Liberty Pumps Omnivore XLSG Series User manual

Approved for Hazardous Locations
Class I, Division 1, Groups C and D T4
Class I, Zone 1, Groups IIA and IIB T4
Installer: Manual must remain with owner or
operator/maintainer.
Prior to installation, record information
from pump nameplate for future reference:
Keep this manual handy for future reference.
For replacement manual, visit LibertyPumps.com,
or contact Liberty Pumps at 800-543-2550.
Retain dated sales receipt for warranty.
Model:
7000 Apple Tree Avenue
Bergen, NY 14416
ph: 800-543-2550
fax: [phone]
www.LibertyPumps.com
Serial:
Mfg Date:
Install Date:
Installation Manual 6850000C
Copyright © Liberty Pumps, Inc. 2020 All rights reserved.
Certified to CSA, UL,
and FM standards
Omnivore®Explosion-Proof
2 HP Grinder Pumps
XLSG and XLSGX-Series
Models
XLSG200-Series
Single-Stage
XLSGX200-Series
2-Stage High Head

2 | EN Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 6850000C
Contents
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 | EN
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . 4 | EN
Operating Constraints . . . . . . . . . . . . . . . . . . . . . . . . . 4 | EN
Model Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 | EN
Inspection and Storage. . . . . . . . . . . . . . . . . . . . . . . . . 4 | EN
Pump Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 | EN
Pump System Components . . . . . . . . . . . . . . . . . . . . . 5 | EN
Wiring Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 | EN
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 | EN
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 | EN
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 | EN
Maintenance and Troubleshooting . . . . . . . . . . . . . . . 8 | EN
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 | EN
Safety Guidelines
Safety Precautions
Accidental contact with electrically live parts, items, fluid, or
water can cause serious injury or death.
Always disconnect pump(s) from power source(s) before
handling or making any adjustments to either the pump(s),
the pump system, or the control panel.
All installation and maintenance of pumps, controls,
protection devices, and general wiring shall be done by
qualified personnel.
All electrical and safety practices shall be in accordance with
the National Electrical Code®, the Occupational Safety and
Health Administration, or applicable local codes and
ordinances.
Do not remove cord and strain relief, and do not connect
conduit to pump.
Pump shall be properly grounded using its supplied
grounding conductor. Do not bypass grounding wires or
remove ground prong from attachment plugs. Failure to
properly ground the pump system can cause all metal
portions of the pump and its surroundings to become
energized.
Do not handle or unplug the pump with wet hands, when
standing on damp surface, or in water unless wearing
Personal Protective Equipment.
Always wear dielectric rubber boots and other applicable
Personal Protective Equipment (PPE) when water is on the
floor and an energized pump system must be serviced, as
submerged electrical connections can energize the water. Do
not enter the water if the water level is higher than the PPE
protection or if the PPE is not watertight.
Do not lift or carry a pump or a float assembly by its power
cord. This will damage the power cord, and could expose the
electrically live wires inside the power cord.
The electrical power supply shall be located within the length
limitations of the pump power cord, and for below grade
installations it shall be at least 4 ft (1.22 m) above floor level.
Do not use this product in applications where human contact
with the pumped fluid is common (such as swimming pools,
fountains, marine areas, etc.).
Protect the power and control cords from the environment.
Unprotected power and control (switch) cords can allow
water to wick through ends into pump or switch housings,
causing surroundings to become energized.
Single-phase 208/230V pumps shall only be operated
without the float switch by using the circuit breaker or panel
disconnect.
Some products may have internal capacitors that could cause
shock. Avoid contact with plug ends after removing from
energy source.
This safety alert symbol is used in the
manual and on the pump to alert of
potential risk for serious injury or death.
This safety alert symbol identifies risk of
electric shock. It is accompanied with an
instruction intended to minimize potential
risk of electric shock.
This safety alert symbol identifies risk of
fire. It is accompanied with an instruction
intended to minimize potential risk of fire.
This safety alert symbol identifies risk of
serious injury or death. It is accompanied
with an instruction intended to minimize
potential risk of injury or death.
Warns of hazards which, if not avoided, will
result in serious injury or death.
Warns of hazards which, if not avoided,
could result in serious injury or death.
Warns of hazards which, if not avoided,
could result in minor or moderate injury.
Signals an important instruction related to
the pump. Failure to follow these
instructions could result in pump failure or
property damage.
Read every supplied manual before using
pump system. Follow all the safety
instructions in manual(s) and on the pump.
Failure to do so could result in serious injury
or death.
RISK OF ELECTRIC SHOCK

6850000C Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 3 | EN
Do not use an extension cord to power the product.
Extension cords can overload both the product and extension
cord supply wires. Overloaded wires will get very hot and can
catch on fire.
