructions
that you understand and have the skills to carry out.
Operating the machine with improperly replaced parts may e a
cause for fire or electric shock.
Do not tamper with controls.
It may lead to electric shock, fire , reak down, deformation.
Do not yank the power cord in an attempt to disconnect the power plug.
Securely hold the power plug to unplug the machine.
Failure to o serve these instructions may cause electric shock or fire
due to short-circuit .
When you are cleaning the washing machine, do not apply water directly to any
part of the washing machine.
It will cause short circuit and electric shock.
WHEN USING
THE WASHER
Caution
WHEN NOT
IN USE
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 6

denti ication o Parts
I
7
Introduction
WATER SUPPLY
HOSE
FUNCTION
SELECTOR
TUB
BASE
ADJUSTABLE LEGS
DRAIN HOSE
for pump model
DRAIN HOSE
POWER PLUG
START/PAUSE
BUTTON
Use to start or
stop the washing
machine
temporarily.
Make sure the
water does not
leak.
If the supply cord is
damaged, it must be
replaced by the
manufacturer or its
service agents or
similarly qualified
person in order to
avoid a hazard.
Check if the drain
hose is hung up
before operating the
washing machine.
for non pump
model
Use to level the washing
machine for correct
balance & spin
operation.
POWDER AND LIQUID
DETERGENT BOX
Bo y
“✽” Part can be different according to the model.
OTE
Drain hose Anti-rat cover (option)
Water supply hoses
or
or
1 Each for COLD an
HOT water
Accessories
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 7

unction In ormation
F
8
Introduction
Our machine provi es various washing metho s which suits various con itions
an types of laun ry.
FUZZY(Normal) Wash
JEANS Wash
WOOL Wash
QUICK WASH
SOAK Wash
DELAY START Wash
OPTION WASH
Use this Program for everyday washing e.g. sheets, towels, T-shirts. (refer to page 16)
SMART CLEANING
Use this program to get better rising performance. (refer to page 16)
FAVORITE Wash
This setting allows you to store your FAVORITE wash conditions in the normal cycle memory. (refer to page 19)
Use this Program for heavily soiled durable garments e.g. overalls, jeans.
Thick and heavy clothes or those which are excessively dirty like jeans or working uniforms can be washed. (refer to page 16)
Wool clothes (lingerie, wool, etc.) which may be easily damaged can be washed. (refer to page 16)
The fibers of machine washable woolens have been specifically modified to prevent felting when they are machine washed.
Most handknitted garments are not made of machine washable wool and we recommend that you hand wash them
• Before washing your woolens check the care label for the washing instructions.
• When washing woolens use a mild Detergent recommended for washing wool.
• Hand washed woolens may be spun in a washing machine to reduce the time they take to dry.
• To dry woolens lay down them flat on a towel and pat into shape. Dry woolens out of direct sunlight.
(The heat and tumble action of a dryer may cause shrinkage or felting of woolen garments.)
Some wool underlays and sheepskin products can be washed in a washing machine but may cause pump blockages.
(Ensure that the whole article is suitable for machine washing and not just the backing material.)
You may wish to handwash these articles and place them in the machine to spin dry.
QUI K WASH can be selected to wash lightly soiled clothes of less than 2.0 kg in a short time. (refer to page 16)
SOAK Wash can be selected to wash heavily soiled laundry by soaking in water for some time to remove dirt and
grime. (refer to page 18)
DELAY START Wash is used to delay the finishing time of the operation.
The number of hours to be delayed can be set by the user accordingly. (refer to page 24)
When the user needs only SPIN, RINSE/SPIN, RINSE, WASH/RINSE, WASH, WASH/RINSE/SPIN,
SOAK/WASH/RINSE/SPIN. (refer to page 23)
TUB CLEAN
Use this program to clean the inside of washing machine especially Inner tub & Outer tub . (refer to page 21)
Washing according to the condition of laundry
Other washing method
Different types of laundry washing
Pre Wash + Normal
Washing laundry with Pre Wash+ Normal cycle that pretreats immediate stain without hand-wash.
i.e. Necessary for clothes which could be smelled badly without prompt laundry.(refer to page 20)
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 8

