linarie CALEDONIA RAHID50BG User manual

Island Rangehood RAHID50BG
www.linarie.com.au

TABLE OF CONTENTS
Correct Conditions of Use
The appliance is intended for use in the home and similar
environments only. It is not intended for commercial use.
The appliance is not suitable for outdoor use, non-stationary
installation (e.g. on ships, vehicles), or heating rooms.
It must only be used to extract vapors and remove odors
from cooking. Any other usage is at the owner's risk.
Wherea recirculation rangehood is fitted above a gas
cooktop, please ensure that there is an adequate supply of
fresh air into the room in which it is installed. Please seek the
advice of a qualified gas fitter if necessary.
Linäriedoes not assume any liability for damage
arising from non-adherenceto thesedocuments
and from improper assembly. The electricity connection
must be made by a qualified specialist. Installation must
comply with the valid standards, regulations and laws. All
safety and warning information and the operating and
installation instructions must be complied with.
Additional information on products, accessories,
warranty, replacement parts and services can be
found at www.linarie.com.au
1. General Information .............................. 03
1.1 Appliance information
2. General Safety Instructions .................... 03
2.1 General safety information
2.2 Safety instruction - Installation
2.3 Exhaust air Operation ..............................04
2.4 Correction use & Operation
2.5 Disassembling and Disposal
of the Appliance......................................05
2.6 Accessories and Spare parts
3. Description of the Functions ...................05
3.1 Air extraction mode
3.2 Recirculation mode
4. Technical data sheet ...............................05
5. Installation .............................................06
5.1 Pre-installation
5.2 Safety distance
5.3 Installation tips/
5.3 Installation {External ventilation}
5.4 Installation {Air extraction} ......................09
6. Operation .................................................09
6.1 Control panel and function keys
6.2 Remote control and features.......................10
6.3 Pairing remote control with
appliance
6.4 Energy saving tips
7. Troubleshooting ........................................11
8. Cleaning and maintenance .......................12
8.1 Stainless steel
8.2 Control panel
8.3 Cleaning agents
8.4 Aluminum grease filter
8.5 Removing the aluminum glass filter
8.6 Activated carbon filter ................................13
8.7 Replacing lamps
9. Environmental tips ....................................14
10. Warranty and After sales service
2
CONGRATULATIONS
Congratulations and thank you for choosing Linärie to
introduce a new comfort of cooking in your home. We are
sure you will find your new appliance a pleasure to use and
a great asset to your kitchen.
This appliance complies with all relevant safety
requirements in Australia. Inappropriate use can, however,
lead to personal injury and damage to property.
In order to operate the unit correctly and safely, please read
this instruction manual carefully before installation and
usage. This user manual which provides you with all
required instructions related to safety, installation, use and
maintenance of the appliance.
For future reference, please store this booklet in a safe place
and ensure that all users are familiar with the contents. Pass
them on to any future owner of the
appliance.
Record Model & Serial Number
Model:.............................................................................................................................
Serial Number .........................................................................................................
Register your product www.linarie.com.au
Adherenceto the directions for use in this manual is extremely
important for health and safety. Failure to strictly adhereto the
requirements in this manual may result in personal injury, property
damage and affect your ability to make a claim under Linärie’s
manufacturer’s warranty provided with your product. Products must
be used, installed and operated in accordance with this manual. You
may not be able to claim on Linärie’s manufacturer’s warranty in the
event that your product fault is due to failure to adhere this manual.