This product requires a separate, properly fused and
grounded branch circuit, sized for the voltage and amperage
requirements of the pump, as noted on the nameplate.
Overloaded branch circuit wires will get very hot and can
catch on fire. When used, electrical outlets shall be simplex of
the appropriate rating.
Do not use this product with or near flammable or explosive
fluids such as gasoline, fuel oil, kerosene, etc. If rotating
elements inside pump strike any foreign object, sparks may
occur. Sparks could ignite flammable liquids.
Hazardous locations contain explosive gases that can be
detonated by sparking or electric shock.
All terminations and penetrations of conduit or cable shall be
done using approved materials and methods intended for
use to mitigate the potential for explosion.
When working in a hazardous location, all precautions to
minimize ignition sources such as spark and flame should be
taken to limit the potential for fire or explosion.
Sewage and effluent systems produce and may contain
flammable and explosive gases. Prevent introduction of
foreign objects into basin as sparks could ignite these gases.
Exercise caution using tools and do not use electronic devices
or have live, exposed electrical circuits in or around basins,
open covers and vents.
Use only non-sparking tools and components in and around
basins, open covers and vents. Do not use electronic devices
that are not rated for use in hazardous locations or have live,
exposed electrical circuits in or around basins, open covers
and vents. Sewage and effluent systems produce and may
contain flammable and explosive gases and sparks could
ignite these gases.
Energizing the control panel or breaker for the first time is
potentially dangerous. Licensed electrical personnel should
be present when the panel or breaker is energized for the first
time. If faults caused by damage or poor installation practices
have not been detected, serious damage, injury or death can
result when power is applied.
All electrical and motor repairs and service must be
performed by a repair facility approved by Liberty Pumps and
certified to work on explosion-proof motor enclosures.
Do not remove power supply or control cord. All electrical
and motor repairs and service must be performed by the
factory or a repair facility approved by Liberty Pumps and
certified to work on explosion-proof motor enclosures.
Refer to Chapter 5 of the National Electric Code®or
applicable local codes and ordinances for all electrical and
wiring requirements in hazardous locations.
Float switches must be connected to an intrinsically safe
circuit in the control panel as per the requirements of
Chapter 5 of the National Electric Code®.
All personnel shall be trained and qualified for safe work
practices and procedures.
All installations shall be in compliance with all applicable
Federal, State, and Local codes and ordinances for hazardous
locations.
All electrical terminations shall be made according to Federal,
State, and Local codes for hazardous or classified locations.
Conduit, junction boxes, and associated components shall be
approved for use with hazardous locations and installed
according to specifications.
Do not modify the pump/pump system in any way.
Modifications may affect seals, change the electrical loading
of the pump, or damage the pump and its components.
All pump/pump system installations shall be in compliance
with all applicable Federal, State, and Local codes and
ordinances.
Do not allow children to play with the pump system.
Do not allow any person who is unqualified to have contact
with this pump system. Any person who is unaware of the
dangers of this pump system, or has not read this manual,
can easily be injured by the pump system.
In 208/230V installations, one side of the line going to the
pump is always “hot”, whether the float switch is on or off. To
avoid hazards, install a double pole disconnect near the
pump installation.
Vent basin in accordance with local code. Proper venting of
sewer and effluent gases alleviates poisonous gas buildup
and reduces the risk of explosion and fire from these
flammable gases.
Wear adequate Personal Protective Equipment when working
on pumps or piping that have been exposed to wastewater.
Sump and sewage pumps often handle materials that can
transmit illness or disease upon contact with skin and other
tissues.
Do not enter a pump basin after it has been used. Sewage
and effluent can emit several gases that are poisonous.
Do not remove any tags or labels from the pump or its cord.
Keep clear of suction and discharge openings. To prevent
injury, never insert fingers into pump while it is connected to
a power source.
This product contains chemicals known to the State of
California to cause cancer and birth defects or other
reproductive harm. www.p65warnings.ca.gov.
A grinder pump contains metal parts that rotate at high
speeds. Be careful around pump base while power is
connected. Make sure that the pump is either in the tank or
clear from people and wires when in operation.
This pump has been evaluated for use with water only.
Wear Personal Protective Equipment as exposed bottom has
sharp edges.
RISK OF FIRE
RISK OF SERIOUS INJURY OR DEATH

4 | EN Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 6850000C
Check 3-phase pumps for correct rotation prior to installing
pump(s) in basin. To change rotation, reverse any two of the
three power leads to the pump (not the ground). Code the
wires for reconnection after installation.
Do not dispose of materials such as paint thinner or other
chemicals down drains. Doing so could chemically attack and
damage pump system components and cause product
malfunction or failure.