reparation Be ore Washing
P
9
Be ore Starting to Wash
•Check all pockets to make sure that they are empty. Things such as nails, hairclips, matches,
pens, coins, and keys can damage both your washer and your clothes.
•Mend any torn garments or loose uttons. Tears or holes may become larger during washing.
• Remove belts, underwires, etc. to prevent damage to the machine or your clothes.
• Pretreat any dirt and stains.
• Make sure the clothes are washable in water.
• heck the washing instructions.
• Remove tissue in pockets.
To get the best results, different fabrics need to be washed in different ways.
• SOIL (Heavy, Normal, Light)
Separate clothes according to the type and amount of soil.
• COLOR (Whites, Lights, Darks) Separate white fabrics from colored fabrics.
• LINT (Lint producers, ollectors) Separate lint producers and lint collectors.
Lint Producers Terry cloth, henille, Towels, Nappies, Diapers
Lint ollectors Synthetics, orduroy, Permanent Press, Socks
Sorting
Check before Loa ing
* Look for a care label on your clothes. This will tell you about the fabric content of your garment
and how it should be washed.
Sort clothes into loads that can be washed with the same wash cycle, Water Temperature and spin speed.
Care Labels
CAUTION
Long laundry items
Use nylon nets for long, DELI ATE items. For laundry with long strings or long length, a net will
prevent tangling during washing.
Fasten zippers, hook, and strings to make sure that these items don't
snag on other clothes.
※Nylon net is not supplied by LG.
Light and Large-sized clothing
lothes like downs and woollens are light weight, large and float easily. Use a nylon net and
wash them in a small amount of water. If the laundry floats during the wash cycle, it may
become damaged. Use dissolved Detergent to prevent the Detergent from clumping.
Do not wash fabrics containing flammable materials (waxes, cleaning fluids, etc.).
Load Size
The WATER LEVEL should just cover the clothes. Adjust the load size
accordingly. Loosely load clothes no higher than the top row of holes in the
washer tub. To add items after washer has started, press Start button and
submerge additional items. lose the lid and press Start button again to restart.
Do not wash or spin any item la eled or known to e water-proof or water-resistant, even if the product care
la el on the item permits machine washing. Failure to follow these instructions could result in severe damage to
your laundry, your washer and/or property damage as a result of abnormal vibration of the washer.
- Examples of water-proof or water-resistant items include certain mattress pads, mattress covers, rain gear, camping
gear, skiing apparel , outdoor gear and similar items.
Loa ing
• Use ‘Pre Wash+Normal’ cycle for very soiled clothes.
In case of heavily soiled clothes, pretreatment may require before the cycle.
• Pretreat shirt collars and cuffs with a pre-wash product or liquid Detergent when placing them in the washer.
Before washing treat special stains with bar soaps, liquid Detergent or a paste of water and granular Detergent.
• Use a pretreat soil and stain remover.
Treat stains AS SOON AS POSSIBLE. The longer they are left the harder they are to remove.
(For more detail refer to page13)
Pretreatment on stains or heavy soil
Fire Hazard
ever place items in the washer that are
dampened with gasoline or other flammable fluids.
o washer can completely remove oil.
Do not dry anything that has ever had any type of
oil on it (including cooking oils).
Doing so can result in death, explosion, or fire.
WAR I G
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 9

