PLASMA MONITOR
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
CHASSIS : RF-03GA
MODEL : MU-42PZ90V MU-42PZ90XV
MODEL : MU-42PZ90XC
CANADA : http//biz.lgservice.com
USA : http//www.lgservice.com
: http//lgservice.com/techsup.html

- 2 -
SAFETY PRECAUTIONS
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in
the Schematic Diagram and Replacement Parts List.
It is essential that these special safety parts should be replaced with the same components as recommended in this manual to
prevent X-RADIATION, Shock, Fire, or other Hazards.
Do not modify the original design without permission of manufacturer.
General Guidance
An lsolation Transformer should always be used during
the servicing of a receiver whose chassis is not isolated from
the AC power line. Use a transformer of adequate power rating
as this protects the technician from accidents resulting in
personal injury from electrical shocks.
It will also protect the receiver and it's components from being
damaged by accidental shorts of the circuitary that may be
inadvertently introduced during the service operation.
If any fuse (or Fusible Resistor) in this monitor is blown, replace
it with the specified.
When replacing a high wattage resistor (Oxide Metal Film
Resistor, over 1W), keep the resistor 10mm away from PCB.
Keep wires away from high voltage or high temperature parts.
Due to high vacuum and large surface area of picture tube,
extreme care should be used in handling the Picture Tube.
Do not lift the Picture tube by it's Neck.
Leakage Current Cold Check(Antenna Cold Check)
With the instrument AC plug removed from AC source,
connect an electrical jumper across the two AC plug prongs.
Place the AC switch in the on positioin, connect one lead of
ohm-meter to the AC plug prongs tied together and touch other
ohm-meter lead in turn to each exposed metallic parts such as
antenna terminals, phone jacks, etc.
If the exposed metallic part has a return path to the chassis, the
measured resistance should be between 1MΩ and 5.2MΩ.
When the exposed metal has no return path to the chassis the
reading must be infinite.
An other abnormality exists that must be corrected before the
receiver is returned to the customer.
Leakage Current Hot Check (See below Figure)
Plug the AC cord directly into the AC outlet.
Do not use a line Isolation Transformer during this check.
Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor
between a known good earth ground (Water Pipe, Conduit, etc.)
and the exposed metallic parts.
Measure the AC voltage across the resistor using AC
voltmeter with 1000 ohms/volt or more sensitivity.
Reverse plug the AC cord into the AC outlet and repeat AC
voltage measurements for each esposed metallic part. Any
voltage measured must not exceed 0.75 volt RMS which is
corresponds to 0.5mA.
In case any measurement is out of the limits sepcified, there is
possibility of shock hazard and the set must be checked and
repaired before it is returned to the customer.
Leakage Current Hot Check circuit
CANADA: LG Electronics Canada, Inc. 550 Matheson
Boulevard East Mississauga, Ontario L4Z 4G3
USA : LG Customer Interactive Center
P.O.Box 240007, 201 James Record Road Huntsville,
AL 35824
Digital TV Hotline [phone]
1.5 Kohm/10W
To Instrument's
exposed
METALLIC PARTS
Good Earth Ground
such as WATER PIPE,
CONDUIT etc.
AC Volt-meter
IMPORTANT SAFETY NOTICE
0.15uF

- 3 -
DESCRIPTION OF CONTROLS...........................................4
SPECIFICATIONS.................................................................6
EXTERNAL CONTROL DEVICE SETUP..............................8
IR CODE(NEC FORMAT) ...................................................14
ADJUSTMENT INSTRUCTION...........................................16
BLOCK DIAGRAM...............................................................19
EXPLODED VIEW...............................................................22
EXPLODED VIEW PARTS LIST.........................................23
REPLACEMENT PARTS LIST............................................24
SCHEMATIC DIAGRAM..........................................................
PRINTED CIRCUIT BOARD ...................................................
TABLE OF CONTENTS

- 4 -
DESCRIPTION OF CONTROLS
Controls
Controls
Connection Options
Connection Options
R
( )( )
( )
( )
L
EXPANDED
INPUT
VIDEO
INPUT
RS-232C INPUT
(CONTROL/SERVICE)
EXTERNAL SPEAKER
Y P B P R
(MONO)
R
AUDIO
L
R
AUDIO
L
S-VIDEO AC INPUT AUDIO INPUT AUDIO INPUT AUDIO INPUT
REMOTE
CONTROL
COMPONENT INPUT DVI INPUT RGB INPUT RGB OUTPUT
1
1. EXTERNAL SPEAKER (8 ohm output)
Connect to optional external speaker(s).
* For further information, refer to ‘Speaker & Speaker
Stand’ manual.
2. RS-232C INPUT (CONTROL/SERVICE) PORT
Connect to the RS-232C port on a PC.
3. DVI (Digital Visual Interface) INPUT/
RGB INPUT/AUDIO INPUT JACKS
Connect the monitor output connector of a PC to the appro-
priate input port.
4. RGB OUTPUT JACKS
You can watch the RGB signal on another monitor, connect
RGB OUTPUT to another monitor’s PC input port.
5. EXPANDED INPUT
Connect the Monitor with the PDP Tuner by using the tuner
box cable.
6. COMPONENT INPUT/AUDIO INPUT JACKS
7. REMOTE CONTROL
Connect your wired remote control to the remote control
port on the Monitor.
8. S-VIDEO INPUTS
Connect video out from an S-VIDEO VCR to the S-VIDEO
input.
AUDIO/VIDEO INPUT JACKS
Connect audio/video out from external equipment to these
jacks.
9. POWER CORD SOCKET
This Monitor operates on an AC power. The voltage is indi-
cated on the Specifications page. Never attempt to operate
the Monitor on DC power.
Back Connection Panel
Back Connection Panel
VOL.MENU
INPUT
SELECT
ON/OFF
Main Power Button INPUT SELECT Button VOLUME (FF,GG) Buttons
Power Standby Indicator
Illuminates red in standby mode,
Illuminates green when the
Monitor is turned on
Remote Control Sensor MENU Button
EE, DDButtons
Front Panel Controls
Front Panel Controls
2 4 5 73 8 9 6