Do not use pump system with mud, sand, cement,
hydrocarbons, grease, or chemicals. Pump and system
components can be damaged from these items causing
product malfunction or failure. Additionally, flooding can
occur if these items jam the impeller or piping.
Do not run dry.
Do not position the pump float directly under the inlet from
drain tile or in the direct path of any incoming water.
Do not use pumps with fluid over 104°F (40°C). Operating the
pump in fluid above this temperature can overheat the pump,
resulting in pump failure.
The Uniform Plumbing Code® states that sewage systems
shall have an audio and visual alarm that signals a
malfunction of the system, to reduce the potential for
property damage.
Keep pump upright.
At no time shall the pump be stored within an incomplete wet
pit. The pump shall not be placed into the pit until it can be
fully operational.
Do not allow the pump to freeze.
Model Specifications
For complete listing of models and their specifications, refer to
http://www.LibertyPumps.com/About/Engineering-Specs. Pump
nameplate provides a record of specific pump information.
Inspection and Storage
Initial Inspection
The pump should be immediately inspected for damage that may
have occurred in shipment.
1. Visually check the pump and any spare parts for damage.
2. Check for damaged electrical wires, especially where they exit
the motor housing.
Contact Liberty Pumps customer service to report any damage or
shortage of parts.
Storage Before Use
Protect the power and control cords from the environment.
Unprotected power and control (switch) cords can allow
water to wick through ends into pump or switch housings,
causing surroundings to become energized.
At no time shall the pump be stored within an incomplete wet
pit. The pump should not be placed into the pit until it can be
fully operational.
Do not allow the pump to freeze.
XLSG/XLSGX-Series Omnivore grinder pumps are shipped from
the factory ready for installation and use. The pump should be
held in storage if the pump station is not complete.
If storage is necessary, the pump should remain in its shipping
container. It should be stored in a warehouse or storage shed that
has a clean, dry temperature-stable environment where the pump
and its container are covered to protect it from water, dirt,
vibration, etc. The cord ends must be protected against moisture.
General Information
Before installation, read these instructions carefully.
Each pump is individually factory tested to ensure
proper performance. Closely following these
instructions will eliminate potential operating
problems, assuring years of trouble-free service.
The XLSG/XLSGX-Series pumps are to be used for
handling septic tank effluent, sewage, and drain
(storm) water.
Provide pump serial number in all correspondence.
Pumps are certified by CSA Group to CSA®, UL®,
and FM standards for use in hazardous locations
with division classification of Class 1, Division 1,
Groups C and D; or as zone classified Class 1,
Zone 1, and Groups IIA and IIB.
Pumps must be serviced at a qualified hazardous
motor enclosure repair facility approved by Liberty
Pumps. Any unauthorized field repairs void
warranty and hazardous location ratings. Contact
Liberty Pumps at 1-800-543-2550 to locate the
closest authorized repair facility.
Operating Constraints
It is extremely important to verify that the pump
has been sized correctly for the intended
installation. The operating point of the pump must
lie within the acceptable range as outlined by the
applicable Liberty Pumps performance chart.
Operating the pump outside of the recommended
range can invalidate the CSA Certification of the
pump and can also cause damage and premature
failure. Operating outside of the recommended
range can cause the pump to exceed its rated
nameplate amp draw, which will void the pump
certification. It can also cause motor overheating,
cavitation, excessive vibration, clogging, and poor
energy efficiency.
RISK OF ELECTRIC SHOCK

6850000C Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 5 | EN
Uninstalled pumps that are idle for greater than three months
should have impellers and cutters manually rotated once a month
to lubricate the seals.
Installed pumps that are idle for greater than one month should
have impellers and cutters manually operated through the breaker
panel once a month to lubricate the seals.
Pump Design
XLSG/XLSGX-Series grinder pumps are designed for continuous
underwater operation. The motor and pump form a close coupled,
watertight unit. The induction motor is insulated against heat and
moisture in accordance with Class F 311°F (155°C) regulations.
The motor is protected against damage from water entry by two
mechanical seals. The lower seal is 2-piece, silicon carbide/silicon
carbide and the upper seal is unitized silicon carbide/silicon
carbide.
The impeller and volute are designed for efficient flow
characteristics and clog-free operation. The hardened cutters
grind solids and fibrous matter into small particles that can be
safely pumped through small diameter piping.
Pump System Components
Control Panel
Float switches must be connected to an intrinsically safe
circuit in the control panel as per the requirements of
Chapter 5 of the National Electric Code®.
XLSG/XLSGX-Series grinder pumps require a separate, approved
control panel for automatic operation. Operation will be
according to the control selected. Refer to separate
manufacturer’s instructions supplied with the unit.