Cleaning & Maintenance
1. GENERAL INFORMATION
2. GENERAL SAFETY
A damaged appliance can be dangerous. If you find the
appliance is damaged or marked, you must report it within
7 days if you wish to claim for damage/marks under the
manufacturer’s warranty. This does not affect your statutory
rights. Do not use a damaged appliance.
The manufacturer's warranty will be invalidated if the
appliance is not repaired by a Linärie approved service
technician.
Faulty components must only be replaced by genuine Linärie
spare parts. The manufacturer can only guarantee the safety
of the appliance when Linärie replacement parts are used.
If the power cord is damaged, it must only be replaced by a
Linärie authorized service technician or suitably qualified
electrician in order to avoid a hazard.
Linärie cannot be held liable for noncompliance with these
instructions, resulting from incorrect or improper use or
operation.
1.1 Appliance Information
Unauthorized Modifications
Unauthorised modifications can cause the appliance to
pose risks. Do not conduct any modifications to the
appliance.
The device must be cleaned regularly. Dirt can lead to
damage or the buildup of odors. (See “Cleaning and
maintenance” section).
Always clean the appliance exactly as indicated in
the operating instructions.
Always ensure the appliance is switched off before
cleaning or replacing parts.
Clean the appliance immediately after any food
spillage and the filter regularly to keep the appliance
working efficiently.
There is a risk of fire if cleaning is not carried out as
described in these operating instructions.
Make sure no water penetrates inside the device when
cleaning. Do not use a steam cleaning appliance to
clean this appliance. The steam could reach electrical
components and cause a short circuit.
In areas which may be subject to infestation by
cockroaches or other vermin, pay particular attention to
keeping the machine and its surroundings in a clean
condition at all times. Any damage which may be
caused by cockroaches or other vermin will not be
covered by the machine warranty.
2.1 General Safety Instructions
Children and People with Special Needs
2.2 Safety Instructions - Installation
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
The appliance must only be installed and assembled by trained
specialists who are familiar with and comply with the standard
national regulations and supplementary regulations of ventilation
systems.
The appliance is NOT suitable for use by children
without supervision.
Young children should be supervised near the appliance
to ensure they do not play with this appliance.
Children may be able to wrap themselves in packing
material or pull it over their heads with the risk of
suffocation. Keep children away from any packing
material.
In order to avoid any potential hazard, the installation
instructions must be followed.
Observe all regional regulations for the installation of
ventilation systems.
During installation, maintenance and repair work, the
appliance must be disconnected from the mains electrici-
ty supply. It is only completely isolated from the electricity
supply when:
– the mains circuit breaker is switched off, or
– it is switched off at the wall socket and the plug is
withdrawn from the socket.
Do not pull the mains connection cable but the mains
plug to disconnect your appliance from the mains
electricity supply.
Refer to the cooktop manufacturer's instructions as to
whether a rangehood may be operated above the
cooktop.
If the rangehood is used with cookers that burn gas or
other fuels, there must be adequate ventilation in the
room.
Insufficient distance between the cooktop and the
rangehood can result in damage to the rangehood. The
minimum safety distances between the top of the
cooktop and the bottom of the rangehood given in the
"Installation" section must be maintained, unless the
cooktop manufacturer states that a greater distance is
required. If more than one cooking appliance is fitted
beneath the rangehood, and they have different
minimum safety distances to the rangehood, select the
greater distance.
3
The appliance complies with the stipulated safety
requirements in Australia. The user is responsible for
appliance cleaning and maintenance as well as its safe
use. Improper use can lead to personal injury and
damage to property.
INSTRUCTIONS