- 5 -
DESCRIPTION OF CONTROLS
Remote Control Key Functions
Remote Control Key Functions
-When using the remote control, aim it at the remote control sensor on the monitor.
- Under certain conditions such as when the beam is interrupted, the remote control may not function. Press the key again if nec-
essary.
1 2 3
4 5 6
7 8
0
9
POWER
MULTIMEDIA INPUT SELECT
APC DASP
ARC SLEEP
PIP
DW
SWAP
MENU MUTE
ENTER
VOL
POWER
STOP
FF
REC
PLAY
REW
P/STILL
WIN.SIZE WIN.POSITION
FAV CH
CAPTION
A.PROG PIP CH
PIP CH
ZOOM +
MTS
ZOOM -
SPLIT ZOOM
MEMORY/ERASE
VOL
CH
CH
PIP INPUT
POWER
Switches the monitor between
ON and STANDBY.
MULTIMEDIA
Selects: Component,RGB or DVI mode.
APC
Adjusts the factory preset picture
according to the room.
ARC
Changes the picture format.
PIP
Switches the sub picture on and off.
SWAP
Exchange main and sub picture
image.
MENU
Displays on screen menus.
Exits the current menu.
Memorizes menu changes. ENTER
CH DD/ EE(Channel button)
Select menu options.
VOL FF/ GG(Volume button)
Increases/decreases sound level.
Adjusts menu settings.
INPUT SELECT
Selects: Video, S-Video,Component,
RGB or DVI mode.
DASP
Selects the sound appropriate to
your viewing program character:
Flat,Music,Movie,Sports, or User.
SLEEP
Sets the sleep timer.
PIP INPUT
Selects the input mode for the sub
picture.
MUTE
Switches the sound on or off.
ZOOM-/ZOOM+
Enlarges or reduces the main picture
size.
DW (Double Window)
Select the Double Window.
WIN. SIZE
Adjusts the sub picture size.
WIN.POSITION
Moves the sub picture.
NUMBER buttons
Not functional
VCR BUTTONS
Control LG video cassette recorders.
SPLIT ZOOM
Enlarge the screen with regular
ration.

- 6 -
•The specifications shown above may be changed without notice for quality improvement.
MODELS
Width (inches / mm)
Height (inches / mm)
Depth (inches / mm)
Weight (pounds / kg)
Power requirement
Resolution
Color
Operating Temperature Range
Operating Humidity Range
Maximum Elevation
MU-42PZ44V
MU-42PZ90V
40.7 / 1033
24.5 / 622
3.2 / 81
75 / 34
AC100-240V ~ 50/60Hz
852 x 480 (Dot)
16,770,000 (256 steps of each R, G and B)
32 ~ 104°F (0 ~ 40°C)
Less than 80%
6561 feet (2000m)
SPECIFICATIONS

- 7 -
SPECIFICATIONS
Monitor Display Specifications
Monitor Display Specifications
RGB/DVI Mode
Resolution
640x350
720x400
640x480
848x480
852x480
Horizontal
Frequency(KHz)
31.468
37.861
31.469
37.927
31.469
35.000
37.861
37.500
43.269
45.913
31.5
35
37.5
31.5
35
37.5
70.09
85.08
70.08
85.03
59.94
66.66
72.80
75.00
85.00
90.03
60.00
70.00
75.00
60.00
70.00
75.00
35.156
37.879
48.077
46.875
53.674
56.000
49.725
48.363
54.476
60.023
54.348
63.995
67.500
68.681
60.000
63.981
56.25
60.31
72.18
75.00
85.06
90.00
74.55
60.00
70.06
75.02
60.05
70.01
75.00
75.06
60.00
60.02
Vertical
Frequency(Hz) Resolution
800x600
832x624
1024x768
1152x864
1152x870
1280x1024
Horizontal
Frequency(KHz) Vertical Frequency(Hz)
1280x960
GROUNDING
Ensure that you connect the grounding / earth wire to prevent possible
electric shock. If grounding methods are not possible, have a qualified
electrician install a separate circuit breaker. Do not try to ground the
unit by connecting it to telephone wires, lightening rods, or gas pipes.
For proper ventilation, allow a clearance of 4” on each
side and 2” from the wall. Detailed installation instruc-
tions are included from your dealer in the optional Wall
Mounting Bracket Installation and Setup Guide.