The control panel shall be installed outside the hazardous area
and appropriately isolated and sealed to prevent any potential
ignition or explosion. Only approved controls that have
intrinsically safe float switch connections shall be used. Mounting,
installation and wiring connections are specific to the control
panel used. Refer to the manufacturer’s instructions supplied with
the unit.
IMPORTANT: When connecting an XLSG/XLSGX-Series pump to
an existing control panel, verify the panel is correctly sized and
equipped for the pump.
The control panel for 3-phase pumps shall have provisions for the
thermostats that open the motor contactors in order to maintain
the T4 (135°C) temperature class. Do not exceed voltage/current
combinations for the thermostat: 16 VDC/20 Amps, 115 VAC/
22 Amps, 277 VAC/8 Amps, 600 VAC/4 Amps. All models have a
temperature (T) class rating of T4 with thermostats connected.
Failure to use the proper circuitry and to connect the thermostat
will void the T4 temperature class of the pump and will drop the
temperature class to T3 (200°C).
Intrinsically safe control panels designed for use with the XLSG/
XLSGX-Series pumps available from Liberty Pumps can be found
at http://www.LibertyPumps.com/Portals/0/Files/
panel_selection_guide.pdf or contact Liberty Pumps.
1-phase pumps require a panel-mounted start circuit consisting of
a start capacitor, run capacitor, and start relay, which are available
separately. Refer to Table 1 for these control panel components.
Overload Protection
XLSG/XLSGX-Series grinder pumps require overload protection in
the control panel. The motor control unit shall be approved and
shall be properly sized or adjusted for the full load input power
indicated on the pump nameplate. It is important to properly
adjust or select the motor control overload protection. The full
load amps on the nameplate should be used as a baseline, but it is
important to consider that events such as supply voltage variation
or large solids passing through the pump can temporarily increase
current draw. To avoid possible nuisance tripping, it may be
necessary to adjust overloads to a value slightly higher than the
full load input power indicated on the pump nameplate.
Thermostats
XLSG/XLSGX-Series grinder pumps are protected from
overheating by means of thermal switches (thermostat) located in
the motors. For 1-phase models, a hermetically sealed thermal
overload device is mounted on the motor windings and wired
directly in series with the motor’s winding, interrupting power in a
high heat condition. 3-phase models utilize two thermostats
mounted in series directly on the motor windings. The thermostat
circuit shall be connected to a control panel that will stop power
to the pump in a high temperature condition.
Both 1- and 3-phase pumps are constructed with class F materials,
with a maximum operation temperature of 155°C. Failure to use
the proper circuitry and connection of the thermostat will drop
temperature class from T4 to T3 on 3-phase units.
Many panels have a manual reset button for the thermostats on
3-phase units. This button must be pressed to reset the system
after the pump has cooled. 1-phase units reset automatically after
the pump has cooled.
RISK OF SERIOUS INJURY OR DEATH
Table 1. Control Panel Components 1-Phase
Required Component and Specification Liberty Pumps
P/N
208 V 1-phase Start Kit
(contains 3 items listed separately below) K001640
Start Capacitor, 270–324 µF 220/250 VAC
Run Capacitor, 65 µF 370 VAC
Start Relay
230 V 1-phase Start Kit
(contains 3 items listed separately below) K001641
Start Capacitor, 270–324 µF 220/250 VAC
Run Capacitor, 50 µF 370 VAC
Start Relay

6 | EN Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 6850000C
Seal Failure Probes
XLSG/XLSGX-Series grinder pumps are equipped with two
mechanical face seals with an intermediate oil chamber between
them. This ensures lubrication for the seals, shaft flame path, and
as a barrier to the motor chamber in the event the lower seal is
compromised. A seal fail or moisture sensing device is located in
the mid oil chamber and continuously monitors for leakage. In the
event of a seal failure, moisture mixes with the oil, tripping the
seal leak circuit. In a failure condition, a fault light will illuminate
on the control panel. The pump will continue to operate, but
service should be scheduled as soon as possible.
Intrinsically safe (ISS and ISD) control panels by Liberty Pumps
have a seal leak test button that tests the integrity of the seal leak
circuit continuity. When pressed, the light should illuminate. The
light should go off when the test button is released. If it remains
on, the potentiometer is set too high. If light does not illuminate,
the light is burned out, the circuitry is open, or the system does
not have power. The seal leak relay requires adjustment upon
installation. See Seal leak relay setup on page 7.
Power and Control Cords
Do not remove cord and strain relief, and do not connect
conduit to pump.
The power and control cords cannot be spliced; a junction box
may be used providing it is rated for hazardous locations and has
approved cord connectors.