se o Water, Dispenser Drawer, Detergent, Bleach and So tener
U
10
Be ore Starting to Wash
• The temperature of the water impacts the effectiveness of all laundry additives and therefore, the cleaning results.
We recommend temperatures of:
- HOT 49~60° …(120-140˚F) White items, diapers, underclothing and heavily soiled, colorfast items.
- WARM 29~40° …(85-105˚F) Most items
- OLD* 18~24° …(65-75˚F) Only very bright colors with light soil.
• When washing in OLD water additional steps may be needed:
- Adjust Detergent amount and pre-dissolve Detergent in WARM water
- Pretreat spots and stains
- Soak heavily soiled items
- Use appropriate bleach
* Temperature below 18° …(65˚F) will not activate laundry additives and may cause lint, residue, poor cleaning, etc.
In addition, Detergent manufactures and care labels define OLD water as 26~29° …(80-85˚F).
If the temperature of the water in the tub is too cold for your hands, the Detergent will not activate and clean effectively.
Water Temperature
Using Water
• The machine sets the appropriate temperature automatically according to the wash program .
• This machine detects the quantity of laundry automatically, then sets the
WATER LEVEL and proper amount of Detergent.
• When you select a wash program, the WATER LEVEL will be shown on the
control panel.
• The following table shows the amount of water.
• When the WATER LEVEL is automatically detected, it may differ depending
on the quantity of laundry even though the same WATER LEVEL is indicated
on the control panel.
Amount of WATER LEVEL
Using the Dispenser Drawer
OTE
If iron is present in the water the clothes may become an all-over yellow or they may be stained with brown or orange
spots or streaks. Iron is not always visible. Installation of water softener or an iron filter may be necessary for severe cases.
OTE
[ Minimum water amount ]
It depends on laundry load and washer model. Or manually you can pour a certain amount water into tub
directly to some height. That’s because if water level reaches to the some height sensed by washer itself, washer
automatically operates. In other words, it is needed to pour water to the point when washer starts operating.
The dispenser drawer contains 2 compartments:
• Liquid Fabric Softener
• Liquid or Powder Low-Sudsing, High-Efficiency Detergent
The dispenser automatically dispenses additives at the proper time in the wash cycle.
1. Slowly open the dispenser drawer by pulling the drawer out until it stops.
2. After adding laundry products, slowly close the dispenser drawer. losing the
drawer too quickly could result in early dispensing of additives.
• Avoid overfilling or splashing when adding laundry products to the dispenser. Doing
so could result in early dispensing of laundry products.
At the end of the cycle, you may see water in the compartments. This is part of the
normal operation of the washer.
NOTE : Do not use bleach in the dispenser drawer.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 10

11
Be ore Starting to Wash
Using Detergent
How much Detergent
The correct amount of Detergent will vary depending on the amount of soil in your clothes (Jeans and work
cloches may need more Detergent, while bath towels usually need less.).
For liquid and concentrated Detergents, follow the recommendations of the Detergent manufacturer.
Note: To check you are using the correct amount of Detergent, lift the lid of your machine a out
half-way through the wash. There should e a thin layer of foam over the surface of the water. Lots of
foam may look good, ut it does not contri ute to cleaning your clothes. No foam means not enough
Detergent has een used; soil and lint can settle ack on the clothes or the washing machine.
If excess Detergent is used, the rinse will not e as clean and efficient. Also, it could cause environ-
mental pollution, so use it accordingly.
Add measured detergent to the detergent compartment of the dispenser drawer.
Detergent is flushed through the dispenser at the beginning of the wash phase.
Detergent usage may need to be adjusted for water temperature, water hardness, size and soil level of the load.
Avoid using too much detergent in your washer, as it can lead to oversudsing and detergent residue being left on
the clothes.
A ing Detergent
Using Detergent
Detergent
Follow the Detergent package directions. Using too little Detergent is a common cause of laundry problems.
Use more Detergent if you have hard water, large loads, greasy or oily soils or lower Water Temperature.
Choosing the right Detergent
We recommend the use of domestic Detergent, (powder, liquid or concentrated). Soap flakes or granulated
soap powders should not be used in your washing machine. When washing woolens remember to use Deter-
gent suitable for washing woolens.
Attention
Using liquid detergent without diluting, or leaving laundry for a long time after pouring
diluted liquid detergent into the tub might cause damage, bleaching or discoloration of cloth.
Note : Using Liquid detergent
- Dilute Liquid detergent with water and pour into the tub, start the cycle.
- Delay wash course is not available if you use liquid detergent.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 11