- 8 -
EXTERNAL CONTROL DEVICE SETUP
No. Pin name
1 No connection
2 RXD (Receive data)
3 TXD (Transmit data)
4 DTR (DTE side ready)
5 GND
6 DSR (DCE side ready)
7 RTS (Ready to send)
8 CTS (Clear to send)
9 No Connection
1
5
6
9
2
3
5
4
6
7
8
RXD
TXD
GND
DTR
DSR
RTS
CTS
TXD
RXD
GND
DSR
DTR
CTS
RTS
PC
7-Wire Configurations
(Standard RS-232C cable)
D-Sub 9
3
2
5
6
4
8
7
PDP
D-Sub 9
2
3
5
4
6
7
8
RXD
TXD
GND
DTR
DSR
RTS
CTS
TXD
RXD
GND
DTR
DSR
RTS
CTS
PC
3-Wire Configurations
(Not standard)
D-Sub 9
3
2
5
4
6
7
8
PDP
D-Sub 9
- Connect the RS-232C input jack to an external control device (such as a computer or an A/V control system)
and control the Monitor’s functions externally.
- Connect the serial port of the control device to the RS-232C jack on the Monitor back panel.
- RS-232C connection cables are not supplied with the Monitor.
T
Type of Connector; D-Sub 9-Pin Male ype of Connector; D-Sub 9-Pin Male
RS-232C Configurations
RS-232C Configurations
RS-232C Setup
RS-232C Setup
R
( )( )
( )
( )
L
EXPANDED
INPUT
VIDEO
INPUT
RS-232C INPUT
(CONTROL/SERVICE)
EXTERNAL SPEAKER
Y P B P R
(MONO)
R
AUDIO
L
R
AUDIO
L
S-VIDEO AC INPUT AUDIO INPUT AUDIO INPUT AUDIO INPUT
REMOTE
CONTROL
COMPONENT INPUT DVI INPUT RGB INPUT RGB OUTPUT
PC

- 9 -
EXTERNAL CONTROL DEVICE SETUP
Set ID
Set ID
Use this function to specify a monitor ID number.
Refer to ‘Real Data Mapping 1’. See page 28.
• Baud rate : 115200 bps (UART)
• Data length : 8 bits
• Parity : None
* Use a crossed (reverse) cable.
• Stop bit : 1 bit
• Communication code : ASCII code
Communication Parameters
Communication Parameters
1. Press the MENU button and then use DD/EEbutton to select the SPECIAL menu.
2. Press the GGbutton and then use DD/EEbutton to select Set ID.
3. Press the GGbutton and then use F / Gbutton to adjust Set ID to choose the desired
monitor ID number. The adjustment range of Set ID is 1 ~ 99.
4. Press the ENTER button to save.
SPECIAL
Prev.
Language
Key lock
ISM Method
Low power
Set ID GG
Caption / Text
Captions
OSD Rotate
SPECIAL
MENU
1
Transmission
* [Command 1]: First command to control PDP set. (j or k)
* [Command 2]: Second command to control PDP set.
* [Set ID]: You can adjust the set ID to choose desired monitor
ID number in special menu. Adjustment range is 1
~ 99. When selecting Set ID ‘0’, every connected
PDP set is controlled. Set ID is indicated as deci-
mal (1~99) on menu and as Hexa decimal
(0x0~0x63) on transmission/receiving protocol.
* [DATA]: To transmit command data.
Transmit ‘FF’ data to read status of command.
* [Cr]: Carriage Return
ASCII code ‘0x0D’
* [ ]: ASCII code ‘space (0x20)’
[Command1][Command2][ ][Set ID][ ][Data][Cr]
T
Transmission / Receiving Protocol ransmission / Receiving Protocol
OK Acknowledgement
* The Monitor transmits ACK (acknowledgement) based on
this format when receiving normal data. At this time, if the
data is data read mode, it indicates present status data. If
the data is data write mode, it returns the data of the PC
computer.
[Command2][ ][Set ID][ ][OK][Data][x]
Error Acknowledgement
* The Monitor transmits ACK (acknowledgement) based on
this format when receiving abnormal data from non-viable
functions or communication errors.
[Command2][ ][Set ID][ ][NG][Data][x]
Data 1: Illegal Code
2: Not supported function
3: Wait more time
01. Power k a 0 ~ 1
02. Input Select k b 0 ~ 4
03. Aspect Ratio k c 0 ~ 3
04. Screen Mute k d 0 ~ 1
05. Volume Mute k e 0 ~ 1
06. Volume Control k f 0 ~ 64
07. Contrast k g 0 ~ 64
08. Brightness k h 0 ~ 64
09. Color k i 0 ~ 64
10. Tint k j 0 ~ 64
11. Sharpness k k 0 ~ 64
12. OSD select k l 0 ~ 1
13. Remote control lock mode k m 0 ~ 1
14. PIP/DW k n 0 ~ 3
15. PIP size k o 0 ~ 1
16. Split Zoom k p 21 ~99
17. PIP position k q 0 ~ 3
18. Treble k r 0 ~ 64
19. Bass k s 0 ~ 64
20. Balance k t 0 ~ 64
21. Color temperature k u 0 ~ 3
22. Red adjustment k v 0 ~ C8
23. Green adjustment k w 0 ~ C8
24. Blue adjustment k $ 0 ~ C8
25. PIP input source k y 0 ~ 4
26. Abnormal Status k z 0 ~ a
27. ISM Method j p 0 ~ 3
28. Low Power j q 0 ~ 1
29. Orbiter Time Setting j r 1 ~ FE
30. Orbiter Pixel Setting j s 0 ~9
31. Picture Size Setting j t 0 ~64
for Double Window mode
32. Auto Config j u 1
COMMAND 1 COMMAND 2 DATA
(Hexadecimal)
•When setting the 27 ~ 32, a menu doesn’t display on
screen.
Command Reference List
Command Reference List