Ensure that all specified vents, openings and airspaces
are not blocked.
All ducting, pipework and fittings must beof non-flam-
mable material.
The appliance must not be connected to a chimney or
vent flue which is in current use for exhausting fumes
from appliances burning gasorother fuels. Neither
should it be connected to ducting which ventilates rooms
with fireplaces. (See “Exhaust Air Operation” section).
Do not connect the appliance to the mains electricity
supply by a multi-socket unit oran extension lead.
Extension leadsare a fire hazard and do not guarantee
the required safety ofthe appliance.
Tampering with electrical connections or components
and mechanical parts is highly dangerousto the user
and can cause operational faults. Only open the
housing asdescribed in the instructions given in
“Installation” and in the “Cleaning & Maintenance”
sections ofthis booklet. Under no circumstances should
any other parts ofthe housing beopened.
THIS APPLIANCE MUST BE PROPERLY EARTHED. It is
most important that this basic safety requirement is
present and tested regularly and, where there is any
doubt, the household wiring system should be inspected
by a qualified electrician.
Linärie cannot be held liable for noncompliance with
these instructions, resulting from incorrect or improper
use oroperation.
2.3 Exhaust Air Operation
2.4 Correction Use & Operation
4
WARNING
Danger ofpoisoning from recirculated exhaust gases! Do not
operatethe appliance in extract air mode if it is operated together
with a roomair-dependent fireplace and sufficient air circulation is
not guaranteed.
CAUTION
The rangehood can get very hot during cooking dueto heat rising
from the cooktop. Do not touch the housing orthe grease filters
until the rangehood has cooled down.
For safety reasons, this appliance may only beused after
it has been built in.
Reliable and safe operation ofthis rangehood can only
be assured if it has been connected to the mains electric-
ity supply.
Before using the appliance, ensure that all packaging
materials are removed from the appliance and make
sure that the connection data onthe data plate [voltage
(V) and frequency (Hz)] indicated onthe rangehood
correspond to the voltageand frequency ofthe power
supply in your household. Consult a qualified electrician
if in doubt.
DO NOT use the rangehood without the filters in place.
This way you will avoid the risk ofgrease and dirt getting
into the appliance and hindering its smoothoperation.
Never use anopen flame beneaththe rangehood. To
avoid the danger of fire, do not flambé orgrill over an
open flame. When switched on, the rangehood could
draw flames into the filter. Fat deposits could ignite,
presenting a fire hazard.
DO NOT store or spray flammable materials in the
appliance or near this appliance while it is in operation
(e.g. aerosols).
The rangehood can become damaged when exposed
to excessive heat.
– When using the rangehood over a gas cooktop,
ensure that any burners in use are always covered by a
pan. Switch the cooking zone off when a pan is
removed, even for a short time.
– Select a panwhich is suitable for the size ofthe
burner.
– Regulatethe flame so that it does not burn up the
sides ofthe pan.
– Avoid overheating the pan (e.g. when cooking with a
wok).
Always switch the rangehood onwhen a cooking zone
is in use, otherwise condensation may collect in the
rangehood, which could cause corrosion.
When cooking with oil or fat, chip pans and deep fat
fryers etc., do not leave the pans unattended. Never
leave anopen grill unattended when grilling. Over-
heated oil and fat can ignite and could set the range-
hood on fire.
Safe operation is only possible if the negative pressure at
the location ofthe fireplace does not exceed 4 Pa (0.04
mbar). This can beachieved if the air required for
combustion can flow in through non-closable openings
in doors and windows in conjunction with a supply air /
exhaust air wall box. Inany case, have a master chimney
sweep advise you and assess the entire ventilation
system ofthe house. If necessary, they can tell you the
necessary measure for ventilation.
If the rangehood is used exclusively in recirculation
mode, where the air is directed back into the room in
which it is located, operating a heating appliance
which depends onthe roomair at the same time is not
hazardous.
Roomair-dependent fireplaces such asgas, oil, wood or
coal heaters, boilers or instantaneouswater heaters draw
the air from the roomand lead it outdoors throughan
exhaust pipe or chimney. In extract air mode, air is
extracted from the kitchen and neighbouring rooms.
Without sufficient supply air, negative pressure is created.
The heating appliance will be starved ofoxygen, impairing
combustion. Toxic gases from the chimney or exhaust pipe
can be sucked back into the living rooms.
Make sure that sufficient fresh air supply is guaranteed
and that the air can circulate.
A supply air/exhaust air wall box is not sufficient to
ensure compliance with the limit value.

