Table of contents
_______________________________________________________________
User Manual Data Video Projector 1
Before use 2
1. Scope of delivery, accessories 8
1.1 Disposal of packing material 8
2. Quick Setting Up
2.1 Setting up and Connecting the Projector 9
2.2 Projector Terminal Connections 9
2.3 Control Panel Keypad 10
2.4 Mouse Connection 11
2.5 Cable Connections 11
2.6 Image Size 12
2.7 Image Height 12
3. Starting up the Projector
3.1 First Steps 12
3.2 Standby Mode 13
3.3 Projector Power Down 13
4. Using System Menu
4.1 Main Menu 14
4.2 Sub Menus 14
4.3 Menu Adjustments / Settings 15
5. Infrared Remote Control
5.1 How to use the Infrared Remote Control 19
5.2 Battery Replacement 21
6. Replacing the Air Filter 22
7. Replacing Projection Lamp
7.1 Lamp Life Indicator 24
8. Cleaning the Projector 24
9. Troubleshooting Problems and Solutions 25
10. Service Hotline 26
11. Product Manufacturer 26
Projection Table 27
Setting non-standard video modes 27
Glossary of terms 28
Technical details 29
Index 31

Before use
_______________________________________________________________
User Manual Data Video Projector 2
Before use
The following notes are intended to be a help for handling the product in accordance
with its designated purpose.
Warnung:
A person could be killed or injured if the wrong operation is done by ignoring this
indication.
_______________________________________________________________
Do not install this unit
in an unstable place.
Avoid placing it in an unstable place such as a weak base, an inclined floor, etc. This may cause
the projector to drop or fall over, resulting in injury.
Do not remodel
this unit.
Do not remodel this unit. It may cause a fire, an electric shock, etc.
Never use
the projector in a humid
environment.
Never use the projector in a humid environment, e.g. bathroom or close to cookers or
humidifiers. This could cause a fire, an electric shock, etc.
Only connect
to the specified mains voltage.
The projector must only be operated with the alternating current specified on the identification
plate. Please immediately check whether the supplied mains connection cable coincides with
wall outlets at the installation location.

Before use
_______________________________________________________________
3 Data Video Projector User Manual
Do not forget
the protective conductors.
Only use extension leads or cables with a minimum cross-section of 1.5 mm² and protective
conductors.
Do not apply any shock.
If you drop this unit or if the casing is broken, turn off the power switch, disconnect the power
plug and contact your dealer. If you use it as it is, it may cause a fire, an electric shock, etc.
If any abnormality occurs.
It there is abnormal smell or smoke, if you use this unit as it is, this could cause a fire or an
electric shock, etc. Immediately turn off the power switch and pull out the power plug. Contact
your dealer to repair the unit. Do not repair it yourself, as it is very dangerous.
Do not use this unit as it is after trouble has occurred. Immediately turn off the power switch and
pull out the power plug, then contact your dealer to have it repaired.
If water, etc., enters the unit, turn it off, pull out the power plug and contact your dealer to have
it repaired.
Be careful with the power cord.
Do not scratch, damage or modify the power cord. Do not bend it forcibly. Also do not put a
heavy object on it, do not heat it and do not pull it. If you do, the power cord may be damaged
and it may cause fire, electric shock, etc.
If the power cord is damaged (exposed or disconnected wire, etc.), replace it. It may otherwise
cause a fire, an electric shock, etc.
Make sure that no dirt adheres to the power plug and insert it until it stops. If dirt adheres or the
connection is incomplete it may cause a fire, an electric shock, etc.

Before use
_______________________________________________________________
User Manual Data Video Projector 4
Do not look directly into the lens
when the lamp is switched on.
Do not look directly into the lens when the lamp is switched on. Since a powerful lamp is used, it
could damage your vision, etc.
Do not put a container, etc,
with liquid on this unit.
Do not put a vase, flower pot, cosmetic container, medicine or water on this unit. If liquid spills
and enters the unit, it may cause fire, electric shock, etc.
Never leave the projector
switched on unsupervised.
Never leave the projector switched on unsupervised or let children play with it as unusual
conditions may occur which can cause a fire, an electric shock, etc.

Before use
_______________________________________________________________
5 Data Video Projector User Manual
Caution !
Non-observance can lead to injury or damage.
_______________________________________________________________
Caution
when carrying the unit.
When the unit is to be moved, be sure to disconnect the power plug and check that all external
connection cords are removed before moving it. If not, the cord may be damaged and it may
cause a fire, an electric shock, etc.
Do not place this unit
where it gets hot.
Be careful if you place the unit outdoors, in a place exposed to direct sunlight or near a heating
device, the casing and parts could be affected.
Cleaning the projector.
Handle the projector as you would do any other device with glass components. Avoid impact or
dropping. Before cleaning the device disconnect the mains plug.
The worktop is covered with a scratch-resistant glass plate. If necessary, the glass can be
cleaned with a soft cloth and a conventional glass cleaner.
The casing can be cleaned with a soft, slightly moistened cloth and mild detergent. Avoid the
ingress of moisture into the inside of the equipment. Never use solvents or abrasive cleaners.
Do not leave cleaners inside the projector.
Handle the power cord carefully.
Do not bring the power cord near a heating device. The cord’s shield may melt and it may cause
a fire, an electric shock, etc.
Do not insert / disconnect the power plug with wet hands. It may cause an electric shock.
Do not pull the power cord when the power plug is to be disconnected. The power cord may be
damaged and it may cause a fire, an electric shock, etc. Be sure to seize the power plug.

