Linear Technology DC1513B Quick setup guide

1
dc1513bf
DEMO MANUAL DC1513B
DESCRIPTION
LTM9004
14-Bit Direct Conversion
Receiver Subsystem
Demonstration circuit 1513 isan evaluation boardfeaturing
Linear Technology Corporation’s LTM
®
9004 14-bit direct
conversion receiver subsystem. DC1513 demonstrates
good circuit layout techniques and recommended external
circuitry for optimal system performance.
DC1513 comes with Linear Technology’s 14-bit LTM9004
receiver subsystem installed. The board includes out-
put CMOS buffers. DC1513 plugs into the DC890 data
QUICK START PROCEDURE
acquisition demo board and the output can be easily ana-
lyzed with Linear Technology’s PScope™ data processing
software, which is available for no charge on our website at
http://www.linear.com/software.
Design files for this circuit board are available at
http://www.linear.com/demo
Validating the performance of the LTM9004 is simple
with DC1513, and requires only two input sources, a
clock source, a computer, and a lab power supply. Refer
to Figure 1 for proper board evaluation equipment setup
and follow the procedure below:
1. Connect the power supply as shown in Figure 1. There
are onboard low noise voltage regulators that provide
the two supply voltages for the DC1513. The entire
board and all components share a common ground.
The power supply should still be a low noise lab power
supply capable of supplying at least 0.5A at 5VDC, and
1A at 3VDC.
2. Provide an encode clock to the ADC via SMA connec-
tor J7. Use a low-phase-noise clock source such as
a filtered RF signal generator or a high quality clock
oscillator.
NOTE:Similar to having a noisyinput, a highjitter (phase
noise) encode clock will degrade the signal-to-noise
ratio (SNR) of the system.
Table 2. DC1513 Connectors and Jumpers
REFERENCE FUNCTION
J3 (SHDN) Enables/Disables the ADC. Default Is ON.
J4 (MODE) Output Format and Clock Duty Stabilizer Pin.
Default Is VDD.
J5 (SHDN_AMP) Enables/Disables the Amplifiers. Default Is ON.
J6 (LO) Board LO Signal Input. Impedance Matched to
50Ω for Use with Lab Signal Generators.
J7 (CLK) Board Clock Input. Impedance Matched to 50Ω.
Drive with a Low-Phase-Noise Clock Oscillator or
Filtered Sine Wave Signal Source.
J8 (MIXER ENABLE) Enables/Disables the RF Mixer. Default Is ON.
J11 (RF) Board RF Signal Input. Impedance Matched to
50Ω for Use with Lab Signal Generators.
TP1 (SENSE_I) Reference Input to Adjust the Full-Scale Range of
the DC1513, I-Channel. Default Is VDD.
TP2 (GND) DC Ground.
TP4 (GND) DC Ground.
TP5 (3V) DC Supply Input (3VDC).
TP7 (5V) DC Supply Input (5VDC).
TP8 (GND) DC Ground.
TP12 (SENSE_Q) Reference Input to Adjust the Full-Scale Range of
the DC1513, Q-Channel. Default Is VDD.
Table 1. DC1513B Variants
DC1513B VARIANTS RESOLUTION MAXIMUM SAMPLE RATE BASEBAND BANDWIDTH
1513B-AA 14-Bit 125Msps DC - 1.92MHz
1513B-AB 14-Bit 125Msps DC - 4.42MHz
1513B-AC 14-Bit 125Msps DC - 9.42MHz
1513B-AD 14-Bit 125Msps DC - 20MHz
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks and PScope
is a trademark of Linear Technology Corporation. All other trademarks are the property of their
respective owners.