Parameter Value
Power Supply Voltage
Dimensions
(width, depth x height)
50 x 40 x 86
176cm
Carton Size
(width, depth x height)
61.5x50.5 x
52.5cm
Weight (incl. accessories /
packaging) 23.3kg
Weight (NOT incl. accessories /
packaging)
19.3g
Rangehood
Power Levels 3 Speeds
Electronic Control Yes
Max. Air Extraction Power 700m3/h
Motor Power 190W
Rated Lamp Power (x2) 1.5W
Sound Power Level <71dB(A)
Filter
Aluminum/Stainless Steel Surface 5 Layers
Accessories
Remote Control (Wireless) Yes
Appliance Dimensions
5
3. DESCRIPTION OF THE FUNCTIONS
2.5 Disassembling and Disposal of the
Appliance
3.1 Air extraction mode
Non-return flap
2.6 Accessories and Spare parts
Depending on the model of the rangehood, the following
options are available:
The air is drawn in and cleaned by the grease filter and
directed outside.
The air is drawn in and cleaned first by the grease filter
and then by a charcoal filter. The cleaned air is then
recirculated back into the kitchen.
When using recirculation mode, ensure a sufficient
supply of fresh air, e.g. by openingawindow.
4. TECHNICAL DATA SHEET
(see the “Environmental Tips” section for best practices on
disposing of this appliance).
The device must only be disassembled by trained special-
ists who are familiar with and comply with the standard
national regulations and supplementary regulations of the
local utility companies.
Work on electrical components must only be conducted by
trained electrical personnel.
The non-return flap is designed to prevent the exchange of
room and outside air taking place. The flap is closed
when the rangehood is switched off. When the rangehood
is switched on, the non-return flap opens for the cooking
vapors to be blown directly outside. If the on-site ventila-
tion system does not have a non-return flap, the nonreturn
flap supplied must be fitted.
Ensure a normal and comfortable room climate (humidity
of 45–60%), e.g. by opening natural ventilation openings
or using domestic ventilation systems.
After every use in recirculation mode, switch the range-
hood to a low level for about 15 minutes.
Incorrect components can lead to personal injury or
damage to the appliance. Only use original Linärie spare
parts for repairs.
Modifications, additions or alterations to the appliance
can lead to safety risks. If spare parts or accessories from
other manufacturers are used, the warranty will be
invalidated, and Linärie cannot accept liability.
Please check www.linarie.com.au for more information.
3.2 Recirculation mode
Activated carbon filter (CF110) Yes
220-240V ~
50Hz 255
25
360
400
255
500
500-1400
150

5.1 Pre-Installation
5.2 Safety Distance Cooking appliance Min. Distance
Electric cooktop (AU, NZ)
Electric grill, deep fat fryer (electric) 650 mm
600mm
Multi-
MJ/h total output, with no burner having a
greater output than 16.2 MJ/h.
650 mm
Multi-burnergas cooktop with total output
greater than 45.4 MJ/h, but with a maximum
of 77.8 MJ/h, with no burner having a greater
output than 17.3 MJ/h.
760 mm
Multi-burnergas cooktop with total output
greater than 77.8 MJ/h, with a single burner
having a greater output than 17.3 MJ/h.
Not possible
Single burnergas cooktop with a maximum
output of 21.6 MJ/h. 650 mm
Single burnergas cooktop with an output
greater than 21.6 MJ/h, but with a maximum
of 29.2 MJ/h.
760 mm
Single burnergas cooktop with an output
greater than 29.2 MJ/h. Not possible
5.3 Installation [External Ventilation]
Mounting of V-flap
Before installation, it is important to read the information given on
the following pages as well as the "General Safety Instructions"at
the beginning of thisbooklet. Failure to install the appliance
correctly could invalidate any warranty or liability claims and lead
to prosecution.
If you are fittingafront panel made of wood or plastic to the
rangehood, observe the safety distances givenby the cooktop
manufacturer regarding the use of easily flammable materials.
To achieveoptimum vapor extraction, the rangehood must
cover the cooktop. It should be positioned centrally over the
cooktop, not to the side.
The cooktop should be no wider than the rangehood and, if
possible, it should be narrower, especially for safety distances
greater than 750 mm.
The installation area must be easily accessible. The rangehood
should be easily accessible and easy to dismantle in the event
that service is required. This should be taken into consideration
when planning the position of cupboards, shelves, ceilings or
features in the vicinity of the rangehood.
If the rangehood does not have a pre-assembled V-flap, install
the parts as follows:
1. Install the first half into the housing
2. The pin should be facing upwards.
3. The axle is inserted into the holes on the housing.
4. Repeat all the steps for the second half of the flap.
Before installing the rangehood, peel off any protective
plastic covering and remove polystyrene from inside
behind the fan motor.
The minimum distances between the highest part of a
cooktop (including trivets, dials - depending on model)
and the bottom of the rangehood are as follows, unless a
greater distance is specified by the manufacturer of your
cooking appliance. See also "General Safety instructions"
section.
5.3. Installation Tips
Note direction
whenattaching
1 2
Flaps
Housing
5. INSTALLATION
6
If you have an air outlet to the outside, the
rangehood can be connected via an extraction
duct (enamel, aluminium, flexible pipe or
non-combustible material with an internal
diameter of 150 mm) as shown on the left.