se o Water, Dispenser Drawer, Detergent, Bleach and So tener
U
12
Be ore Starting to Wash
Using Fabric Softener
If you wish to use fabric softener we recommen
Attention
■Do not mix with Detergent or bleach.
■Never pour fabric softener directly on clothes. It may stain them.
■Do not stop the washer during the first spin for timely dispensing.
■Option washing is not designed to be used with fabric softener dispenser.
If desired, pour the recommended amount of liquid
fabric softener into the right-hand compartment.
Use only liquid fabric softener.
Dilute with water to the maximum fill line.
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing of the fabric
softener, which could stain clothes.
NOTE : Do not pour fabric softener directly on the
wash load. It may stain the clothes.
Using Bleach Check fabric care labels for special instructions.
• Use oxygenated bleach.
• Do not use liquid bleach.
• For more details refer to the products instruction for use.
Scrud(Waxy Build up)
Scrud is the name given to the waxy build-up that can occur within any washer when the fabric softener comes into
contact with Detergent. This build-up is not brought about by a fault in the machine.
If scrud is allowed to uild-up in the machine it can result in stains on your clothes or an unpleasant smell in
your washer.
• Using fabric softener sparingly.
• When filling the dispenser, do not splash or overfill.
• lean dispenser as soon as the cycle is finished.
• lean your machine regularly. (refer to page 21 or 32)
• old water washing increases the chance of this build-up occurring. We recommend a regular WARM or HOT wash
e.g. every 5th wash should be at least a warm one.
• Fabric softener of thinner consistency is less likely to leave residue on the dispenser and contribute to a build-up.
AVAILABLE BLEACH TYPE
• Separate the laundry to be bleached.
• Measure powdered bleach carefully, following instructions on the box.
• Before starting the washer, pour measured amount of bleach following instructions on the box.
DEPOSITING BLEACH
Attention
■Never pour undiluted liquid bleach directly onto clothes or into the wash basket.
This may affect colors or damage clothing.
■Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover.
Mixing can produce a toxic gas which may cause death.
■Do not pour liquid bleach into bleach dispenser.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 12

pecial Guide or Stain Removal
S
13
Be ore Starting to Wash
• Remove stains promptly.
• Use ‘Pre Wash+Normal’ cycle for very soiled clothes.
In case of heavily soiled clothes, pretreatment may require before the cycle.
• Determine the kind of stain, then follow the recommended treatment in the stain removal chart below.
• To pretreat stains, use a prewash product, liquid Detergent, or a paste made from
granular Detergent and water.
• Use OLD water on unknown stains because HOT water can set stains.
• heck care label instructions for treatments to avoid on specific fabrics.
• heck for colorfastness by testing stain remover on an inside seam.
• Rinse and wash items after stain removal.
For successful stain removal:
Follow fa ric care
la el instructions
WAR I G
Stain Removal
STAIN
Adhesive tape, chewing gum, rub-
ber cement
Baby formula, dairy products, egg
Beverages (coffee, tea, soda, juice,
alcoholic beverages)
Blood
andle wax, crayon
hocolate
ollar or cuff soil, cosmetics
Dye transfer on white fabric
Grass
Grease, oil, tar (butter, fats, salad
dressing, cooking oils, car grease,
motor oils)
Ink
Mildew, scorch
Mud
Mustard, tomato
Nail polish
Paint, varnish
Rust, brown or yellow
discoloration
Shoe polish
TREATMENT
■ Do not use or mix liquid chlorine bleach with other household chemicals such as toilet cleaners, rust removers, acid or
products containing ammonia. These mixtures can produce dangerous fumes which can cause serious injury or death.
■ To reduce the risk of fire or serious injury to persons or property, comply with the basic warnings listed below:
• Read and comply with all instructions on stain removal products.
• Keep stain removal products in their original labeled containers and out of children’s reach.
• Thoroughly wash any utensil used.
• Do not combine stain removal products, especially ammonia and chlorine bleach. Dangerous fumes may result.
• Never wash items which have been previously cleaned in, washed in, soaked in or spotted with gasoline, dry cleaning solvents
or other flammable or explosive substances because they give off vapors that could ignite or explode.
• Never use highly flammable solvents, such as gasoline, inside the home. Vapors can explode on contact with flames or sparks.
Apply ice. Scrape off excess. Place stain face down on paper towels. Saturate with prewash stain remover or
nonflammable dry cleaning fluid.
Use product containing enzymes to pretreat or soak stains.
Pretreat stain. Wash using OLD water and bleach safe for fabric.
Rinse with OLD water. Rub with bar soap. Or pretreat or soak with product containing enzymes. Wash using
bleach safe for fabric.
Scrape off surface wax. Place stain face down between paper towels. Press with warm iron until wax is absorbed.
Replace paper towels frequently. Treat remaining stain with prewash stain remover or nonflammable dry cleaning
fluid. Hand wash to remove solvent. Wash using bleach safe for fabric.
Pretreat or soak in WARM water using product containing enzymes. Wash using bleach safe for fabric.
Pretreat with prewash stain remover or rub with bar soap.
Use packaged color remover. Wash using bleach safe for fabric.
Pretreat or soak in WARM water using product containing enzymes. Wash using bleach safe for fabric.
Scrape residue from fabric. Pretreat. Wash using hottest water safe for fabric. For heavy stains and tar, apply
nonflammable dry cleaning fluid to back of stain. Replace towels under stain frequently. Rinse throughly. Wash
using hottest water safe for fabric.
Some inks may be impossible to remove. Washing may set some inks. Use prewash stain remover, denatured
lcohol or nonflammable dry cleaning fluid.
Wash with chlorine bleach if safe for fabric. Or, soak in oxygen bleach and HOT water before washing. Badly
mildewed fabrics may be permanently damaged.
Brush off dry mud. Pretreat or soak with product containing enzymes.
Pretreat with prewash stain remover. Wash using bleach safe for fabric.
May be impossible to remove. Place stain face down on paper towels. Apply nail polish remover to back of stain.
Repeat, replacing paper towels frequently. Do not use on acetate fabrics.
WATER BASED : Rinse fabric in cool water while stain is wet. Wash. Once paint is dry, it cannot be removed,
OIL BASED AND VARNISH : Use solvent recommended on can label. Rinse throughly before washing.
For spots, use rust remover safe for fabric. For discoloration of an entire load, use phosphate Detergent and
nonchlorine bleach. Do not use chlorine leach ecause it may intensify discoloration.
LIQUID : Pretreat with a paste of granular Detergent and water. PASTE : Scrape residue from fabric. Pretreat with
prewash stain remover or nonflammable dry cleaning fluid. Rub Detergent into dampened area, Wash using bleach
safe for fabric.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 13

