LightPointe FlightLite 100 Instruction Manual

505-016300-00000 Rev A 2004-07
FlightTransportSystems
FlightLite100/100E
Installation and Maintenance

Copyrights and Disclaimer
2004, LightPointe Communications, Inc. All Rights Reserved
Information in this document is provided in connection with LightPointe
Communications, Inc. (LightPointe) products as a service to our customers and may be
used for information purposes only. LightPointe assumes no responsibility for errors or
omissions in these materials. LightPointe may make changes to specifications and
product descriptions at any time, without notice. LightPointe makes no commitment to
update the information and shall have no responsibility whatsoever for conflicts or
incompatibilities arising from future changes to its specifications and product
descriptions.
No license, express or implied, by estoppel or otherwise, to any intellectual property
rights is granted by this document. Except as provided in LightPointe’s Terms and
Conditions of Sale for such products, LightPointe assumes no liability whatsoever.
THESE MATERIALS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESSED OR IMPLIED, RELATING TO SALE AND/OR USE OF LIGHTPOINTE PRODUCTS
INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR
PURPOSE, CONSEQUENTIAL OR INCIDENTAL DAMAGES, MERCHANTABILITY, OR
INFRINGEMENT OF ANY PATENT COPYRIGHT OR OTHER INTELLECTUAL PROPERTY
RIGHT. LIGHTPOINTE FURTHER DOES NOT WARRANT THE ACCURACY OR
COMPLETENESS OF THE INFORMATION, TEXT, GRAPHICS OR OTHER ITEMS CONTAINED
WITHIN THESE MATERIALS. LIGHTPOINTE SHALL NOT BE LIABLE FOR ANY SPECIAL,
INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT
LIMITATION, LOST REVENUES OR LOST PROFITS, WHICH MAY RESULT FROM THE USE
OF THESE MATERIALS.
LightPointe products are not intended for use in medical, lifesaving or life sustaining
applications. LightPointe customers using or selling LightPointe products for use in such
applications do so at their own risk and agree to fully indemnify LightPointe for any
damages resulting from such improper use or sale.
FlightLite, FlightPath, FlightSpectrum, FlightStream, FlightPower, FSO,
FlightStrata, FlightApexand FlightManagerare trademarks of LightPointe.
Product names or services listed in this publication are for identification purposes only,
and may be trademarks of third parties. Third-party brands and names are the property
of their respective owners.
LightPointe believes the printed matter contained herein to be accurate from date of
publication and reserves the right to make changes as necessary without notice
Reader Response: LightPointe strives to produce quality documentation and welcomes
your feedback. Please send comments and suggestions to LightPointe. For technical
questions, contact your local LightPointe sales office or field applications engineer, or
visit our website at www.lightpointe.com.

505-016300-00000 Rev A
i
Table of Contents
1. SYSTEM OVERVIEW .............................................................. 1-1
1.1. The LightPointe FlightLite System ................................................... 1-1
1.2. Link Head Devices ........................................................................ 1-4
1.3. Laser Safety ................................................................................ 1-5
2. SYSTEM INSTALLATION AND ALIGNMENT ............................ 2-1
2.1. Major System Components ............................................................ 2-1
2.2. Recommended Survey and Installation Tools .................................... 2-6
2.3. Site Review ................................................................................. 2-7
2.4. Site Preparation prior to installing the linkheads ............................. 2-11
2.5. The installation process ............................................................... 2-12
2.6. Assemble and Mount the System Hardware.................................... 2-12
2.7. Install the Power Over Ethernet Injector ........................................ 2-16
2.8. Assemble and Mount the Local Power Supply.................................. 2-17
2.9. Link Head Alignment................................................................... 2-24
2.10. Network Connections ................................................................ 2-26
3. MAINTENANCE...................................................................... 3-1
3.1. Scheduled Maintenance................................................................. 3-1
4. TROUBLESHOOTING AND DIAGNOSTICS .............................. 4-1
4.1. Failure Types ............................................................................... 4-1
4.2. Additional Troubleshooting Methods ................................................ 4-4
4.3. Technical Support......................................................................... 4-5
4.4. Return Material Authorization (RMA) Procedure................................. 4-6
5. SPECIFICATIONS .................................................................. 5-1
6. INDEX................................................................................... 6-1