NOTE:
cont.. installation
7
1. Before installation, make sure to switch off the main switch.
2. The ceiling must be able to supportaweight of atleast 120kg
and the thickness of the ceiling must be equal of greater than 30cm.
3. Rangehood should be position at a distance of 65-75cm for optimal
efficiency.
a
b
36cm
65-75cm
c
a - ceiling to floor distance =
Measure the distance between the ceiling ang the floor.
(refer to the image on the right)
b - cook top =
c - length of the rope =
1
M10 screw nut
Screw barrel
Hanging
board
(upside down)
Attach the screw cylinder to the hanging board
using 2 M10 screw nuts as shown below.
2Attach 4 adjustable screws to the hanging board.
Align the screw and do not over tighten.
3
Pass wire ropes through the adjustable screws.
and fix using clamping screw and nut.
Make sure to measure ropes according to length
on step 1.
4
Mark the ceiling with (8) corresponding holes from
the hanging board. Then make holes usingadrill.
5
1mm
1
2
Pass through the wire rope to the cover.
Match the hole for the power cord.
6
Secure the cover using the lock nut.
7

cont. installation
8
Insert wire rope to rangehood hole as shown.
Secure it with countersunk screws (ST4x8mm).
8Loosen the cover lock nut 9
Insert power cable to rangehood cover plate
and connect to the cables coming out of the ceiling.
Secure connected wires with insulating tape.
10 Slowly loosen adjusting screws and align rangehood
horizontally. Tighten the wire ropes evenly.
11
Re-attach the rangehood cover.
Make sure power cable is secured.
12
1
2

WARNING
5.4 Installation [Air Extraction]
The following rules must be strictly observed to
achieve optimum air extraction.
6.1 Control Panel and Function Keys
Timer Button
Light Button
Speed Button
Power Button
TimerLampSpeed Power
Make sure that the exhaust pipe extends as short and
straight aspossible.
Do not reduce the size or restrict the exhaust pipe. When
using exhaust air pipes, always install the pipe tightly to
minimise pressure loss.
Non-compliance with these basic instructions will reduce
the performance and increase the noise level ofthe
rangehood.
All installation work must be carried out by an
electrician ora qualified person.
Best results are obtained by using a low speed for
normal conditions and a high speed when odors are
more concentrated.
Turn the hood on for a few minutes before you start
cooking.
The hood should be left on for 15 minutes after
cooking oruntil all odors have dispersed.
The control switches are located onthe front panel of
the unit. See Imagebelow.
When the rangehood is in operation and the TIMER
button is pressed, the rangehood switches to timer
mode. Press again to exit the timer function. The
above steps can beoperated repeatedly.
The default setting is 9 minutes. The timer then starts
counting downthe time. The remaining time is
shown in the display: 9 >8 >7 >6 >5 >4 >3
>2 >1 >0. When [0] is shown, the rangehood is
automatically switched off.
Press and hold the TIMERbuttonto deactivatethe
timer again.
Press the LIGHT buttonto switch onthe light. Press
the buttonagain to switch it off.
The lamp function could beoperated without
pressing the power button.
The motoroffers 3 speed levels: low/1, medium/2
and high/3.
Press the INCREASE / REDUCE button several times
to run the motorat the following power: low >
medium > high > low. LED display showsthe
corresponding speed: 1 >2 >3 >1.
Press the POWER buttonto switch the rangehood on
and off.
Do not connect the exhaust pipe ofthe rangehood to an
existing ventilation system used for another appliance,
e.g. a flue, gaspipes or hot air pipes.
In case the exhaust air pipe is bent, the angle ofthe
exhaust air pipe should not be less than 120°. Never
point the exhaust air pipe downwards, but always
horizontally orguide the pipe from the starting point
upwards to the air outlet onthe outside wall.
After installation, please make sure that the rangehood is
positioned horizontally to prevent grease from
accumulating.
Make sure that the exhaust pipe selected for installation
complies with the relevant standards and is fire-retardant.
CAUTION
Before installation, it is important to read the information given
on the following pages aswell asthe "Appliance Dimensions"
and the "Warning and Safety instructions" sections at the
beginning ofthis booklet. This is particularly crucial when using
the rangehood at the same time asa heating appliance that
relies onoxygen from the same room, which could result in the
build-up oftoxic fumes.
The rangehood should be installed according to local and
national building regulations. Seek approval from the building
inspectorwhere necessary.
CAUTION
Risk of injury! For safety reasons, only use the size of fastening or
mounting screw recommended in these operating instructions.
Non-compliance with these instructions can lead to injuries and
electric shocks.
Remember that any constriction ofthe airflow will reduce extraction
performance and increase operating noise.
NOTE
The rangehood may only beoperated when the aluminum
stainless steel grease filter and ofthe rangehood is installed
(see “Installation Instructions” section).
Clean the cooking zone before using the cooktop for the
first time (see the “Cleaning” section).
Observe all safety and warning information during
operation (see the “General Safety Instructions” section).
6. OPERATION
9

