LINE LEADER AV SS-AVJ42C User manual

SS-AVJ42C
AV CART
[email protected]
Made in Taiwan
1-703-688-DESK (3375)
Contact Us:
www.standsteady.com

1
PRODUCT OVERVIEW
A (X1) B (X1) C (X2) D (X2)
G (X1)
E (X1)
1C (X2)
CART COMPONENTS
HARDWARE
F (X1)
1B (X4)
G
A
B
C
C
D
D
E
F
1A (X4) 1D (X2)

2
1A
QTY. 4
REQUIRED HARDWARE
STEP 1: ALIGN CART COMPONENTS STEP 3: SECURE CART COMPONENTS
Rest parts A&B on their side. Slide together until
the holes on the legs are aligned at the desired
height.
Secure parts A&B using 1A & 1B (x4)
1B
QTY. 4
STEP 2: ALIGN CART COMPONENTS
Flip lower cart assembly
(B) upside down. Install
casters (C&D) using
rubber mallet
REQUIRED TOOLS
A
B
1B
1A
Note: Open door to attach
1A (x4)
C
C
D
D
B

3
1D
1D
1C
QTY. 2
REQUIRED HARDWARE
STEP 5: ATTACH POWER STRIP
1C
F
E
1C
Stand up Cart. Secure parts E&F in
desired location using 1C & 1D (x2)
STEP 4: CHOOSE LOCATION
Power Strip can be installed in
multiple places on the cart.
*NOTE: Secure bracket/power
strip from inside cabinet
using 1D (x2)
1D
QTY. 2