unction o each Button
F
14
Be ore Starting to Wash
OTE
* For optimizing the washing algorithm, the displaying time may be changed during washing-increased by 8
minutes at maximum and decreased by 4 minutes at maximum.
* Because the detecting ability of the sensor may be decreased by using it for a long time, periodically use
TUB LEAN course to clean the tub. (refer to page 21)
* Even if the water level is changed by the user in FUZZY(Normal) Program,
the sensor will still work. The sensor algorithm may differ according to models.
* The control panel may differ according to different models.
CHILD LOCK FU CTIO
• Use to lock or unlock the
control buttons to prevent
settings from being
changed by a child.
To lock,push the RINSE
and SPIN buttons
simultaneously and to
unlock push them one
more time during the
washing process.
(refer to page 25)
WASH. RI SE. SPI BUTTO
• Use when wash, rinse, spin
time need to be adjusted.
• The time increases when the
button is pressed .
• If adjustments are needed
during the wash,press the
[start/pause ] button before
making any changes.
• When the button is pressed
during washing,the
remaining time is displayed.
WATER LEVEL BUTTO
• Use to select the proper amount of water in relation to the weight and
type of laundry.
• Automatically controlled,but can be selected manually by pressing the
WATER LEVEL Botton.
• WATER LEVEL is automatically selected for FUZZY(normal) program.
The following settings are indicated as the button is pushed
7 ▶ 8 ▶9 ▶10 ▶1 ▶2 ▶3 ▶4 ▶ 5 ▶6 ▶7
SOIL LEVEL BUTTO
• This button allows you to
select the strength of the
wash action.
• Power option selections
light up in sequence as
follows Normal ▶Heavy
▶Light ▶Normal as the
button is pushed.
This can be selected for any
program.
• Adjustment can be made
while washing.
WATER TEMPERATURE BUTTO
• Use to select Water Temperature.
Pressing the button allows you to select
OLD ▶ WARM (HOT& OLD) ▶
HOT ▶OLD respectively.
TUB DRY
• Use this when you
want to dry the
empty tub after a
wash.
• This can be
set/canceled by
pressing the Wash
button and Rinse
button
simultaneously.
(refer to page 22)
AIR DRY
• This function is used to reduce the drying time
of the laundry by allowing air to circulate
within the bowl in order to reduce moisture
levels.It does not dry the clothes completely.
• Air dry selections light up in sequence as
follows.
60 ▶90 ▶120 ▶60 as the button is pushed.
• Press the button for 3 seconds to select and
press the Power botton to cancel the operation.
(refer to page 22)
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 14