Setting the timer
The remote control must establish a new connection with
the rangehood in order to beused.
Pairing the Remote Control
Pairing the Remote Control
6.2 Remote Control and Features
6.3 Pairing remote control with your Appliance
6.4 Energy Saving tips
Light Button
Reduce speed
Timer button
Increase speed
Press the buttonto switch onthe light. Press the
buttonagain to switch it off. The light is independent
of other functions.
Each time you press the button, the speed is
decreased. The display indicates the corresponding
speed. Ifyou want to switch off the motor,
press the buttonuntil the motor stops.
Press the buttonto activatethe timer function.
The timer is initially set to 5 minutes. Each time you
press , the time is increased by 1 minute. Each time
you press , the time is reduced by 1 minute.
Atime of1-60 minutes can be set.
Once you have set the timer, press the button
again to confirm orwait 10 seconds until the set time
is automatically. The motor runs until the time you set
runs out, then it switches off automatically.
In case you want to use the timer with the same time,
just press the TIMER buttonand then wait 10 seconds.
If you want to enter a different time, proceed as
described in steps 1 and 2.
Each time you press the button, the speed is
increased to the next level. The display indicates the
corresponding speed. Ifyou want to switch off the
motor, press the buttonuntil the motor stops.
Turn the rangehood onand long press the power
button for 5 seconds. The indicators light will flash
from one buttonto another which means the range-
hood is in connection mode.
Press any buttonon remote control to confirm the
connection. The remote control can beused to control
the rangehood: power on/off, speed control, light,
timer.
This rangehood operates very efficiently and economically.
The following will help you to save even more energy when
using it:
Ensure that there is sufficient ventilation in the kitchen
when cooking. In extraction mode, if there is
insufficient air flow the rangehood cannot operate
efficiently and this causes increased operating noise
levels.
Always cookwith the lowest possible setting. This
produces fewer cooking vapors, so you can use a
lower rangehood power level and therefore benefit
from reduced energy consumption.
Check the power level selected onthe rangehood. A
lower power level is generally sufficient for the majority
of cooking. Only use the Booster setting when
necessary.
When a large volume of cooking vapors is being
produced, switch to a high-power level in good time.
This is more efficient than operating the rangehood
for longer to try to capture cooking vapors which have
already been distributed throughout the kitchen.
Make sure that you switch the rangehood off after use.
Clean or change the filters at regular intervals. Heavily
soiled filters reduce performance, increase the risk of
fire and are unhygienic.
To establish a new connection, you will need to reset
the previous connection.
To reset the existing connection, long press the power
buttononthe rangehood for 5 seconds. The indica-
tors light will flash from one buttonto another. Then
long press the power button for 5 seconds again so
that the existing connection is cleared.
Once the previous connection is reset, the rangehood
will go into standby mode. Then, repeat the steps
above to connect the rangehood to a new remote
control.
If you want to end anactive timer prematurely, press the TIMER
buttonwhile the timer is running.
NOTE
10
www.linarie.com.au

