Color LCD Monitor
Installation Manual

2
This product has been adjusted specically for use in the region to which it was originally shipped. If
operated outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by
any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless
prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every
effort has been made to ensure that this manual provides up-to-date information, please note that EIZO
monitor specications are subject to change without notice.

3
CONTENTS
CONTENTS
CONTENTS............................................................. 3
Chapter 1 Basic Adjustment / Setting.............. 4
1-1. Loading the Monitor Settings...................... 4
1-2. Switching Input Signals ............................... 5
1-3. Using Function Buttons ............................... 6
Chapter 2 Advanced Adjustment / Setting ...... 7
2-1. Operation via the Main Menu....................... 7
2-2. Individual Functions of Main Menu............. 8
●Input Cong ..................................................... 8
●Video Cong ...................................................10
●System Cong ................................................11
●Function ..........................................................13
●Window Cong ...............................................14
●Remote ...........................................................16
●Control ............................................................19
Chapter 3 Troubleshooting.............................. 20
3-1. No Picture Displayed .................................. 20
3-2. Imaging Problems........................................21
3-3. Other Problems............................................21
Chapter 4 Reference ........................................ 22
4-1. Main Default Settings ................................. 22
4-2. PinSpecications....................................... 23
Appendix.............................................................. 24
LIMITED WARRANTY............................................. 24
Trademark ............................................................... 25
License .................................................................... 25
Recycling Information ........................................ 26

4Chapter 1 Basic Adjustment / Setting
Chapter 1 Basic Adjustment / Setting
This chapter describes the basic functions that can be adjusted and set by pressing the buttons on the front
of the monitor.
1-1. Loading the Monitor Settings
It is possible to switch to PRESET, FACTORY, or the USER settings that have been set in advance.
PRESET Basic settings are made in advance at the factory. The settings of PRESET cannot be
changed.
FACTORY Returns to settings when shipped from the factory.
USER Various settings including menus can be made for personal use. For details, see “Preset”
(page 11).
1. Press (PRESET).
The preset menu is displayed.
2.
Press to select the PRESET number, FACTORY, or USER number to
load, and then press (ENTER).
The pre-made settings are loaded and the settings are changed. The selectable settings are as
follows.
• PRESET1 to PRESET5
• FACTORY
• USER1 to USER10
Note
• The “PRESET” menu will disappear after ve seconds have elapsed if no operation is performed.
• is displayed for the USER number that has already been registered.
• When selecting a USER number that has not yet been registered, “No Data” is displayed.
• For information about the main default settings, see “4-1. Main Default Settings” (page 22).

5
Chapter 1 Basic Adjustment / Setting
1-2. Switching Input Signals
Select the signal input to the monitor and display it on the screen.
1. Press (INPUT).
The “Input Select” menu appears.
2.
Press to select an input signal.
This switches to the selected input signal.
3.
Press (INPUT).
The menu screen exits.
Note
• If you press (INPUT) while the “Input Select” menu is displayed in dual screen mode, the “Input Select” menu
of the subscreen is displayed.
• When RGB / YPBPR is selected, if the color is abnormal, set it correctly with “Input Cong” (page 8) on the
main menu.
• The “Input Select” menu will disappear after ve seconds have elapsed if no operation is performed.

6Chapter 1 Basic Adjustment / Setting
1-3. Using Function Buttons
Execute the functions assigned to the function buttons (F1 ( ), F2 ( ), F3 ( ), F4 ( ) and F5
( )). For information on how to set a function to each button, see “Function” (page 13).
1. Press F1 ( ), F2 ( ), F3 ( ), F4 ( ) or F5 ( ).
The function menu is displayed.
2.
Press the button with the target function set while the function menu is
displayed.
Note
• In dual screen mode, press (INPUT) to select a screen for performing the target function.
• When the setting of “Function Display” (page 13) is “Off”, the “INVALID FUNCTION” message is displayed if
you press a function button that cannot operate.
• When the setting of “Function Display” (page 13) is “Off”, the “UNDEFINED” message is displayed if you press
a function key assigned to “Undef”.

7
Chapter 2 Advanced Adjustment / Setting
Chapter 2 Advanced Adjustment / Setting
This chapter describes advanced monitor adjustment and setting procedures using the main menu.
2-1. Operation via the Main Menu
1. Menu display
1. Press (MENU).
The main menu is displayed.
2. Press to select the desired item, and then press .
2.
Adjusting / setting
1. Press to select the desired item.
2. Press to set.
If “Next Menu” is displayed for items, press , and a next menu is displayed.
3.
Exiting
1. If you repeatedly press (MENU), the menu screen exits.

