DL-SP Installation Guide
Important notice:
• Do not attempt to disassemble or alter the extender housing. There are
no user-serviceable parts inside the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic
discharge (ESD), all source and destination equipment must be powered o
during installation.
• Do not connect the extender to a telecommunication outlet wired
to unrelated equipment. Doing so may damage the unit or any connected
equipment.
• Allow proper ventilation to reduce the risk of thermal failure.
The DigitaLinx DL-SP is an HDMI Surge Protector. The DL-SP is an ideal solution designed
to protect HDMI devices against electro-static discharge, surges & spikes from mains, or
lightning strikes that cause electrical transients up to 15000 Volts (air) and 8000 Volts
(contact).
The DL-SP oers 3D, HEC and ARC passthrough from compatible source to sink devices.
The DL-SP is active on all HDMI TMDS channels oering lossless signal transmission
while performing as the best line of defense against ESD and lightning surge. DL-SP
provides hassle-free install with integrated mounting brackets and passive design
without requiring a power supply.

Instructions
• Verify all components included with the DL-SP are present before installation.
• Connect an HDMI source to the input port of the DL-SP.
• Connect an HDMI display to the output port of the DL-SP.
• Power on attached audio/video devices.
• Attaching the ground wire (provided with the product) to the screw hole of the HDMI
socket will provide extra electric shock protection.
Typical Application

11675 Ridgeline Dr.
Colorado Springs, CO 80921
Toll-Free: 800-530-8998
Fax: [phone]
www.libav.com rev 151202
Input Connections
Video Input One (1) HDMI
Input Connector 19-pin Type A female HDMI
HDMI Standard HDMI 1.4 with 3D and HDCP compliant
Input Video Signal 0.5~1.2 V p-p
Output Connections
Outputs One (1) HDMI
Output Connector 19-pin Type A female HDMI
Video Performance
Video Resolution VESA: 640x480, 800x600, 1024x768, 1280x1024, 1600x1200, 1920x1080,
1920x1200
HDTV: 480i, 576i, 480p, 576p, 720p, 1080i, 1080p
Transmission Distance 15m/ 49ft max
Supported HDMI Features HDMI Ethernet Channel (HEC), Audio Return Channel (ARC) passthrough
Chassis and Environmental
Enclosure Dimensions (W x H x D) 65 mm x 46 mm x 25 mm ( 2.6 in x 1.8 in x 1.0 in)
Shipping Weight (80g) 0.17lbs
Operating Temperature 0°C to + 45°C (+32° to + 113° F)
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -20°C to + 70°C (-4° to + 140° F)
Storage Humidity 10% to 90%, Non-condensing
Power and Regulatory
IEC Specifications IEC 61000-1-2/ 4-2 (ESD) ±15kV (15000 Volts) (Air), ±8kV (8000 Volts)
(Contact)
Maximum Spike Protection ±8kV (8000 Volts)
ESD Protection ±15 kV (Air-gap discharge), ±8 kV (Contact discharge)
Other
Warranty 2 years
Included Accessories (1) Ground Wire and Installation Guide
Technical Specifications