Problem Possible Cause Possible Solution
The light turns on but
the motor does not
run.
The motor is switched off. Switch on the motor with the SPEED button.
The motor switch is broken. Contactaspecialist company.
The motor is broken. Contactaspecialist company.
Lights and engine
do not work.
Your mains security fuse is
flipped or broken. Flip the fuse switch or replace the fuse..
The power cable is loose or
not connected.
Connect the power cord correctly.
The light does not
work. The light is broken. Replace the bulb..
Unsatisfactory suction
performance.
The rangehood hangs
crooked.
The rangehood has
switch off during
operation.
The distance between the
cooker and the rangehood
is too far.
Reduce the distance.
Check that the fan speed is set high enough for the task.
Clean the grease filter.
One of the fixing screws is not
propely tightened. Tighten the screw securely.
Turn off the hob and wait for the deviceto reset.
7. TROUBLESHOOTING
Checkto see if the kitchen is adequately vented to allow
the entry of fesh air.
If set up for recirculation, check that the charcoal filter
is still effective.
(recommended to be replaced every 2-3months)
If set up for extraction, check that the ducting and
outlets are not blocked.
Fix the distance. If the distance is not appropriate, the
motor will cut out frequently which willdamage the hood.
The safety cut-out device
has been tripped off.
The rangehood has been
installed below the heights
indicated in the installation
instructions.
11
www.linarie.com.au
WARNING
Any electrical repairsto thisappliance must conform to your local, state and federal laws. Please contact the service center if in any
doubt before undertaking any of the above. Always disconnect the unit from the power source whenopening the unit.
If you have completed all of the above checks and is still experiencing difficulty,
please contact your local Linärie Service Center (see the “Warranty and Spare Parts” sections).
Observe all safety and warning information during operation. ( see the General Safety Instructions” section)

The stainless steel must be cleaned regularly (weekly)
to ensure a long service life. Stainless steel surfaces
can be cleaned with a proprietary nonabrasive
cleaning agent designed specifically for use on
stainless steel.
Observe all safety and warning information during operation
(see the “General Safety Instructions” section).
Before maintenance or cleaning, the rangehood should always
be disconnected from the power supply. Make sure that the
rangehood is switched off and the plug has been removed.
Exterior surfaces are prone to scratches and dents. Therefore,
please follow the cleaning instructions to achieve the best
possible result without damage.
Do not use stainless steel cleaning agents on the controls.
Use neutral cleaning agents and avoid using harsh cleaning
chemicals, strong household cleaners or products containing
abrasive cleaners as this will affect the appearance of the
appliance and may remove the printed symbols on the control
panel.
An oversaturated filter is a fire hazard. The aluminum grease filter
in the appliance removes solid particles from the kitchen vapors,
grease, dust, etc., therefore, preventing soiling of the rangehood.
8. CLEANING & MAINTENANCE
8.1 Stainless steel
The control panel can be cleaned with warm soapy
water. Make sure the cloth is clean and thoroughly
wrung out before cleaning the control panel.
Usea dry, soft cloth to remove excess moisture after
cleaning.
The reusable aluminum filter can be cleaned by hand.
Soak them in water together with a grease-dissolving
detergent for about 3 minutes and then brush them
gently with a soft brush. Do not apply too much
pressure to avoid damaging the filter. Allow the filter
to air dry afterwards, but do not place it directly in the
sun. Filters should always be washed separately from
crockery and kitchenutensils!
The grease filter should be cleaned regularly (at least
every 3-4 weeks)to avoid a build-up of grease
When removing the grease filter do not tilt it down-
wards at an angle. This can damage the retaining
pins.
With the deflector plate pushed in, grip the front of
the deflector plate and hold the grease filter securely.
Whilst holding the grease filter, pull the deflector plate
out as shown.
Thenpull the filter downwards to remove it.
Switch off the fan.
8.2 Control panel
8.4 Aluminum grease filter
Grease filter cleaning intervals
8.5 Removing the aluminum grease filter
Cleaning the grease filter by hand
Remove the filter as shown in the image
below and reinsert the filter in reverse order.
8.3 Cleaning agents
Allow the applianceto cool down completely before cleaning and
maintenance.
The surfaces and controls are susceptible to scratches and
abrasion. Please observe the following cleaning instructions.
12
When handling a grease filter, be careful not to
drop it. This can result in damage to the filter
and the cooktop below. Make sure you hold the
filter securely at all times when handling it.
2
3
1