2
dc1513bf
DEMO MANUAL DC1513B
QUICK START PROCEDURE
Figure 1. Proper Measurement Equipment Setup
3. Apply an RF input signal to the board. For best results,
use a low distortion, low noise signal generator with
sufficient filtering to avoid degrading the performance
of the receiver.
4. Apply an LO input signal to the board. Note that the
difference in frequency between this signal and the RF
signal will be the IF frequency resulting at the IF filter
and ADC input.
5. ObservetheADCoutputwithdemocircuitDC890B,aUSB
cable, a Windows computer, and Linear Technology’s
PScope data processing software.
POWER SUPPLY
(5V AT 0.5A, 3V AT 1A)
TO DC890
RF SIGNAL GENERATOR
(HP 8644B) OR OTHER
LOW PHASE NOISE
CLOCK SOURCE (e.g. DC1216)
NOTE: EVEN A HIGH QUALITY SIGNAL
SYNTHESIZER WILL STILL HAVE NOISE AND
HARMONICS THAT SHOULD BE ATTENUATED
WITH A LOWPASS OR BANDPASS FILTER. FOR
GOOD QUALITY HIGH ORDER FILTERS, SEE TTE,
LARK ENGINEERING, OR EQUIVALENT.
SIGNAL GENERATOR
HP 8644B OR EQUIVALENT
BPF
BPF
SIGNAL GENERATOR
HP 8644B OR EQUIVALENT BPF

3
dc1513bf
DEMO MANUAL DC1513B
OTHER BOARD CIRCUITRY
Device U1 is an EEPROM device that is used by the PScope
software to identify the board and apply the correct set-
tings for the data collection.
USING PSCOPE SOFTWARE
PScope, downloadable from Linear Technology’s website
http://www.linear.com/, processes data from the DC890
data acquisition board and displays FFT and signal analysis
information on the computer screen.
The onboard EEPROM U1 should enable automatic board
detection and auto configuration of the software, but if the
user wishes to change the settings, they can easily do so.
From the configure menu in the toolbar, uncheck autode-
tect device. The default settings for DC1513 are shown
in Figure 2.
Figure 2. Entering the Correct Device Information for Your ADC.
Select the Correct Parameters for the DC1513. Under Normal
Conditions, PScope Should Automatically Recognize the Board
and Adjust the Software Settings Accordingly.
QUICK START PROCEDURE

