CEILING SPEAKER LTS.PL206A / LTS.PL249
Operation manual
Please follow the instructions in this manual to obtain the optimum results from this unit.
We also recommend that you keep this manual handy for future reference.
2
1. About this product
2. Safety precautions
3. Dimensions
4. Installation
5. Specications
Page 3
Page 3
Page 3
Page 4
Page 4
TABLE OF CONTENTS
3
These PL206A and PL249 loudspeakers broadcast pan-for hotels, commercial buildings,
supermarkets, schools, leisure and entertainment venues, is your ideal choice. For your
installation, commissioning and use of this product, the installation please read this note.
2. SAFETY PRECAUTIONS
Common warning signs and security
The manual shown warning signs and security is to prevent the improper operation due
to personal injury arising from the loss of property, please read before using this product
must understand that this manual security symbols and Warning to indicate fully aware of
potential risks.
Warning : Such as the inappropriate use of sta will cause injury, death and property damage.
When installed loudspeakers
• Restricted by the provisions of the speakers on the voltage, such as the us of high
voltage may cause electric shock or re disaster. Is no pruning, distorted, or replacement
of damaged wires.
• Avoid instability in the installation or set up speakers, such as shaking the table or at
surface , the speaker can avoid falling caused personal injury or property damage.
• Speakers will be installed in support of the speaker or the weight of a solid shelf. Speaker
swap can be avoided caused personal injury or property damage.
• Wet hands must not be admitted into or plugs, may lead to electric shocks.
• The allocation of plugs, make sure that pull plugs, rather than pull wires.
• The use of a damaged power line of machinery may cause re or electric shock.
• Mobile speaker, you plug the prior allocated. If the speaker and plugs may be moving
together will cause re or electric shock. For plugs,identied as plugs for grip.
• Will not be allowed to speakers on the vent cover. May cause intern heating caused by
the re.
• Avoid speakers installed in the humidity or dust, direct contact with the sun from the
near-electric, or smoke or steam, may cause re or electric shock.
1. ABOUT THIS PRODUCT
3. DIMENSIONS
4
Step 1 : With a measurement tool measuring speaker hole in the ceiling opening size, the
wiring through the hole to open a good connection on the speaker.
Step 2 : Separate speakers on both sides of the iron, so that the edge close to the ceiling
speakers, the merger places in the ceiling hole.
Step 3 : So that speakers and xed on the ceiling, and the completion of the installation of
speakers.
Model PL206A PL249
Power taps 100V 1,5W / 3W / 6W 3W / 6W / 9W
Power taps 70V 0,75W / 1,5W / 3W 1,5W / 3W / 4,5W
Impedance Black : Com, red : 6.7KΩ,
green : 3.3KΩ , white : 1.7KΩ
Black : Com, red : 3.3KΩ,
green : 1.7KΩ, white : 1.1KΩ
Frequency response 92 dB 92 dB
SPL (1W/1m) 110 Hz – 18 KHz 110 Hz – 18 KHz
Cutout size Ø170 mm Ø220 mm
Dimensions 200 x 55 mm 246 x 70 mm
Weight 0,8 kg 1 kg
5. SPECIFICATIONS
4. INSTALLATION
