DEMO MANUAL DC2270A
DESCRIPTION
LT3095
Dual-Channel Low Noise Bias
Generators
Demonstration circuit 2270A is a dual-channel low noise
biasgeneratorfeaturingLT3095.TheLT3095generatestwo
lownoise bias supplies fromacommon input voltage range
from 3V to 20V. Each channel includes a fixed frequency,
peak current mode step-up switching regulator and a low
noise, single resistor programmable linear regulator. The
maximum load current is 50mA for each channel.
Each boost regulator adjusts its output voltage to 2V above
the corresponding linear regulator’s output voltage, opti-
mizing power dissipation, PSRR and transient response.
The integrated boost regulator, frequency compensation
and Schottky diodes minimize the external component
count and simplify system design.
The switching frequency can be programmed either via
oscillator resistor or an external clock from 450kHz to L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear
Technology Corporation. All other trademarks are the property of their respective owners.
PERFORMANCE SUMMARY
2MHz. The SYNC pin on the demo board is grounded by
default. To synchronize to an external clock, move JP1
to SYNC and apply the external clock to the SYNC turret.
The RTresistor (R2) should be chosen to set the LT3095
internal switching frequency to the SYNC frequency.
The LT3095 is available in a thermally enhanced 24-Lead
3mm × 5mm QFN package.
The LT3095 data sheet gives a complete description of
the device, operation and application information. The
data sheet must be read in conjunction with this quick
start guide for demo circuit 2270.
Design files for this circuit board are available at
http://www.linear.com/demo/DC2270A
Specifications are at TA= 25°C
SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
VIN Input Voltage Range 3 20 V
VOUT1 Channel1 Output Voltage 4.9 5 5.1 V
VOUT2 Channel2 Output Voltage 14.7 15 15.3 V
IOUT1 Channel1 Max Output Current 50 mA
IOUT2 Channel2 Max Output Current 50 mA
fSW Switching Frequency RT= 100kΩ 0.95 1 1.05 MHz
VOUT,P-P Output Voltage Peak-to-Peak Noise VIN = 5V, VOUT = 15V, IOUT = 50mA, fSW = 1MHz
20MHz BW
65 µV

2
dc2270afa
DEMO MANUAL DC2270A
QUICK START PROCEDURE
Demonstration circuit 2270 is easy to set up to evaluate
the performance of the LT3095. Refer to Figure 2 for
proper measurement equipment setup and follow the
procedure below:
1. Place JP1 on RT position.
2. With power off, connect the input power supply to VIN
and GND. Make sure that the input voltage does not
exceed 20V.
3. With power off, connect loads from VOUT1 to GND, and
VOUT2 to GND.
4. Turn on the power at the input.
5. Check for the proper output voltages (5V and 15V).
NOTE: If there is no output, temporarily disconnect the
load to make sure that the load is not set too high or
is shorted.
6. Once the proper output voltage is established, adjust
the load within the operating range and observe the
output voltage regulation and other parameters.
7. An external clock can be added to the SYNC terminal
whenSYNC function is used(JP1onthe SYNC position).
The set switching frequency should be programmed
to the SYNC frequency. See the data sheet section
Programming the Switching Frequency for details.
8. The output noise can be measured by J1 and J2. Please
refer to Application Notes 70 for details.
1µs/DIV
V
BSTOUT
20mV/DIV
V
OUT
50µV/DIV
dc2270a F01
V
IN
= 5V
V
OUT
= 15V
I
LOAD
= 50mA
f
OSC
= 1MHz
20MHz BW
Figure 1. Transient Output Ripple

3
dc2270afa
DEMO MANUAL DC2270A
QUICK START PROCEDURE
*J1 AND J2 ARE THE BNC CONNECTORS TO COAXIAL CABLE FOR NOISE MEASUREMENT.
PLEASE REFER TO AN70 APPENDIX B FOR DETIALS
Figure 2. Proper Measurement Equipment Setup

4
dc2270afa
DEMO MANUAL DC2270A
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 2 C1, C2 CAP., 2.2µF, X7R, 25V, 10%, 0805 MURATA, GRM21BR71E225KA73L
2 2 C3, C4 CAP., 10µF, X7R, 25V, 10%, 1210 MURATA, GRM32DR71E106KA12L
3 2 C5, C6 CAP., 2.2µF, X7R, 25V, 10%, 1210 AVX, 12103C225KAT2A
4 2 C7, C8 CAP., 1µF, X7R, 25V, 10%, 0603 MURATA, GRM188R71E105KA12D
5 1 C9 CAP., 0.1µF, X7R, 6.3V, 10%, 0603 AVX, 06036D104KAT2A
6 1 L1 INDUCTOR, 6.8µH COILCRAFT LPS4012-682MR
7 1 L2 INDUCTOR, 10µH COILCRAFT LPS4012-103MR
8 4 R1, R2, R4, R5 RES., CHIP, 100k, 1/10W, 1%, 0603 VISHAY, CRCW0603100KFKEA
9 1 R3 RES., CHIP, 300k, 1/10W, 1%, 0603 VISHAY, CRCW0603300KFKEA
10 1 U1 I.C., REGULATOR, QFN24-3X5-UDD LINEAR TECH., LT3095EUDD#PBF
Additional Demo Board Circuit Components
1 0 C10, C11 (OPT) CAP., 0805
2 0 C12, C13 (OPT) CAP., 0603
3 0 R6, R7 (OPT) RES., 0603
4 0 C14 (OPT) CAP, TANT., 10µF, 25V, 20%, 2312 AVX, TAJW106M025RNJ
Hardware: For Demo Board Only
1 10 E1-E10 TESTPOINT, TURRET, 0.094" pbf MILL-MAX, 2501-2-00-80-00-00-07-0
2 1 JP1 HEADER 3 PIN 0.079 SINGLE ROW WURTH, 620 003 111 21
3 1 XJP1 SHUNT, 0.079" CENTER WURTH, 608 002 134 21
4 2 J1-J2 CONN, BNC, 5 PINS CONNEX, 112404

5
dc2270afa
DEMO MANUAL DC2270A