Before use
_______________________________________________________________
User Manual Data Video Projector 6
Do not step on this unit.
Do not put a heavy object on it.
Do not step on this unit or put a heavy object on it. Pay attention when children are present. If
you do, the unit may fall over or may be broken causing an injury.
Never block
the ventilation slots.
Never block the openings for the ventilation or place objects in the projector. Heat may
accumulate inside the projector and it may catch fire.
Set the caster stoppers.
When this unit is installed on a table with casters, set the caster stoppers. If the table moves, it
may fall over, causing an injury.
If you do not use
the unit for a long time.
If you do not use the unit for an extended period of time, be sure to pull out the power plug from
the power outlet.
Replacing the lamp.
Switch off the projector and disconnect the mains plug before replacing the lamp. Let the device
cool down, as the lamp and other components in the projector casing have heated up during
operation, which can cause injury when touched.
Do not place this unit
in a moist or dusty place.
Do not place this unit in a moist or dusty place. It may cause a fire, an electric shock, etc. Do not
place this unit where it would be exposed to soot or steam, near a cooking stove or humidifier,
etc. It may cause a fire, an electric shock, etc.

Before use
_______________________________________________________________
7 Data Video Projector User Manual
Volume.
Use a volume level that does not bother persons in the neighborhood. Especially, since the
sound is likely to carry well at nighttime even at a low volume, be careful to choose a suitable
level.
Clean the projector inside
at least once a year!
Ask your dealer to clean the unit inside once a year. If the unit is left with too much dust inside it
may cause fire.
Use of batteries.
Do not use batteries not specified for this unit. Do not use new batteries mixed with old ones.
This may cause a fire, injury due to burst of battery, liquid leakage.
When inserting batteries in this unit, pay attention to the direction of the + and - polarities and
insert the batteries correctly. If the polarities are confused, it may cause injury or damage near
the unit due to burst batteries, liquid leakage, etc.

Scope of delivery / Accessories / Packing
_______________________________________________________________
User Manual Data Video Projector 8
1. Scope of delivery, accessories
The packing contains the following parts:
1 projector
1 infrared remote control with batteries
1 connecting cable for IBM compatible PC
1 mouse cable for serial Microsoft mouse
1 PS/2 mouse adapter
1 video / audio cable
1 S-VHS cable
1 Scart adapter
1 mains cable with Schuko plug
1 user manual
The following accessories are available:
Travel case, hard case, connecting set for Macintosh (computer cable,
monitor cable, ADB mouse adapter), connecting cables for workstations,
booster box, extension cables, ceiling mount kit
Important note
The projector features its own electronic multi-range power supply with
automatic switching. It must only be operated with 100 V - 130 V or 200 - 240
V AC with a frequency of 50 Hz to 60 Hz. The unit must only be connected to
aproperly installed network with protective conductor. Please check
immediately whether the supplied mains cable is compatible with the mains
sockets on-site. Please contact your supplier if a different power supply cable
is required for use abroad.
1.1 Disposal of packing material
The transport packing consists of materials which may be disposed of as
paper and cardboard.
Remark: the transport packing offers perfect protection for the product and
should be kept for further transport etc.

Quick Setting Up: Setting up and connecting the projector
_______________________________________________________________
9 Data Video Projector User Manual
2. Quick Setting Up
2.1 Setting up and connecting the projector
These instructions are intended to get you going fast.
Attention: To avoid damage to the equipment, all power to projector and
input sources must be turned off during cable hook up.
1. Place the projector on a rigid, non-slip surface.
2. Connect the power cord.
3. Connect the audio and computer/video input cables to the projector input
terminals.
4. For mouse emulation, connect the mouse and, in case of PS/2, the
appropriate adapter. (Apple Macintosh computers require an additional
adapter or connecting cable.)
5. Power up the projector then the computer and the video sources.
6. Move the projector nearer or further away from the screen to obtain the
best image size or adjust the image size with the Zoom buttons of the remote
control. The image height may be adjusted with the +/- buttons of the remote
control. Also see menu point Frame Test Picture, page 19.
2.2 Projector Terminal Connections
Take a moment to look over the input terminals on the back of the projector.
Terminal connectors for the computer source are: RGB 1/RGB 2, Monitor,
RS232C, Audio 1/Audio 2. Terminal connectors for the video sources are:
Video, S-Video, Audio 1/Audio 2. For both sources: Audio out.