15
Be ore Starting to Wash
DELAY START (RESERVATIO ) BUTTO
• Use to set a delayed finishing time.
• The time increases when the button
is pushed.
• The following settings are indicated
3 ▶ 4 ▶ 5 ▶…11 ▶ 12 ▶ 14 ▶
16 ▶ 18 ▶ 3 Hour.
• To cancel delay time, turn the power
switch off.
(refer to page 24)
START/PAUSE BUTTO
• Use to start or pause the
washing process.
• Repeats start and pause by
pushing the button.
PROGRAM BUTTO
• Use for selecting wash program.
• This button allows you to select 8
different programs for different kinds of
laundry and dirtiness.
• program selections light up in sequence as
follows: FUZZY (NORMAL) ▶WOOL
▶QUI K WASH ▶JEAN ▶SMART
LEANING ▶TUB LEAN ▶
FAVORITE ▶PRE WASH+NORMAL
▶FUZZY (NORMAL) etc. Select the de-
sired program by pressing the button.
TIME LEFT, DELAY START (RESERVATIO ), ALARM I DICATIO
• Time left - During operation, the remaining time is indicated.
• DELAY START INDICATION (RESERVATION) - When DELAY
START (RESERVATION) program is selected, it indicates the finishing
time. (RES.=DELAY)
• Alarm indication - When an error occurs, an error message appears to
indicate the abnormality.
For example, DE indicates that the lid is open.
SMARTDIAG OSISTM
FU CTIO DISPLAY
• It marks the place to put the
phone to receive signal when a
problem occurs.
POWER (AUTO OFF)
BUTTO
• Use to turn the power on or off.
• Push again and power goes on or off
• The power goes off automatically
about 10 seconds after the wash is
finished.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 15

ashing Programs
W
16
Washing Programs
Washi g
Programs
Add
the
lau dry
Add
the Deterge t
(Normal Wash)
Use for normal loa s, this
mo e automatically selects the
most appropriate con itions
an completes the sequence
in one operation. The built-in
sensor etects the size of the
loa an the i eal wash power
an wash, rinse an spin times
are set accor ingly.
Use this mo e when washing
lightly soile clothes for a short
time. The highly recommen e
laun ry amount is un er 2.0kg.
Use this program to increase
rinsing performance.
This woul inclu e un erwear
an baby clothes.
If someone has sensitive skin or
skin trouble,use this program.
• Select the
QUICK
WASH
program on
the Control
panel.
• A the appropriate
quantity of Detergent
as in icate by the
WATER LEVEL.
Or follow the
Detergent
manufacturer’s
instructions
• A the appropriate
quantity of Detergent
as in icate by the
WATER LEVEL.
Or follow the
Detergent
manufacturer’s
instructions
•
•
Use Jean program when
washing Jeans of ifferent sizes
• Select the
JEANS
program on
the Control
panel.
• Sprea
the jean
evenly in
the tub
• Select the
WOOL
program on
the Control
panel.
Use this program for washing
elicate fabrics such as lingerie
an woolens. (wash only “water
washable” clothes)
Before washing your woolens
check the care label for the
washing instructions.
(wash only water washable clothes)
• Use neutral
Detergent
appropriate for the
laun ry.
• When washing
woolens use a mil
Detergent
recommen e for
washing wool.
• Select the
SMART
CLEANING
program on the
Control panel.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 16