13
cont. cleaning and maintenance
Make sure that the filter is tightly closed. It can otherwise detach
and become dangerous. If an activated carbon filter is connected,
the suction power is reduced.
The lamps become hot when in use. Allow the lamps to cool
down completely before changing them.
The lamp must be replaced by the manufacturer, its after-sales
service or similarly qualified persons.
Always switch off the power supply before carrying out any work
on the appliance.
Always hold the lamp with a cloth or gloves when inserting or
removing it to ensure that sweat does not come into contact with
the lamp, as this can reduce its life.
If the rangehood is connected for recirculation,acharcoal
filter must be inserted in addition to the grease filter. This
is designed to absorb cooking odors.
The installation of the activated carbon filter is done as
follows:
Disconnect the rangehood from the power supply
before installation.
Press the filter lock and remove the main filter.
Rotate the carbon filter counter-clockwise on both
sides of the motor. Replace the old carbon filters with
new carbon filters.
Replace the main filters.
Reconnect the power supply.
The activated charcoal filter should be changed after 3 to
6 months, depending on your cooking habits. Allow the
applianceto cool down completely before maintenance.
Replacement charcoal filters can be obtained from
www.linarie.com.au
The used activated charcoal filter can be disposed with the
normal household waste.
Observe all safety and warning information during
operation (see the “General Safety Instructions”
section).
The lamps should be replaced with the following:
ILCOS D code: DSS-1.5/65-S-120/33
LED Type: Reactangle LED light
Wattage: 2 x1.5W
Voltage Range: DC 12V
Dimensions:
Disconnect the rangehood from the mains electrical
supply before replacing the lamps
Rotate the cover counter-clockwise. Loosen the screw
of the stainless-steel filter and remove it.
Press the light connector to remove the light bulb.
Install the new light and reconnect the cable.
8.6 Activated carbon filter
8.7 Replacing the lamps
To replace the lamps:
Installing and replacing the activated charcoal filter
When to change the activated charcoal filter?
Disposing of the activated charcoal filter
2
1 3
5
4
Open
Replace filter on both sides
Close

14
9.2 Disposing of your old appliance
9. ENVIRONMENTAL TIPS
10. WARRANTY & AFTER SALES SERVICE
The transport and protective packaging has been selected
from materials which are environmentally friendly for
disposal, and can normally be recycled.
Recycling the packaging reduces the use of raw materials
in the manufacturing process and also reduces the
amount ofwaste in landfill sites. Ensure that any plastic
wrappings, bags etc. are disposed of safely and kept out
of the reach ofbabies and young children. Danger of
suffocation.
Observe all safety and warning information during
operation (see the “General Safety Instructions” section).
Observe all safety and warning information during
operation (see the “General Safety Instructions” section).
Incorrect components can lead to personal injury or
damageto the appliance. Use only genuine original
Linärie spare parts.
Modifications, additions oralterations to the appliance
can lead to safety risks. If spare parts oraccessories from
other manufacturers are used, the warranty will be
invalidated, and Linärie cannot accept liability.
Please check www.linarie.com.au for more information.
Model:…………………………………………………………
Serial Number:.………………………………………………
Register yourproduct www.linarie.com.au
In the event ofa fault which you cannot remedy yourself,
please contact Linärie.
The manufacturer’s warranty for this appliance is 2 years.
The contact details for Linärie are given at the beginning
and ofthese instructions.
When contacting Linärie, please quotethe model and
serial number ofyourappliance. These can be found on
the data plate, after removing the grease filter.
Electrical devices marked with this label may not be
disposed of in domestic waste at the end oftheir service
life.
Electrical and electronic appliances often contain valuable
materials. They also contain specific materials, compounds
and components, which were essential for their correct
function and safety. These could be hazardousto human
health and to the environment if disposed ofwith your
domestic waste or if handled incorrectly. Please do not,
therefore, dispose ofyourold appliance with your house-
hold waste.
Please dispose ofthose materials by contacting yourlocal
authorities and ask for the correct method ofdisposal.
Please ensure that yourold appliance poses no risk to
children while being stored prior to disposal.
By disposing ofthis product in accordance with the
regulations, you protect the environment and the health of
those around you from negative consequences.
9.1 Disposal considerations
10.1 Warranty10.3 Replacement of spare parts
10.2 After sales service
Record model &serial number
www.linarie.com.au

LIKE TO
KNOW MORE?
© Linärie