8Chapter 2 Advanced Adjustment / Setting
2-2. Individual Functions of Main Menu
●InputCong
Setting for each input terminal.
Function Setting range Description
SDI Main Stream 1
Stream 2
Sets the picture on Main screen for dual-stream SDI
signal. This is also applied to the single screen mode.
SDI Sub Stream 1
Stream 2
Sets the picture on the subscreen for dual-stream SDI
signal.
RGB/YPBPRYPBPR
RGB-VIDEO
RGB-PC
Sets to match the connected signal at the Y/G, PB/B, PR/R
input terminal.
• “YPBPR”
Set to Y, PB/CB, or PR/CR signal.
• “RGB-VIDEO”
Set to RGB signals. Signal decision gives priority to
VIDEO system.
• “RGB-PC”
Set to RGB signals. Signal decision gives priority to
PC system.
HD15 RGB-VIDEO
RGB-PC
Sets to match signal connected to the HD15 input terminal.
• “RGB-VIDEO”
Signal decision gives priority to VIDEO system.
• “RGB-PC”
Signal decision gives priority to PC system.
Sync. Select (RGB) Auto
Sync on Green
VBS
Sets the synchronization signal input method for the RGB
input terminals.
• “Auto”
Automatically switches between SYNC input and
SYNC on G. When synchronized with SYNC input and
SYNC on G, SYNC input is given priority.
• “Sync on Green”
When synchronized with SYNC input and SYNC on G,
select this to synchronize with SYNC on G.
• “VBS”
Select this when connecting by synchronizing the
composite sync (VBS) signal with the SYNC input
terminal. E.g., when a non-synchronous R / G / B
image signal and a VBS signal output device are
connected to the monitor, connect the VBS signal to
the SYNC input terminal, and select VBS.

9
Chapter 2 Advanced Adjustment / Setting
Function Setting range Description
Sync. Select (HD15) Auto
Sync on Green
Sets the synchronization signal input method for the HD15
input terminal.
• “Auto”
Automatically switches between HD/VD input and
SYNC on G. When HD/VD input and SYNC on G are
synchronous, HD/VD input is given priority.
• “Sync on Green”
When HD/VD input and SYNC on G are synchronous,
select this to synchronize with SYNC on G
Analog
Adjustment
Auto Setup - Automatically adjusts “H Position”, “V Position”, and “Dot
Clock” when the PC signal is input.
H Position 0 to 300 To move screen left and right.
V Position 0 to 100 To move screen up and down.
Dot Clock 0 to 100 When a striped pattern is displayed, adjust so that noise
will decrease when the synchronous striped pattern (noise)
is produced.
Clock Phase 0 to 31 When inputting RGB signals and PC signals, adjust
for ease of viewing if bleeding or blurring of the screen
contour occurs.
Signal Format 4:3
Wide
Sets signal type for unidentiable signals.

10 Chapter 2 Advanced Adjustment / Setting
●VideoCong
Adjustments / settings for image display.
Function Setting
range Description
Color 0 to 100 Adjusts color depth of the image.
Tint 0 to 100 Adjusts skin tones.
Brightness 0 to 100 Adjusts image darkness (black).
Picture 0 to 100 Adjusts image intensity.
Sharpness 0 to 20 Adjusts image contour color denition.
Gamma 1.8 to 2.6
DICOM
Adjusts brightness.
Backlight 0 to 100 Adjusts brightness of backlight. In case of multiple windows,
select the main screen. The setting cannot be changed
when a screen other than the main screen is selected.
Color Temp 6500 K
9300 K
Off
Switches tone of the image.
R Gain 0 to 100 Adjusts the brightness of red in bright portions.
G Gain 0 to 100 Adjusts the brightness of green in bright portions.
B Gain 0 to 100 Adjusts the brightness of blue in bright portions.
R Bias 0 to 100 Adjusts the brightness of red in dark portions.
G Bias 0 to 100 Adjusts the brightness of green in dark portions.
B Bias 0 to 100 Adjusts the brightness of blue in dark portions.
Color Gamut sRGB
Native
Sets the Color Gamut.
Input Range 0 to 255
16 to 235
The dynamic range is modulated in accordance with the
input signals from the DVI-D terminal.
• “0 to 255”
Use this setting when connecting PC format source.
• “16 to 235”
Use this setting when connecting video format source.
NTSC Setup 0
7.5
Select set up level for NTSC signals. Note that the standard
level for NTSC signals varies between countries.
• “0”
Set when the dark parts of the screen are too dark.
(0 IRE)
• “7.5”
Set when the dark parts of the screen are too bright.
(7.5 IRE)
Noise Reduction Off
Light
Middle
Heavy
Select Noise Reduction level for picture.