ii
505-016300-00000 Rev A
List of Figures
Figure 1-1: Typical FL 100 / 100E Installation and Connections .................. 1-1
Figure 1-2: FlightLite 100 / 100E Link Head ............................................. 1-4
Figure 2-1: LightPointe Universal Mounting Kit ......................................... 2-1
Figure 2-2: Medium Pan and Tilt assembly............................................... 2-2
Figure 2-3: Indoor FlightLite Wall-Mount Arm........................................... 2-2
Figure 2-4: FL 100 / 100E Powering Options ............................................ 2-3
Figure 2-5: Power Over Ethernet Power Supply components....................... 2-4
Figure 2-6: FlightLite100 / 100E (LPL-A12) Power Supply Assembly ............ 2-4
Figure 2-7: Link Head and Pan and Tilt Assemblies ................................... 2-5
Figure 2-8: Completed Mounting assembly ............................................ 2-13
Figure 2-9: Vertical Power Supply Mounting ........................................... 2-17
Figure 2-10: Horizontal Power Supply Mounting...................................... 2-17
Figure 2-11: Wall Power Supply Mounting.............................................. 2-18
Figure 2-12: Front of Link Head showing operational features................... 2-24
Figure 2-13: Link Head Back Panel Key and labeling scheme .................... 2-28
Figure 4-1: Normal Back Panel Display.................................................... 4-3
Figure 4-2: Ping Test Setup................................................................... 4-4
List of Tables
Table 1-1: FlightLite 100 / 100E Operating Parameters.............................. 1-3
Table 1-2: Safe Distances for Telescope Operation.................................... 1-5
Table 2-1: FlightPower Power Supply Options........................................... 2-3
Table 2-2: Link Head Mounting .............................................................. 2-9
Table 2-3: Link Head Back Panel Displays, Controls, and Indicators........... 2-29
Table 2-4: Bar graph and LED Operational Checks .................................. 2-30
Table 4-1: Networking Equipment Problems............................................. 4-2
Table 4-2: LED Operational Checks......................................................... 4-3
Table 5-1: System Specifications............................................................ 5-1

505-016300-00000 Rev A
iii
Safety
Cautions and Warnings
The following symbols are used in this manual to indicate that the
installer should take particular caution to prevent injury or damage to
the equipment.
Exercise caution when you see this symbol. It indicates actions
that could be harmful to the installer or to the equipment.
Exercise extreme caution when you see this symbol. It
indicates potentially lethal voltages!
Note: There are no serviceable parts within the units and the link heads
should not be opened in the field.
Observe Standard Precautions
All persons having access to this equipment must observe all standard
precautions as defined in applicable national statutory health and
safety legislation.
Qualified Personnel
There are hazardous circuits within this product. Qualified personnel
who understand and are trained to work with these hazards must
perform all repair, modification, reconfiguration, and upgrading
operations.
Note: Power the system down before removing the link head.

iv
505-016300-00000 Rev A
Warranty
LightPointe warrants this product against faulty materials or
workmanship under the terms of our current Standard Warranty And
Support Agreement provided that the product was purchased directly
from us or from one of our authorized resellers. Please visit
http://www.lightpointe.com for specifics on our Warranty and
Warranty Registration forms.
Contacting LightPointe
Corporate Office
10140 Barnes Canyon Road, Suite B, San Diego, CA 92121
P: 858.834.4083, F: 858.430.3458
Technical Support
Phone: [phone]
Website: www.lightpointe.com
Email: [e-mail]

505-016300-00000 Rev A
v
Using This Manual
This manual describes how to install and maintain the FlightLite 100
Optical Wireless transmission system.
Step-by-step procedures describe:
Performing a site review
Preparing an installation site
Performing a physical installation
Performing system connection and alignment
Checking the system for proper operation
Performing troubleshooting procedures
Section Contents
1. System Overview System functional and physical overview
2. System Installation and
Alignment
Detailed step-by-step installation and alignment
procedures
3. Maintenance Minimal activities to maintain the system
4. Troubleshooting and
Diagnostics
Resolving operational problems
5. Specifications Physical and electrical specifications
6. Index Keyword index
Additional Resources
Refer to the following documents for additional information about the
LightPointe system.
Document Number Title
Not numbered Field Engineering and Planning Guide