IMPORTANT: Each cord has a green lead. This is the ground wire
and must be grounded properly per NEC®and/or local codes.
Wiring Instructions
Always disconnect pump(s) from power source(s) before
handling or making any adjustments to either the pump(s),
the pump system, or the control panel.
All installation and maintenance of pumps, controls,
protection devices, and general wiring shall be done by
qualified personnel.
All electrical and safety practices shall be in accordance with
the National Electrical Code®, the Occupational Safety and
Health Administration, or applicable local codes and
ordinances.
Figure 1. Wiring Diagram 1-Phase
Figure 2. Wiring Diagram 3-Phase
RISK OF ELECTRIC SHOCK
RISK OF ELECTRIC SHOCK
WHITE WHITE
GREEN
BLACK
GREEN
GREEN
BLACK
GREEN
NOT
USED*
NOT
USED*
* Note:
On
1-phase
pumps, the
white and red
leads of the
control cord
are not used.
SEAL
LEAK
BLACK
WHITE
RED
MOTOR
BLACK
WHITE
RED
RED
WHITE
GREEN
BLACK
L2/NL1
RUN
CAP
START
CAP
POTTING
RESIN
SEAL
FAILURE
PROBES
START
RELAY
5 2
1
CONTROL
CORD
POWER
CORD
START CIRCUITSTART CIRCUIT
SEAL FAILURE
PROBES
MOTOR
SEAL LEAK
POWER
CORD
CONTROL
CORD
WHITE
WHITE WHITE
WHITE
GREEN GREEN
RED
RED
RED RED
WHITE
WHITE
GREEN
GREEN
BLACK
BLACK BLACK
BLACK
POTTING
RESIN
L3 L2L1
THERMOSTAT
THERMOSTAT
L3
L2
L1 BLK
PNK
VIO
RED
WHT
BLU
BRN
ORN
YEL
440–480V 3PH
L3
L2
L1 BLK
PNK
VIO
575V 3PH
BLK
PNK
VIO
RED
WHT
BLU
BRN
ORN
YEL
L3
L2
L1
208V/230V 3PH

6850000C Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 7 | EN
Preparation
Always disconnect pump(s) from power source(s) before
handling or making any adjustments to either the pump(s),
the pump system, or the control panel.
Prepare Sump [Basin]
If replacing a previously installed pump, prepare the basin by
removing the old pump and cleaning any debris from the basin.
Inspect all remaining equipment in the basin including guide rails,
piping, valves, and electrical junction boxes (if present) and repair
or replace as appropriate. Ensure that control hardware such as
floats or pressure transducers are clean, properly adjusted, and in
good working order.
Pump installation should be at a sufficient depth to ensure that all
plumbing is below the frost line. If this is not feasible, remove the
check valve and size the basin and/or adjust pump differential to
accommodate the additional backflow volume. Consult Liberty
Pumps for details on how this should be done.
Pump Control and Alarm Floats
The water level in the basin is determined by the placement of the
control floats and should be positioned such that the motor
housing is completely submerged to properly cool the motor. If
full submersion is not possible, the minimum water depth must be
no less than 13 inches as measured from the bottom of the pump
legs. The upper water level should be positioned to minimize
pump starts. The alarm float must be above the turn-on float
switch but below any inlets. No control should be set above the
inlet to the basin.
Set the second (turn-on) control above the lower turn-off control.
The exact distance between the two floats must be a compromise
between a frequent pumping cycle (10 starts per hour max) to
properly manage sewage level, and a longer pump run duration
per start, which maximizes energy efficiency. This distance must
be determined by the engineer, depending on the conditions of
the application.
Cutter and Impeller Free Movement Check
Wear Personal Protective Equipment as exposed bottom has
sharp edges.
Do not connect any power to pump until this check is complete.
Manually rotate the cutter to check that it spins freely with very
little resistance. The cutter is located on the bottom of the pump.
The cutter can be carefully rotated by hand, or rotated by
inserting a tool into the cutter bolt. If rotating by hand, wear
protective gloves as the cutter and cutter plate have sharp edges.
The pump can remain upright or can be laid down on its side for
easier access to the cutter. Besides verification that the cutter and
impeller are freely spinning, rotating the cutter helps to lubricate
the shaft seals if the pump has been non-operational for more
than a week. It is recommended to rotate the cutter 5–10 full
rotations.
Installation
All installation and maintenance of pumps, controls,
protection devices, and general wiring shall be done by
qualified personnel.
All electrical and safety practices shall be in accordance with
the National Electrical Code®, the Occupational Safety and
Health Administration, or applicable local codes and
ordinances.
