Lighthouse A136-15-OB User manual

Document: LH-A136-15-OB-OPM-DR-1.00 Page 1 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
1.5625 mm Pixel Pitch with SMD LEDs
A136-15-OB
All-in-one LED Display
A modular system for indoor applications
Operation Manual
2021.08
Document version 1.00

Document: LH-A136-15-OB-OPM-DR-1.00 Page 2 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
WARNING
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT OPEN THE PANEL ACCESSIBLE DOORS WHEN
POWER IS ON.
Always ensure that the unit is properly earthed and power connections correctly made
This equipment must be supplied from a power system providing a PROTECTIVE EARTH connection and
having a neutral connection, which can be reliably identified
The power outlet supplying power to the unit should be close to the unit and easily accessible
Always remember to close and lock the panel access doors after servicing and before resuming the power
supply
Ensure whole system power off before connect or disconnect the net cable
Always remember to dry the panel fully before packing
Store in a dry and airy place
Suggest using below method to cleaning the Intelligent Modules (IM): Using electrostatic-proof soft-brush to
clean the IM per month to keep the LEDs clean. Clean with solvents is not allowed.
The picture in the manual just for reference, the actual subject to shipment product.
Electrostatic discharge may harm the surface of the LED units. To prevent such damage, you should
discharge static electricity from your body before you contact with the LED units.
The product must be installed in an environment out of human reach. If a person touches the product, its
performance may deteriorate. If the product needs to be installed in a place where human contact with the
product is likely, a separate measure to prevent people from touching it needs to be taken.
[Caution to prevent damage to the LED from static] Do not touch the product without anti-static gloves.
RISK OF ELECTRIC SHOCK
DO NOT OPEN DOORS WHILE THE
EQUIPMENT IS REMAINING ON
NO USER SERVICEABLE PARTS
REFER SERVICING TO QULIFIED
PERSONNEL ONLY

Document: LH-A136-15-OB-OPM-DR-1.00 Page 3 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
TABLE OF CONTENTS
Section
Item
Page
1
General………………….…………………………………………………………………………………
4
1.1
Brief Description of Purpose and Operation of System …………………………………………………
4
1.2
A136-15-OB LED Panel Specification ………………………………………………………………..
5
1.3
A136-15-OB LED Panel System Specification …………………………………………………………
6
2
Main Assemblies………………….…………………………………………….………………………..
7
2.1
A136-15-OB Panel Assembly …………………………………………………………………………
7
2.1.1
Component Placement …………………………………………………………….………………………
7
2.2
Intelligent Modules (IM)…………………………………………………………………………………….
8
3
Installation Guides…………………………………………………………….………………………
9
3.1
Installation…………………………………………………………………………………………………
9
3.1.1
3.1.2
Mounting Plate Installation ………...…………………………………………….…………………………..
Screen Installation……………………………………………………………………………………………
9
13
3.2
Electrical…………………………………………………………………….………………………..……….
23
3.2.1
Circuit Protection…………………………………………………………….……………………..…….....
23
3.2.2
Earth Leakage Considerations………………………………………………………………………………
23
3.2.3
Inrush-current and Over-current Considerations………………………….……………………………...
23
3.2.4
Earthing……………………………………………………………………….………………..….…………
23
3.2.5
EMC Statement………………………………………………………….…...………………………………
23
3.2.6
FCC Statement………………………………………………………….…..………………………………
23
3.3
Power Cable Wiring………………………………………………….……………………..…….…………
24
3.3.1
AC Power……………………………………………………………………………………………………
24
3.3.2
3.3.3
Number of Power Cords……………………………………………………………………………………
DC Power……………………………………………………………….…………………………………...
24
24
4
4.1
4.1.1
4.1.2
4.1.3
4.2
4.2.1
4.2.2
4.2.3
4.2.4
4.2.5
4.2.6
Setting………………………………………………………………………………………………………
The Introduction of A136-15-OB Screen Interface and Function……………………………………
Remote Controller…………………………………………………………………………………………...
Interface Specifications………………………………………………………………………………………
Connection…………………………………………………………………………………………………
Parameter Settings…………………………………………………………………………………………
Set Up the Connection………………………………………………………………………………………
Basic Setup…………………………………………………………………………………………………
Parameter Settings…………………………………………………………………………………………
Video Source Settings………………………………………………………………………………………
Others………………………………………………………………………………………………………
Detect the Receiver Card……………………………………………………………………………………
25
25
25
25
26
27
27
28
28
28
30
30
Appendix A
Appendix B
Procedure for IM Replacement …………………...……….…………………………………
Trouble Shooting Guide…………………………………………………………………………
31
31
Appendix C
Appendix D
Appendix E
A136-15-OB Mechanical Assembly …………………...……….……………………………..
A136-15-OB Data Wiring Diagram………………………………………………………….
A136-15-OB Power Wiring Diagram………………………………………………………..
34
36
37