vi
505-016300-00000 Rev A

505-016300-00000 Rev A
1-1
1. System Overview
This chapter covers the following main topics:
The LightPointe system
Link head devices
Laser safety
1.1. The LightPointe FlightLite System
1.1.1. Free-Space Optical Transmission
LightPointe wireless optical systems communicate using single or
multi-beam infrared light transmission (invisible to the human eye).
The systems require true line-of-sight between locations or relay
locations (hopping points) and operate in high and ultra-high
bandwidths.
Figure 1-1: Typical FL 100 / 100E Installation and Connections
The link head on the transmission side transmits a narrow infrared
light beam carrying the data received from the network interface. The
link head on the opposite side receives the beam, filters the optical
signal, and places it on the network interface on the opposite end. The
system is capable of operating in a full-duplex mode, transmitting and
receiving the entire bandwidth of data simultaneously.
Router/Mux/Switch
Linkhead
Universal Mount
Pan & Tilt
Power
Inserter
Category 5 UTP
100 – 240VAC

FlightTransport Installation Guide
1-2
505-016300-00000 Rev A
1.1.2. Typical Applications
Typical system applications include the following:
LAN Extension
10/100 Ethernet connectivity
1.1.3. Network Interface Connectivity
The LightPointe FlightLite 100 / 100E can support any current network
architecture using Ethernet or Fast Ethernet Unshielded Twisted Pair
cabling.
1.1.4. Transmission Method
The FlightLite 100 / 100E systems use a single transmitter and a single
receiver for bidirectional full data rate transmission through space. The
system operates as a “piece of fiber” through the air.
Transmitter Components
The linkhead receives electrical 10/100tdata traffic from the network.
The electrical signal is used to modulate a high power laser source that
transmits an infrared beam into free-space.
Receiver Components
The receive amplifier converts the infrared signal coming from free-
space into an electrical signal by using a highly sensitive photo diode.
This amplified receive signal is sent to the opposite network device
interface on a standard RJ 45 Category 5/6 cable connection.

FlightTransport Installation Guide
505-016300-00000 Rev A
1-3
1.1.5. FlightLite 100 / 100E Operating Parameters
Table 1-1: FlightLite 100 Operating Parameters
Bit rate 10 or 100 Mbps
20 dB 15 dB 5 dB
Calculated distances, in
meters, at LightPointe
recommended
Fade Margins 400 600 1300
Protocol 802.3 10h/10f or 100h/100f
Beam Divergence 5 mrad
Transmit Power 15 mW (+11.8 dBm)
Receiver Sensitivity -40 dBm
Temperature Range -35º C to +65º C
FlightLite 100E Operating Parameters
Bit rate 10 or 100 Mbps
20 dB 15 dB 5 dB
Calculated distances, in
meters, at LightPointe
recommended
Fade Margins 800 1000 1600
Protocol 802.3 10h/10f or 100h/100f
Beam Divergence 5 mrad
Transmit Power 15 mW (+11.8 dBm)
Receiver Sensitivity -40 dBm
Temperature Range -35º C to +65º C

FlightTransport Installation Guide
1-4
505-016300-00000 Rev A
Link Head Devices
1.1.6. The FlightLite 100 / 100ELink Heads
The FlightLite products utilize a single transmitter laser and lens and a
single Photodiode optical receiver and receive lens.
Figure 1-2: FlightLite 100/100E Link Head
The FlightLite 100 features:
Front protective window with heater/lens defroster
Internal telescope for coarse alignment of the system
Receive amplifier with avalanche photo diode (APD)
Transmitter amplifier with Vertical Cavity Surface Emitting Laser
(VCSEL)
Standard Power over Ethernet power inserter supply
Optional local Power supply with external connectors
Back panel with system status display and optical level meter
Four FSO Receive Power indicators that are visible from a distance
to aid in alignment