- 10 -
EXTERNAL CONTROL DEVICE SETUP
02. Input Select (Command2:b) (Main Picture Input)
GTo select input source for the Monitor.
You can also select an input source using the INPUT
SELECT button on the Monitor's remote control.
Transmission
Data 0 : RGB
1 : Component
2 : Video
3 : S-Video
4 : DVI
[k][b][ ][Set ID][ ][Data][Cr]
Acknowledgement
[b][ ][Set ID][ ][OK][Data][x]
01. Power (Command2:a)
GTo control Power On/Off of the Monitor.
Transmission
Data 0 : Power Off 1 : Power On
[k][a][ ][Set ID][ ][Data][Cr]
Acknowledgement
[a][ ][Set ID][ ][OK][Data][x]
GTo show Power On/Off.
Transmission
[k][a][ ][Set ID][ ][FF][Cr]
Acknowledgement
Data 0 : Power Off 1 : Power On
* In like manner, if other functions transmit ‘FF’ data based
on this format, Acknowledgement data feed back presents
status about each function.
[a][ ][Set ID][ ][OK][Data][x]
* Real data mapping 1
0 : Step 0
A : Step 10 (SET ID 10)
F : Step 15 (SET ID 15)
10 : Step 16 (SET ID 16)
64 : Step 100
05. Volume Mute (Command2:e)
GTo control volume mute on/off.
You can also adjust mute using the MUTE button on
remote control.
Transmission
Data 0 : Volume mute on (Volume off)
1 : Volume mute off (Volume on)
[k][e][ ][Set ID][ ][Data][Cr]
Acknowledgement
[e][ ][Set ID][ ][OK][Data][x]
03. Aspect Ratio (Command2:c) (Main picture format)
GTo adjust the screen format.
You can also adjust the screen format using the ARC
(Aspect Ratio Control) button on remote control or in the
Screen menu.
Transmission
Data 0 : Wide screen (16:9)
1 : Normal screen (4:3)
2 : Full screen (Zoom)
3 : Horizon
[k][c][ ][Set ID][ ][Data][Cr]
Acknowledgement
* Using the PC input, you select either 16:9 or 4:3 screen
aspect ratio.
[c][ ][Set ID][ ][OK][Data][x]
04. Screen Mute (Command2:d)
GTo select screen mute on/off.
Transmission
Data 0 : Screen mute off (Picture on)
1 : Screen mute on (Picture off)
[k][d][ ][Set ID][ ][Data][Cr]
Acknowledgement
[d][ ][Set ID][ ][OK][Data][x]
06. Volume Control (Command2:f)
GTo adjust volume.
You can also adjust volume with the volume buttons
on remote control.
Transmission
Data Min : 0 ~ Max : 64
•Refer to ‘Real data mapping1’ as shown below.
[k][f][ ][Set ID][ ][Data][Cr]
Acknowledgement
[f][ ][Set ID][ ][OK][Data][x]
07. Contrast (Command2:g)
GTo adjust screen contrast.
You can also adjust contrast in the Picture menu.
Transmission
Data Min : 0 ~ Max : 64
•Refer to ‘Real data mapping1’ as shown below.
[k][g][ ][Set ID][ ][Data][Cr]
Acknowledgement
[g][ ][Set ID][ ][OK][Data][x]