4
dc1513bf
DEMO MANUAL DC1513B
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
DC1513B
1 2 C11, C13 CAP, X7R, 1000pF, 16V, 10%, 0402 AVX 0402YC102KAT
2 13 C2, C6, C24, C25, C27 TO C32,
C34, C35, C36
CAP, 0402 0.1μF 10% 10V X5R AVX 0402ZD104KAT2A
3 2 C20, C23 CAP, X7R, 0.1μF, 16V, 10%, 0603 AVX 0603YC104KAT
4 2 C21, C22 CAP, NPO, 100pF, 50V, 5%, 0402 AVX 04025A101JAT2A
5 7 C3, C8 TO C10, C14, C15, C19 CAP, 0805 4.7μF 20% 25V X7R TAIYO YUDEN TMK212BJ475MG-T
6 0 C1, C4, C5, C12, C16, C18 CAP, 0402, DNI
7 2 C7, C17 CAP, NPO, 10pF, 50V, 5%, 0402 AVX 04025A100JAT2A
8 3 J3, J4, J5 HEADER, 3 × 2 PIN, 2mm SAMTEC TMM-103-02-L-D
9 3 J6, J7, J11 CONN, SMA 50Ω EDGE-LANCH E.F. JOHNSON, 142-0701-851
10 1 J8 HEADER, 3 × 1 PIN, 2mm SAMTEC TMM-103-02-L-S
11 1 J9 HEADER, 2 × 1 PIN, 2mm SAMTEC TMM-102-02-L-S
12 7 JP1 TO JP7 SHUNT SAMTEC, 2SN-BK-G
13 1 L1 FERRITE BEAD, 60Ω, 0603 MURATA BLM18PG600SN1D
14 1 Q1 XSTR, MOSFET, SOT23 DIODES/ZETEX 2N7002-7-F
15 9 R1, R2, R12, R14, R33, R34 RES, 0402 1k 1% 1/16W NIC NRC04F1001TRF
16 2 R36, R37, R42, R10, R15 RES, 0402 33.2Ω 1% 1/16W NIC NRC04F33R2TRF
17 1 R13 RES, 0402 49.9Ω 1% 1/16W NIC NRC04F49R9TRF
18 1 R16 RES, 0805 0Ω JUMPER VISHAY CRCW08050000Z0EA
19 5 R19, R21, R22, R24, R30 RES, 0402 100k 1% 1/16W VISHAY CRCW0402100KFKED
20 1 R20 RES, 0402 75k 1% 1/16W VISHAY CRCW040275K0FKED
21 0 R23, R27, R28 RES, 0402, DNI
22 2 R3, R4 POT, 10k, TOP ADJUSTMENT, THROUGH HOLE BOURNS 3262W-1-103LF
23 1 R39 RES, 0402 10k 1% 1/16W VISHAY CRCW040210K0FKED
24 2 R6, R7 RES, 0402 4.75k 1% 1/16W VISHAY CRCW04024K75FKED
25 8 R8, R11, R17, R18, R25, R26,
R29, R43
RES, 0402 4.99k 1% 1/16W VISHAY CRCW04024K99FKED
26 7 TP1, TP2, TP4, TP5, TP7, TP8,
TP12
TURRET MILL-MAX, 2308-2-00-80-00-00-07-0
27 1 U1 IC, SERIAL EEPROM, TSSOP MICROCHIP 24LC025-I/ST
28 2 U2, U8 IC, LOGIC, INV, UNBUFFERED SC70 FAIRCHILD NC7SVU04P5X
29 4 U3, U4, U5, U7 IC, BUS BUF LVL XLATE CMOS, OCTAL,
DFN 8mm × 4mm
FAIRCHILD FXLH42245MPX
30 1 U6 IC, DFN12, VREG, DUAL, 500MA, 100MA LINEAR TECHNOLOGY LT3024IDE#PBF
31 4 HW, SPACER, NYLON, 0.25" KEYSTONE 8831
DC1513B-AA
1 1 DC1513B GENERAL BOM
2 1 R31 RES, 0603 0Ω JUMPER VISHAY CRCW06030000Z0EA
3 0 R32 RES, 0603 DNI
4 0 R5, R9 RES, 0402 DNI
5 1 U9 LTM9004CV-AA LINEAR TECHNOLOGY LTM9004CV-AA#PBF
6 1 FAB, PRINTED CIRCUIT BOARD DEMO CIRCUIT 1513B

5
dc1513bf
DEMO MANUAL DC1513B
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
DC1513B-AB
1 1 DC1513B GENERAL BOM
2 1 R31 RES, 0603 0Ω JUMPER VISHAY CRCW06030000Z0EA
3 0 R32 RES, 0603 DNI
4 0 R5, R9 RES, 0402 DNI
5 1 U9 LTM9004CV-AB LINEAR TECHNOLOGY LTM9004CV-AB#PBF
6 1 FAB, PRINTED CIRCUIT BOARD DEMO CIRCUIT 1513B
DC1513B-AC
1 1 DC1513B GENERAL BOM
2 0 R31 RES, 0603 DNI
3 1 R32 RES, 0603 0Ω JUMPER VISHAY CRCW06030000Z0EA
4 2 R5, R9 RES, 0402 7.5k 1% 1/16W VISHAY CRCW04027K50FKED
5 1 U9 LTM9004CV-AC LINEAR TECHNOLOGY LTM9004CV-AC#PBF
6 1 FAB, PRINTED CIRCUIT BOARD DEMO CIRCUIT 1513B
DC1513B-AD
1 1 DC1513B GENERAL BOM
2 0 R31 RES, 0603 DNI
3 1 R32 RES, 0603 0Ω JUMPER VISHAY CRCW06030000Z0EA
4 2 R5, R9 RES, 0402 7.5k 1% 1/16W VISHAY CRCW04027K50FKED
5 1 U9 LTM9004CV-AD LINEAR TECHNOLOGY LTM9004CV-AD#PBF
6 1 FAB, PRINTED CIRCUIT BOARD DEMO CIRCUIT 1513B

6
dc1513bf
DEMO MANUAL DC1513B
SCHEMATIC DIAGRAM

7
dc1513bf
DEMO MANUAL DC1513B
Information furnished by Linear Technology Corporation is believed to be accurate and reliable.
However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-
tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
SCHEMATIC DIAGRAM

