Liesegang Solid Cinema 215 User manual

Projector
Solid Cinema
Model No.215
ENGLISH
FRANÇAIS
DEUTSCH
ESPAÑOL
ITALIANO
TECHNICAL
00SolidCinema1Basic04.3.301:23PMページ2

Thank you for purchasing this projector.
• The information in this manual is subject to change without notice.
• The manufacturer assumes no responsibility for any errors that may appear in this manual.
• The reproduction, transmission or use of this document or contents is not permitted without
express written authority.
TRADEMARK ACKNOWLEDGMENT :
• VGA and XGA are registered trademar s of the International Business Machines Corporation.
• Apple and Mac are registered trademar s of Apple Computer, Inc.
• VESA and SVGA are trademar s of the Video Electronics Standard Association.
• Windows is a registered trademar of Microsoft Corporation.
All other trademar s are the property of their respective owners.
NOTE
WARNING Before using, read the "User's Manual - Safety Guide" and
these manuals to ensure correct usage through understanding. After reading,
store them in a safe place for future reference.
Projector
Solid Cinema
Model No.215
User's Manual - Operating Guide
1
01SolidCinemaEn04.4.216:45PMページ1

●
Ultra High Brightness
Crisp, ultra-bright presentations is achieved by using a UHB (ultra high brightness) lamp and a highly
efficient optical system.
●
Whisper Mode Equipped
Special mode is available for reducing projector noise to achieve quieter operation.
●
User Memory Function
This projector can memorize 4 settings by MY MEMORY function.
●
Partial Magnification Function
Interesting parts of images can be magnified for closer viewing.
●
Keystone Distortion Correction
Quick correction of distorted images electrically.
Preparation
Please see the “Contents Of Package” of the “User’s Manual – Quick Guide”.
Your projector should come with the items shown there. Contact your dealer
anything is missing.
Projector Features
This multimedia projector is used to project various computer signals as well as
NTSC / PAL / SECAM video signals onto a screen. Little space is required for
installation and large images can easily be realized.
• Keep the original packing material for future reshipment.
NOTE
2
01SolidCinemaEn04.4.216:45PMページ2

3
Projector Features ……………………………………2
Preparation ……………………………………………………2
Part Names ……………………………………………………4
The Projector ………………………4
Fastening The Lens Cap …………4
The Remote Control ………………6
Setting Up …………………………………………………………7
Arrangement ………………………7
Adjusting The Projector’s
Elevator ……………………………8
Connecting Your Devices…………9
Connecting Power Supply ………11
Remote Control…………………………………………12
Putting Batteries …………………12
Operating The Remote Control…13
Power ON/OFF …………………………………………14
Turning On The Power …………14
Selecting An Input Signal ………15
Turning Off The Power …………16
Operating ……………………………………………………17
Adjusting The Volume …………17
Temporarily Muting The Sound…17
Adjusting The Position …………18
Using The Automatic
Adjustment Feature………………19
Correcting Keystone
Distortions…………………………19
Using The Magnify Feature ……20
Freezing The Screen ……………20
Signal Searching …………………21
Selecting The Aspect Ratio ……21
Temporarily Blanking
The Screen ………………………21
Multifunctional Settings ……………………22
Using The Menu Functions ……22
MAIN Menu ………………………23
PICTURE-1 Menu ………………24
PICTURE-2 Menu ………………26
INPUT Menu ……………………27
AUTO Menu ………………………29
SCREEN Menu …………………30
OPTION Menu ……………………31
Lamp ………………………………………………………………32
Replacing The Lamp ……………33
Air Filter …………………………………………………………34
Caring For The Air Filter…………34
Replacing The Air Filter …………35
Other Care ……………………………………………………36
Caring For The Inside
Of The Projector …………………36
Caring For The Lens ……………36
Caring For The Cabinet
And Remote Control ……………36
Troubleshooting ……………………………………37
Related Messages ………………37
Regarding
The Indicator Lamps ……………39
Phenomena That May Easily Be
Mistaken For Machine Defects …41
Warranty And After-Service ……42
Specifications …………………………………………43
TECHNICAL
Contents
01SolidCinemaEn04.4.216:45PMページ3

4
Strap Rivet
Strap
hole
Part Names
The Projector
Zoom ring 15
Focus ring 15 Air filter cover
(An air filter is
inside.)
34
Elevator button
8
Elevator feet
8
Indicates the corresponding
reference page
Lens cap 14
Lens
(The picture is
projected from
here.)
Remote sensor
13
Projector (Front/Right)
Fastening The Lens Cap
To avoid losing, please fasten the lens cap to the projector using the strap.
1Fix the strap to the strap ring of lens
cap, as the right drawing.
2Put one piece of the strap into the
groove on rivet, as the right drawing.
3Push the rivet into the strap hole.
Lens cap Strap ring Strap
Pull
Rivet
Push in
(Bottom side)
