LINEAR SOUND LTS.EC2880 User manual
Linear Technologie • 11 rue du Puits Rochefort • 42 100 Saint-Etienne
Tél: +33 (0)4 77 81 49 49 • Fax: +33 (0)4 77 81 49 40 • www.lineartech.fr V.2017
WALL SPEAKER LTS.EC2880
Operation manual
Read the instructions carefully before installing the device.
Please follow the instructions of this manual in order to obtain optimum product results.
2
TABLE OF CONTENTS
Page 3
Page 3
Page 4
1. Safety instructions
2. Features
3. Installation
3
When used as indicated, this device is designed and manufactured to ensure your personal
safety. Nevertheless, improper use may cause a risk of electric shock or re. Please carefully
read all safety instructions and the user manual before any installation and use; keep them
for reference.
Pay attention to all warnings in these instructions and on the device.
• Water and moisture : Do not expose the unit to rain or moisture (near a bathtub, sink,
kitchen sink or laundry room, in a wet basement or near a swimming pool)
• Ventilation : The unit must be positioned so that its location or position does not interfere
with proper ventilation. For example, it should not be situated on a bed, sofa, rug or
similar surface that may block the vents; secondly, do not place it in a recessed area,
such as a bookcase or cabinet that may prevent air from owing through the vents.
• Heat : Place the unit away from heat sources such as radiators, heat registers, stoves,
or other device (including ampliers) that produce heat.
• Power sources : Before connecting, make sure the voltage is correct and that it is not
higher than that listed on the back cover of the unit, the operating manual or marked on
the unit.
• Make sure you place the device on a stable surface.
• Penetration by objects and liquids : Make sure nothing falls or no liquid ows into the
openings or vents of the product.
• Accessories : Do not use not recommended accessories by the product manufacturer.
• Protection against lightning and overload : Unplug the unit from the wall outlet and
disconnect the antenna or cable during a lightning storm or when left unattended and
unused for long periods. This will prevent damage to the unit due to lightning or a
temporary surge.
The unit must be repaired by qualied technicians.
1. SAFETY PRECAUTIONS
2. FEATURES
Power supply 100V 5W / 10W / 20W / 40W / 80W
Power supply 70V 2,5W / 5W / 10W / 20W / 40W
Impedance Black : COM / White : 2 KΩ
1 KΩ / 500Ω / 250Ω / 125Ω
Sensitivity 94 dB
Frequency response 100 - 17 KHz
Dimension 280 x 225 x 375 mm
Weight 6,2 kg
4
Step 1 : Attach the bracket to the wall with the provided screws.
Step 2 : Remove logo.
Step 3 : Unscrew the adjustable mounting system.
Step 5 : Using the key provided, screw the mounting rotating system.
7 mm
3. INSTALLATION
Step 4 : Place the speaker on the bracket.