Document: LH-A136-15-OB-OPM-DR-1.00 Page 4 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
1. General
This manual provides an overview of the A136-15-OB LED display system, the main system components and
interconnection methods. If any details in this document are unclear, please contact your local representative, or the
head office for more details.
1.1 Brief Description of Purpose and Operation of System
The A136-15-OB LED display system is designed for indoor use, where a high quality dynamic image is to be made
visible to large numbers of people. The panel size is designed from the beginning according to end-user requirements.

Document: LH-A136-15-OB-OPM-DR-1.00 Page 5 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
1.2 A136-15-OB(12X6IM) LED Panel Specification
1.5625mm Indoor SMD LED AIO Screen
Parameter
Unit
Value
Brightness(typ*)
nits
800
Color temperature
deg. K
6,500
Visual viewing angle - Horizontal
deg.
160(+80/-80)
Visual viewing angle - Vertical
deg.
160(+80/-80)
Panel weight(max)
kg / lb
131/288.9
weight(max)(sq.m)
kg / lb
25.7/56.7
Display diagonal/ Panel diagonal
mm / ft
3448.3/11.31
3,442/11.29
Display width / Panel width
mm / ft
3004.6/9.86
3,000/9.84
Display height / Panel height
mm / ft
1692.1/5.55
1,687.5/5.54
Panel depth(min)
mm / ft
35.5/0.116
Display area / Panel area
sq.m / sq.ft
5.1
54.5
Panel material
Aluminum
Panel Color
/
Pantone Matte Black
Aspect ratio
16:9
Ingress protection(Front/rear)
IP
IP40/IP20
Operating / storage temperature
deg. C
0 to +40 / -10 to 50
Operating / storage humidity
%
< 90 (Without condensation)
Pixel type and configuration
R/G/B
SMD 3 in 1
Pixel pitch
mm
1.5625
Pixel LED per Panel
1,920x1,080
Pixel per Panel
2,073,600
Pixel Lines per meter
640
Pixel per sq. meter
409,600
Recommended minimum viewing distance
m
1.5
Colors
281 Trillion
Grey scale (linear)
Levels
65,536 levels per color
Brightness control
Levels
100
Contrast ratio
3,000:1
Processing depth
bit
16
Video frame rate
Hertz
50/60
Display refresh rate
Hertz
≥2880
Input voltage (nominal)
VAC
100 to 240
Input power frequency
Hertz
50 to 60
Input power (max)
VA
3,000
Lifetime (50% brightness)
Hours
≥100,000
Panel input format
USB/HDMI
Data interconnection
USB/HDMI
Mounting system
Wall Mount, Stand with support
Panel Maintenance
Front Access
Certificate
CE, FCC, ETL, CB, RoHS2.0, REACH
（DR）
* Specification subjected to change without prior notice
* The tolerance of brightness is ±3%

Document: LH-A136-15-OB-OPM-DR-1.00 Page 6 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
1.3 A136-15-OB LED Panel System Specification
Control interface
USB-B
Display configuration interface
Indicator light and Button
Indicator light
Standby light(red)
Power light(green)
Button
（customizable）
Brightness Keys（up, down button）
Standby/Power On Button
Other Ports
USB3.0
1xUSB3.0, supports Ultra-highspeed USB device
USB2.0
2xUSB2.0, supports external USB flash disk and other external
expansion equipment
Media Format
Video Formats
Common formats such as AVI, WMV, MPG, RM/RMVB, MOV, DAT,
VOB, MP4, FLV and etc. Supports multiple videos play at the same
time.
Video Formats
MPEG-1 Layer III，AAC , etc.
Image Formats
bmp、jpg、png、etc.

