LIGNEUS 4-Tier A-Frame User manual

4-Tier Wooden A-Frame 486x530x1455 For more information visit https://ligneus.co.uk/a-frames
Ligneus Products Ltd. Hangar 107, Aston Down Business Park, Stroud Gloucestershire. GL6 8GA • Tel: [phone] • Email: [email protected] • www.ligneus.co.uk
4-Tier A-Frame
What’s included:
Parts:
Legs 3 unique boxes 1 base & casters Top Panel
Tools & fixings:
Bolts Nuts Allan Key
What you will need:
•A basic level of DIY experience

4-Tier Wooden A-Frame 486x530x1455 For more information visit https://ligneus.co.uk/a-frames
Ligneus Products Ltd. Hangar 107, Aston Down Business Park, Stroud Gloucestershire. GL6 8GA • Tel: [phone] • Email: [email protected] • www.ligneus.co.uk
Products covered in this guide:
Name
MPN
GTIN
Rustic Brown 4-Tier Frame
DS4FP-4865301455RB
5060632682369
Black 4-Tier Frame
DS4FP-4865301455BK
Amberley Grey 4-Tier Frame
DS4FP-4865301455AG
Kingscote Blue 4-Tier Frame
DS4FP-4865301455KB
Tetbury Green 4-Tier Frame
DS4FP-4865301455TG
Gretton Grey 4-Tier Frame
DS4FP-4865301455GG
Assembly instructions:
Please refer to diagrams overleaf
1. Clarify the front and back of each leg. This is determined by the
holes. The lower holes indicate the front edge.
2. Clarify the order of each box. The hole configuration widens toward
the base.
3. Using 2 of the M6x30 bolts connectors and 2 M6x17 nuts fix base box
to one leg. Only loosely tighten the connectors
4. Using 2 of the M6x30 bolts connectors fix top panel to the same leg
5. Now fix the other leg to the base box and top panel creating a frame
6. Now slide in the 3 tiered boxes and fasten
7. When all boxes in place tighten all connectors.
Do contact us if you are unsure of the assembly instructions
Maintenance:
These A-Frames are robustly manufactured so should be very
comfortable in a busy environment. We do however recommend a wipe
over with a damp cloth from time to time and also a visual check over for
any defects and tighten any fastenings as appropriate.
We recommend keeping these assembly instructions in a
safe place for future reference. You can also scan the QR
code for an electronic copy
