DEMO MANUAL DC2177A-C
DESCRIPTION
LT3063
45V VIN, Micropower,
Low Noise, 200mA LDO
with Output Discharge
Demonstration circuit 2177A-C features the LT
®
3063, a
micropower, low noise and low dropout voltage linear
regulator with output discharge. The input voltage ranges
from 2.1V to 45V and the maximum output current is
200mA. A resistor divider determines the output voltage,
and a jumper adjusts the divider to set the output voltage
to either 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V, 5V or a voltage
that is user-programmed but requires the installation of
a resistor. The output uses a 10µF ceramic capacitor and
the internal reference is bypassed with a 10nF capacitor
to reduce output noise and program the soft-start. There
is also a 10nF feedforward capacitor to improve load
transient response and decrease noise at higher output
voltages. The position of the VOUTEN jumper either pulls
up the SHDN pin to the input supply through a 100k re-
sistor, shorts SHDN to ground or floats the SHDN pin so
it can be driven directly by a signal applied to the SHDN
terminal. The input supply to the LT3063 is bypassed by a
2.2µF ceramic capacitor and there is also a 50V tantalum
polymer capacitor on the input to dampen ringing that
may occur when the input is hot-plugged using long leads.
The LT3063 saves energy by being micropower and low
dropout. The LT3063 has excellent regulation and fast
response to load transients and also tolerates wide input
voltage variations and discharges its output in a controlled
manner as required by some image sensor loads.
The LT3063 targets systems with inputs that are battery-
powered or have multiple sources, especially those with
sensitive loads. DC2177A-C features the LT3063 in the
8-lead 2mm ×3mm DFN package. The LT3063 data sheet
must be read in conjunction with this demo manual to
properly use or modify demo circuit DC2177A-C.
Design files for this circuit board are available at
http://www.linear.com/demo
PERFORMANCE SUMMARY
Specifications are at TA= 25°C
PARAMETER CONDITIONS MIN TYP MAX UNITS
Minimum Input Voltage, VIN VIN – VOUT ≥ 360mV 2.1 V
Maximum Input Voltage, VIN 45 V
Output Voltage, VOUT VOUT SELECT = 1.2V
VOUT SELECT = 1.5V
VOUT SELECT = 1.8V
VOUT SELECT = 2V
VOUT SELECT = 2.5V
VOUT SELECT = 3.3V
VOUT SELECT = 5V
1.17
1.47
1.76
1.97
2.43
3.23
4.85
1.2
1.5
1.8
2.0
2.5
3.3
5.0
1.23
1.54
1.85
2.07
2.56
3.41
5.13
V
V
V
V
V
V
V
Maximum Output Current, IOUT VIN = 2.3V, VOUT = 1.8V 200 mA
Output Discharge Time VOUT = 2.9V, COUT = 10µF 750 µs
Downloaded from Arrow.com.

2
dc2177acf
DEMO MANUAL DC2177A-C
QUICK START PROCEDURE
To use DC2177A-C to evaluate the performance of the
LT3063, refer to Figure 1 for the proper measurement
equipment setup and follow the procedure below:
1. With the input supply and load off and turned down,
make all connections according to Figure 1. Make sure
the jumper to set VOUT is in the proper position for the
desired output voltage and the VOUTEN jumper is in
the ON position.
2. Turn on the input supplies and increase them to the
desired input voltages.
Note When Setting The Input Voltage: An input voltage
that is too close to the programmed output voltage (too
low) may cause dropout operation and a loss of output
voltage regulation. Also, an input voltage that is too high
above the output may increase power dissipation to an
unacceptable level.
3. Increase the load to the desired output current. Verify
that the VOUT voltage is as programmed by the jumper.
Note: If the output voltage is low, temporarily disconnect
the load to make sure that it is not set too high.
4. Oncetheproperoutputvoltageisestablished,adjustthe
input voltage and load within the operating range and
observe the output voltage regulation, low quiescent
current, shutdown, output discharge operation and
other parameters.
Downloaded from Arrow.com.Downloaded from Arrow.com.