- 11 -
EXTERNAL CONTROL DEVICE SETUP
09. Color (Command2:i)
GTo adjust the screen color.
You can also adjust color in the Picture menu.
Transmission
Data Min : 0 ~ Max : 64
•Refer to ‘Real data mapping1’. See page 28.
[k][i][ ][Set ID][ ][Data][Cr]
Acknowledgement
[i][ ][Set ID][ ][OK][Data][x]
10. Tint (Command2:j)
GTo adjust the screen tint.
You can also adjust tint in the Picture menu.
Transmission
Data Red : 0 ~ Green : 64
•Refer to ‘Real data mapping1’. See page28.
[k][j][ ][Set ID][ ][Data][Cr]
Acknowledgement
[j][ ][Set ID][ ][OK][Data][x]
08. Brightness (Command2:h)
GTo adjust screen brightness.
You can also adjust brightness in the Picture menu.
Transmission
Data Min : 0 ~ Max : 64
•Refer to ‘Real data mapping1’. See page 28.
[k][h][ ][Set ID][ ][Data][Cr]
Acknowledgement
[h][ ][Set ID][ ][OK][Data][x]
13. Remote Control Lock Mode (Command2:m)
GTo lock the remote control and the front panel controls on
the monitor.
Transmission
[k][m][ ][Set ID][ ][Data][Cr]
Acknowledgement
Data 0: Lock off 1: Lock on
•If you’re not using the remote control, use this mode.
When main power is on/off, remote control lock is released.
[m][ ][Set ID][ ][OK][Data][x]
14. PIP / DW (Command2:n)
GTo control the PIP (Picture In picture)/DW (Double Window).
You can also control the PIP/DW using the PIP or DW but-
ton on the remote control or in the PIP/DW menu.
Transmission
Data 0: PIP/DW off
1: PIP 2: DW1 3: DW2
[k][n][ ][Set ID][ ][Data][Cr]
Acknowledgement
[n][ ][Set ID][ ][OK][Data][x]
GTo adjust the screen sharpness.
You can also adjust sharpness in the Picture menu.
Transmission
11. Sharpness (Command2:k)
Data Min: 0 ~ Max: 64
•Refer to ‘Real data mapping1’. See page 28.
[k][k][ ][Set ID][ ][Data][Cr]
Acknowledgement
[k][ ][Set ID][ ][OK][Data][x]
12. OSD Select (Command2:l)
GTo select OSD (On Screen Display) on/off.
Transmission
[k][l][ ][Set ID][ ][Data][Cr]
Acknowledgement
Data 0: OSD off 1: OSD on
[l][ ][Set ID][ ][OK][Data][x]
15. PIP Size (Command2:o)
GTo select the PIP picture format.
You can also select the PIP picture format using WIN.SIZE
on the remote control.
Transmission
[k][o][ ][Set ID][ ][Data][Cr]
Acknowledgement
Data 0: 4:3 1: 16:9
[o][ ][Set ID][ ][OK][Data][x]
16. Split Zoom (Command2:p)
GTo operate split zoom function and select the split
zoom section number.
Transmission
Data Min: 21 ~ Max:99
ex. Data 21: Selection 1 of 2 split zoom.
•Refer to ‘Real data mapping 2’.
[k][p][ ][Set ID][ ][Data][Cr]
Acknowledgement
[p][ ][Set ID][ ][OK][Data][x]
* Real data mapping 2
21: Selection 1 of 2 split zoom
24: Selection 4 of 2 split zoom
41: Selection 1 of 4 split zoom
42: Selection 2 of 4 split zoom
44: Selection 4 of 4 split zoom
45: Selection 5 of 4 split zoom
91: Selection 1 of 9 split zoom
99: Selection 9 of 9 split zoom

- 12 -
EXTERNAL CONTROL DEVICE SETUP
22. Red Adjustment (Command2:v)
GTo adjust red in color temperature.
Transmission
Data Min: 0 ~ Max: C8
•Refer to ‘Real data mapping3’ as shown below.
[k][v][ ][Set ID][ ][Data][Cr]
Acknowledgement
[v][ ][Set ID][ ][OK][Data][x]
23. Green Adjustment (Command2:w)
GTo adjust green in color temperature.
Transmission
Data Min: 0 ~ Max: C8
•Refer to ‘Real data mapping3’ as shown below.
[k][w][ ][Set ID][ ][Data][Cr]
Acknowledgement
[w][ ][Set ID][ ][OK][Data][x]
24. Blue Adjustment (Command2:$)
GTo adjust blue in color temperature.
Transmission
Data Min: 0 ~ Max: C8
•Refer to ‘Real data mapping3’ as shown below.
[k][$][ ][Set ID][ ][Data][Cr]
Acknowledgement
[$][ ][Set ID][ ][OK][Data][x]
21. Color Temperature (Command2:u)
GTo adjust color temperature.
You can also adjust ACC in the Sound menu.
Transmission
Data 0: Normal 1: Cool 2: Warm 3: User
[k][u][ ][Set ID][ ][Data][Cr]
Acknowledgement
[u][ ][Set ID][ ][OK][Data][x]
20. Balance (Command2:t)
GTo adjust balance.
You can also adjust balance in the Sound menu.
Transmission
Data Min: 0 ~ Max: 64
•Refer to ‘Real data mapping1’. See page 28.
[k][t][ ][Set ID][ ][Data][Cr]
Acknowledgement
[t][ ][Set ID][ ][OK][Data][x]
18. Treble (Command2:r)
GTo adjust treble.
You can also adjust treble in the Sound menu.
Transmission
Data Min: 0 ~ Max: 64
•Refer to ‘Real data mapping1’. See page 28.
[k][r][ ][Set ID][ ][Data][Cr]
Acknowledgement
[r][ ][Set ID][ ][OK][Data][x]
19. Bass (Command2:s)
GTo adjust bass.
You can also adjust bass in the Sound menu.
Transmission
Data Min: 0 ~ Max: 64
•Refer to ‘Real data mapping1’. See page 28.
[k][s][ ][Set ID][ ][Data][Cr]
Acknowledgement
[s][ ][Set ID][ ][OK][Data][x]
17. PIP Position (Command2:q)
GTo select sub picture position for PIP.
You can also adjust the sub picture position using
WIN.POSITION on the remote control or in the PIP/DW menu.
Transmission
Data 0: Right down on screen
1: Left down on screen
2: Left up on screen
3: Right up on screen
[k][q][ ][Set ID][ ][Data][Cr]
Acknowledgement
[q][ ][Set ID][ ][OK][Data][x]
* Real data mapping 3
0 : -20
5 : -19
A : -18
5F: -1
64: 0
69: +1
C3: +19
C8: +20