11
Chapter 2 Advanced Adjustment / Setting
●SystemCong
Settings for devices.
Function Setting
range Description
Menu Position The display locations of menu screen, Input Select menu
screen, and PRESET menu screen are set here.
• “ ”
Selected screens are displayed in the center of the
panel.
• “ ”
Selected screens are displayed in the upper right
corner of the panel.
• “ ”
Selected screens are displayed in the lower right corner
of the panel.
• “ ”
Selected screens are displayed in the lower left corner
of the panel.
• “ ”
Selected screens are displayed in the upper left corner
of the panel.
Preset Save - Saves currently set values, and the status for each user.
Attention
• “Power On Setup”, “Language” and “Logo Display”
settings cannot be made.
Clear - The set values of “USER1” to “USER10” (USER NAME) can
be deleted.
Rename - The character strings of “USER1” to “USER10” (USER
NAME) can be changed.
Status Display Continue
3Sec
Off
Sets whether information about the current input signal and
terminal name is displayed.
Information about the resolution at the PC signal input is
also displayed.
Power On Setup Last
PRESET1 to
PRESET5
FACTORY
USER1 to
USER10
Settings for switching on can be set in advance.
• “Last”
Starts with last saved state.
• “PRESET1 to PRESET5”
State saved in PRESET is called. Five types of
PRESET are stored in advance in the monitor as xed
data.
• “FACTORY”
Returns to factory settings.
• “USER1 to USER10”
State saved in USER is called. It is possible to store 10
types of data in USER.

12 Chapter 2 Advanced Adjustment / Setting
Function Setting
range Description
Power Save Mode On
Off
Sets whether function that the backlight turns off due to no
video signal after 30 sec is valid.
Language English
Deutsch
Français
日本語
簡体中文
Italiano
Español
Svenska
繁體中文
Sets the language to be used for display in settings and all
menus.
Logo Display On
Off
The logo display on power-on can be set to On or Off.

13
Chapter 2 Advanced Adjustment / Setting
●Function
Congure the setting related to function buttons (F1 ( ), F2 ( ), F3 ( ), F4 ( ), and F5 ( )).
Function Setting range Description
F1
F2
F3
F4
F5
PIP
Display Direction
Scan Size
Gamma Select
Undef
Window Mode
Auto Setup
Input VIDEO
Input S VIDEO
Input RGB/YPBPR
Input HD15
Input SDI 1
Input SDI 2
Input DVI-D 1
Input DVI-D 2
Noise Reduction
POP
Color Gamut
Sets functions assigned to function buttons.
• “PIP”
Switches the screen display between dual screen (P in P: small
screen is displayed on normal screen) and single screen.
• “Display Direction”
Rotates / ips the screen.
• “Scan Size”
Switches the setting values of “Window Cong” - “Scan Size” in
sequence.
• “Gamma Select”
Switches the setting values of “Video Cong” - “Gamma” in sequence.
• “Undef”
No function assigned.
• “Window Mode”
Switches the “Window Mode” set value for the dual screen that are
currently displayed in sequence.
• “Auto Setup”
Executes “Input Cong” - “Analog Ajustment” - “Auto Setup”.
• “Input VIDEO”
Switches to the designated input.
• “Input S VIDEO”
Switches to the designated input.
• “Input RGB/YPBPR”
Switches to the designated input.
• “Input HD15”
Switches to the designated input.
• “Input SDI 1”
Switches to the designated input.
• “Input SDI 2”
Switches to the designated input.
• “Input DVI-D 1”
Switches to the designated input.
• “Input DVI-D 2”
Switches to the designated input.
• “Noise Reduction”
Switches the setting of “Video Cong” - “Noise Reduction” in
sequence.
• “POP”
Switches between 2 screens (P out P: Splits screen horizontally) and
1 screen on the display.
• “Color Gamut”
Switches the color gamut.
Function
Display
Mode1
Mode2
Off
• “Mode1”
After the function menu has been displayed, pressing the function
button executes the function.
• “Mode2”
Displays the function menu, and executes the function.
• “Off”
Executes the function without displaying the function menu.