3
dc2177acf
DEMO MANUAL DC2177A-C
QUICK START PROCEDURE
Figure 1: Proper Measurement Equipment Setup for DC2177A-C
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

4
dc2177acf
DEMO MANUAL DC2177A-C
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 1 C1 Cap., X5R 2.2µF 50V 10% 1206 Murata GRM31CR61H225KA88K
2 1 C2 Cap., X7R 10µF 25V 20% 1206 TDK C3216X7R1E106MT
3 2 R1, R2 Res., Chip 60.4k 0.06W 1% 0402 Vishay CRCW040260K4FKED
4 1 U1 I.C., Low Dropout Reg. DFN(08)(DCB)2MMX3MM Linear Tech. Corp. LT3063EDCB
Optional Demo Circuit Components
1 2 C3, C4 Cap., X7R 0.01µF 25V 10% 0603 AVX 06033C103KAT2A
2 1 C5 Cap., Tant. Polymer 10µF 50V 20% 7343 AVX TCJD106M050R0120
3 0 C6 (Opt) Cap., 0805
4 0 C7 (Opt) Cap., 7343
5 1 R3 Res., Chip 90.9k 0.06W 1% 0402 Vishay CRCW040290K9FKED
6 1 R4 Res., Chip 121k 0.06W 1% 0402 Vishay CRCW0402121KFKED
7 1 R5 Res., Chip 143k 0.06W 1% 0402 Vishay CRCW0402143KFKED
8 1 R6 Res., Chip 191k 0.06W 1% 0402 Vishay CRCW0402191KFKED
9 1 R7 Res., Chip 274k 0.06W 1% 0402 Vishay CRCW0402274KFKED
10 1 R8 Res., Chip 442k 0.06W 1% 0402 Vishay CRCW0402442KFKED
11 0 R9 (Opt) Res., 0603
12 1 R10 Res., Chip 100k 0.06W 5% 0603 Vishay CRCW0603100KJNEA
Hardware
1 5 E1, E2, E3, E4, E5 Turret, Testpoint Mill Max 2501-2-00-80-00-00-07-0
2 1 JP1 Headers, 2 x 8 (2mm Ctrs.) Sullins NRPN082PAEN-RC
3 1 JP2 Headers, 4 Pins 2mm Ctrs. Sullins NRPN041PAEN-RC
4 2 XJP1, XJP2 Shunt, 2mm Ctrs. Samtec 2SN-BK-G
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

5
dc2177acf
DEMO MANUAL DC2177A-C
Information furnished by Linear Technology Corporation is believed to be accurate and reliable.
However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-
tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
SCHEMATIC DIAGRAM

R2
60.4k
IN IN
OUT OUT
SHDN
GND GND REF/BYP
ADJ
U1 LT3063EDCB
8
2
1
7
35
9
46
+
C7
(Opt) 7343
NOTES: UNLESS OTHERWISE SPECIFIED: 1. RESISTORS ARE 0402 1%, CAPACITORS ARE 06O3.
E2
VIN
2.1V - 45V
*
R3
90.9K
E4
GND
E5
SHDN
R4
121k
R5
143k
R6
191k
R7
274k
E1
VOUT
200mA
R9
(Opt)
0603
E3
GND
R8
442k
SEE PERFORMANCE SUMMARY FOR MINIMUM INPUT VOLTAGE CONDITIONS
JP1
1.2V 1.5V 1.8V 2.0V 2.5V 3.3V 5.0V USER SELECT VOUT
1 3
2 4
5 6 7 8 910
11 12 13 14 15 16
+
C5 10µF 50V 7343
C3 0.01µF
C4 0.01µF
*
C6 (Opt) 0805
JP2
ON OFF
EXT
VOUTEN
1 3 2 4
C1 2.2µF 50V 1206
R1
60.4k
C2 10µF 25V 1206
R10 100k 5% 0603