- 13 -
EXTERNAL CONTROL DEVICE SETUP
27. ISM Method (Command2:p)
GTo avoid having a fixed image remain on screen.
Transmission
Data 0: Normal
1: White wash 2: Orbiter 3: Inversion
[j][p][ ][Set ID][ ][Data][Cr]
Acknowledgement
[p][ ][Set ID][ ][OK][Data][x]
28. Low Power (Command2:q)
GTo control the low power function on/off.
Transmission
Data 0: Low power off
1: Low power on
[j][q][ ][Set ID][ ][Data][Cr]
Acknowledgement
[q][ ][Set ID][ ][OK][Data][x]
29. Orbiter Time Setting (Command2:r)
GTo adjust orbiter operation time term.
Transmission
Data Min: 1 ~ Max: FE
•Refer to ‘Real data mapping1’. See page 28.
[j][r][ ][Set ID][ ][Data][Cr]
Acknowledgement
[r][ ][Set ID][ ][OK][Data][x]
30. Orbiter Pixel Setting (Command2:s)
GTo adjust pixel number in orbiter function.
Transmission
Data Min: 0 ~ Max: 9
[j][s][ ][Set ID][ ][Data][Cr]
Acknowledgement
[s][ ][Set ID][ ][OK][Data][x]
31. Picture Size Setting for Double Window
mode (Command2:t)
GTo adjust main window size in Double Window mode.
Transmission
Data Min: 0 ~ Max: 64
•Refer to ‘Real data mapping1’. See page 28.
[j][t][ ][Set ID][ ][Data][Cr]
Acknowledgement
[t][ ][Set ID][ ][OK][Data][x]
32. Auto Configure (Command2:u)
GTo adjust picture position and minimize image shaking
automatically. It works only in RGB (PC) mode.
Transmission
Data 1: To set
[j][u][ ][Set ID][ ][Data][Cr]
Acknowledgement
[u][ ][Set ID][ ][OK][Data][x]
25. PIP Input Select (Command2:y)
G To select input source for sub picture in PIP mode.
Transmission
Data 0 : RGB
1 : Component
2 : Video
3 : S-Video
4 : DVI
[k][y][ ][Set ID][ ][Data][Cr]
Acknowledgement
[y][ ][Set ID][ ][OK][Data][x]
26. Abnormal State (Command2:z)
GTo recognize an abnormal state.
Transmission
Data 0: Normal (Power on and signal exist)
1: No signal (Power on)
2: Turn the monitor off by remote control
3: Turn the monitor off by sleep time function
4: Turn the monitor off by RS-232C function
5: 5V down
6: AC down
7: Turn the monitor off by Fan Alarm function
8: Turn the monitor off by off time function
9: Turn the monitor off by auto off function
a: Turn the monitor off by AV board detect
Data FF:Read
[k][z][ ][Set ID][ ][FF][Cr]
Acknowledgement
[z][ ][Set ID][ ][OK][Data][x]

- 14 -
IR Code(NEC Format)
G Connect your wired remote control to the Remote port on the Monitor.
G Output waveform
Single pulse, modulated with 37.917KHz signal at 455KHz
G Configuration of frame
G Repeat code
G Lead code
• 1st frame
Low
custom code
Lead
code High custom code Data code Data code
TC
Tf
T1
C0
Carrier frequency
FCAR = 1/TC= fOSC/12
Duty ratio = T1/TC= 1/3
• Repeat frame
C1 C2 C3 C4 C5 C6 C7 C0 C1 C2 C3 C4 C5 C6 C7 D0 D1 D2 D3 D4 D5 D6 D7 D0 D1 D2 D3 D4 D5 D6 D7
Repeat code
9 ms 4.5 ms
0.55 ms
9 ms
2.25 ms
G Bit description
G Frame interval : Tf
The waveform is transmitted as long as a key is depressed.
• Bit “0”
Tf Tf
Tf=108ms @455KHz
0.56 ms 0.56 ms
1.12 ms
• Bit “1”
2.24 ms
How to Connect
How to Connect
Remote Control IR Code (NEC Format)
Remote Control IR Code (NEC Format)