17
Washing Programs
Close the lid Fi ish Cautio & Note
• The pulsator rotates for
8 secon s to etect the
laun ry loa .
• Then the WATER LEVEL
an the amount of
Detergent to be use
will be shown an water
will be supplie .
• Water will be sup-
plie for 2 minutes
after the start of the
wash to supplement
the water the laun ry
has absorbe .
• When the wash
program en s, the
buzzer will ring
for 10 secon s
before the Power
goes off
automatically.
• If water is alrea y in the tub, or
putting wet laun ry into the tub
before starting will increase the
WATER LEVEL.
• With lightweight bulky loa s,
WATER LEVEL can be set low.
• Changes to Water Temperature
(HOT/COLD) an wash level are
possible uring operation.
(refer to page 14)
• When setting the WATER LEVEL
manually, o not set to Me ium to
prevent amage to laun ry.
• Washing with HOT water may
amage the laun ry (Water is set
to col automatically). Ensure that
the loa is un er 2kg.
• In or er to avoi amage to
laun ry,
the spin cycle may appear slow.
This also avoi s wrinkles an
clothing may still contain some
water. This is normal.
• When static pressure of water is
more than 2kg/cm2, the QUICK
WASH course will be within
19min.
Maximum
Load
Less than
19.0 kg
Less than
2.0 kg
Less than
2.0 kg
Less than
19.0 kg
Less than
19.0 kg
RECOMMENDED LOADS
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 17

OAK Wash
S
18
Washing Programs
minmin min minminmin min min min min min min min
Lamp
Off
Soak-Wash
Use this mode to wash normal clothes or thick and heavy clothes which are excessively dirty.
SOAK mode can be used with FUZZY or JEA or SMART CLEA I G or FAVORITE program.
• Keep pressing the WASH button until the light turns on
‘SOAK’ and‘WASH’ simultaneously as next image.
• SOAK program only works when socking time is 40, 50 or
60 minutes.
• The WATER LEVEL will be shown and water will be
supplied.
Press the POWER (AUTO OFF) button to turn power on.
Press the PROGRAM button to select the washing program.
A the laun ry an press the START/PAUSE button.
• When the wash program ends, the buzzer will ring for
10seconds before the Power goes off automatically.
Finish
Press the WASH button, to select SOAK program.
• Add the appropriate quantity of Detergent as the Detergent
manufacture instruction.
A the Detergent.
• Water will be supplied for 2 minutes after the start of the
wash to supplement the absorbed water by the laundry.
Close the li .
1
3
4
5
6
2
OTE
• Order of Soak-Wash timing
• Select soaking time 40minutes, 50minutes, or 60minutes (including washing time) by pressing
the Wash button repeatedly.
• If necessary, select the times of Rinse and the time for Spinning by pressing the Rinse or Spin
buttons till you reach the desired times.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 18

AVORITE Wash
F
19
Washing Programs
Pressing the FAVORITE button allows you to store your FAVORITE wash conditions in the
normal cycle memory and then recall it for use at a later time.
• Press the TEMP. button to select wash Water
Temperature.
• Press the WATER LEVEL button to select
WATER LEVEL.
• Press the WASH button, the RINSE button &
the SPIN button to select wash time, rinse time &
spin time respectively you want to store.
Press the POWER (AUTO OFF) button to turn power on.
Select the FAVORITE program.
Select your FAVORITE wash con itions.
Press the START/PAUSE button to store & start your FAVORITE wash cycle.
Power turns off automatically after wash.
1
2
3
4
OTE
To recall your FAVORITE cycle.
1. Press POWER on.
2. Select the FAVORITE cycle by pressing the PROGRAM.
3. Press the START/PAUSE button. Then the wash cycle starts.
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 19

re Wash + Normal
P
20
Washing Programs
Washing laundry with Pre Wash+ ormal cycle that pretreats immediate stain without hand-wash.
i.e. ecessary for clothes which could be smelled badly without prompt laundry.
Press the POWER (AUTO OFF) button to turn power on.
Press the PROGRAM button to select Pre Wash + Normal program.
Press the START/PAUSE button.
A the laun ry into the washing tub.
A the Detergent an close the li .
1
3
4
5
2
MFL68019779(영)_레이아웃 1 16. 5. 11. 오전 10:07 페이지 20