Electrical Connections
With main power disconnected, complete pump and control
wiring connections per wiring diagrams included with the control
panel and Figure 1/Figure 2 as applicable. All wires should be
checked for unintentional grounds with an ohmmeter after the
connections are made.
Thermostat and Seal Failure Connections
Verify thermostat wires are connected in series with the contactor
and that seal fail probes are properly connected and relay
sensitivity properly adjusted. Connections are provided on the
terminal strip inside the Liberty Pumps control panel.
Seal leak relay setup: Turn the potentiometer dial clockwise until
the red light turns on, then turn the dial counterclockwise until the
red light turns off. The tick marks on the seal leak relay are for
reference only. The seal leak adjustment dial should be set to
around 75 (range is 75 to 125).
3-Phase Pump Rotation Verification
Check 3-phase pumps for correct rotation prior to installing
pump(s) in basin. To change rotation, reverse any two of the
three power leads to the pump (not the ground). Code the
wires for reconnection after installation.
3-phase power uses three separate
alternating currents that peak at
different integrals. With pumps that
are powered by three phase electric,
the phase sequence of the motor
must match the phase sequence of
the power source. When the phase
sequences match, the pump operates
properly. However, when the phases
are out of order, the pump runs
backward (i.e., the impeller rotates in
the wrong direction). This causes an
extreme loss of performance and
could raise the current draw, which
could result in tripping an overload
or circuit breaker.
To ensure that the power to the pump is installed correctly, always
verify proper rotation before lowering it into the basin. If the
pump is rotating in the wrong direction, turn off the power and
reverse any two power leads. This reverses the phase sequence
and corrects the pump rotation. Rotation must be
counterclockwise when looking from the bottom of the pump.
RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK
Correct Impeller Rotation
BOTTOM VIEW

8 | EN Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 6850000C
Guide Rail System
When working in a hazardous location, all precautions to
minimize ignition sources such as spark and flame should be
taken to limit the potential for fire or explosion.
If guide rails are used, refer to the separate instructions supplied
with the unit for proper installation and operation, making sure all
gaskets and components are present. Use of a guide rail system
shall be of a non-sparking design. Contact Liberty Pumps for
available models, such as GR20NS.
If guide rails are not used, complete all pump-mounted plumbing
at this time, being sure all gaskets and components are present.
Pump
Record information from pump nameplate onto inside cover of
these instructions. Complete a visual inspection before lowering
into basin.
Place pump in basin being sure the mounting interface (i.e., guide
rail, torque stop) is engaged correctly.
Discharge
Make all discharge connections. A check valve is required to
prevent the backflow of liquid after each pumping cycle. A gate
valve should follow the check valve to allow periodic cleaning of
the check valve or removal of the pump. The remainder of the
discharge line should be as short as possible with a minimum
number of turns to minimize friction head loss. Do not reduce the
discharge to below the pump outlet size. Larger pipe sizes may be
required to eliminate friction head loss over long runs. Contact
Liberty Pumps or other qualified person if questions arise
regarding proper pipe size and flow rates.
Vent
Vent basin in accordance with applicable plumbing codes.
Operation
Energizing the control panel or breaker for the first time is
potentially dangerous. Licensed electrical personnel should
be present when the panel or breaker is energized for the first
time. If faults caused by damage or poor installation practices
have not been detected, serious damage, injury or death can
result when power is applied.
Starting System
1. Verify all plumbing components in the basin are installed
correctly and functional. Verify all valves are open and ready
for pump use.
2. Double check all wire connections. Re-tighten all factory and
field connections.
3. Ensure pump has no obstructions.
4. With all electrical and mechanical connections complete and
secure, turn on power to control panel and pump.
5. Verify operation of the pump, floats, and alarm circuits.
6. Run several cycles of water through the system to verify
correct control operation for the installation.
Be certain to complete adequate testing, especially on systems
with multiple pumps or custom control configurations.
Maintenance and Troubleshooting
Accidental contact with electrically live parts, items, fluid, or
water can cause serious injury or death.
Always disconnect pump(s) from power source(s) before
handling or making any adjustments to either the pump(s),
the pump system, or the control panel.
All electrical and motor repairs and service must be
performed by a repair facility approved by Liberty Pumps and
certified to work on explosion-proof motor enclosures.
Use only non-sparking tools and components in and around
basins, open covers and vents. Do not use electronic devices
that are not rated for use in hazardous locations or have live,
exposed electrical circuits in or around basins, open covers
and vents. Sewage and effluent systems produce and may
contain flammable and explosive gases and sparks could
ignite these gases.
Wear adequate Personal Protective Equipment when working
on pumps or piping that have been exposed to wastewater.
Sump and sewage pumps often handle materials that can
transmit illness or disease upon contact with skin and other
tissues.