- 15 -
IR Code(NEC Format)
00H
01H
02H
03H
08H
C4H
C5H
09H
10H
11H
12H
13H
14H
15H
16H
17H
18H
19H
0BH
98H
D5H
C6H
BFH
5AH
D8H
0EH
44H
43H
52H
4DH
60H
61H
63H
64H
6BH
40H
41H
69H
6AH
7BH
79H
76H
77H
AFH
99H
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button (Power On/Off)
Discrete IR Code (Only Power On)
Discrete IR Code (Only Power Off)
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button (Video/S-video/Component/RGB/DVI)
R/C Button (Component/RGB/DVI)
Discrete IR Code (Input RGB Selection)
Discrete IR Code (Input DVI Selection)
Discrete IR Code (Input Component Selection)
Discrete IR Code (Input Video Selection)
Discrete IR Code (Input S-video Selection)
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button (PIP/Double window Exchange)
R/C Button (4:3/16:9)
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button
R/C Button (4:3/16:9/Zoom mode Selection)
Discrete (Only 4:3 mode)
Discrete (Only 16:9 mode)
Discrete (Only Zoom mode)
Discrete IR Code
Code (Hexa) Function Note
UP (D)
DOWN (E)
VOL+ (G)
VOL- (F)
POWER ON/OFF
POWER ON
POWER OFF
MUTE
Number Key 0
Number Key 1
Number Key 2
Number Key 3
Number Key 4
Number Key 5
Number Key 6
Number Key 7
Number Key 8
Number Key 9
INPUT SELECT
MULTIMEDIA
RGB
DVI
Component
Video
S-video
SLEEP
ENTER (ç)
MENU
DASP
APC
PIP
PIP INPUT
SWAP
PIP ARC
DW
ZOOM +
ZOOM -
Window Size
Window Position
Split Zoom
ARC
ARC (4:3)
ARC (16:9)
ARC (Zoom)
AUTO CONFIG

1. Application Object
These instructions are applied to all of the PDP monitor/TV
with Tuner Box, RF-03GA.
2. Notes
(1) Because this is not a hot chassis, it is not necessary to use
an isolation transformer. However, the use of isolation
transformer will help protect test instruments.
(2) Adjustments must be performed in the correct order.
(3) The adjustments must be performed in conditions between
68° and 86°F with 55-75% relative humidity.
(4) The input voltage of the receiver must keep at 100~240V,
50/60Hz during adjustment(s).
(5) The receiver must be operated for at least 15 minutes prior
to the adjustment(s).
1) The receiver must be operated receiving 100% white
pattern, prior to adjustment(s).
(White condition in HEAT-RUN mode)
2) Enter into HEAT-RUN mode
- Press the POWER ON KEY on Adjustment R/C.
- OSD display HEAT-RUN WHITE and screen display
100% full WHITE PATTERN.
[Set is activated HEAT-RUN without signal generator in
this mode.
[Single color pattern of HEAT-RUN mode uses to check
PANEL. (RED/BLUE/GREEN)
[Caution] If you turn on a still screen more than 20 minutes
(such as Cross Hatch Pattern, Digital Pattern), an
afterimage may be occur in the black level part of the
screen. (Image Burn)
O Data values, adjusted in the board, are valid until the VSC
Board is dissued and must be protected. For the protection of
data, Micom does not permit any more adjustments after
completion.
O In case of re-adjustment, operate First Value Setting.
Each PCB Assy must be checked prior to installation.
(Especially, be careful Power PCB Assy which can cause
damage to PDP Module.)
3. POWER PCB Assy Voltage
Adjustments (Va, Vs Voltage Adjustments)
3-1 Test Equipment :Digital Multi-Meter (DMM)
3-2 Connection Diagram for Measuring
Refer to Fig 1.
3-3 Adjustment Method
(1) Va Adjustment
1) Select White Mode of HEAT RUN or receive a 100%
Full White Pattern with the Video/RGB from a Pattern
Generator.
2) Connect the + terminal of the DMM to Va pin of P805
and the - terminal of the DMM to GND pin of P805.
3) Adjust RV601 until the reading of Va on the DMM is the
same as Va voltage on label of panel Right/Top.
(Deviation : ±0.5V)
(2) Vs adjustment
1) Connect the + terminal of the DMM to Vs pin of P805
and the - terminal of the DMM to GND pin of P805.
2) Adjust RV401 until the reading of Vs on the DMM is the
same as Vs voltage on label of panel Right/Top.
(Deviation : ±0.5V)
4. Auto ADC Adjustments
4-1 RGB Auto Offset & Gain Adjustment
(1) Input Half Black/White (255 Gray) signal from a Pattern
Generator into the RGB Input.
(XGA 1024*768 60Hz)
- 16 -
ADJUSTMENT INSTRUCTIONS
DMM
+ -
RV401
Vs ADJ
RV601
Va ADJ
P804
P805
Vs
NC
Va
GND
DMM
+ --
RV401
Vs ADJ
RV601
Va ADJ
P804
P805
RV401
Vs ADJ
RV601
Va ADJ
P804
P805
Vs
NC
Va
GND
Vs
NC
Va
GND
<Fig 1> Connection Diagram of Power Adjustments