14 Chapter 2 Advanced Adjustment / Setting
●WindowCong
Settings for screen display.
Function Setting range Description
Multi Window Off
2PIP
2POP
Sets dual screen display.
• “Off ”
Sets single screen display mode.
• “2PIP ”
Displays small screen (subscreen) on normal screen (P in P).
• “2POP ”
Displays split window (P out P).
Window Mode (When “2PIP” is
selected)
Mode1
Mode2
Mode3
Mode4
In accordance with the multiple window, selects the display position
and display size of the subscreen for the respective modes.
(When “2PIP” is selected)
• “Mode1 ”
Displays subscreen at top right.
• “Mode2 ”
Displays subscreen at bottom right.
• “Mode3 ”
Displays subscreen at bottom left.
• “Mode4 ”
Displays subscreen at top left.
(When “2POP” is selected)
• “Mode1 ”
Displays subscreen at 1/2 display size.
• “Mode2 ”
Displays subscreen at 1/3 display size.
• “Mode3 ”
Displays subscreen at 1/4 display size.
(When “2POP” is
selected)
Mode1
Mode2
Mode3
Display Direction Normal
180°
Mirror
Sets the rotation angle or horizontally ips the main screen and
subscreen.

15
Chapter 2 Advanced Adjustment / Setting
Function Setting range Description
Scan Size Normal
x1.05
x1.10
x1.33
x1.50
16:9
Through
4:3
1:1
V Fit
Sets zoom in and out ratios when displaying input video on the
monitor.
• “Normal”
When using the single screen, enlarges or reduces so that the
vertical resolution is 1080 dots. Dark bands form left and right
when the aspect ratio is other than 16:9. When using multiple
windows, the display matches the display frame of the main
screen and subscreen.
• “x1.05”
Enlarges images displayed with “Normal” to 1.05 times.
• “x1.10”
Enlarges images displayed with “Normal” to 1.1 times.
• “x1.33”
Enlarges images displayed with “Normal” to 1.33 times.
• “x1.50”
Enlarges images displayed with “Normal” to 1.50 times.
• “16:9”
Displays converted aspect ratio of images displayed with “Normal”
to 16:9.
• “Through”
Signals with vertical resolutions of over 720 dots are displayed
without the scaling (scale-up / scale-down) process being
applied.
• “4:3”
Extracts the input signal so that the aspect ratio is 4:3, and
displays it matching the display frame.
• “1:1”
Extracts the input signal so that the aspect ratio is 1:1, and
displays it matching the display frame.
• “V Fit”
Displays the input signal matching the vertical display frame of
the POP.
Note
• “Normal” displays at 4:3 when input signal is NTSC, PAL, 480/60i, 480/60p, 576/50i, or 576/50p.
• “16:9” is selectable when input signal is NTSC, PAL, 480/60i, 480/60p, 576/50i, or 576/50p.
• “4:3” and “1:1” work only in PIP or POP mode and “V Fit” works only in POP mode. They do not work with a
full (non-split) screen display.

16 Chapter 2 Advanced Adjustment / Setting
●Remote
Congure the settings related to a remote function (a function used to control this product from
external devices connected to the RS232C or GPI terminal).
Function Setting range Description
RS-232C On
Off
Sets the On / Off status of the remote function via the RS-
232C terminal.
GPI Control On
Off
Sets the On / Off status of the remote function via the GPI
terminal.

