Lightwell LW-SY Spring Eye User manual

IK
08
A
230V~ 50/60Hz
IP65
ta
30°C IEC
EN60598
GB
7000
Spring Eye
Maximum Windage: 0,132m2
A
402mm
B
523mm
C
574mm
D
50mm
kg
9.5kg
8
8718843021152 LW-SY Installation manual EN 1.0 - www.lightwell.eu
90mm
2xM8
13 N.m+0
-1
4
LW-SY Spring Eye
6
A B
C
D
5

B
C
D
23
8718843021152 LW-SY Installation manual EN 1.0 - www.lightwell.eu
1 2
BROWN - L
BLUE - N
YELLOW-GREEN - G
1 2
BROWN - L
BLUE - N
+15°
-15°
1xM10
13 N.m+0
-1
4
Open Close
4
2xM6
13 N.m+0
-1
3
56
x= Max. dist. 10mm
x
x
1
1
1
1xM6
13 N.m+0
-1
3
x
2
123

E
1. Do not install this xture in water or close to re.
2. This xture must be installed by a qualied electrician conform the last IEEE electric
regulations of national standards.
3. Check if the screw cap on this xture are closed correctly to ensure watertightness.
4. Do not connect this xture to power before installation is complete.
5. Wiring instructions: the external cable has to be connected to a terminal block inside
the pole, in an enclosure of which the IP value has to be higher than the IP value of the
xture. The terminal block must have a xation possibility for wiring. The terminal
block must be in accordance with EN 60998-2-1 or EN 60998-2-2 (Specication: three
cores, at least 250V and 1,5 mm2).
6. The external cable must at least have 3 cores (Class 1) or 2 cores (Class 2) with a
minimal cross-sectional area of 1,5 mm2. The external cable has to pass the 60245 IEC
57 restrictions.
7. If any of the exterior components are broken, then a full replacement of the
luminaire is required. If only the metal top is broken, a replacement is possible. Please
contact us.
8. If the external exible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar qualied
person in order to avoid a hazard.
9. The xture must be install in such a position that prolonged staring into the
lightsource from a distance closer than 0,406 m is not expected
10. The light source contained in this luminaire shall only be replaced by the
manufacturer or his service agent or a similar qualied person.
!
8718843021152 LW-SY Installation manual EN 1.0 - www.lightwell.eu