Do not enter a pump basin after it has been used. Sewage
and effluent can emit several gases that are poisonous.
Verify correct 3-phase pump rotation before retuning to
service.
RISK OF FIRE
RISK OF SERIOUS INJURY OR DEATH
RISK OF ELECTRIC SHOCK
RISK OF FIRE
RISK OF SERIOUS INJURY OR DEATH

6850000C Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 9 | EN
Maintenance
Pump should be checked quarterly for corrosion and wear. As the
motor is oil-filled, no lubrication or other maintenance is required.
Severe operating environments will require more frequent checks.
Field Service on Hazardous Location Pumps
The power and control cord are not field replaceable. If either cord
is compromised, the entire pump must be brought to an
authorized hazardous motor enclosure repair facility approved by
Liberty Pumps.
The only allowable repair/replacement without compromising the
hazardous location rating of the pump is the lower shaft seal. A
certified repair shop should perform this task since they have the
capability to clean and flush the mid oil chamber.
Otherwise, the pump must be returned to Liberty Pumps or an
authorized hazardous repair facility for electrical and motor
service. This will ensure the integrity of the hazardous location
rating of the pump and comply with Liberty Pumps warranty
requirements.
Troubleshooting
No repair work shall be carried out during the warranty period
without prior factory approval. To do so may void the warranty.
Liberty Pumps, Inc. assumes no responsibility for damage or injury
due to disassembly in the field. Disassembly, other than an
authorized hazardous motor enclosure repair facility approved by
Liberty Pumps or its authorized service centers, automatically
voids warranty.
Table 2. Troubleshooting Matrix
Problem Possible Cause Corrective Action
Pump does not start.
Damaged power cable. Return pump to an authorized repair facility.
Control panel selector switch in Off position. Set selector switch to Hand or Auto position.
Blown control circuit transformer fuse. Replace fuse.
Tripped circuit breaker, blown fuse, or other
interruption of power.
Reset tripped circuit breaker; replace blown fuse with
properly sized fuse; investigate power interruption.
Improper voltage. Have an electrician check all wiring for proper
connections and adequate voltage and capacity.
Float switch unable to move to the PUMP ON
position due to interference in basin or other
obstruction.
Position the pump or float switch so that it has adequate
clearance for free movement.
Insufficient liquid level. Verify the liquid level is allowed to rise enough to
activate float switch(es).
Defective float switch. Replace float switch.
Obstructed impeller or volute. Remove obstruction.
Loose wiring connections. Check and tighten all connections.
Thermal overload tripped. Wait for pump to cool to operating temperature.
Pump does not start
and overload heaters
trip.
Unintentional ground. Turn off power and check motor leads for possible
ground.
3-phase motor winding failure. Check resistance of motor windings. All three phases
should have the same reading.
Obstructed impeller or volute. Remove obstruction.
Pump operates with
control panel selector
switch in Hand position
but does not operate in
Auto position.
Control circuits malfunctioning.
Check float level control or the alternator relay for issues.
Check control panel.

10 | EN Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 6850000C
Pump runs, but does
not turn off.
Pump is airlocked. Turn pump off and let set for several minutes, then
restart.
Control panel selector switch in Hand position. Set selector switch to Auto position.
Float switch unable to move to the PUMP OFF
position due to interference with the side of
basin or other obstruction.
Position the pump or float switch so that it has adequate
clearance for free movement.
Control panel failure. Check control panel.
Defective float switch. Replace float switch.
Motor stops and then
restarts after short
period but overload
heaters in starter do not
trip.
Pump operating on a short cycle due to basin
being too small. A larger basin may be required. Consult Liberty Pumps.
Pump cycles too
frequently.
Improper float switch setting. Adjust float switch setting.
Check valve not installed, is stuck open, or is
leaking.
Install check valve(s); remove check valve and examine
for freedom of operation and proper installation.
Pump runs or hums, but
does not pump.
Discharge line is blocked or restricted. Check the discharge line for foreign material, including
ice if the discharge line passes through or into cold areas.
Check valve is stuck closed or installed backward. Remove check valve(s) and examine for freedom of
operation and proper installation.
Gate or ball valve is closed. Open gate or ball valve.
Total head (lift height) is beyond pump's
capability.
Route piping to a lower level. If not possible, a larger
pump may be required. Consult Liberty Pumps.
Obstructed impeller or volute. Remove obstruction.
Pump is airlocked.
Turn pump off and let set for several minutes, then
restart.
Add baffle to reduce trapped air bubbles.
Capacitor failure in control panel. Check capacitors and replace if needed.
Stuck/defective motor contactor in control
panel. Replace motor contactor.