FlightTransport Installation Guide
505-016300-00000 Rev A
1-5
1.2. Laser Safety
LightPointe optical systems use semiconductor lasers as transmission
sources. You must be aware of corresponding laser safety regulations
and take the necessary precautions to avoid close direct exposure to
the laser beam. The infrared laser beam is invisible and has the
potential to penetrate to the retina and cause thermal damage.
The FlightLite optical laser communication systems use a Class 1M
laser in accordance with the international laser safety standard IEC/EN
60825-1 A2:2001.
Familiarize yourself with laser safety regulations and strictly enforce all
necessary precautions.
Warning: Do not look directly into the laser aperture from a
short distance. Never use any optical instruments to
view the laser beam.
When using the built-in telescope, you must be aware of the
appropriate safety distance (refer to Table 1-2). For distances below
the safety distance the operator must wear appropriate eye-protective
laser safety glasses. These distances assume an exposure of more
than ten seconds.
Table 1-2: Safe Distances for Telescope Operation
Link head Naked Eye safety
distance
Telescope* safety
distance
FlightLite 100 /
100E
0 0
*Internal telescope contains a safety filter
Caution: Use of controls or adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
Caution: This is a Class 1M Free Space Optical
Communication System (FSOCS) transmitter and
may be installed in unrestricted, restricted or
controlled locations. For additional details, please
refer to IEC 60825: SAFETY OF LASER PRODUCTS
Part 12: Safety of free space optical communication
systems used for transmission of information.

FlightTransport Installation Guide
1-6
505-016300-00000 Rev A
Unrestricted locations are those areas that are normally accessible to
the public (e.g., unrestricted areas of rooftops, public areas at ground
level, open areas of offices and industrial premises, etc.). To install a
LightPointe Communications FSO system in an unrestricted location,
the link head must be installed 3 meters high or higher above the
surface of the unrestricted area or must be 1 meter or closer to the
edge of the unrestricted area. If a LightPointe Communications FSO
system is installed in an unrestricted area, a warning sign must be
posted that states “Do not use binoculars, telescopes or other
optical aids to view the FSO link heads.”
Restricted locations are those areas that are normally inaccessible by
the general public (including workers, visitors, and residents in the
immediate vicinity) by means of any administrative or engineering
control measure but that is accessible to authorized personnel (e.g.
maintenance or service personnel including window cleaners in exterior
locations) that may not have laser safety training. There are no
special requirements for a LightPointe Communications FSO system
installed in a restricted area.
Controlled locations are those locations where any kind of engineering
or administrative control measure is introduced to make it inaccessible
except to authorized personnel with appropriate laser safety training
(e.g., tower-mounted terminals, fenced/secure areas of rooftops,
locked rooms with strictly-controlled access, etc.). There are no
special requirements for a LightPointe Communications FSO system
installed in a controlled area.
The laser system shall be installed in accordance with ANSI Z136.1
control measures (engineering, administrative, and procedural
controls).
1.2.1. Laser Safety Labels
All relevant labels are affixed to the inside of the link head near the
laser aperture.
The warning labels are affixed to the outer shell of the link head.
Caution: Do not modify this certified laser product.

505-016300-00000 Rev A
2-1
2. System Installation and Alignment
This chapter covers the following main topics
Major system components
Recommended installation tools and test equipment
Site review
Site installation preparation
Installation
Link head alignment
2.1. Major System Components
2.1.1. Universal Mounting Kit
The universal mount is used for pedestal or wall mounting of the link head in
external environments. The mounting must be ordered with the Medium Pan
and Tilt assembly as described in the next section.
Base Plate
Head Plate
Mounting Post
Figure 2-1: LightPointe Universal Mounting Kit
Linkhead
Pan & Tilt Assymbly
Head Plate
Mounting Post
Base Plate

FlightTransport Installation Guide
2-2
505-016300-00000 Rev A
2.1.2. Medium Pan and Tilt Assembly
The pan and tilt hardware is used for coarse alignment of the link head
and mounts to the Universal Mounting Kit described above.
Figure 2-2: Medium Pan and Tilt assembly
2.1.3. Optional Indoor FlightLite Wall-Mount Arm
The FlightLite mounting arm may be used for wall mounts in an indoor
or protected location. The arm mount is not fully rated for longer term
or extended exposure to the outdoor environment. The Pan and Tilt
Assembly is not required for the Indoor Wall Mounting Arm assembly.
Figure 2-3: Indoor FlightLite Wall-Mount Arm