8
dc1513bf
DEMO MANUAL DC1513B
Linear Technology Corporation
1630 McCarthy Blvd., Milpitas, CA 95035-7417
[phone] ●FAX: [phone] ●www.linear.com
© LINEAR TECHNOLOGY CORPORATION 2012
LT 0612 • PRINTED IN USA
DEMONSTRATION BOARD IMPORTANT NOTICE
Linear Technology Corporation (LTC) provides the enclosed product(s) under the following AS IS conditions:
This demonstration board (DEMO BOARD) kit being sold or provided by Linear Technology is intended for use for ENGINEERING DEVELOPMENT
OR EVALUATION PURPOSES ONLY and is not provided by LTC for commercial use. As such, the DEMO BOARD herein may not be complete
in terms of required design-, marketing-, and/or manufacturing-related protective considerations, including but not limited to product safety
measures typically found in finished commercial goods. As a prototype, this product does not fall within the scope of the European Union
directive on electromagnetic compatibility and therefore may or may not meet the technical requirements of the directive, or other regulations.
If this evaluation kit does not meet the specifications recited in the DEMO BOARD manual the kit may be returned within 30 days from the date
of delivery for a full refund. THE FOREGOING WARRANTY IS THE EXCLUSIVE WARRANTY MADE BY THE SELLER TO BUYER AND IS IN LIEU
OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE. EXCEPT TO THE EXTENT OF THIS INDEMNITY, NEITHER PARTY SHALL BE LIABLE TO THE OTHER FOR
ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user releases LTC from all claims
arising from the handling or use of the goods. Due to the open construction of the product, it is the user’s responsibility to take any and all
appropriate precautions with regard to electrostatic discharge. Also be aware that the products herein may not be regulatory compliant or
agency certified (FCC, UL, CE, etc.).
No License is granted under any patent right or other intellectual property whatsoever. LTC assumes no liability for applications assistance,
customer product design, software performance, or infringement of patents or any other intellectual property rights of any kind.
LTC currently services a variety of customers for products around the world, and therefore this transaction is not exclusive.
Please read the DEMO BOARD manual prior to handling the product. Persons handling this product must have electronics training and
observe good laboratory practice standards. Common sense is encouraged.
This notice contains important safety information about temperatures and voltages. For further safety concerns, please contact a LTC applica-
tion engineer.
Mailing Address:
Linear Technology
1630 McCarthy Blvd.
Milpitas, CA 95035
Copyright © 2004, Linear Technology Corporation

X-ON Electronics
Largest Supplier of Electrical and Electronic Components
Click to view similar products for Sub-GHz Development Tools category:
Click to view products by Analog Devices manufacturer:
Other Similar products are found below :
EVAL-ADF7021DBJZ EVAL-ADF7021-NDBZ2 EVAL-ADF7021-VDB3Z EVAL-ADF7023DB3Z MICRF219A-433 EV MICRF220-433
EV AD6679-500EBZ EVAL-ADF7901EBZ EVAL-ADF790XEBZ 110976-HMC453QS16G STEVAL-IKR002V7D MAX2602EVKIT+
MAX1472EVKIT-315 MAX1479EVKIT-315 STEVAL-IKR002V3D MAX7042EVKIT-315+ MAX2902EVKIT# MAX1470EVKIT-315
SKY66188-11-EK1 SKY66013-11-EVB EVAL-ADF7023DB5Z DRF1200/CLASS-E 1096 1097 1098 MDEV-900-PRO DVK-SFUS-1-
GEVK DVK-SFUS-API-1-GEVK US-SIGFOX-GEVB STEVAL-IKR002V2D 107755-HMC454ST89 DM182017-2 110961-HMC453ST89
DM182017-1 3179 DC689A DC1513B-AB 3229 3230 3231 3232 DC1250A-AA DC1513B-AC DC1513B-AD DC1513B-AA TEL0075
RFX1010-EK1 131903-HMC921LP4E EU-SIGFOX-GEVB 856512-EVB