Document: LH-A136-15-OB-OPM-DR-1.00 Page 7 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
2. Main Assemblies
2.1 A136-15-OB Panel Assembly
Each A136-15-OB LED panel comprises an outer cladding panel with integral aluminum framework for increased
rigidity and a central stacker for the fast rigging. The panel is designed to be mounted to a fixed framework.
The listing in Table 2.1 is the main components of a A136-15-OB LED panel. The profile of the panel is shown in
Figure 2.2.
Item
Description
Qty
1
Intelligent Modules (IM)
72
2
I/O Board
1
3
AIO controller Board
1
4
Power Board
1
5
IR Receiver Board
1
6
Power and Mini Card Convertor Board(2 in 1)
36
7
12V/200W Switched Mode Power Supply
1
8
3.8V/189W Switched Mode Power Supply
18
9
EMI / RFI AC power line filter
2
2.1.1 Component Placement
There are five kinds of system board worked for the LED display, IR Receiver Board, Power and Mini Card Convertor
Board, I/O Board, AIO controller Board and Power Board. Please refer to the description for each board in the
follow sections.
A136-15-OB LED display is combined with intelligent module and case. The intelligent modules and case are fixed by
magnetic structure.
Note: The PSU output is adjustable, the actual value would subject to the label of manufacturing data
Table 2.1 - Major components of A136-15-OB LED panel assembly
Figure 2.1 Major components placement for A136-15-OB
Power and Mini Card Convertor Board (2in1)
PSU 189W/3.8V(18pcs)
PSU 200W/12V
Power Board
I/O Board
EMI filter
AIO controller Board

Document: LH-A136-15-OB-OPM-DR-1.00 Page 8 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
2.2 Intelligent Modules (IM)
The front face of the A136-15-OB LED display is fitted with 72 light emitting diode (LED) dot LED modules known as
Intelligent Modules. Each intelligent module is fitted with 28880 LEDs* plus associated drive electronics. Electrical
connections (low voltage power, and digital data) are made to the rear of each intelligent module, from inside of the
enclosure.
Figures 2 and 3 are showing the front and rear views of an A136-15-OB intelligent module.
*Remark: each intelligent module contains 160x180 pixels (row x column) and each pixel is composed by 3 in 1 LEDs, so there
are totally 28800 LEDs fitted on the front face of an intelligent module.
xzz
Intelligent Module - rear view
Intelligent Modules - front view

Document: LH-A136-15-OB-OPM-DR-1.00 Page 9 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
3. Installation Guidelines
The A136-15-OB LED display, each intelligent module is equipped with 4 pcs guide pin, are fixed with magnetic
structure and jointed together both vertically and horizontally, so that they can form one surface of screen-
configuration.
The A136-15-OB LED display is designed to be mounted on the stand (sold separately) or on the wall. When
installing, it is important to ensure that the entire screen is correctly aligned, both vertically and horizontally.
3.1 Installation
3.1.1 Mounting Plate Installation
1. Wall mount piece list:
Item
Qty
Description
Item
Qty
Description
1
PANEL CENTER LINE
HORIZONTAL
2
Left plate
2
PANEL CENTER LINE
HORIZONTAL
2
Right plate
3
2
Left
connection
plate
4
PANEL CENTER LING
VERTICAL
2
Middle
connection
plate
5
1
Right
connection
plate
6
1
Bottom
connection
plate
7
44
Flat head
screw M3X12
Please read the following carefully before installing the panels

Document: LH-A136-15-OB-OPM-DR-1.00 Page 10 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
Step1. Install the left plate with connection plate .
PANEL CEN TER LINE
HORIZONTAL
PANEL CEN TER LINE
HORIZONTAL
Step2. Install the right plate with connection plate.
PANEL CEN TER LINE
HORIZONTAL
PANEL CEN TER LINE
HORIZONTAL
Use 16pcs M3X12 screw (item 7) to install
the left plate（item1）with left connection
plate(item3).
Use 12pcs M3X12 screw (item 7) to install the
right plate（item2）with right connection plate
and bottom connection plate(item5/item6).