Pump is not seated correctly in guide rail base. Lift pump and re-position.
Pump runs periodically
when fixtures are not in
use.
Check valve not installed, is stuck open, or is
leaking.
Install check valve(s); remove check valve and examine
for freedom of operation and proper installation.
Fixtures are leaking. Repair fixtures as required to eliminate leakage.
Table 2. Troubleshooting Matrix (continued)
Problem Possible Cause Corrective Action

6850000C Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 11 | EN
Pump does not deliver
proper capacity.
Discharge valve(s) partially closed or clogged. Check the discharge line for foreign material, including
ice if the discharge line passes through or into cold areas.
Check valve partially clogged. Raise liquid level up and down to clear; remove check
valve to remove obstruction.
Incorrect motor rotation.
1-Phase: Contact factory.
3-Phase: Correct 3-phase pump rotation direction. Refer
to section 3-Phase Pump Rotation Verification.
Total head (lift height) is beyond pump's
capability.
Route discharge piping to a lower level. If not possible, a
larger pump may be required. Consult Liberty Pumps.
Low liquid level. Check liquid level.
Obstruction in pump or piping. Remove obstruction.
Pump operates noisily.
Piping attachments to building are too rigid. Replace a portion of the discharge line with rubber hose
or connector.
Incorrect motor rotation.
1-Phase: Contact factory.
3-Phase: Correct 3-phase pump rotation direction. Refer
to section 3-Phase Pump Rotation Verification.
Pump is being run below minimum head
requirement causing cavitation.
A different sized pump or impeller may be required.
Consult Liberty Pumps.
Foreign objects in the impeller cavity. Clean the impeller cavity.
Broken impeller. Consult Liberty Pumps for information regarding impeller
replacement.
Worn bearings. Return pump to an authorized repair facility.
Seal fail light is
illuminated.
Lower (outer) seal has been compromised. Replace lower seal.
Control panel relay sensitivity is incorrect. Adjust sensitivity dial.
Repeated tripping.
Circuit protection underrated. Check rating and replace with proper size.
Current unbalance. Check current draw.
Other appliance on same circuit. Pump requires separate circuit.
Pump is connected to an extension cord or
wiring is inadequate or compromised. Have an electrician check for proper wiring.
Improper voltage. Have an electrician check all wiring for proper
connections and adequate voltage and capacity.
Obstruction in pump. Remove obstruction.
Foreign matter build-up. Clean motor housing.
Incorrect motor rotation.
1-Phase: Contact factory.
3-Phase: Correct 3-phase pump rotation direction. Refer
to section 3-Phase Pump Rotation Verification.
Table 2. Troubleshooting Matrix (continued)
Problem Possible Cause Corrective Action

12 | EN Copyright © Liberty Pumps, Inc. 2020 All rights reserved. 6850000C
Warranty
Liberty Pumps Wholesale Products Limited Warranty
Liberty Pumps, Inc. warrants that Liberty Pumps wholesale products are free from all factory defects in material and workmanship for a
period of three (3) years from the date of purchase (excluding batteries). The date of purchase shall be determined by a dated sales
receipt noting the model and serial number of the pump. The dated sales receipt must accompany the returned pump if the date of
return is more than three years from the date of manufacture noted on the pump nameplate.
The manufacturer's sole obligation under this Warranty shall be limited to the repair or replacement of any parts found by the
manufacturer to be defective, provided the part or assembly is returned freight prepaid to the manufacturer or its authorized service
center, and provided that none of the following warranty-voiding characteristics are evident:
The manufacturer shall not be liable under this Warranty if the product has not been properly installed, operated, or maintained per
manufacturer instructions; if it has been disassembled, modified, abused, or tampered with; if the electrical cord has been cut, damaged,
or spliced; if the pump discharge has been reduced in size; if the pump has been used in water temperatures above the advertised rating;
if the pump has been used in water containing sand, lime, cement, gravel, or other abrasives; if the product has been used to pump
chemicals, grease, or hydrocarbons; if a non-submersible motor has been subjected to moisture; or if the label bearing the model and
serial number has been removed.
Liberty Pumps, Inc. shall not be liable for any loss, damage, or expenses resulting from installation or use of its products, or for indirect,
incidental, and consequential damages, including costs of removal, reinstallation or transportation.
There is no other express warranty. All implied warranties, including those of merchantability and fitness for a particular purpose, are
limited to three years from the date of purchase. This Warranty contains the exclusive remedy of the purchaser, and, where
permitted, liability for consequential or incidental damages under any and all warranties are excluded.
7000 Apple Tree Avenue
Bergen, NY 14416
ph: 800-543-2550
fax: [phone]
www.LibertyPumps.com