17
Chapter 2 Advanced Adjustment / Setting
Function Setting range Description
GPI Setup GP1
GP2
GP3
GP4
GP5
GP6
GP7
GP8
PIP
POP
Display Direction
Display Direction
Display Direction
Window Mode
Input VIDEO
Input S VIDEO
Input RGB/YPBPR
Input HD15
Input DVI-D 1
Input DVI-D 2
Input SDI 1
Input SDI 2
Input VIDEO
Input S VIDEO
Input RGB/YPBPR
Input HD15
Input DVI-D 1
Input DVI-D 2
Input SDI 1
Input SDI 2
Sync. Select RGB
Sync. Select HD15
Red Tally
Green Tally
WINDOW SELECT
Undef
Sets functions assigned to each terminal of the GPI terminals.
• “PIP”
Switches between dual screen (P in P) and single screen.
• “POP”
Switches between dual screen (P out P) and single
screen.
• Display Direction
Rotates or ips screen.
• “Display Direction ”
Rotates or ips main screen.
• “Display Direction ”
Rotates / ips subscreen.
• “Window Mode”
Switches the setting values of “Window Cong” - “Window
Mode” in sequence.
• “ Input VIDEO”
Switches main screen input signal to VIDEO.
• “ Input S VIDEO”
Switches main screen input signal to S VIDEO.
• “ RGB/YPBPR”
Switches main screen input signal to RGB/YPBPR.
• “ Input HD15”
Switches main screen input signal to HD15.
• “ Input DVI-D 1”
Switches main screen input signal to DVI-D 1.
• “ Input DVI-D 2”
Switches main screen input signal to DVI-D 2.
• “ Input SDI 1”
Switches main screen input signal to SDI 1.
• “ Input SDI 2”
Switches main screen input signal to SDI 2.
• “ Input VIDEO”
Switches subscreen input signal to VIDEO.
• “ Input S VIDEO”
Switches subscreen input signal to S VIDEO.
• “ RGB/YPBPR”
Switches subscreen input signal to RGB/YPBPR.
• “ Input HD15”
Switches subscreen input signal to HD15.
• “ Input DVI-D 1”
Switches subscreen input signal to DVI-D 1.

18 Chapter 2 Advanced Adjustment / Setting
Function Setting range Description
GPI Setup GP1
GP2
GP3
GP4
GP5
GP6
GP7
GP8
PIP
POP
Display Direction
Display Direction
Display Direction
Window Mode
Input VIDEO
Input S VIDEO
Input RGB/YPBPR
Input HD15
Input DVI-D 1
Input DVI-D 2
Input SDI 1
Input SDI 2
Input VIDEO
Input S VIDEO
Input RGB/YPBPR
Input HD15
Input DVI-D 1
Input DVI-D 2
Input SDI 1
Input SDI 2
Sync. Select RGB
Sync. Select HD15
Red Tally
Green Tally
WINDOW SELECT
Undef
• “ Input DVI-D 2”
Switches subscreen input signal to DVI-D 2.
• “ Input SDI 1”
Switches subscreen input signal to SDI 1.
• “ Input SDI 2”
Switches subscreen input signal to SDI 2.
• “Sync. Select RGB”
Switches the setting values of “Input Cong” - “Sync.
Select RGB” in sequence.
• “Sync. Select HD15”
Switches the setting values of “Input Cong” - “Sync.
Select HD15” in sequence.
• “Red Tally”
Sets (red) displayed at screen top center to On or Off.
• “Green Tally”
Sets (green) displayed at screen top center to On or
Off.
• “WINDOW SELECT”
Switches the operation target screen.
• “Undef”
Not set.
Note
• The GPI is an edge operation without tally. Operations can be received by setting the terminal potential from
open to the same potential as GND. The edge operation requires a period of at least 200 ms of the same
potential as GND. After the operation, the same potential as GND should be canceled.

19
Chapter 2 Advanced Adjustment / Setting
●Control
Settings for lock functions.
Function Setting range Description
Lock On
Off
Changing settings via the main menu is prevented.
Attention
• When this function is set to “On”, no settings other than “Control” can be changed.
Note
• If you hold down (MENU) and (ENTER) for approximately four seconds, buttons are locked, and the
“LOCKED” message is displayed. If you perform the same operation again, buttons are unlocked, and the
“UNLOCKED” message is displayed.

20 Chapter 3 Troubleshooting
Chapter 3 Troubleshooting
3-1. No Picture Displayed
Problem Possible cause and remedy
1. No picture • Check whether the power cord is connected properly.
• Check whether the DC OUT terminal and the DC IN terminal
are connected properly.
• Turn on the power switch.
• Check whether the main power indicator of the AC adapter is
on.
• Turn off the power and then turn it on again.
2. The message below appears. This message appears when the signal is not input correctly even
though the monitor is functioning properly.
• This message appears when no signal is
input.
Example:
• The message shown on the left may appear, because some
devices to be connected do not output the signal immediately
after power-on.
• Check whether the device to be connected is turned on.
• Check whether the signal cable is connected properly.
• Turn off the power and then turn it on again.
• The message indicates that the input signal
is outside the specied frequency range.
Example:
• Check whether the device to be connected is congured to
meet the resolution and vertical scan frequency requirements
of the monitor.
• Reboot the device to be connected.
