Lifely Coco Series Operation instructions

Assemble Instructions
Coco Series
Product Code
CCO-DEBED137-WHT
King Bed Frame
Dimensions(W x D x H)
1995*460*950mm
Important
Please read through instructions carefully
Before assembly and keep for future reference.
For our full catalogue of assembly instructions,
Visit:lifely.com.au/assembly.

Important Tips and Maintenance
1.
Keep children and animals
away from working area as
smaller parts may cause chok-
ing if swallowed
5.
Use a soft or damp cloth(dry
cloth)when wiping or cleaning
surface.
2.
Newer place liquids or anything
damp upon furniture as it
will mark,Ensure a coaster or
running is beneath.
3.
New use ammonia based
cleaning products as it will
damage the finish.
4.
To avoid fading,keep furniture
out of direct sunlight.
6.
Two person are required
7.
Lay a soft matt down to protect
the furniture pieces before and
during assembly.
CCO - DBED137 - WHT / 2

So your relationship is strong.But is it flat-pack furniture
strong?Unless you're an aerospace engineer,assembling
furniture can be slightly stressful.We recommend meditating
quietly,pouring yourself a herbal tea (or slightly less herbal
wine) and tackling things one step at a time. If you feel a
passive aggressive remark coming on,try a compliment
instead .E.g."You're so good looking".
This 49-Step assembly should take around 75 minutes
with an Allen Key-or 55 minutes with an electric drill.
Godspeed.
Designed for everyday
CCO - DBED137 - WHT / 3

Components Hardware
Please check you have all the fittings
part or tools are listed in below.
No.A No.A No.B No.C
No.D No.E No.F No.G No.H
Quantity:66Pcs
Cam Bolt
Quantity:66Pcs
Cam Nut
Quantity:12Pcs
Double Head Bolt
Quantity:4Pcs
Connect Metal Sheet
Quantity:4Pcs
Plastic Hammer Head Screw
CCO - DBED137 - WHT / 4
Quantity:88Pcs
Dowel
No.C
Quantity:24Pcs
Cam Nut
Quantity:48Pcs
Screw M3.5*35mm
Quantity:74Pcs
Screw M3.5*14mm
Quantity:12Pcs
Screw M3.5*25mm
No.I
Quantity:4Pcs
Angle Iron
No.J
Quantity:2Pcs
Dowel
No.K
Quantity:3Pcs
Handle
No.L No.M
Quantity:3Pcs
Drawer Runner Quantity:1Pcs
Screwdriver

Components Panels & Part List
Please check you have all the panels
are listed below.
CCO - DBED137 - WHT / 5
1.
2.
3.
4.
5.
Backleg footboard
Side leg footboard right
Frontleg footboard
Side leg footboard left
6.
7.
8.
9.
10.
11.
Large pillar leg left
Large pillar leg right
Headboard upper
Headboardlower
Back panel footboard
Middle panel footboard
Middleleg footboard
x1
x1
x2
x1
x1
x1
x1
x1
x1
x2
x1
CTN 1/3
CTN 2/3
CTN 2/3
CTN 1/3
CTN 2/3
CTN 2/3
CTN 2/3
CTN 1/3
CTN 1/3
CTN 3/3
CTN 1/3
20.Bottom panel footboard
21.Centre rall bed
22.Left support bed
12.Inner right side footboard
13.Inner left side footboard
14.Outer left side footboard
15.Outer right side footboard
23.Side support brace
24.Right side rail panel
25.Left side rail panel
26.Large drawer back
27.Drawer side left
28.Drawer side right
29.Large drawerfront
30.Large drawer base
16.Small pillar leg left
17.Small pillar leg right
31.Drawer base support rail
32.Small drawer back
33.Small drawer front left
34.Small drawer front right
18.Footboard top crossbar
19.Headboard top panel
35.Small drawer base
36.Bed slat
37.Footboard top panel
38.Bed slat with screw hole
x1 CTN 1/3
x1 CTN 3/3
x2 CTN 2/3
x1 CTN 1/3
x1 CTN 1/3
x1 CTN 2/3
x1 CTN 2/3
x2 CTN 1/3
x1 CTN 3/3
x1 CTN 3/3
x1 CTN 2/3
x3 CTN 1/3
x3 CTN 1/3
x1 CTN 2/3
x1 CTN 1/3
x1 CTN 2/3
x1 CTN 2/3
x1 CTN 2/3
x2 CTN 2/3
x1 CTN 2/3
x1 CTN 2/3
x1 CTN 2/3
x1 CTN 1/3
x2 CTN 1/3
x9 CTN 3/3
x1 CTN 1/3
x3 CTN 3/3