- 17 -
(2) Press POWER ON KEY on the Adjustment R/C and select
RGB Cut.
(3) Press Vol. + key and operate TO SET(Black).
(4) Original Half Black/White(255 Gray) screen will be
presented about 5~10 seconds later. And Cursor moves
with a lower part Y-cut.
This case RGB Auto Offset, MAX Gain adjustment will be
completed.
4-2 Component Auto Offset & Gain
Adjustment (Y, Pb, Pr Adjustment)
(1) Input Half Black/White (255 Gray) signal from a Pattern
Generator into the component Input. (1280*720p 60Hz)
(2) Press Vol. + key and operate To SET from the condition
where the cursor moves with the Y-cut.
(3) Original Half White(255 Gray) screen will be presented
about 5~10 seconds later. And Cursor moves with a lower
part Pb-cut.
This case Component Y-offset & Gain adjustment will be
completed.
(4) After adjustment of item (3), receive Half Blue(127 level)
signal for Pb-offset adjustment.
(5) Press Vol. + key and operate To SET for Pb-offset
adjustment.
(6) Original Half Blue(127 level) screen will be presented
about 5~10 seconds later. And Cursor moves with a lower
part Pr-cut.
This case Component Pb-offset & Gain adjustment will be
completed.
(7) After adjustment of item (5), receive Half Red(127 level)
signal for Pr-offset adjustment.
(8) Press Vol. + key and operate To SET for Pr-offset
adjustment.
(9) Original Half Red(127 level) screen will be presented
about 5~10 seconds later and the OK indication appears.
This case Component Auto offset & Gain adjustment will
be completed.
O You can check whether circuit adjustment is correct or not,
below. (Item 4-1)
(1) Display RGB to the Main picture, CVBS to the Sub picture
in TWIN PICTURE mode. (DOUBLE WINDOW)
(2) To check the Offset, input Full Black (0 gray) signal into
CVBS and RGB input part at the same time in the Pattern
Generator.
(3) To check the MAX-Gain, input Full White (255 gray) signal
into CVBS and RGB input part at the same time in the
Pattern Generator.
(4) Visually compare Black and White Levels. If there is no
Level difference, then the adjustment is correct.
O You can check whether circuit adjustment is correct or not,
below. (Item 4-2)
(1) Display Component to the Main picture, CVBS to the Sub
picture in TWIN PICTURE mode. (DOUBLE WINDOW)
(2) Using HD STB(SK-010T) or equal equipment input Digital
Pattern into CVBS and Component input part.
(720p or 1080i)
(3) Visually compare Black and White Levels of Main and Sub
screen. If there is no Level difference, then the adjustment
is correct.
ADJUSTMENT INSTRUCTIONS
White : 255 Gray level
White : 255 Gray level

- 18 -
5. Adjustment of White Balance
5-1. Required Equipment
Color analyzer (CA-100 or similar product)
5-2. Connection Diagram of Equipment for
Measuring (Manual Adjustment)
5-3. Adjustment of White Balance
O Operate the Zero-calibration of the CA-100, then apply the
sensor to the PDP display surface.
O Manual adjustment is also possible with the following sequence.
(1) Select WHITE PATTERN of HEAT RUN mode by pressing
POWER ON KEY on the Adjustment R/C, then operate the
HEAT RUN for at least 15 minutes.
(2) Supply 216Gray, 50% size length and breadth signal to RGB
input. (Refer to Fig 2)
(3) W/B adjustment must be adjusted only High Light and then
save the adjustment value with YKey.
(4) To adjust High Light, apply sensor to 216 Gray Level (or 105-
115 Cd/m2) Pattern, press ADJ Key on Adjustment R/C and
press T, U on Adjustment R/C to select R-L or G-L, press
VOL +, - Key(s) to adjustuntil color coordination becomes as
below.
X: 0.280±0.003, Y: 0.290±0.003
Color temperature: 10,000°K±500°K
(5) Exit adjustment mode using YKey.
6. DDC Data Input
6-1. Required Test Equipment
(1) A jig for adjusting PC, DDC. (PC serial to D-sub.
Connection equipment)
(2) S/W for writing DDC(EDID data write & read)
(3) D-Sub 15P cable, D-Sub to DVI Connector (DVI-D)
6-2. Setting of Device
6-3. Preparation for Adjustments
(1) Set devices as above and turn the PC, JIG on.
(2) Open S/W for writing DDC (EDID data write & read).
(operated in DOS mode)
6-4. Sequence of Adjustments
(1) DDC Data Input for Analog-RGB
1) Place the set on the table and turn the power on.
2) Connect PC Serial to D-sub 15P Cable of JIG for DDC
Adjustment to RGB terminal (D-Sub 15Pin).
3) Open S/W for DDC record and select DDC Data for
Analog RGB in Model Menu.
4) Operate EDID Write command.
5) Operate EDID Read command and check whether
Check Sum is OK.
6) If Check Sum is NG, repeat 3) ~ 4).
7) If Check Sum is OK, DDC Data for Analog-RGB input is
completed.
(2) DDC Data input for Digital-RGB
1) Connect PC Serial to DVI Cable(DVI-D) of JIG for DDC
Adjustment to DVI terminal.
2) Operate S/W for DDC record and select DDC Data for
Digital RGB in Model Menu.
3) Operate EDID Write command.
4) Operate EDID Read command and check whether
Check Sum is OK.
5) If Check Sum is NG, repeat 3) ~ 4).
6) If Check Sum is OK, DDC Data for Digital-RGB input is
completed.
ADJUSTMENT INSTRUCTIONS
R-H 216R-H 216
G-H 216G-H 216
Window
VG828, MSPG-2100
or MSTG-5200
High Light
216 Gray Level
<Fig 2> Connection Diagram of Manual Adjustment
RGB Signal Input
PDP MONITOR

- 19 -
BLOCK DIAGRAM

- 20 -
BLOCK DIAGRAMBLOCK DIAGRAM