Document: LH-A136-15-OB-OPM-DR-1.00 Page 11 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
Step3. Connect the left assembly and right assembly by intermediate plate.
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CEN TER LING
VERTICAL
PANEL CEN TER LING
VERTICAL
Step4. Double check the dimension after assembling.
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CE NTER LING
VERTICAL
PANEL CE NTER LING
VERTICAL
It is suggested to fix the assemble frame of shelves completely according to the fixed points shown in the
circle.
Use 16pcs M3X12 screw (item 7), to install
the left assembly and right assembly
together.

Document: LH-A136-15-OB-OPM-DR-1.00 Page 12 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
Step5. Remove the bottom connection plate after installation.
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LINE
HORIZONTAL
PANEL CENTER LING
VERTICAL
PANEL CENTER LING
VERTICAL

Document: LH-A136-15-OB-OPM-DR-1.00 Page 13 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
2. Screen assembly
a. First, the 8 PCS fixed screw behind the box are assembled to the box and locked with tools.
b. The following figure is marked in red.
3.1.2 Screen Installation
Brief installation diagram
Rear view
Large-headed Screw

Document: LH-A136-15-OB-OPM-DR-1.00 Page 14 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
Installation Guides
1. The two members jointly lifted the right half cabinet and placed it on the Stand's bracket.
2. Place the left half cabinet on the bracket in order.

Document: LH-A136-15-OB-OPM-DR-1.00 Page 15 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
3. You need to connect all the cables and install back all the intelligent modules.
NETWORK CABLE(4PCS)
Please pay attention to the labels,eg.RJ45 cable
labelled OUT1 is matched to the connector
labelled OUT1.
AC CABLE(1PC)

Document: LH-A136-15-OB-OPM-DR-1.00 Page 16 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
4. The cabinet is combined by sliding on the wall mount, we must make sure that the steel block is properly
connected to the positioning.
5. After the cabinet is joined, follow the instructions of Label to quickly fix the cabinet with the hexagonal plate.

Document: LH-A136-15-OB-OPM-DR-1.00 Page 17 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
6. Install and tighten 8 pcs black M4 flat head screws to both top and bottom side of the case.
7. Install M4 screws.
4 PCS M4 screws
4 PCS M4 screws
before install screws
install back screws
Install 11 pcs fasten screws
Install 20 pcs M4 flat head screws

Document: LH-A136-15-OB-OPM-DR-1.00 Page 18 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
8. All the intelligent modules (LED Panel) have labels stuck on the back side. Please follow below number to install
back the intelligent modules.
Install the Sensor Box
1. Take out a sensor box. Run the cable through the hole on the back side.
2. Connect the cable to the convertor board. Align the sensor box to the panel and tighten it with two screws.
Front view

Document: LH-A136-15-OB-OPM-DR-1.00 Page 19 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
Dismount Intelligent Module
Step1. Power off the LED display.
Step2. Hold the 2pcs handles, push the lock inward and pull the handles toward outside, and then take it up.
Step3. Take the tool up and horizontaly fit it closely to the display surface. Please pay more attention to the direction.
Step4. Pull the handles towards the centre.
Step5. Ensure the magnet is locked. Detach the tile carefully.
lock
handles

Document: LH-A136-15-OB-OPM-DR-1.00 Page 20 of 37 ©Lighthouse Technologies Ltd.
HK: T [phone] F+852 2423 1092 [e-mail] www.lighthouse-tech.com
Step6. Put down the intelligent module and tool together carefully onto an EPE (or other soft pad).
Step7. Push the lock toward inside and pull the right handle toward outside and lift the tool up carefully.
Mount Intelligent Module
Step1. Take out a spare intelligent module and locate the intelligent module to case,please pay attention to the arrow
direction on the back side of it.
Step2.Flatten the intelligent module.
Note: When mounting an intelligent module back, pay more attention to the guide pin which
is located in corners to mount it smoothly.
9. We recommend that all the intelligent modules are installed to the corresponding position on case, or the screen
will show color difference. Also, there is a panel serial number at the left bottom of case which match to the one
on the back side of intelligent modules and spare intelligent modules.