STEP1
STEP2
CCO - DBED137 - WOK / 6
No.B
No.A
Quantity:4Pcs
Dowel
Quantity:11Pcs
Cam Nut
No.A
Quantity:6Pcs
Cam Bolt
No.B
No.A
Quantity:10Pcs
Dowel
Quantity:10Pcs
Cam Nut
No.A
Quantity:2Pcs
Cam Bolt

STEP3
STEP4
CCO - DBED137 - WHT / 6
No.B
No.C
Quantity:2Pcs
Dowel
Quantity:10Pcs
Cam Nut

STEP5
STEP6
CCO - DBED137 - WHT / 8
No.B
No.A
Quantity:8Pcs
Dowel
Quantity:5Pcs
Cam Nut
No.C
Quantity:4Pcs
Cam Nut
No.B
Quantity:4Pcs
Dowel
No.C
Quantity:4Pcs
Cam Nut

STEP 7
STEP 8
CCO - DBED137 - WHT / 9
No.C
Quantity:8Pcs
Double Head Bolt
No.E No.F
Quantity:4Pcs
Connect Metal Sheet Quantity:16Pcs
Screw M3.5*14mm

STEP 9
STEP 10
CCO - DBED137 - WHT / 10
No.B
No.A
Quantity:4Pcs
Dowel
Quantity:4Pcs
Cam Nut
No.B
Quantity:10Pcs
Dowel
No.F
Quantity:8Pcs
Screw M3.5*14mm
No.L
Quantity:4Pcs
Drawer Runner
No.A
Quantity:2Pcs
Cam Nut

STEP 11
STEP 12
CCO - DBED137 - WHT / 11
No.B
Quantity:6Pcs
Dowel
No.F
Quantity:2Pcs
Screw M3.5*14mm
No.L
Quantity:1Pcs
Drawer Runner
No.A
Quantity:1Pcs
Cam Nut
No.B
Quantity:6Pcs
Dowel
No.F
Quantity:2Pcs
Screw M3.5*14mm
No.L
Quantity:1Pcs
Drawer Runner
No.A
Quantity:1Pcs
Cam Nut

STEP 13
STEP 14
CCO - DBED137 - WHT / 12
No.B
No.A
Quantity:12Pcs
Dowel
Quantity:4Pcs
Cam Nut
No.A
Quantity:4Pcs
Cam Bolt
No.C
Quantity:4Pcs
Cam Nut
No.A
Quantity:2Pcs
Cam Nut
No.A
Quantity:6Pcs
Cam Bolt

STEP 15
STEP 16
CCO - DBED137 - WHT / 13
No.B
No.A
Quantity:8Pcs
Dowel
Quantity:5Pcs
Cam Nut
No.A
Quantity:16Pcs
Cam Bolt
No.D
Quantity:8Pcs
Screw M3.5*35mm

STEP 17
STEP 18
CCO - DBED137 - WHT / 14

STEP 19
CCO - DBED137 - WHT / 15
No.D
Quantity:18Pcs
Screw M3.5*35mm
STEP 20

STEP 21
STEP 22
CCO - DBED137 - WHT / 16
No.A
Quantity:13Pcs
Cam Bolt

STEP 23
STEP 24
CCO - DBED137 - WHT / 17
No.A
Quantity:1Pcs
Cam Bolt
No.B
Quantity:4Pcs
Dowel
No.J
Quantity:2Pcs
Dowel
No.B
No.A
Quantity:4Pcs
Dowel
Quantity:4Pcs
Cam Nut

STEP 25
STEP 26
CCO - DBED137 - WHT / 18
No.B
Quantity:8Pcs
Dowel
No.A
Quantity:2Pcs
Cam Bolt
No.C
Quantity:4Pcs
Cam Nut
No.G
Quantity:4Pcs
Plastic hammer head
No.H
Quantity:12Pcs
Screw M3.5*25mm

STEP 27
STEP 28
CCO - DBED137 - WHT / 19
No.A
Quantity:1Pcs
Cam Bolt

STEP 29
STEP 30
CCO - DBED137 - WHT / 20
No.C
Quantity:4Pcs
Double Head Bolt
No.D
Quantity:2Pcs
Screw M3.5*35mm