FlightTransport Installation Guide
505-003686-00000 Rev A
2-3
2.1.4. Three methods to power the FL 100
Table 2-1: FlightPower Power Supply Options
Power Supply Description
LPS-APOE LightPointe Power Over Ethernet PSE Adaptor
LPL-A12 LightPointe Standard Ruggedized AC Power Supply 90 – 240
VAC, 50/60Hz supplying 12 VDC to the linkhead
Direct ±12 to ±48V
DC
The linkhead will accept any DC input voltage from 12 to 48
Volts. If there is a local DC power supply, UPS or battery
plant, power the linkhead from the input pins on the rear
panel using the connector supplied with the linkhead
The most straightforward way to power the linkhead is with the Power
Over Ethernet power inserter. This eliminates the need for AC power
run to the mounting location of the linkhead – often on the roof of the
building.
Figure 2-4: FL 100 Powering Options
Router/Mux/Switch
POE Power
Inserter
(
Indoor
)
Category 5 UTP
100 – 240VAC
DC Power feed
to Linkhead
Standard
Power
Supply
(Outdoor)
90 – 240VAC or ±
48VDC
Router/Mux/Switch
Category 5 UTP
Power Over Ethernet Powering LightPointe Standard
Power Supply Powering

FlightTransport Installation Guide
2-4
505-016300-00000 Rev A
2.1.5. Power Over Ethernet Powering Method
The FPW PSE FL100 Power Over Ethernet injector consists of the
following components:
Figure 2-5: Power Over Ethernet Power Supply components
The Power Injector is equipped with a powered and a non-powered RJ
Port. Use the Non-Powered port to connect data into the Network
Equipment, hub, switch or router. The Injector is plugged into
commercial AC. The Injector places power over up to 100 meters of
Cat 5/6 Unshielded Twisted Pair wiring to power the linkhead from the
powered RJ Port.
2.1.6. Local AC Power Supply at linkhead
A weatherproof outdoor local power supply may be provisioned at the
linkhead mounting location in place of the POE injector:
INPUT OUTPUT
Indicator Lamps for
Input and Output
Voltage
Primary Fuse 0,8 A
Output 1 Output 2
Input
Selector switch
110/230V
Secondary Fuse 4 A
Figure 2-6: FlightLite100 (LPL-A12) Power Supply Assembly
Category 5 UTP
100 – 240VAC
Power Cord
POE Power
Injector
DC Cord

FlightTransport Installation Guide
505-003686-00000 Rev A
2-5
This assembly provides:
Capability to power the linkhead using 90-240 VAC 50/60Hz power.
Dual power outputs to power one or two link heads
Input and output power LED indicators
2.1.7. Link Head Assembly
The link head and pan and tilt hardware are mounted on the head
plate assembly.
Linkhead
Pan & Tilt assy
Figure 2-7: Link Head and Pan and Tilt Assemblies
The link head assembly consists of:
A waterproof linkhead rear cover
A 10/100 copper interface for data connections and power
An optional connector for local alarms and powering
Optics, Laser Transmit, and Receive assembly
An alignment telescope
User Interface back panel with a full set of local diagnostics and
status indicators.
The linkhead is the smallest replaceable component.
In the event of failure, there are no replaceable parts inside the
linkheads- return the entire linkhead unit in the original
shipping container.
Empty shipping boxes are available.

FlightTransport Installation Guide
2-6
505-016300-00000 Rev A
2.2. Recommended Survey and Installation Tools
The following tools and supplies may be needed for survey,
installation, testing, and maintenance of the LightPointe system
hardware.
Site Surveys:
Accurate scaled map for locating sites and doing rough distance
calculations
Laser range finder binoculars with 1000 meter range (as used by
golfers, hunters and target shooters) or GPS for accurate
distance measurement
Binoculars to assist in installation
Sketch pad to make rough drawings and notes (recommend
using LightPointe Field Engineering Guide)
Tape measure to determine approximate short distance fiber,
power runs, etc.
Camera (digital recommended) to photograph installation sites to
reduce need for return visits to sites (optional)
Installations:
Standard electro-mechanical tool kit with pliers, screwdrivers,
wire cutters, wire strippers, etc.
Two-way radio or cell phones to communicate when aligning link
heads
Plastic tie wraps to secure flexible conduits, etc.
Two each 6mm hex (Allen) wrenches to supplement wrenches
shipped with the equipment
13mm socket or open end wrench for mounting bolts
Electrical tape for securing and fastening
Measuring level to evaluate flatness of mounting surfaces
The tape measure and camera from the site survey can also be
helpful in completing and documenting site installations
Category 5/6 cabling integrity tester
